Summary of Contents for Honda CB500FA

  • Page 1 CB500FA/XA CBR500RA...
  • Page 2 This publication includes the latest production information available before printing. Honda Motor Co., Ltd. reserves the right to make changes at any time without notice and without incurring any obligation.
  • Page 3 Welcome Congratulations on your purchase of a new Destination Codes Honda vehicle. Your selection of a Honda Code Destination makes you part of a worldwide family of CB500FA satisfied customers who appreciate Honda's PH, II PH Philippines reputation for building quality into every CBR500RA product.
  • Page 4 A Few Words About Safety DANGER Your safety, and the safety of others, is very important. Operating this vehicle safely is an You WILL be KILLED or SERIOUSLY important responsibility. HURT if you don’t follow instructions. To help you make informed decisions about safety, we have provided operating WARNING procedures and other information on safety...

  • Page 5: Table Of Contents

    Contents Vehicle Safety P. 2 Operation Guide P. 20 Maintenance P. 101 Troubleshooting P. 144 Information P. 160 Specifications P. 176...

  • Page 6: Vehicle Safety

    Vehicle Safety This section contains important information for safe riding of your vehicle. Please read this section carefully. Safety Guidelines ..........P. 3 Image Labels............P. 7 Safety Precautions..........P. 12 Riding Precautions ..........P. 13 Accessories & Modifications......P. 17 Loading ..............

  • Page 7: Safety Guidelines

    Safety Guidelines Safety Guidelines Before Riding Except CB500XA Follow these guidelines to enhance your safety: Make sure that you are physically fit, mentally Perform all routine and regular inspections ● focused, and free of alcohol and drugs. Check specified in this manual. that you and your passenger are both wearing Stop the engine and keep sparks and flames ●...
  • Page 8 Safety Guidelines Take Time to Learn & Practice Ride within Your Limits Even if you have ridden other vehicles, practice Never ride beyond your personal abilities or riding in a safe area to become familiar with faster than conditions warrant. Fatigue and how this vehicle works and handles, and to inattention can impair your ability to use good become accustomed to the vehicle's size and...
  • Page 9 Safety Guidelines for fluid leaks, check the tightness of critical nuts Keep Your Honda in Safe Condition and bolts, and check the handlebar, control It's important to keep your vehicle properly levers, brakes, and wheels. Ride slowly and maintained and in safe riding condition.
  • Page 10 Safety Guidelines WARNING Carbon Monoxide Hazard Exhaust contains poisonous carbon monoxide, a Running the engine of your vehicle colourless, odorless gas. Breathing carbon while in an enclosed or even partially monoxide can cause loss of consciousness and enclosed area can cause a rapid build- may lead to death.

  • Page 11: Image Labels

    Image Labels Image Labels The following pages describe the label Read instructions contained in Owner's meanings. Some labels warn you of Manual carefully. potential hazards that could cause serious injury. Others provide important safety Read instructions contained in Shop Manual information.
  • Page 12 Image Labels KO, II KO, III KO, PH, II PH, III PH type BATTERY LABEL DANGER YTZ8V IN, II IN type • Keep flame and spark away from the battery. Battery produce explosive gas that can cause explosion. • Wear the eye protection and rubber gloves when handling the battery, or you can get burned or lose your eyesight by the battery electrolyte.
  • Page 13 Image Labels RADIATOR CAP LABEL DANGER FO, III FO, PH, II PH, III PH type NEVER OPEN WHEN HOT. Hot coolant will scald you. Relief pressure valve begins to open at 1.1 kgf/cm REAR CUSHION LABEL FO, III FO, PH, II PH, III PH type GAS FILLED Do not open.
  • Page 14 Image Labels TYRE INFORMATION & DRIVE CHAIN LABEL CB500FA/CBR500RA Except KO, III KO type Cold tyre pressure: [Driver only] Front 250 kPa (2.50 kgf/cm , 36 psi) Rear 290 kPa (2.90 kgf/cm , 42 psi) [Driver and passenger] Front 250 kPa (2.50 kgf/cm...
  • Page 15 Image Labels SAFETY REMINDER LABEL FO, III FO, PH, II PH, III PH type FO, III FO, IN, II IN, PH, II PH, III PH type For your protection, always wear helmet, protective apparel. FUEL LABEL Unleaded petrol only ETHANOL up to 10 % by volume IN, II IN type IN, II IN type only Research Octane Number (RON) 90 or higher...

  • Page 16: Safety Precautions

    Safety Precautions Safety Precautions Helmet Safety-standard certified, high-visibility, correct size for your head Ride cautiously and keep your hands on the ● Must fit comfortably but securely, with the handlebar and feet on the footpegs. ● chin strap fastened Except CB500XA ●...

  • Page 17: Riding Precautions

    Riding Precautions Riding Precautions Gloves Full-finger leather gloves with high abrasion resistance Running-in Period Boots or Riding Shoes During the first 500 km (300 miles) of running, follow these guidelines to ensure your vehicle's Sturdy boots with non-slip soles and ankle future reliability and performance.
  • Page 18 Riding Precautions Exercise caution on low traction surfaces. The brake lever and pedal may recoil slightly ● ● The tyres slip more easily on such when applying the brakes. This is normal. surfaces and braking distances are Always use the recommended front/rear ●...
  • Page 19 Riding Precautions Turn the handlebar fully to the left. Parking Turning the handlebar to the right Park on a firm, level surface. ● reduces stability and may cause the If you must park on a slight incline or loose ● vehicle to fall.
  • Page 20 Torque Control may not compensate for rough Honda Selectable Torque Control road conditions or rapid throttle operation. When the Honda Selectable Torque Control Always consider road and weather conditions, (Torque Control) detects rear wheel spin during as well as your skills and condition, when acceleration, the system will limit the amount of applying throttle.

  • Page 21: Accessories & Modifications

    We strongly advise that you do not add any seriously hurt or killed. accessories that were not specifically designed for your vehicle by Honda or make Follow all instructions in this owner's modifications to your vehicle from its original manual regarding accessories and design.

  • Page 22: Loading

    Loading Loading WARNING Overloading or improper loading can Carrying extra weight affects your vehicle's ● cause a crash and you can be seriously handling, braking and stability. hurt or killed. Always ride at a safe speed and never exceed 130 km/h (80 mph) for the load you are carrying.

  • Page 24: Operation Guide

    Parts Location CB500FA Tool kit (P.98) Document bag (P.99) Front brake fluid reservoir (P.132) Front brake lever (P.142) Throttle grip (P.141) Rear brake fluid reservoir (P.132) Engine oil fill cap (P.128) Brakelight switch (P.134) Engine oil level inspection window (P.128)
  • Page 25 Clutch lever (P.138) Fuel fill cap (P.93) Main fuse (P.159) Battery (P.121) Front seat (P.123) Rear seat (P.124) Fuse boxes (P.158) Left side cover (P.126) Rear suspension spring preload adjuster (P.143) Shift lever (P.90) Drive chain (P.136) Coolant reserve tank (P.130) Side stand (P.135)
  • Page 26 Parts Location (Continued) CBR500RA Tool kit (P.98) Document bag (P.99) Front brake fluid reservoir (P.132) Front brake lever (P.142) Throttle grip (P.141) Rear brake fluid reservoir (P.132) Engine oil fill cap (P.128) Brakelight switch (P.134) Engine oil level inspection window (P.128) Rear brake pedal...
  • Page 27 Clutch lever (P.138) Fuel fill cap (P.93) Main fuse (P.159) Battery (P.121) Front seat (P.123) Rear seat (P.124) Fuse boxes (P.158) Left side cover (P.126) Rear suspension spring preload adjuster (P.143) Shift lever (P.90) Drive chain (P.136) Coolant reserve tank (P.130) Side stand (P.135)
  • Page 28 Parts Location (Continued) CB500XA Tool kit (P.98) Document bag (P.99) Front brake fluid reservoir (P.132) Front brake lever (P.142) Throttle grip (P.141) Rear brake fluid reservoir (P.132) Engine oil fill cap (P.128) Brakelight switch (P.134) Engine oil level inspection window (P.128) Rear brake pedal...
  • Page 29 Clutch lever (P.138) Fuel fill cap (P.93) Main fuse (P.159) Battery (P.121) Seat (P.125) Fuse boxes (P.158) Left side cover (P.127) Rear suspension spring preload adjuster (P.143) Shift lever (P.90) Drive chain (P.136) Coolant reserve tank (P.130) Side stand (P.135)
  • Page 30 Instruments You can change the speed and mileage, and fuel mileage meter units. (P.44) (P.59) Do not operate the display functions for a long time with the engine stopped. It may result in a low (or dead) battery.
  • Page 31 Status bar (P.30) Tachometer (P.28) Speedometer (P.28) Selectable area (P.40) Except KO, II KO, III KO type Honda RoadSync area (P.83) Fuel gauge INFO area (P.32) (P.28) Pop-up information Gear position (P.72) indicator (P.31) Continued...
  • Page 32 Instruments (Continued) Speedometer/Tachometer/Fuel gauge Display type: BAR Tachometer red zone (excessive engine rpm range) Tachometer NOTICE Do not operate the engine in Speedometer the tachometer red zone. Excessive engine speed can adversely affect engine life. INFO area (P.32) Fuel gauge Remaining fuel when only 1st (E) segment KO, II KO, III KO type starts flashing: approximately 2.8 L (0.74...
  • Page 33 This meter has three display types. The display and arrangement of speedometer, tachometer, and INFO area change depending on each display type. The tachometer is not displayed when select the SIMPLE type display. To change the display type: (P.44) (P.52) Display type: CIRCLE Display type: SIMPLE Tachometer...
  • Page 34 Instruments (Continued) Status bar Except KO, II KO, III KO type Status icons Clock (12-hour or 24-hour Displays the status of Honda display) RoadSync. (P.83) To set the clock: (P.44) (P.58) High beam indicator Warning indicator Comes on when your vehicle has warning information.
  • Page 35 Gear position indicator The gear position is shown in the gear position indicator. “-” appears when the transmission is not shifted properly. Continued...
  • Page 36 Instruments (Continued) INFO area TOTAL The INFO area displays various vehicle information. INST. CONS. TRIP A The following items are displayed by default. • Odometer [TOTAL] TRIP A CONS. • Current fuel mileage [INST. CONS.] • Tripmeter A [TRIP A] TRIP A AVG CONS.
  • Page 37 The types of information item that can be displayed in the INFO area are as follows: TOTAL (P.34) INST. CONS. (P.34) TRIP A (P.35) TRIP A CONS. (P.35) TRIP A AVG CONS. (P.36) TRIP B (P.37) TRIP B CONS. (P.37) TRIP B AVG CONS.
  • Page 38 Instruments (Continued) Odometer [TOTAL] Current fuel mileage [INST. CONS.] Total distance ridden. Displays the instantaneous fuel mileage as a bar graph. FO, III FO, KO, II KO, III KO type Display range: 0 to 4 L/100 km (40 km/L, 100 mile/gal, 25 mile/L) When “------”...
  • Page 39 Tripmeter A [TRIP A] Tripmeter A fuel consumption [CONS.A] Distance ridden since the tripmeter A was reset. Displays the tripmeter A fuel consumption since the tripmeter A was reset. FO, III FO, KO, II KO, III KO type Display range: 0.0 to 299.9 L (gal) Except FO, III FO, KO, II KO, III KO type When “----.-”...
  • Page 40 Instruments (Continued) When “---.-” is displayed except for the Tripmeter A average fuel mileage above-mentioned cases, go to your dealer [AVG CONS. A] for service. Displays the average fuel mileage since the Tripmeter A average fuel mileage is reset tripmeter A was reset. when you reset tripmeter A.
  • Page 41 Tripmeter B [TRIP B] Tripmeter B fuel consumption [CONS.B] Distance ridden since the tripmeter B was reset. Displays the tripmeter B fuel consumption since the tripmeter B was reset. FO, III FO, KO, II KO, III KO type Display range: 0.0 to 299.9 L (gal) Except FO, III FO, KO, II KO, III KO type When “----.-”...
  • Page 42 Instruments (Continued) When “---.-” is displayed except for the Tripmeter B average fuel mileage above-mentioned cases, go to your dealer [AVG CONS. B] for service. Displays the average fuel mileage since the Tripmeter B average fuel mileage is reset tripmeter B was reset. when you reset tripmeter B.
  • Page 43 Average speed [AVG SPEED] Blank display Displays average speed since the engine was Display the blank. started. FO, III FO, KO, II KO, III KO type Display range: 0 to 299 km/h (0 to 186 mph) Except FO, III FO, KO, II KO, III KO type Display range: 0 to 299 km/h Initial display: “---”...
  • Page 44 • Honda RoadSync transition (P.83) transition • Honda RoadSync mute Move to the Honda RoadSync transition and Honda RoadSync RoadSync mute can be selected only when operation display. your smartphone is connected to the vehicle. Except KO, II KO, III KO type...
  • Page 45 General Menu Status mode You can select the following: The Status mode displays various vehicle information. • Status mode The Status mode has four pages and displays • Trip reset mode two pieces of information on each page. • Setting mode Press on the sel switch while select the Status mode...
  • Page 46 Instruments (Continued) To switch the information page To change the information page, press on the sel switch. Page 1 Page 2 Page 3 Page 4 Press on the sel switch. Press on the sel switch. To change the information: (P.44) (P.55)
  • Page 47 Trip reset mode Press and hold the on the sel switch. You can reset the tripmeter A or tripmeter B. The tripmeter A or B is reset. Select the trip reset mode. (P.41) Press on the sel switch. Also, the tripmeter A, tripmeter A fuel consumption and tripmeter A average fuel Select the A or B by pressing the mileage are automatically reset when the fuel...
  • Page 48 Instruments (Continued) Setting mode To shift to the setting mode Select the general menu. (P.40) Select the setting mode. (P.41) Press on the sel switch, and then display moves to the setting mode. Operation while driving is prohibited. Ordinary display Setting mode To return to the ordinary display •...
  • Page 49 Setting flow Ordinary display Setting mode SHIFT POINT (P.49) (P.50) TRIP A AUTO RESET FUNCTION HISS (P.51) DISPLAY Press on the sel switch Press on the sel switch Press on the sel switch Press on the sel switch Continued...
  • Page 50 Instruments (Continued) FUNCTION DISPLAY TYPE (P.52) BRIGHTNESS (P.53) DISPLAY BACKGROUND (P.54) FAVORITE INFORMATION (P.55) GENERAL Press on the sel switch Press on the sel switch Press on the sel switch Press on the sel switch...
  • Page 51 DISPLAY DATE & TIME (P.58) UNIT (P.59) GENERAL LANGUAGE (P.60) RESTORE DEFAULT (P.61) Except KO, II KO, III KO type (P.62) BLUETOOTH PAIRING RESET SERVICE Press on the sel switch Press on the sel switch Press on the sel switch Press on the sel switch Continued...
  • Page 52 Instruments (Continued) GENERAL MAINTENANCE (P.63) SERVICE EQUIPMENT (P.70) (P.71) SYSTEM INFORMATION Press on the sel switch Press on the sel switch Press on the sel switch Press on the sel switch...
  • Page 53 SHIFT POINT When select the (On) Press on the sel switch to select the (On) / (Off) :You can activate or deactivate desired setting using on the sel the shift up mode. switch. SHIFT POINT :You can change the engine Press on the sel switch to complete revolutions at which the...
  • Page 54 Instruments (Continued) TRIP A AUTO RESET You can enable or disable the tripmeter A automatic reset mode. Select the (On) or (Off) using on the sel switch. Press on the sel switch to complete the setting. Return to the ordinary display to complete the setting.
  • Page 55 HISS You can select the blink or off the HISS indicator. Select the (On) or (Off) using on the sel switch. Press on the sel switch to complete the setting. Return to the ordinary display to complete the setting. (P.44) To continue setting, press on the sel switch to return to the upper hierarchy.
  • Page 56 Instruments (Continued) DISPLAY TYPE You can change the display type. (P.28) Select the display type ("BAR", "CIRCLE" or "SIMPLE") using on the sel switch. Press on the sel switch to complete the setting. Return to the ordinary display to complete the setting.
  • Page 57 BRIGHTNESS When select the "AUTO" Press on the sel switch to complete You can adjust the backlight brightness to the setting. one of the eight levels or select the auto When select the "MANUAL" adjustment. Press on the sel switch to select the Automatic brightness control: (P.165) backlight brightness using...
  • Page 58 Instruments (Continued) BACKGROUND You can change the setting of the background to one of the two colours or select the auto adjustment. Select the background colour using on the sel switch. Press on the sel switch to complete the setting. Return to the ordinary display to complete the setting.
  • Page 59 FAVORITE INFORMATION You can change the information items displayed in the INFO area and status mode. 1 line information You can change the information items displayed in the INFO area. (P.32) 1 line information setting: (P.56) Select the 1 line or 2 line information using on the sel switch.
  • Page 60 Instruments (Continued) 1 line information setting Select the desired information setting using on the sel switch. Select the 1 or 2 using on the sel Press on the sel switch, set the switch. information item. Items that have already been set are displayed with a green cursor.
  • Page 61 2 line information setting Select the upper or lower row using on the sel switch. Upper row Information Page item (Upper) Press on the sel switch to select the information items. Information Select the desired information item using item (Lower) on the sel switch.
  • Page 62 Instruments (Continued) Return to the ordinary display to complete the setting. (P.44) To continue setting, press on the sel switch to return to the upper hierarchy. DATE & TIME Select the "Day","Month", "Year", "Hour", "Minute", "24h or 12h" or "AM / PM" using on the sel switch.
  • Page 63 UNIT You can change the speed and mileage, and fuel mileage meter units. Select the "SPEED" or "FUEL CONS." using on the sel switch. "TEMP" is displayed but not selectable. Select the desired setting using FO, III FO, KO, II KO, III KO type the sel switch.
  • Page 64 Instruments (Continued) Press on the sel switch. LANGUAGE Changes the system language. Select the 1 or 2 using on the sel switch. Select the language using on the sel switch. Press on the sel switch to select the language. Items that have already been set are displayed with a green cursor.
  • Page 65 The following items are restored to their RESTORE DEFAULT default values: The set values can be returned to the default • DISPLAY TYPE settings. • SHIFT POINT Select the “NO” (not restore) or “YES” • HISS (restore) using the on the sel •...
  • Page 66 Instruments (Continued) If the pairing information remains in your BLUETOOTH PAIRING RESET smartphone even if the pairing information Except KO, II KO, III KO type is deleted from the vehicle, the smartphone You can reset the pairing record of may be connected to the vehicle again. Bluetooth ®...
  • Page 67 MAINTENANCE PERIODIC MAINTENANCE (P.64) You can select the following: • PERIODIC MAINTENANCE (P.64) • OIL CHANGE OIL CHANGE (P.66) (P.66) • BATTERY VOLTAGE (P.69) • WATER TEMP (P.69) BATTERY VOLTAGE (P.69) • WARNING INFO (P.70) WATER TEMP (P.69) WARNING INFO (P.70) Press on the sel switch.
  • Page 68 Instruments (Continued) PERIODIC MAINTENANCE Display range: You can check the next periodic inspection Distance: time. FO, III FO, KO, II KO, III KO type You can program a reminder for the next ------, 12,000 to -99,999 km (8,000 to periodic inspection time. -99,999 mile) Except FO, III FO, KO, II KO, III KO type ------, 6,000 to -99,999 km...
  • Page 69 Next inspection setting Available setting range of the distance: Select the distance, month or year using FO, III FO, KO, II KO, III KO type on the sel switch. ------, 100 to 12,000 km (100 to 8,000 mile) Initial setting:------ Date Except FO, III FO, KO, II KO, III KO type ------, 100 to 6,000 km...
  • Page 70 Instruments (Continued) OIL CHANGE Display range: You can check the next engine oil change. Distance: You can program a reminder for the next FO, III FO, KO, II KO, III KO type engine oil change. ------, 12,000 to -99,999 km (8,000 to -99,999 mile) Except FO, III FO, KO, II KO, III KO type Date...
  • Page 71 Next oil change setting Available setting range of the distance: Select the distance, month or year using FO, III FO, KO, II KO, III KO type on the sel switch. ------, 100 to 12,000 km (100 to 8,000 mile) Initial setting:------ Date Except FO, III FO, KO, II KO, III KO type ------, 100 to 12,000 km...
  • Page 72 Instruments (Continued) When reaching any of the following, the pop-up information is appears in the ordinary display. (P.72) “500 km” (“300 mile”) from the next ● periodic inspection. “100 km” (“60 mile”) from the next engine ● oil change. One month before the set month. ●...
  • Page 73 BATTERY VOLTAGE WATER TEMP Displays the current voltage. Displays the current coolant temperature. If the segment H flashes and warning indicator turned on. (P.146) Continued...
  • Page 74 Instruments (Continued) WARNING INFO EQUIPMENT Displays a current maintenance information "EQUIPMENT" is displayed but not selectable. and (or) warning information. (P.72) If your vehicle has warning information, have your vehicle inspected by your dealer as soon as possible. Warning information Maintenance information...
  • Page 75 SYSTEM INFORMATION Displays the softwear version and hardware information. Continued...
  • Page 76 Instruments (Continued) Pop-up information In the following cases, pop-up information is displayed at the INFO area. Maintenance information: ● When the inspection time of your vehicle is approaching. Warning information: ● When your vehicle has warning information. When your vehicle has multiple pieces of information, pop-up information display appears alternately.
  • Page 77 Warning Information Indication Explanation Remedy Warning indicator Refer to “Low Oil When the oil pressure Pressure Indicator” in the engine is low. (P.147) Low oil pressure indicator Warning indicator When the coolant Refer to “Overheating” temperature becomes (P.146) high. High coolant temperature indicator You can hide the pop-up information by pushing either the sel switch while the...
  • Page 78 Instruments (Continued) Tachometer colour function Shift Up Mode When shift up mode is (On), the tachometer colour changes according to the shift point setting. To set the shift up mode (P.44) (P.49) The tachometer blinks when the engine revolutions exceeds the set value of SHIFT POINT.
  • Page 79 Indicators If one of these indicators does not come on when it should, have your dealer check for problems. Refer to the "Instruments" about indicators appeared on the display: (P.30) (P.73) Left turn signal indicator Right turn signal indicator PGM-FI (Programmed Fuel Injection) malfunction indicator lamp (MIL) Comes on briefly when the ignition...
  • Page 80 Indicators (Continued) Torque Control indicator • Comes on when the ignition switch is turned to the (On) position. Goes off when your speed reaches approximately 5 km/h (3 mph) to indicate Torque Control is ready to work. • Blinks when Torque Control is operating. If it comes on while riding: (P.150) HISS indicator...
  • Page 81 Switches CB500FA Ignition Switch (P.81) Left handlebar switch Right handlebar switch (P.80) (P.81) Continued...
  • Page 82 Switches (Continued) CBR500RA Ignition Switch (P.81) Left handlebar switch Right handlebar switch (P.80) (P.81)
  • Page 83 CB500XA Ignition Switch (P.81) Left handlebar switch Right handlebar switch (P.80) (P.81) Continued...
  • Page 84 : Flashes the high beam headlight. Sel switch Used to operate and set the display. (P.44) Except KO, II KO, III KO type Also used to operate Honda RoadSync. (P.83) Horn button Turn signal switch Pressing the switch turns the turn signal off.
  • Page 85 Right handlebar switches Engine stop switch Should normally remain in the (Run) position. In an emergency, switch to the (Stop) position (the starter motor will not operate) to stop the engine. Hazard switch Switchable when the ignition switch is in the (On) position. Start button (On) Turns electrical system...
  • Page 86 Switches (Continued) Steering Lock Locking Turn the handlebar all the way to the left. Lock the steering when parking to help Push the key down, and turn the ignition prevent theft. switch to the (Lock) position. A U-shaped wheel lock or similar device is Jiggle the handlebar if the lock is difficult also recommended.
  • Page 87 Honda RoadSync For terms of service and information on how Except KO, II KO, III KO type Connecting your smartphone with the vehicle to install/operate the dedicated application, and a Bluetooth headset via Bluetooth see the following URL: ® ®...
  • Page 88 The Bluetooth word mark and logos are ® registered trademarks owned by Bluetooth SIG, Inc., and any use of such marks by Honda Motors Co., Ltd., is under license. Other trademarks and trade names are those of their respective owners.
  • Page 89 Honda RoadSync functionality obey traffic laws while riding. and services. WARNING Honda cannot and does not provide any Using the Honda RoadSync while riding warranty or guarantee of future Honda can take your attention away from the RoadSync performance or functionality.
  • Page 90 Honda RoadSync (Continued) After resetting, complete pairing while the Pairing your smartphone via Bluetooth indicator flashing by operated Bluetooth ® ® the application on your smartphone. Select the BLUETOOTH PAIRING RESET When the display returns to the ordinary menu. (P.44) (P.62)
  • Page 91 Honda Selectable Torque Control Torque Control (engine power control) can Torque Control on and off be selected or turned on/off. Torque Control can be turned on and off by Do not operate the Torque Control switch pressing and holding the Torque Control while riding.
  • Page 92 Starting the Engine Start your engine using the following procedure, CB500XA regardless of whether the engine is cold or warm. CB500FA NOTICE • If the engine does not start within 5 seconds, turn the ignition switch to the (Off) position and...
  • Page 93 Make sure the engine stop switch is in the If the engine does not start: (Run) position. Open the throttle fully and press the start Turn the ignition switch to the (On) position. button for 5 seconds. Shift the transmission to Neutral ( indicator The engine will not start at this time.
  • Page 94 Shifting Gears Your vehicle transmission has 6 forward gears in a one-down, five-up shift pattern. If you put the vehicle in gear with the side stand down, the engine will shut off.
  • Page 95 Emergency Stop Signal Emergency stop signal activates when the The emergency stop signal stops operating system detects hard braking about 50 km/h when: (31 mph) or above to alert drivers behind you You release the brakes. ● about sudden braking by rapidly flashing The ABS is deactivated.
  • Page 96 Emergency Stop Signal (Continued) The emergency stop signal is not a system that can prevent a possible rear-end collision caused by your hard braking. It is always recommended to avoid hard braking unless it is absolutely necessary. The emergency stop signal does not activate with the hazard switch pressed in.
  • Page 97 Refuelling Lock cover Ignition Except CB500XA Tank capacity: 17.1 L (4.52 US gal, 3.76 Imp gal) Level plate CB500XA MA, II MA, KO, II KO type Tank capacity: 17.5 L (4.62 US gal, 3.85 Imp gal) CB500XA IN, II IN, PH, II PH type Tank capacity: 17.7 L (4.68 US gal, 3.89 Imp gal) Refuelling and Fuel Guidelines (P.15)
  • Page 98 Refuelling (Continued) Opening the Fuel Fill Cap Open the lock cover, insert the ignition key, and turn it clockwise to open the cap. Closing the Fuel Fill Cap After refuelling, push the fuel fill cap closed until it locks. Remove the key and close the lock cover. The key cannot be removed if the cap is not locked.
  • Page 100 Storage Equipment Helmet Holder CB500XA The helmet holder is located under the seat. Except CB500XA The helmet holders are located underside of A helmet set wire is in the tool kit. the rear seat. Helmet set wire Helmet holder Helmet D-ring Helmet set wire Helmet D-ring...
  • Page 101 WARNING Riding with a helmet attached to the holder can interfere with the rear wheel or suspension and could cause a crash in which you can be seriously hurt or killed. Use the helmet holder only while parked. Do not ride with a helmet secured by the holder.
  • Page 102 Storage Equipment (Continued) Tool Kit CB500XA The tool kit is located under the seat. Except CB500XA The tool kit is located under the rear seat. Rubber strap Tool kit Rubber strap Tool kit Removing the Seat (P.125) Removing the Rear Seat (P.124)
  • Page 103 Document Bag CB500XA The document bag is located underside of Except CB500XA The document bag is located underside of the seat. the front seat. Document bag Document bag Rubber strap Rubber strap Removing the Seat (P.125) Removing the Front Seat (P.123) Continued...
  • Page 104 Storage Equipment (Continued) Luggage Tie-Down Hooks Except CB500XA The luggage tie-down hooks is located on the underside of the rear seat. Luggage tie-down hooks Luggage tie-down hooks Never use the tie-down hooks to tow or lift the vehicle. Removing the Rear Seat (P.124)

  • Page 105: Maintenance

    Maintenance Please read “Importance of Maintenance” and “Maintenance Fundamentals” carefully before attempting any maintenance. Refer to “Specifications” for service data. Importance of Maintenance ......P. 102 Brakes..............P. 132 Maintenance Schedule........P. 103 Side Stand ............P. 135 Maintenance Fundamentals ......P. 108 Drive Chain ............

  • Page 106: Importance Of Maintenance

    Importance of Maintenance Importance of Maintenance Maintenance Safety Keeping your vehicle well-maintained is Always read the maintenance instructions absolutely essential to your safety and to before you begin each task and make sure that protect your investment, obtain maximum you have the tools, parts, and skills required. performance, avoid breakdowns, and reduce air We cannot warn you of every conceivable pollution.

  • Page 107: Maintenance Schedule

    Maintenance work should be performed in new owner. accordance with Honda's standards and specifications by properly trained and equipped Honda recommends that your dealer should technicians. Your dealer meets all of these road test your vehicle after each periodic requirements. Keep an accurate record of maintenance is carried out.
  • Page 108 Inspect (clean, adjust, lubricate, or replace, if necessary) dealer, unless you have the necessary tools and are Lubricate mechanically skilled. Replace Procedures are provided in an official Honda Shop Manual. Clean : Technical. In the interest of safety, have your vehicle serviced by your dealer.
  • Page 109 Maintenance Schedule Frequency Pre-ride Annual Regular Refer to Items Check × 1,000 km Check Replace page P. 108 × 1,000 mi Drive Chain Every 1,000 km (600 mi): Drive Chain Slider Brake Fluid 2 Years Brake Pads Wear Brake System Brakelight Switch Headlight Aim –...
  • Page 110 Inspect (clean, adjust, lubricate, or replace, if necessary) dealer, unless you have the necessary tools and are Lubricate mechanically skilled. Replace Procedures are provided in an official Honda Shop Manual. Clean : Technical. In the interest of safety, have your vehicle serviced by your dealer.
  • Page 111 Maintenance Schedule Frequency Pre-ride Annual Regular Refer to Items Check × 1,000 km Check Replace page P. 108 × 1,000 mi Evaporative Emission – Control System Drive Chain Every 1,000 km (600 mi): Drive Chain Slider Brake Fluid 2 Years Brake Pads Wear Brake System Brakelight Switch...

  • Page 112: Maintenance Fundamentals

    Maintenance Fundamentals Drive chain - Check condition and slack, Pre-ride Inspection ● adjust and lubricate if necessary P. 136 To ensure safety, it is your responsibility to Brakes - Check operation; ● perform a pre-ride inspection and make sure Front and Rear: check brake fluid level and that any problem you find is corrected.
  • Page 113 Maintenance Fundamentals Replacing Parts CB500XA KO, II KO type only The colour label is attached to the rear fender Always use Honda Genuine Parts or their under the seat. P. 125. equivalents to ensure reliability and safety. When ordering coloured components, specify...
  • Page 114 Maintenance Fundamentals Battery This symbol on the battery means that this product must not be treated Your vehicle has a maintenance-free type as household waste. battery. You do not have to check the battery electrolyte level or add distilled water. Clean the NOTICE battery terminals if they become dirty or An improperly disposed of battery can be...
  • Page 115 Maintenance Fundamentals WARNING What to do in an emergency If any of the following occur, immediately see The battery gives off explosive your doctor. hydrogen gas during normal operation. Electrolyte splashes into your eyes: ● Wash your eyes repeatedly with cool water for at least 15 minutes.
  • Page 116 Always replace the battery with another maintenance-free battery of the same type. Blown fuse NOTICE Installing non-Honda electrical accessories can overload the electrical system, discharging the battery and possibly damaging the system. NOTICE Replacing a fuse with one that has a higher rating greatly increases the chance of damage to the electrical system.
  • Page 117 For recommended engine oil, see or “Resource Conserving” on the circular API “Specifications.” P. 179 service symbol. If you use non-Honda engine oil, check the label to make sure that the oil satisfies all of the following standards: JASO T 903 standard : MA ●...
  • Page 118 (REPLACE) (REPLACE) Wipe up spills immediately and wash thoroughly. Recommended brake fluid: NOTICE Honda DOT 4 Brake Fluid or equivalent Use of a new chain with worn sprockets will cause rapid chain wear. Drive Chain Cleaning and Lubricating The drive chain must be inspected and lubricated After inspecting the slack, clean the chain and regularly.
  • Page 119 O-ring chains Except KO, II KO, III KO type If not available, use SAE 80 or 90 gear oil. Use only genuine HONDA PRE-MIX COOLANT without diluting with water. Genuine HONDA PRE-MIX COOLANT is excellent at preventing corrosion and overheating.
  • Page 120 Maintenance Fundamentals Crankcase Breather KO, II KO, III KO type Pro Honda HP Coolant is a pre-mixed solution Service more frequently when riding in rain, at of antifreeze and distilled water. full throttle, or after the vehicle is washed or Concentration: overturned.
  • Page 121 Maintenance Fundamentals Inspecting for Abnormal Wear Tyres (Inspecting/Replacing) Checking the Air Pressure Inspect the tyres for Visually inspect your tyres and use an air signs of abnormal wear pressure gauge to measure the air pressure at on the contact surface. least once a month or any time you think the tyres look low.
  • Page 122 Maintenance Fundamentals WARNING Inspecting Tread Depth Inspect the tread wear indicators. If they Riding on tyres that are excessively become visible, replace the tyres immediately. worn or improperly inflated can cause a For safe riding, you should replace the tyres crash in which you can be seriously hurt when the minimum tread depth is reached.
  • Page 123 ● equivalents of the same size, construction, speed rating, and load range. Always use the size and type of tyres Have the wheel balanced with Honda ● recommended in this owner's manual. Genuine balance weights or equivalent after the tyre is installed.

  • Page 124: Tools

    Tools Except CB500XA The tool kit is stored under the rear seat. P. 124 CB500XA The tool kit is stored under the seat. P. 125 You can perform some roadside repairs, minor adjustments and parts replacement with the provided tools. Pin spanner ●...

  • Page 125: Removing & Installing Body Components

    Removing & Installing Body Components Battery Removal Make sure the ignition switch is in the Negative (Off) position. Rubber terminal Except CB500XA strap Remove the front seat. P. 123 CB500XA Battery Remove the seat. P. 125 Unhook the rubber strap from rear side. Disconnect the negative - terminal from the battery.

  • Page 126: Clip

    Removing & Installing Body Components Clip Clip Installation Install the parts in the reverse order of Except CB500XA removal. Always connect the positive + terminal first. Make sure bolts and nuts are Removal tight. Press down on the centre pin to release Make sure the clock information is correct the lock.

  • Page 127: Front Seat

    Removing & Installing Body Components Front Seat Front Seat Removal Pull the rear corners of the front seat up, Except CB500XA then remove the mounting bolts. Pull the front seat back and up. Mounting bolts Installation Front seat Insert the tab into the recess. Install and tighten the mounting bolts securely.

  • Page 128: Rear Seat

    Removing & Installing Body Components Rear Seat Rear Seat Removal Move the seat strap forward. Except CB500XA Insert the ignition key into the seat lock. Rear seat Turn the ignition key clockwise, then pull Ignition key the rear seat forward and up. Installation Insert the tab into the recess.

  • Page 129: Seat

    Removing & Installing Body Components Seat Seat Removal Insert the ignition key into the seat lock. CB500XA Turn the key clockwise, then pull the seat back and up. Rear Seat prongs Installation Front prong Align the groove of the recess with the tab.

  • Page 130: Left Side Cover

    Removing & Installing Body Components Left Side Cover Left Side Cover Removal Remove the front seat. P. 123 Except CB500XA Remove the bolt and clip. P. 122 Remove the prongs from the grommets, Left side cover then remove the left side cover backward Grommet by releasing the hooks.
  • Page 131 Removing & Installing Body Components Left Side Cover Removal CB500XA Remove the seat. P. 125 Grommets Hook Remove the bolt. Remove the prongs from the grommets, Grommet then remove the left side cover backward by releasing the hook. Installation Install the parts in the reverse order of Prongs removal.

  • Page 132: Engine Oil

    Engine Oil Checking the Engine Oil Oil fill cap If the engine is cold, idle the engine for 3 to 5 minutes. Oil level inspection window Turn the ignition switch to the (Off) position and wait for 2 to 3 minutes. Upper level Place your vehicle in an upright position on a firm, level surface.
  • Page 133 Engine Oil Adding Engine Oil Adding Engine Oil Securely reinstall the oil fill cap. NOTICE If the engine oil is below or near the lower Overfilling with oil or operating with insufficient level mark, add the recommended engine oil. oil can cause damage to your engine. Do not mix P.

  • Page 134: Coolant

    Coolant Checking the Coolant Reserve tank UPPER level Check the coolant level in the reserve tank mark while the engine is cold. Place your vehicle on a firm, level surface. Hold your vehicle in an upright position. Check that the coolant level is between LOWER level the UPPER level and LOWER level marks mark...
  • Page 135 Coolant Adding Coolant Remove the reserve tank cap and add fluid while monitoring the coolant level. Reserve tank cap Do not overfill above the UPPER level mark. Make sure no foreign objects enter the reserve tank opening. Securely reinstall the reserve tank cap. WARNING Removing the radiator cap while the engine is hot can cause the coolant to...

  • Page 136: Brakes

    Brakes Checking Brake Fluid Front Front brake fluid reservoir Place your vehicle in an upright position on a firm, level surface. Check that the brake fluid reservoir Front LOWER is horizontal and that the fluid level is level mark above the LOWER level mark. Check that the brake fluid reservoir Rear is horizontal and that the fluid level is...
  • Page 137 Brakes Inspecting the Brake Pads Inspecting the Brake Pads Front Except CB500XA Pads Check the condition of the brake pad wear indicators. The pads need to be replaced if a brake pad is: worn to the bottom of Front Except CB500XA the indicator.
  • Page 138 Brakes Adjusting the Brakelight Switch Adjusting the Brakelight Switch Rear Pads Check the operation of the brakelight switch. Hold the brakelight switch and turn the adjusting nut in the direction A if the switch operates too late, or turn the nut in the direction B if the switch operates too soon.

  • Page 139: Side Stand

    Side Stand Checking the Side Stand Start the engine, pull the clutch lever in, and shift the transmission into gear. Lower the side stand all the way. The engine should stop as you lower the side stand. If the engine doesn't stop, have your vehicle inspected by your dealer.

  • Page 140: Drive Chain

    Drive Chain Inspecting the Drive Chain Slack Check the drive chain slack at several points Drive chain along the chain. If the slack is not constant at all points, some links may be kinked and binding. Have the chain inspected by your dealer. Shift the transmission to Neutral.
  • Page 141 Drive Chain Checking the Drive Chain Slider Checking the Drive Chain Slider Check the condition of the drive chain slider. The drive chain slider will need to be replaced if it is worn to the wear limit line. If necessary, have the drive chain slider replaced by your dealer.

  • Page 142: Clutch

    Clutch Checking the Clutch Check the clutch cable for kinks or signs of wear. If necessary, have it replaced by your Checking the Clutch Lever Freeplay dealer. Lubricate the clutch cable with a Check the clutch lever freeplay. commercially available cable lubricant to Freeplay at the clutch lever: prevent premature wear and corrosion.
  • Page 143 Clutch Adjusting the Clutch Lever Freeplay Adjusting the Clutch Lever Upper lock nut Freeplay – Upper Adjustment Attempt adjustment with the upper clutch cable adjuster first. Loosen the upper lock nut. Turn the upper clutch cable adjuster until Upper clutch the freeplay is 10 - 20 mm (0.4 - 0.8 in).
  • Page 144 Clutch Adjusting the Clutch Lever Freeplay Loosen the upper lock nut and turn the Lower lock nut upper clutch cable adjuster all the way in (to provide maximum freeplay). Tighten the upper lock nut. Loosen the lower lock nut. Turn the adjusting nut until the clutch lever freeplay is 10 - 20 mm (0.4 - 0.8 in).

  • Page 145: Throttle

    Throttle Checking the Throttle With the engine off, check that the throttle rotates smoothly from fully closed to fully open in all steering positions and throttle freeplay is correct. If the throttle does not move smoothly or close automatically, or if the cable is damaged, have the vehicle inspected by your dealer.

  • Page 146: Other Adjustments

    Other Adjustments Adjusting the Brake Lever Forward Index mark You can adjust the distance between the brake lever and handle grip. Brake lever Adjustment method Handle grip Turn the adjuster until the numbers align with the index mark while pushing the lever forward in the desired position.

  • Page 147: Adjusting The Rear Suspension

    Other Adjustments Adjusting the Rear Suspension Adjusting the Rear Suspension Extension Spring Preload You can adjust the spring preload by the adjuster to suit the load or the road surface. Turn the adjuster using the pin spanner and extension bar provided in the tool kit P.

  • Page 148: Troubleshooting

    Troubleshooting Engine Will Not Start (HISS indicator stays Tyre Puncture ........... P. 153 on)..............P. 145 Smartphone Pairing Trouble ......P. 154 Overheating (High coolant temperature/ Electrical Trouble..........P. 156 warning indicators are on)......P. 146 Battery Goes Dead..........P. 156 Warning Indicators On or Flashing.....

  • Page 149: Engine Will Not Start (Hiss Indicator Stays On)

    Engine Will Not Start (HISS indicator stays on) Starter Motor Operates But Check if there are no any metallic seals or stickers on the key. Engine Does Not Start If the HISS indicator still stays on, have your vehicle inspected by your dealer. Check the following items: Check the correct engine starting Starter Motor Does Not...

  • Page 150: Overheating (High Coolant Temperature/Warning Indicators Are On)

    Overheating (High coolant temperature/warning indicators are on) The engine is overheating when the following Check that the radiator fan is operating, occurs: and then turn the ignition switch to the High coolant temperature indicator and (Off) position. ● warning indicator come on. If the fan is not operating: The high coolant temperature indicator is Suspect a fault.

  • Page 151: Warning Indicators On Or Flashing

    Warning Indicators On or Flashing Low Oil Pressure Indicator If the low oil pressure indicator and the warning indicator stay on when the oil level is at the proper level, stop the engine and If the low oil pressure indicator and the contact your dealer.

  • Page 152: Pgm-Fi (Programmed Fuel Injection) Malfunction Indicator Lamp (Mil)

    Warning Indicators On or Flashing PGM-FI (Programmed Fuel Injection) Malfunction Indicator Lamp (MIL) PGM-FI (Programmed Fuel What to do when the indicator lamp comes on Injection) Malfunction Avoid high speeds and immediately get your Indicator Lamp (MIL) vehicle inspected at a dealer. NOTICE Except KO, II KO, III KO type If you drive with the malfunction indicator lamp...

  • Page 153: Abs (Anti-Lock Brake System) Indicator

    Warning Indicators On or Flashing ABS (Anti-lock Brake System) Indicator ABS (Anti-lock Brake System) If the ABS indicator stays on, your brakes will continue to work as a conventional system, Indicator but without the anti-locking function. If the indicator operates in one of the The ABS indicator may flash if you turn the following ways, you may have a serious rear wheel while the rear wheel is lifted off...

  • Page 154: Torque Control Indicator

    Warning Indicators On or Flashing Torque Control Indicator Torque Control Indicator Even when the Torque Control indicator is on, your vehicle will have normal riding ability without Torque Control function. If the indicator operates in one of the When the indicator comes on while the following ways, you may have a serious Torque Control is in operation, you will problem with the Torque Control.

  • Page 155: Other Warning Indications

    Other Warning Indications Fuel Gauge Failure Indication If the fuel system has an error, the fuel gauge indicators will be displayed as shown in the illustration. If these occurs, see your dealer as soon as possible.

  • Page 156: Coolant Temperature Gauge Failure Indication

    Other Warning Indications Coolant Temperature Gauge Failure Indication Coolant Temperature Gauge Failure Indication If the cooling system has an error, all segments will blink as shown in the illustration. If this occurs, see your dealer as soon as possible.

  • Page 157: Tyre Puncture

    Tyre Puncture WARNING Repairing a puncture or removing a wheel requires special tools and technical expertise. Riding your vehicle with a temporary We recommend you have this type of service tyre repair can be risky. If the temporary performed by your dealer. repair fails, you can crash and be After an emergency repair, always have the seriously injured or killed.

  • Page 158: Smartphone Pairing Trouble

    Smartphone Pairing Trouble Except KO, II KO, III KO type Symptom Cause/remedy Some smartphones you use may be incompatible with the vehicle and/or the operable functions may be limited. Check that the vehicle and smartphone are both in pairing mode. P.
  • Page 159 Smartphone Pairing Trouble Symptom Cause/remedy Depending on the smartphone you use, it may take some time for the vehicle to connect to a smartphone and to start using a dedicated application. The connection may be temporarily disconnected when starting the engine, which is normal and not a malfunction. The smartphone will be reconnected after the engine is started.

  • Page 160: Electrical Trouble

    Electrical Trouble Battery Goes Dead Burned-out Light Bulb Charge the battery using a motorcycle Follow the procedure below to replace a battery charger. burned-out light bulb. Remove the battery from the vehicle before Turn the ignition switch to the (Off) or charging.
  • Page 161 Electrical Trouble Burned-out Light Bulb License Plate Light Bulb Remove the screws, license light cover and license light cover packing. Pull out the bulb without turning it. License plate Bulb light cover Screw Screw Cover packing Install a new bulb and reinstall the parts in the reverse order of removal.

  • Page 162: Blown Fuse

    Electrical Trouble Blown Fuse Blown Fuse Except CB500XA Fuse box cover Before handling fuses, see “Inspecting and Replacing Fuses.” P. 112 Fuse Box Fuses Spare fuses Except CB500XA Remove the front seat. P. 123 CB500XA Fuse box Remove the seat. P.
  • Page 163 Electrical Trouble Blown Fuse Main Fuse Pull the main fuse out and check for a blown fuse. Always replace a blown fuse with a spare fuse of the same rating. Wire connector Spare main fuse is provided in the starter magnetic switch. Reinstall parts in the reverse order of removal.

  • Page 164: Information

    Information Service Diagnostic Recorders....... P. 161 Keys..............P. 161 Instruments, Controls, & Other Features... P. 162 Caring for Your Vehicle........P. 167 Storing Your Vehicle........P. 171 Transporting Your Vehicle ......P. 171 You & the Environment ......... P. 172 Serial Numbers ..........

  • Page 165: Service Diagnostic Recorders

    Do not bend keys or subject them to undue of the vehicle owner. ● stress. However this data may be accessed by Honda, Avoid prolonged exposure to sunlight or high its authorised dealers and authorised repairers, ● temperatures. employees, representatives and contractors only...

  • Page 166: Instruments, Controls, & Other Features

    Instruments, Controls, & Other Features Instruments, Controls, & If you lose a key, make another duplicate key immediately. Other Features To make a duplicate key and register it with your Ignition Switch HISS system, take the spare key, the key tag, and Leaving the ignition switch in the (On) position the vehicle to your dealer.
  • Page 167 Taiwan only Each tripmeter resets to 0.0 when the trip mileage exceeds 9,999.9. HISS The Honda Ignition Security System (HISS) immobilizes the engine's ignition system if an improperly-coded key is used to try and start the Korea only engine. When the ignition switch is turned to the (Off) position, the HISS immobilizer system is always alert, even if the HISS indicator is not flashing.
  • Page 168 Instruments, Controls, & Other Features Document Bag Assist-slipper Clutch System The assist-slipper clutch system helps to prevent Except CB500XA The owner’s manual, registration, and insurance the rear tyre from locking up when the information can be stored in the plastic deceleration of your vehicle produces a strong document bag underside of the front seat.
  • Page 169 Instruments, Controls, & Other Features Automatic Brightness Control The backlight brightness of the meter will be controlled automatically when "AUTO" is selected on the brightness setting. Ambient brightness is detected by the photosensor. Do not damage or cover the photosensor. Otherwise, the automatic brightness control may not work properly.
  • Page 170 Instruments, Controls, & Other Features Honda RoadSync Indonesia only Taiwan only...

  • Page 171: Caring For Your Vehicle

    Thoroughly rinse your vehicle with plenty of Frequent cleaning and polishing is important to clean water and dry with a soft, clean cloth. ensure the life of your Honda. A clean vehicle After the vehicle dries, lubricate any moving makes it easier to spot potential problems.
  • Page 172 Caring for Your Vehicle Washing Precautions Do not direct water at the air cleaner: ● Water in the air cleaner can prevent the Follow these guidelines when washing: engine from starting. Do not use high-pressure washers: ● Do not direct water near the headlight: High-pressure water cleaners can ●...
  • Page 173 Caring for Your Vehicle Aluminium Components Windscreen Aluminium will corrode from contact with dirt, Except CB500FA Using plenty of water, clean the windscreen with mud, or road salt. Clean aluminium parts a soft cloth or sponge. (Avoid using detergents regularly and follow these guidelines to avoid...
  • Page 174 Caring for Your Vehicle Exhaust Pipe and Muffler NOTICE Even though the exhaust is made of stainless The exhaust pipe and muffler are stainless steel steel, it can become stained. Remove all marks but may become stained by mud or dust. and blemishes as soon as they are noticed.

  • Page 175: Storing Your Vehicle

    Storing Your Vehicle Storing Your Vehicle Transporting Your Vehicle If you store your vehicle outdoors, you should If your vehicle needs to be transported, it consider using a full-body cover. should be carried on a motorcycle trailer or a If you won't be riding for an extended period, flatbed truck or trailer that has a loading ramp follow these guidelines: or lifting platform and motorcycle tie-down...

  • Page 176: You & The Environment

    You & the Environment You & the Environment Recycle Wastes Put oil and other toxic wastes in approved Owning and riding a vehicle can be enjoyable, containers and take them to a recycling centre. but you must do your part to protect the Call your local or state office of public works or environment.

  • Page 177: Serial Numbers

    Serial Numbers Serial Numbers CB500XA The frame and engine serial numbers uniquely identify your vehicle and are required in order to register your vehicle. They may also be required when ordering replacement parts. You should record these numbers and keep them in a safe place.

  • Page 178: Fuels Containing Alcohol

    Fuels Containing Alcohol Fuels Containing Alcohol The use of petrol containing more than 10% ethanol may: Some conventional fuels blended with alcohol Damage the painting of the fuel tank. ● are available in some locales to help reduce Damage the rubber tubes of the fuel line. ●...

  • Page 179: Catalytic Converter

    A defective catalytic converter contributes to air pollution and can impair your engine's performance. A replacement unit must be an original Honda part or equivalent.

  • Page 180: Specifications

    Specifications Main Components ■ CB500FA/ PH, II PH, III PH type CBR500RA 1,409 mm (55.5 in) CB500FA/ PH, II PH, III PH type CBR500RA 2,081 mm (81.9 in) FO, III FO, KO, III KO type CBR500RA 1,410 mm (55.5 in)
  • Page 181 Specifications Except CB500FA 142 kg (313 lb) 25º 30´ CB500XA PH, III PH type MA, II MA type 142 kg (313 lb) Caster angle 27º 30´ FO, III FO type CB500XA CBR500RA Except MA, II MA type 182 kg (401 lb) 27º...
  • Page 182 Specifications CB500FA 2.70 m (8.9 ft) Except 17.1 L (4.52 US gal, 3.76 Imp CB500XA gal) CBR500RA 2.90 m (9.5 ft) KO, II KO, MA, II MA type Minimum turning KO, II KO, MA, II MA type 17.5 L (4.62 US gal, 3.85 Imp radius 2.5 m (8.2 ft)
  • Page 183 Tyre size Except Idle speed 1,200 ± 100 rpm 160/60ZR17M/C (69W) CB500XA Rear Honda 4-stroke motorcycle oil API Service CB500XA 160/60R17M/C 69H Classification SJ or higher, excluding oils Recommended marked as “Energy Conserving” or Tyre type Radial, tubeless engine oil “Resource Conserving,”...
  • Page 184 Specifications Bulbs ■ KO, II KO, III KO type Pro Honda HP Coolant Recommended Headlight coolant Except KO, II KO, III KO type Brakelight/Taillight HONDA PRE-MIX COOLANT Front turn signal/Position light LED Drive chain lubricant designed specifically Recommended Rear turn signal...
  • Page 188 Online Owner’s Manual https://www.hondamotopub.com/ 32MLRD00 XXXX.2023.XX.R 00X32-MLR-D000 PRINTED IN XXXXX...

This manual is also suitable for:

Cb500xaCbr500ra

Table of Contents
