Summary of Contents for Hollyland LARK M2
- Page 1 LARK M2 User Manual V1.0...
- Page 3 Product Version Overview LARK M2 Solo (Android) LARK M2 Solo (iOS)
- Page 4 Product Version Overview LARK M2 Duo (iOS) LARK M2 Duo (Camera)
- Page 5 Product Version Overview LARK M2 Combo * The quantity of the items depends on the product configuration.
-
Page 6: Interface Description
Interface Description Mobile Version RX(Android/iOS） Charging Case Camera Version Charging Case... - Page 7 Interface Description TX：Transmitter Built-in Microphone Indicator Light Magnet Power/Noise Cancellation Button/Pairing Button Contacts Mobile Version RX: Receiver (iOS/Android) USB-C Interface Noise Cancellation/ TX1 Indicator Light Pairing Button TX2 Indicator Light *The plug interface varies between Android and iOS versions.
- Page 8 Interface Description Camera Version RX: Receiver Indicator Light Volume Control Knob Contacts 3.5 Audio Input USB-C Interface Interface Back Clip Power Button Mode Switch/Pairing Button Volume/Mode Indicator Light Contacts...
- Page 9 Mobile Version Installation and Connection Guide ① Preferred Placement for TX: Attach it to your collar. If you speak loudly, place it higher up on your chest. Use either a clip or magnet for attachment. Place the magnet on the inside of your collar and Firstly, clip the back clip to your collar and attach attach the TX to the magnet on the outer side.
- Page 10 Mobile Version Installation and Connection Guide Connect RX (iOS) to iPhone Connect RX (Android) to Android Phone...
- Page 11 Mobile Version Installation and Connection Guide Charge your mobile device with RX while using it.
- Page 12 Camera Version Installation and Connection Guide Connecting Receiver to Camera Attach the receiver to a camera via the hot shoe or cold shoe using the back clip. Connect the 3.5mm audio output interface on the receiver to the 3.5mm audio input interface on the camera using a 3.5mm TRS to TRS cable.
- Page 13 Product Indicator Lights Guide TX Indicator Lights Description Status Blue light flashing TX and RX not connected Blue light steady TX and RX connected Green light steady (In use) Noise Cancellation ON Pink light steady TX updating Orange light steady TX charging Green light steady (While charging) TX fully charged...
- Page 14 Product Indicator Lights Guide Blue light steady TX and RX connected Green light steady (In use) Noise Cancellation ON Pink light steady RX updating Orange light steady RX charging Green light steady (While charging) RX fully charged Red light flashing slowly TX low battery RX two red lights flashing quickly RX low battery...
-
Page 15: Product Usage
Product Usage Automatic On/Off Remove the device from the charging case to turn on automatically. Place the device back in the case to turn off automatically. Manual On/Off Press and hold the TX power button, or the Camera Version RX power button for 3 seconds: To turn on/off Press and hold the TX power button for 3 seconds Press and hold the RX power button for 3 seconds... - Page 16 Product Usage Noise Cancellation Manual Pairing Press the noise cancellation button on the TX to With the TX turned off, press and hold the pairing turn noise cancellation on or off. When activated, button for 6 seconds to start pairing. The TX status the TX status light turns green.
- Page 17 Product Usage Manual Charging With the camera version RX turned on, hold the When the TX status light slowly flashes red or both pairing button for 3 seconds to start pairing. status lights on the camera RX flash red quickly, use the magnetic charger to charge the TX.
- Page 18 Product Usage Volume Adjustment - Only Supported by Camera Mode Switching - Only Supported by Camera Version RX Version RX Default volume setting is medium, with low, medium, Connect to Smartphone: Green light on, supports only and high options. Turn the volume knob clockwise to mono mode.
- Page 19 App Information LARK SOUND LARK SOUND The LARK SOUND app is a perfect match for Hollyland The LARK SOUND app is available for download on wireless microphones. With the app, you'll have access Xiaomi, Huawei, and Apple App Stores. Official QR code to a range of smart features, such as parameter con- scanning is also supported.
-
Page 20: Specifications
Specifications Mic Sensitivity –37dBFS±2dB@1 kHz, 94dB SPL Modulation Mode GFSK Wireless Transmission 2.4GHz Mobile Version: Up to 984ft (300m) for LOS/197ft (60m) for NLOS Transmission Range Camera Version: Up to 984ft (300m) for LOS/131ft (40m) for NLOS Mic Polar Pattern Omnidirectional Frequency Response 20 Hz–20 kHz... - Page 21 Specifications TX: About 8 hours Camera Version RX: About 8 hours Operating Time Mobile Version Charging Case: Approx. two times of charging for 2 TX Camera Version Charging Case: Approx. three times of charging TX: About 1.5 hours Camera Version RX: 1.5H Charging Time Mobile Version Charging Case: <1.5 hours Camera Version Charging Case: <2 hours...
- Page 22 Specifications Charging power 2.4V * The data provided above is based on laboratory testing results.
- Page 23 Support If you encounter any problems in using the product or need any help, please contact Hollyland Support Team via the following ways: Hollyland User Group HollylandTech HollylandTech HollylandTech support@hollyland.com www.hollyland.com Statement: All copyrights belong to Shenzhen Hollyland Technology Co., Ltd. Without the written approval of Shenzhen Hol- lyland Technology Co., Ltd., no organization or individual may copy or reproduce part or all of any written or illustra-...
