Memphis Shades MEM-9888 Quick Start Manual

LOW PROFILE INDEPENDENT LOWERS HARDWARE KIT FOR EXPOSED
TOOLS REQUIRED: 3/16" Allen wrench (provided)
1. Cover the front fender with a towel, in case you drop something.
Note: The neoprene washer has been replaced by four Santoprene grommets. The rubber
grommets should be inserted through the holes in the windshield so that the flat round part
of the grommet lays flat on each side of the windshield.
2. Attach the lowers plastic to the lowers mounting plates using the pre-assembled bolts and button nuts. Install the
components in the order shown in Figure 1.
3. The mounting plate tabs should point away from each other when installed correctly. (see Figure 2)
Note: The mounting plates can be mounted pointing up, for those applications where the
windshield is too short to reach them other wise
4. Loosely install the two fork clamps onto the forks. MAKE SURE THE LOWERS WILL CLEAR ALL
FENDERS, RADIATORS, OIL COOLERS, ETC. WHEN INSTALLED. Attach the lowers mounting plates
to the fork clamps. Adjust height, angle and position of the clamps and then tighten them.
Fig. 1 Order of assembly
To clean your windshield, wash it with warm water and a mild, non-abrasive, dishwashing liquid. Use a soft
cloth such as a T-shirt or flannel cloth.
To protect your windshield, use NOVUS #2 to remove minor scratches, or use
Memphis Shades Shinola polish specially designed for plastic. NEVER use glass
cleansing agents, they may cause severe damage to your windshield.
Never use any petroleum-based chemicals, or cleaning agents with ammonia.
MEM-9888
FORKS 35-43MM

CARE AND CLEANING

Fig.2 Position of plate tabs
