Microtest SimpliFiber 850/1300 Source User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SimpliFiber
A Guide to using the Microtest SimpliFiber
install, manage, and troubleshoot single-mode
and multimode fiber cabling systems.
SimpliFiber
single-mode and multimode fiber optic cabling.
It features automatic wavelength detection,
storage of test results, and PC database support
in an easy-to-use low cost design.
C
OPYRIGHT
SimpliFiber
USER GUIDE
ENGLISH
TM
accurately measures power loss of
© 1999 M
ICROTEST
, I
. A
NC
LL RIGHTS RESERVED
TM
TM
to
ENGLISH - 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SimpliFiber 850/1300 Source and is the answer not in the manual?

Questions and answers

Related Manuals for Microtest SimpliFiber 850/1300 Source

Summary of Contents for Microtest SimpliFiber 850/1300 Source

  • Page 1 SimpliFiber USER GUIDE ENGLISH A Guide to using the Microtest SimpliFiber install, manage, and troubleshoot single-mode and multimode fiber cabling systems. SimpliFiber accurately measures power loss of single-mode and multimode fiber optic cabling. It features automatic wavelength detection, storage of test results, and PC database support in an easy-to-use low cost design.

  • Page 2: Table Of Contents

    The Simple Fiber Solution ........5 The SimpliFiber Kit ..........6 The SimpliFiber Accessory Kits ......7 SimpliFiber Meter ..........8 SimpliFiber 850/1300 Source ......9 SimpliFiber 1310 Source ........ 10 SimpliFiber Meter ..........11 Using the Keypad ........... 11 Reading the Display ........
  • Page 3 Saving Results ........... 28 Viewing Results ..........29 Deleting Results ..........29 Uploading to a PC ..........30 Chapter 3 - Measuring Power ... 31 Measuring Power ..........31 Appendix A - Technical Specifica- tions ........... 33 SimpliFiber Meter ..........33 SimpliFiber Source ..........

  • Page 4: Simplifiber English

    SimpliFiber ENGLISH - 4...

  • Page 5: Chapter 1 - Introduction

    Chapter 1 - Introduction The Simple Fiber Solution Welcome to the Microtest family of fiber optic installation, test and diagnostic products. SimpliFiber is a high quality fiber optic cabling test tool for easy and rapid identification of failure points in a fiber network. It consists of two units: SimpliFiber Meter and SimpliFiber Source.

  • Page 6: The Simplifiber Kit

    The SimpliFiber Kit Microtest’s SimpliFiber kit contains the SimpliFiber Meter and SimpliFiber 850/1300 Source units. The kit includes the optical cleaning supplies that are needed to keep fiber connectors and adapt- ers free from contamination.

  • Page 7: The Simplifiber Accessory Kits

    • A communication cable to connect to the PC • Registration Card and User Guide The SimpliFiber Accessory Kits Microtest’s SimpliFiber Meter allows you to use different light sources. SimpliFiber 1310 Source, an additional source kit for the verification of single-mode fiber at 1310nm is sold separately.

  • Page 8: Simplifiber Meter

    SimpliFiber ENGLISH - 8 SimpliFiber Meter DB-9 Serial Connector allows SimpliFiber ST or SC attachment of a serial cable for optical receiver port interface with PC-based software (ScanLink). Powers SimpliFiber ON or OFF. SHFT in conjunction with other keys executes extended functions.

  • Page 9: Simplifiber 850/1300 Source

    SimpliFiber 850/1300 Source 850 nm ST or SC 1300 nm ST or SC connector port connector port Powers SimpliFiber Source ON or OFF. AUTO senses the wavelength currently used by SimpliFiber. MOD allows you to toggle between continuous and modulated lightsource λ...

  • Page 10: Simplifiber 1310 Source

    SimpliFiber ENGLISH - 10 SimpliFiber 1310 Source 1310 nm ST or SC connector port Powers SimpliFiber Source ON or OFF. AUTO senses the wavelength currently used by SimpliFiber. MOD allows you to toggle between continuous and modulated lightsource...

  • Page 11: Simplifiber Meter

    SimpliFiber Meter The SimpliFiber Meter interface consists of an LCD display and a keypad. Using the Keypad Use the SimpliFiber Meter keypad to select the functions necessary to test and troubleshoot fiber optic cabling. Each key performs at least two functions. When multiple keys are required to activate a function, press and hold each key in the order shown below.

  • Page 12: Reading The Display

    SimpliFiber ENGLISH - 12 connecting to a lightsource other than SimpliFiber Source. When using SimpliFiber 850/1300 or 1310 Sources in AUTO mode, the wavelength will be detected automatically. Use these buttons to change the mode between Power Meter (dBm) and Loss Meter (dB).
  • Page 13 If no icons appear when the unit is in operation, check the batteries for correct installation or install new batteries. Measure at 850nm wavelength Measure at 1300nm wavelength Measure at 1310nm wavelength Measure at 1550nm wavelength Align units, set Reference Send SimpliFiber in for Calibration Low Battery power Error occurred...

  • Page 14: Simplifiber Source

    SimpliFiber ENGLISH - 14 SimpliFiber Source The SimpliFiber Source is an active and intelli- gent light source that works with SimpliFiber Meter to verify optical cable transmission quality. The SimpliFiber 850/1300 is an LED light source. The SimpliFiber 1310 Source is a laser light source.

  • Page 15: Led Indicators

    2kHz (modulated) is selected, the LED will blink. Use this feature with all third party power meters. (SimpliFiber 850/1300 Source) Press λ λ λ λ λ (Lambda) to manually switch the wavelength between 850 nm and 1300 nm. Connect the launch cable to the appropriate port.

  • Page 16: Calibration

    Time to replace AA batteries Calibration The SimpliFiber Meter should be calibrated annually with specialized Microtest equipment. Contact Microtest Technical Support for informa- tion on calibration and service requirements. Technical Support Note: All connectors and fiber end faces need to be clean prior to testing.
  • Page 17 If you have technical questions, you may contact Microtest Technical Support by phone, fax, or e- mail. Note: Before calling Technical Support, please have your product version number available. Americas and Asia Pacific: 1-800-NET-FIXR ( 1-800-638-3497) (U.S. and Canada only) 1-800-419-8991 (FAX) (U.S.

  • Page 18: Product Versions

    SimpliFiber ENGLISH - 18 Product Versions To display the Product Version, turn SimpliFiber Meter off. Hold the key down while pressing the key. Release both keys. The Product Version will be displayed as shown below. WARNING: DURING OPERATION, TEST- ING, OR MAINTENANCE OF A FIBER OP- TIC SYSTEM, NEVER LOOK INTO AN AC- TIVE FIBER OPTIC CABLE.

  • Page 19: Chapter 2 - Measuring Loss

    Chapter 2 - Measuring Loss Loss measures the signal degradation in a fiber optic cable. SimpliFiber 850/1300 Source injects a signal into the fiber cable and SimpliFiber Meter measures the received signal at 850nm or 1300nm. Described in this chapter are the procedures for measuring loss in a fiber optic cable plant using SimpliFiber Meter and SimpliFiber Source.

  • Page 20: The Reference Methods

    SimpliFiber ENGLISH - 20 The reference value must be stored before a loss measurement can be calculated. SimpliFiber requires the reference value to compensate for the signal loss in the launch cable. This value is then automatically subtracted from the actual measured value to determine cable plant loss.

  • Page 21: Method A

    METHOD A For Method A two launch cables are used to set the reference. Method A cancels the effects of the launch cables and one coupler for all subsequent measurements. 1. Connect a Launch Cable to SimpliFiber Meter. 2. Connect a Launch Cable to SimpliFiber Source.

  • Page 22: Measuring Loss Using Method A

    SimpliFiber ENGLISH - 22 button to set and save the new reference value. The reference value will be displayed. 7. Disconnect the coupler SimpliFiber without disturbing the fiber Meter connections to the units. Measuring Loss using Method A When Method A was used to set the reference, proceed as follows: 1.

  • Page 23: Method B

    save the test result. When using Method A, the effects of both launch cables and one coupler are removed. METHOD B SimpliFiber This method is commonly Meter recommended by ISO 11801 and ANSI/EIA/TIA 568A. For Method B, one launch cable is used to set the reference.

  • Page 24: Measuring Loss Using Method B

    SimpliFiber ENGLISH - 24 press 4. Power on SimpliFiber Meter. The unit will auto- sense the appropriate wavelength. Note: When using a light source other than SimpliFiber Source, press the to select the appropriate wavelength. Both units must be set to the same wavelength.

  • Page 25: Method C

    coupler is needed. SimpliFiber Meter 3. SimpliFiber Meter will immediately report the loss in 4. Press and hold save the test result. Method B removes the effect of one launch cable. METHOD C SimpliFiber Source For Method C three launch cables and two connectors are used to set the reference.
  • Page 26 SimpliFiber ENGLISH - 26 Fiber Source. SimpliFiber Meter 3. Use two couplers to join the two launch cables with a third launch cable. 4. Power on SimpliFiber Source and press 5. Choose the appropriate wavelength, 850 or 1300, press Note: When using a light source other than SimpliFiber Source, press the to select the...

  • Page 27: Measuring Loss Using Method C

    Measuring Loss using Method C SimpliFiber When Method C was used to Meter set the reference, proceed as follows: 1. Do not disconnect the launch cables from the SimpliFiber units. 2. Remove the launch cable located in the center without disturbing the couplers.

  • Page 28: Saving Results

    SimpliFiber ENGLISH - 28 Saving Results SimpliFiber Meter will store 100 test results. Each test is stored in order, e.g. 5 is the fifth test that was stored. 1. To save a test result press . A number (between 1 and 100) will flash in the lower right corner of the display.

  • Page 29: Viewing Results

    Viewing Results 1. Press and then to display the last stored test. A number (between 1 and 100) and the test result start flashing alternately. Deleting Results 1. Press and then hold to delete the result. OK and the number of the deleted test will be displayed to confirm that number 4 is available again.

  • Page 30: Uploading To A Pc

    ENGLISH - 30 Uploading to a PC Test results can be uploaded to a PC using the included ScanLink software from Microtest. 1. Connect the SimpliFiber Meter serial port to the serial port on your PC with the supplied communications cable.

  • Page 31: Chapter 3 - Measuring Power

    Chapter 3 - Measuring Power Measuring Power When measuring power, the overall power is reported. Use it to quickly verify cabling and equipment problems. 1. To measure power, connect the fiber optic cable to the appropriate SimpliFiber 850/1300 Source output. 2.
  • Page 32 SimpliFiber ENGLISH - 32 length. 6. Press and then the button to change the units from dB to dBm. 7. SimpliFiber Meter will immediately report the overall power in dBm.

  • Page 33: Appendix A - Technical Specifications

    Appendix A - Technical Specifications SimpliFiber Meter Physical Characteristics • Dimensions: 13.97 cm x 8.25 cm x 2.54 cm (6.25" x 3.50" x 1.25") • Weight: 171.54 g (.38 lbs) Power Source • 2 AA Alkaline batteries • Battery Life: Varies depending on usage and battery quality.
  • Page 34 SimpliFiber ENGLISH - 34 Environmental • Operating Temperature: 0° to 45°C (32° to 113°F) • Storage Temperature: -20° to 60°C (14° to 140°F) • Humidity: 10% to 90% non-condensing • Storage Humidity: 5 to 95% Serial Port • RS-232, DB 9 Memory •...

  • Page 35: Simplifiber Source

    SimpliFiberSource Physical Characteristics • Dimensions: 13.97 cm x 8.25 cm x 2.54 cm (6.25" x 3.50" x 1.25") • Weight: 171.54 g (.38 lbs) Power Source • 2 AA Alkaline batteries • Battery Life: Varies depending on usage and battery quality. 850/1300 Source: On average, the batteries will last 10-50 hours, depending on Mode 1310 Source: On average, the batteries will last...

  • Page 36: Accessories

    SimpliFiber ENGLISH - 36 • Storage Humidity: 5 to 95% Governmental Certifications • CE Accessories SimpliFiber Source 1310 ST, Model 8251-01 SimpliFiber Source 1310 SC, Model 8251-11 Fiber Optic Cable Kit ST - SC 62.5/125 Model 8252-01 50/125 Model 8252-03 Single Model 8252-05 Fiber Optic Cable Kit ST - ST...

  • Page 37: Appendix B - Error Messages

    Appendix B - Error Mes- sages Err 1 - Invalid Reference value. Error code 1 indicates that the reference value is ‘under’ or ‘over’ the limits. - Store a new Reference value. Err 2 - UNDER or OVER limit. The measured value is under or over the limit. The numeric values displayed on the LCD can range from -55.00 dB/dBm to 3.00 dB/dBm.

  • Page 38: Err 4 - No Results Are Stored In Memory

    SimpliFiber ENGLISH - 38 - Upload the stored test results to your PC. - Delete saved results from the unit’s memory. Err 4 - No results are stored in memory. Error code 4 indicates that there are no results stored in the units memory. - SimpliFiber’s memory is empty.

  • Page 39: Err 8 - Connection Error Between Simplifiber And Pc

    Err 8 - Connection error between Simpli- Fiber and PC Connection between SimpliFiber and PC is broken. - Verify connection between SimpliFiber and the PC and retry. SimpliFiber ENGLISH - 39...
  • Page 40 SimpliFiber ENGLISH - 40...
