  • Page 1 Operating instructions ML 033 controller...

  • Page 2: Table Of Contents

    Page Quick reference guide - ML 033 controller ....Bathing modes ..........
  • Page 3 Contents Page If something does not work ........11.1.

  • Page 4: Quick Reference Guide - Ml 033 Controller

    ML 033 controller Quick reference guide - ML 033 controller The Klafs ML 033 controller enables you to operate your S1 sauna quickly and easily. There are special programs for each sauna or SANARIUM (optional) bathing mode. Changes to settings are saved in a custom program. There is a custom program for each bathing mode.

  • Page 5: Bathing Modes

    ML 033 controller Bathing modes All bathing modes in your Klafs S1 sauna have been designed to improve your general health and well-being. However, you should still take into account any pre-existing health conditions when choosing your bathing program. This includes:...

  • Page 6: Intended Use

    ML 033 controller Intended use The controller is intended for use with the heaters tested and approved by the German VDE (Association for Electrical, Electronic and Information Technologies) or TÜV (Technical Inspection Authority): Sauna heater with or without evaporator The controller is only to be used as intended. Intended use also assumes adherence to the instructions for operation, installation and servicing as prescribed by the manufacturer.

  • Page 7: General Safety Precautions

    Customer Services department, or by another suitably qualified individual. Contact Klafs customer service if faults cannot be rectified by a qualified electrician. Remote operation (remote switch-on): Setting, controlling and/or adjusting the controller using a command or a remote control unit that is outside the range of vision of the sauna heater or is implemented via preset time mode.

  • Page 8: Controller

    ML 033 controller Controller 6.1. Operating and display elements Item Element Description Controller main switch. The main switch switches off the mains power to the controller. The internal clock has a power reserve for a few months in the event of a power failure.

  • Page 9: Touchscreen

    ML 033 controller Controller 6.2. Touchscreen SAUNA SANARIUM PROGRAM INDIVIDUAL Section Description Time or fault alert symbols. A + B (A) see page 11. (B) see page 11. Status bar. See page 12. Bathing mode. See page 13. Selected bathing program.

  • Page 10: Touchscreen - Basic Operation And Display Symbols

    ML 033 controller Controller 6.3. Touchscreen - Basic operation and display symbols The control panel must be switched on at the main switch. See page 17. Operate the control panel by pressing on the touchscreen with your finger. The touchscreen is divided into display sections and function symbols.

  • Page 11: Touchscreen - Section 1 A: Time

    ML 033 controller Controller 6.4. Touchscreen - Section 1 A: Time Setting the time. See page 19. 6.5. Touchscreen - Section 1 B: Fault alert symbols When a fault occurs, the status bar displays the relevant fault alert symbol instead of the time.

  • Page 12: Touchscreen - Section 2: Status Bar

    Symbol permanently lit: The sauna cabin has been checked. The sauna cabin is ready to be operated remotely via the Klafs Sauna app. Symbol not visible: If the sauna door is opened after the cabin check has been performed and before a bathing program has started, the symbol will go out.

  • Page 13: Touchscreen - Section 3: Bathing Modes

    ML 033 controller Controller 6.6. Touchscreen - Section 2: Status bar Continued Symbol Display/function Status symbols WLAN is installed and activated (optional). The dot inside the symbol indicates that a WLAN module is installed. The waves appear if there is a connection between the controller and a router.

  • Page 14: Touchscreen - Section 4: Selected Bathing Program

    ML 033 controller Controller 6.8. Touchscreen - Section 4: Selected bathing program Symbol Display/function Selected bathing program. PROGRAM INDIVIDUAL Select a bathing program, see page 39. 6.9. Touchscreen - Section 5: Temperature, relative humidity, remaining bathing time, preset time mode...

  • Page 15: Controller Touch Keys

    ML 033 controller Controller 6.10. Controller touch keys Symbol Display/function Selecting a special program/custom program. See page 39. Setting preset time mode. See page 43. Cabin light. See page 18. Extras. See page 44. Coloured light, see page 45. Settings.

  • Page 16: Cabin Touch Keys

    ML 033 controller Controller 6.11. Cabin touch keys Symbol Display/function Extending the cabin Requirement: Option: Lay floor protectors. Floor protectors are required for the cabin if it is installed on flooring such as carpet. Before extending the cabin, ensure that no persons or objects are in the path of the cabin.

  • Page 17: Basic Functions And Settings

    ML 033 controller Basic functions and settings 7.1. Switching the power supply on/off at the main switch Switching the power supply on Press the touch key (1). The controller goes into standby mode. The time is shown when the controller is switched on.

  • Page 18: Switching The Cabin Light On/Off

    ML 033 controller Basic functions and settings 7.2. Switching the cabin light on/off Press the touch key (1) or the symbol (2). The cabin light will switch on or off. The cabin light can be switched on even when the main switch is switched off.

  • Page 19: Setting The Time/Date

    ML 033 controller Basic functions and settings 7.3. Setting the time/date Press the SETTINGS symbol (1). < SETTINGS Press the TIME line (2). LANGUAGE > The screen for setting the time and date will TIME > appear. CONNECTING Press the line you require to set the time or date.

  • Page 20: Pairing A Bluetooth Device (E.g. Smartphone, Tablet)

    Read the operating instructions for your Bluetooth device to find out how to activate the Bluetooth function. Press the SETTINGS symbol (1) on the Klafs sauna controller. Press the CONNECTING line (2). You now have three minutes to pair your Bluetooth device with the AudioRelax system.
  • Page 21 ML 033 controller Basic functions and settings 7.4. Pairing a Bluetooth device (e.g. smartphone, tablet) Continued Your Bluetooth device The following example shows how to pair a device with the controller: Activate the Bluetooth function (3) on your Bluetooth device.

  • Page 22: Input Tone

    ML 033 controller Basic functions and settings 7.5. Input tone The ML 033 controller can be set to emit a sound when you enter values and settings. < SETTINGS This input tone can also be switched off. LANGUAGE > Press the SETTINGS symbol (1).

  • Page 23: Water Hardness

    ML 033 controller Basic functions and settings 7.6. Water hardness Requirement: < SETTINGS Ask your water supplier about your area's water hardness in order to set the correct > LANGUAGE settings on the control panel. > TIME Press the SETTINGS symbol (1).

  • Page 24: Scc Exhaust Air Module

    ML 033 controller Basic functions and settings 7.7. SCC exhaust air module The SCC exhaust air module can be set for the bathing session. < SETTINGS > LANGUAGE Press the SETTINGS symbol (1). > TIME Press the OTHER symbol (2).
  • Page 25 ML 033 controller Basic functions and settings 7.7. SCC exhaust air module Continued Set the SCC exhaust air module < Select one of the functions shown. AFTER BATH READY ALWAYS E.g. Press the line (4). ALWAYS OFF A symbol will appear next to the function you have selected (5).

  • Page 26: Standby Mode

    ML 033 controller Basic functions and settings 7.8. Standby mode The screen displays the following symbols in standby mode: Time on analogue clock (1) Day of the week, date (2). The backlighting switches off automatically after five minutes of non-use.

  • Page 27: Operation

    ML 033 controller Operation 8.1. Extending the cabin Lay floor protectors (optional) Floor protectors are required if the cabin is installed on flooring such as carpet. If floor protectors are not required, proceed to ”Extend the cabin”. Lay the floor protector (1) flush with the floor protector underneath the cabin (2).

  • Page 28: Starting Sauna Mode

    ML 033 controller Operation 8.2. Starting Sauna mode Risk of fire! Remove all flammable objects near the sauna heater before commissioning the controller. Prerequisite: The cabin must be fully extended. The cabin status symbol (1) appears. SAUNA SANARIUM SAUNA SANARIUM To extend the cabin, see page 16, 27.

  • Page 29: Ending A Sauna Session

    ML 033 controller Operation 8.3. Ending a sauna session Press the STOP symbol (1). The bathing session is automatically ended after three seconds. STOP The sauna heater switches off. PROGRAM INDIVIDUAL The controller then goes into standby mode. After a bathing session, open the cabin door to ventilate the cabin.

  • Page 30: Starting Sanarium Bathing Mode (Optional)

    ML 033 controller Operation 8.4. Starting SANARIUM bathing mode (optional) Risk of fire! Remove all flammable objects near the sauna heater before commissioning the controller. Prerequisite: The cabin must be fully extended. The cabin status symbol (1) appears. SAUNA SANARIUM To extend the cabin, see page 16, 27.

  • Page 31: Ending The Sanarium Bathing Session

    ML 033 controller Operation 8.5. Ending the SANARIUM bathing session Press the STOP symbol (1). The bathing session is automatically ended after three seconds. STOP PROGRAM INDIVIDUAL The sauna heater switches off. Subsequent drying starts. SAUNA SANARIUM The controller will switch to standby mode once subsequent drying has finished.
  • Page 32 ML 033 controller Operation 8.5. Ending the SANARIUM bathing session Continued After a bathing session, open the cabin door to ventilate the cabin. To retract the cabin, see page 16, 38. WEDNESDAY 12.11.2014 PAGE 32 50001180/06.17...

  • Page 33: Blockade Control Unit (Keypad Lock)

    ML 033 controller Operation 8.6. Blockade control unit (keypad lock) Removing ”blockade control unit” (keypad lock) Touch the screen (1). The screen for entering your security code will appear. WEDNESDAY 12.11.2014 Enter the four digits via the number pad (2).

  • Page 34: Folding Down The Foldaway Lounger

    ML 033 controller Operation 8.7. Folding down the foldaway lounger Risk of injury! Do not use the foldaway lounger until the supports (1) have been swung out and the foldaway lounger is firmly secured. Extend the cabin before folding down the foldaway lounger.

  • Page 35: Folding Up The Foldaway Lounger

    ML 033 controller Operation 8.8. Folding up the foldaway lounger Risk of crushing! Only handle and fold up the foldaway lounger using the hand strap (1). Grasp the foldaway lounger (1) by the hand strap, pull it up and fold it over onto the lounger.

  • Page 36: Varius S - Commissioning The Evaporator

    ML 033 controller Operation 8.9. Varius S - Commissioning the evaporator Risk of fire! Before commissioning, always check that there are no inflammable objects on or near the sauna heater. Hot surfaces - Risk of scalding! The cover (1) will be hot straight after a bathing session has finished.

  • Page 37: Varius S - Decommissioning The Evaporator

    ML 033 controller Operation 8.10. Varius S - Decommissioning the evaporator Draining residual water Drain off residual water after every use. Hot surfaces - Risk of scalding! The residual water will be hot straight after a session has finished. Protect your hands and fingers from scalding.

  • Page 38: Retracting The Cabin

    ML 033 controller Operation 8.11. Retracting the cabin Retract the cabin Conditions for retracting the cabin: No bathing session may be started. The cabin must be cooled after a bathing session. Remove any objects on the sauna heater (1) or the multifunctional duct (2) inside the cabin.

  • Page 39: Custom Settings

    ML 033 controller Custom settings 9.1. Selecting a special program/custom program Each bathing mode comes with a custom program in which you can apply your own personal settings and special programs with preset bathing parameters that cannot be changed. Any changes made to bathing parameters are saved automatically.
  • Page 40 Pressing the line at the top (8) will take you back to the previous screen. < IMMUNE-POWER-SANARIUM START PROGRAM DESCRIPTION Ideal in the cold season: mild warmth and little humidity are a boon for the airways and strengthen your immune system. KLAFS wishes best health! PAGE 40 50001180/06.17...

  • Page 41: Setting The Temperature

    ML 033 controller Custom settings 9.2. Setting the temperature Press the TEMPERATURE line (1) to activate it. Set the desired temperature (2) by pressing the +/- symbols (3). STOP Sauna setting range: 10 °C - 90 °C. SANARIUM setting range: 48 °C - 75 °C.

  • Page 42: Setting The Bathing Time

    ML 033 controller Custom settings 9.4. Setting the bathing time Press the BATHING TIME line (1) to activate The bathing time display (2) starts flashing. STOP Select the number of hours the bathing time should last by pressing the +/- symbols (3).

  • Page 43: Setting Preset Time Mode

    ML 033 controller Custom settings 9.5. Setting preset time mode Risk of fire! Remove all flammable objects near the sauna heater before commissioning the controller. Press the PRESET TIME line (1) to activate it. The pre-programmed start time (2) starts flashing.

  • Page 44: Extras

    ML 033 controller Custom settings 9.6. Extras Switching extras on/off and changing their settings < EXTRAS < EXTRAS Press the EXTRAS symbol (1). > > The extras screen (2) appears. You can then do the following for the extra: >...

  • Page 45: Coloured Light

    ML 033 controller Custom settings 9.7. Coloured light Setting the coloured light < EXTRAS Press the EXTRAS symbol (1). The extras display appears. > Press the Coloured light symbol (2). > The display for setting the coloured light COLOURED LIGHT appears.
  • Page 46 ML 033 controller Custom settings 9.7. Coloured light Continued Apply the change you have made by COLOURED LIGHT touching the NEW symbol (7). Pressing the OLD symbol (8) will discard the SZENE change and retain the current setting. SETTING Continued on the next page PAGE 46 50001180/06.17...
  • Page 47 ML 033 controller Custom settings 9.7. Coloured light Continued Set a theme COLOURED LIGHT Set a theme for the coloured light. Press the symbol (1). SZENE The menu below shows a list of available CHOICE options. EMBERS Select a theme.

  • Page 48: Assigning A Pin To The Controller

    Once the activation process has completed successfully, the WLAN symbol (8) stops flashing and becomes permanently lit. The KLAFS WLAN module is now ready to be configured. To configure the KLAFS WLAN module, see the installation instructions with the item number 5060108/5060109.

  • Page 49: Enabling/Disabling "Blockade Control Unit" (Locking/Unlocking The Keypad)

    ML 033 controller Custom settings 9.9. Enabling/disabling ”blockade control unit” (locking/unlocking the keypad) Calling up the ”blockade control unit” menu When enabled, the ”blockade control unit” function prevents the controller from being operated unintentionally. Switch the controller on at the main switch (1).

  • Page 50: Programming The Controller For Remote Operation

    KLAFS server. To assign a PIN to the ML 033 controller, see page 48. To set up the KLAFS WLAN module, see the installation instructions with the item number 5060108/5060109.
  • Page 51 Close the sauna door (3). The symbol (2) is permanently lit. The controller now informs the KLAFS server that it is in standby mode and ready for remote operation. Now you can program and switch on your SANARIUM®...

  • Page 52: If Something Does Not Work

    Repairs and maintenance must only be carried out by Klafs service engineers or by technicians expressly authorised by Klafs. Klafs can only provide repairs and servicing work under warranty if this work is carried out by Klafs service engineers. Displaying and acknowledging errors...
  • Page 53 ML 033 controller If something does not work 11.1. Error messages on the screen Continued Fault How to rectify the fault The cabin drive was switched off due to Remove obstacles in the cabin's range of motor overload. motion. If the error message is repeated, this indicates a technical problem.

  • Page 54: Other Possible Errors

    Fuse SI100 or SI101 has Replace fuse SI100 (1.0 AT) or blown. SI101 (3.15 AT), or inform Klafs service engineers. The cabin light The bulb is defective. Change the bulb. does not light up...

  • Page 55: Resetting The Error Message

    ML 033 controller If something does not work 11.3. Resetting the error message Notice! Only allow work on electrical components/assemblies to be carried out by qualified electricians who work in accordance with electrical rules and regulations. Switch the controller off, disconnect it from the mains and make sure that it cannot be switched on again.

  • Page 56: Cleaning And Maintenance

    ML 033 controller Cleaning and maintenance 12.1. Cleaning the sauna cabin Never use a hose or pressure washer on the inner cabin walls, benches or seats. Wipe the surfaces with a damp cloth. The humidity generated during operation will not damage the wood of your cabin.

  • Page 57: Evaporator

    ML 033 controller Cleaning and maintenance 12.3. Evaporator Hot surfaces - Risk of scalding! The cover (5) will be hot straight after a bathing session has finished. Protect your hands and fingers from scalding. Draining the evaporator Press down on the cover flap (1) at the bottom (2) and then pull it out.
  • Page 58 ML 033 controller Cleaning and maintenance 12.3. Evaporator Continued Rinsing the evaporator 12. Press down on the cover flap (1) at the bottom (2) and then pull it out. 13. Hold the filler can (3) below the drain valve (4).
  • Page 59 ML 033 controller Cleaning and maintenance 12.3. Evaporator Continued Resetting the message < SETTINGS 25. Press the SETTINGS symbol (1). LANGUAGE > 26. Press the WATER HARDNESS (2) symbol. > TIME CONNECTING BEEP POP UP > BLOCKADE CONTROL UNIT >...

  • Page 60: Cleaning The Outer Panelling Of The Varius Sauna Heater

    ML 033 controller Cleaning and maintenance 12.4. Cleaning the outer panelling of the Varius sauna heater Brush the outer panelling with a clothes brush or lint brush. Work with the clothes brush or lint brush in one direction only. Vacuum the outer panelling with a vacuum cleaner with a brush attachment.

  • Page 61: Scc Exhaust Air Module - Condensate Tray

    ML 033 controller Cleaning and maintenance 12.5. SCC exhaust air module - Condensate tray Drain the condensate that has collected after every sauna session. Open the wooden hatch underneath the bench in the cabin. Undo the catches (1) on both sides of the SCC exhaust air module.

  • Page 62: Scc Exhaust Air Module - Changing The Filters

    ML 033 controller Cleaning and maintenance 12.6. SCC exhaust air module - Changing the filters The filters must be changed once a year. Pull the supply air duct (1) out of the bracket (2) on the SCC exhaust air module and put it to the left-hand side.

  • Page 63: Notes

    ML 033 controller Notes PAGE 63 50001180/06.17...

  • Page 64: Addresses

    KLAFS GmbH Sonnwiesenweg 19 A-6361 Hopfgarten/Tirol Tel. +43 5335 2330-0 We hope your ”ML 033 controller” promotes your well-being and provides you with hours of fun, leaving you feeling relaxed and rejuvenated. Subject to technical modifications. Reproduction in whole or in part is prohibited without the written permission of KLAFS GmbH &...
