Memphis Shades MEM-9892 Quick Start Manual

TOOLS REQUIRED: 3/16" Allen wrench (provided)
1. Cover the front fender with a towel, in case you drop something.
2. Attach the lowers plastic to the lowers mounting plates using the pre-assembled bolts and button nuts.
Install the components in the order shown in Figure 1.
Note: The neoprene washer has been replaced by four santoprene grommets. The rubber grommets should
be inserted through the holes in the windshield so that the flat round part of the grommet lays flat
on each side of the windshield.
3. The mounting plate tabs should point away from each other when installed correctly. (see Figure 2)
Note: The mounting plates can be mounted pointing up, for those applications where the windshield
is too short to reach them other wise
4. Protective tape has been applied to the inside of the clamps. Loosely install the two fork clamps onto the
fork covers. MAKE SURE THE LOWERS WILL CLEAR ALL FENDERS, RADIATORS, OIL
COOLERS AND TURNSIGNALS WHEN INSTALLED. Attach the lowers mounting plates to the fork
clamps. Adjust height, angle and position of the clamps and then tighten them.
Fig. 1 Order of assembly
To clean your windshield, wash it with warm water and a mild, non-abrasive, dishwashing liquid. Use a
STANDARD INDEPENDENT LOWERS HARDWARE KIT FOR
soft cloth such as a T-shirt or flannel cloth.
To protect your windshield, use NOVUS #2 to remove minor scratches, or use
Memphis Shades Shinola polish specially designed for plastic. NEVER use glass
cleansing agents, they may cause severe damage to your windshield.
Never use any petroleum-based chemicals, or cleaning agents with ammonia.
MEM-9892
COVERED FORKS
Fig.2 Position of plate tabs
CARE AND CLEANING
