Memphis Shades MEM-9980 Mounting Instructions

MEM-9980 Fats/Slims Mounting Kit for Kawasaki 1600 Vulcan Classic
Read and follow these directions carefully.
During installation, make certain that when turning the
forks, there can be no interference with wiring or cables
AND, that the windshield can not hit the gas tank,
through the windshield's full range of adjustment.
This is a quick change kit, ALWAYS tighten all mounting
bolts after removing or installing the windshield!
The improper installation of this kit and related compo-
nents could result in serious injury or death.
Additional tools required, that are not included in this kit.
7/16" or 11mm wrench or ¼" drive sockets and ratchet.
1. Cover gas tank and front fender with towels to avoid
damage during installation.
2. Locate the upper and lower mounting bolts located on the
sides of the front fork covers and remove them.
3. Using the new bolts and spacers included, loosely install
the new top bolt assembly (longer bolt and wider spacer) and
lower bolt assembly (shorter bolt and narrower spacer).
(see Figure 1) Note: Use wide spacers and longer bolts on the
upper mounting holes and in the lower mounting holes, use
the shorter bolts and narrow spacers.
4. Attach the windshield to the windshield mounting plates
using the bottom and third bolt on each side. Leave the Nylon
washers off. The Mounting tabs should be pointing in towards
the headlight when installed correctly. (See Figure 2)
5. With the mounting bolts loose, slip the windshield assem-
bly onto the mounting bolts. Adjust the angle and height and
tighten all bolts. (see Figure 3)
Note: This is a quick change kit. Always tighten all mount-
ing bolts after removing or installing the windshield.
Upper bolt
Lower bolt
assembly
Fig. 1
MOUNTING INSTRUCTIONS
Memphis Shades Windshields and Lowers are made of
Lucite® acrylic, and will last for years with proper care.
Clean your windshield with plenty of soapy water — mild
dishwashing liquid is best — and a soft cotton cloth. Use your
bare hand to feel and dislodge bugs, or cover with a wet soapy
towel and let it soak. Don't use paper towels and don't scrape
with anything. Small scratches can be removed with NOVUS
# 2.
NEVER use any glass cleaning products, petroleum based
chemicals, or cleaning agents with ammonia, bleach or any
other harsh chemicals. This includes (but not limited to)
RainX, brake fluid, acetone, paint thinner, benzene and
gasoline. "If it hurts your nose, it will hurt the plastic."
IMPORTANT CARE AND CLEANING INSTRUCTIONS
Glass cleansing agents will cause severe damage
to your windshield, and will void your warranty.
NOTE: At certain times of the day the Sunlight can reflect
off the curvature of a windshield and cause extreme heat
build-up on motorcycle instruments and instrument panel.
Take care when parking. Park facing the sun, place an opaque
object over the instruments or adjust the windshield to avoid
reflections.
Fig.2
Fig. 3
MEM9980 11-12-07
