Page 1 SAMSUNG SIDE BY SIDE REFRIGERATOR SSEDA-14 -PJT New product training for refrigerator SIDE BY SIDE BASIC : RH25H561* MODEL NAME : RH25H5611SR, RH25H5613SL MODEL NAME : RH25H5611SR/AA, RH25H5613SL/AP, RH25H5613SL/EY, RH25H5613SL/BZ, RH25H5613SL/EM, RH25H5613SL/CL, RH25H5613SL/PE, RH25H5613SL/BG, RH25H5613SL/ZS RH25H5611BC/AA, RH25H5611WW/AA 2014. 10...
Page 2 Thank you The End - This Service Manual is a property of Samsung Electronics Co., Ltd. Any unauthorized use of Manual can be punished under applicable International or domestic law.
Page 3: Table Of Contents
Contents Precautions(Safety Warnings)---- 6 Product Specifications-------------13 2-1. Introduction of Main Function----------------------------------------------------------- 13 2-2. Model Specification-------------------------------------------------------------------------- 14 2-3. Interior Views ---------------------------------------------------------------------------------- 16 2-4. Electrical Part Specifications & Standard ------------------------------------------- 17 2-5. Dimensions of Refrigerator (Inches)---------------------------------------------------- 23 2-6. Optional Material Specification----------------------------------------------------------- 24 2-7.
Page 4 Contents Full disassembly and assembly- 29 3-7. Tempered Glass Shelf ----------------------------------------------------------------------- 40 3-8. Plastic Drawers in Refrigerator ---------------------------------------------------------- 41 3-9. Gallon Door Bin ------------------------------------------------------------------------------- 41 3-10. Water Filter ------------------------------------------------------------------------------------ 42 3-11. Water Filter Tank of Refrigerator ------------------------------------------------------ 43 3-12. Damper of Refrigerator ------------------------------------------------------------------- 45 3-13.
Page 5 Contents Check the installation status------63 4-4. Cooling Off Function(US Model Only) ---------------------------------------------------- 67 4-5. Exhibition Mode Function(NON US Model Only) -------------------------------------- 68 4-6. Self-Diagnostics Function -------------------------------------------------------------------- 69 4-7. Load Operation Check Function ------------------------------------------------------------ 75 4-8. Function for failure diagnosis ---------------------------------------------------------------- 76 4-9.
Page 6 Contents Wiring diagram ----------------------- 121 PCB Diagram ------------------------------ 122 7-1. Part Arrangement (Main Board) ------------------------------------------------------------ 122 7-2. Connector Layout & Descriptions of Inverter Controller Board ---------------------- 124 7-3. Connector Arrangement (Main Board) ---------------------------------------------------- 125 Reference Information ------------------ 126 8-1. Connector Layout & Description (Inverter comp control Board) -------------------- 126 Schematic Diagram ---------------------- 127 9-1.
Page 7: Precautions(Safety Warnings)
1. Precautions(Safety Warnings) Unplug the appliance before replacing or repairing electrical parts. ● ⇒ Be careful to avoid electric shock. Always use only the correct replacement parts. ● ⇒ Check the model, rated voltage, rated current and running temperature rating. When troubleshooting, verify that wiring harnesses are connected securely.
Page 8 1. Precautions(Safety Warnings) Read all instructions before repairing the product and follow the instructions in order to prevent danger or property damage. Plug out and remove all the items in regrigerator prior to repair. CAUTION/WARNING SYMBOLS DISPLAYED means “Prohibited”. Indicates that a danger Warning of death or serious means “Do not disassemble”.
Page 9 1. Precautions(Safety Warnings) Pull the power plug out before attempting to Use only rated components for replacement. exchange the interior lamp of the refrigerator. • Check the correct model, rated voltage, rated • This will prevent danger of electric shock. current, operating temperature.
Page 10 1. Precautions(Safety Warnings) After repair, check the assembled state of Check if there is any trace indicating the components. permeation of water. • It must be in the same assembled state as before • If there is that kind of trace, change the related components or do the necessary treatment such disassembly.
Page 11 1. Precautions(Safety Warnings) Do not allow users to store pharmaceutical Do not allow users to insert the power plugs for many products at the same time. products, scientific materials, etc., in the refrigerator. • May cause abnormal generation of heat or fire. •...
Page 12 1. Precautions(Safety Warnings) Do not allow users to store articles on the Do not allow users to install the product. refrigerator in the wet place or the place where water splashes. • Opening or closing the door may cause things to •...
Page 13 1. Precautions(Safety Warnings) CAUTION When installing, servicing, or cleaning behind the refrigerator, be sure to pull the unit straight out and push back in straight after finishing. Also, make sure your floor supports the full-load refrigerator. Otherwise, it may cause floor damage.
Page 14: Product Specifications
2. Product Information To do list 2-1. Introduction of main Function ■ Major feature Changed Part Description Picture New Ice Maker Cabinet Ice Maker (Auger Motor Located in CABI) DOOR DISPENSER New Design Dispenser...
Page 15: Model Specification
This operation instruction covers various models. The characteristics of your appliance may differ slightly from those described in this manual. Key features of your new refrigerator Your Samsung Side-By-Side Refrigerator comes equipped with many space- saving, innovative storage and energy-efficient features. Twin Cooling Plus™...
Page 16 2. Product Information To do list 2-2. Model Specifications CoolSelect Zone has three selections. - Fresh : The temp. of the compartment is similar to that of the surrounding refrigerator compartment. - Quick Cool : This function can be used to chill quickly beverages. - Thaw : This function can be used to defrost foods.
Page 17: Interior Views
2. Product Information To do list 2-3. Interior Views...
Page 18: Electrical Part Specifications & Standard
2. Product Information To do list 2-4. Model Specification &Specification Chart Items Specification RH25H5611* RH25H 5613* Model D-power G-power TOTAL 9.1 cu.ft 9.8 cu.ft Net Capacity Refrigerator 15.6 cu.ft 15.6 cu.ft Freezer 24.7 cu.ft 25.4 cu.ft Net Dimension(W x D x H) 36 1/20"...
Page 19 2. Product Information To do list 2-4. Model Specification &Specification Chart Items Specification Model RH25H5611* / RH25H 5613* MKV190CL2B/SM1 Model MKV190GL2J/SM1 Compressor Starting type BLDC Oil Charge FREOL α 15 Freezer SPLIT FIN TYPE Evaporator Refrigerator SPLIT FIN TYPE Condenser Forced and natural convection type Dryer Molecular sieve XH-9...
Page 20 2. Product Information To do list 2-4. Model Specification &Specification Chart Items Specification Model RH25H5611* / RH25H 5613* Model Temperature Selection On(°F) Off(°F) -8 ˚F (-23˚C) -5˚F (-21˚C) -11˚F (-24 ˚C) THERMISTOR (F-SENSOR) 0 ˚F (-18˚C) 3˚F (-16˚C) -3˚F (-19 ˚C) 502AT 5 ˚F (-15˚C) 8˚F (-13˚C)
Page 21 2. Product Information To do list 2-4. Model Specification &Specification Chart Items Specification Model RH25H5611* / RH25H 5613* First Defrost Cycle 6hr ± 10min (Comp on integation) (Concurrent defrost of F and R) Defrost Cycle (FRE) 12~48hrs (vary according to the conditions used) 10 ±...
Page 22 2. Product Information To do list 2-4. Model Specification &Specification Chart Items Specification RH25H5611* / RH25H 5613* Model D-Power G-Power Defrost Heater(FRE) Conducting at F Defrost AC 120V / 218W AC 230V / 218W Defrost Heater(REF) Conducting at R Defrost AC 120V / 140W AC 230V / 218W DISPENSER Heater...
Page 23 2. Product Information To do list 2-4. Model Specification &Specification Chart Items Specification RH25H5611* / RH25H 5613* Model D-Power G-Power G6015S12B, DC12V, 0.07A, 1.0W, G6015S12B, DC12V, 0.07A, 1.0W, MOTOR-BLDC(Box Fan) 2400rpm±7%, CW 2400rpm±7%, CW MVCC18AR19, AC120V/60Hz, MVCC18AR19, AC120V/60Hz, MOTOR GEARED I/M INDOOR 18.18rpm, 3.5W, 0.04A, CW 18.18rpm, 3.5W, 0.04A, CW MVCD18AR19, AC120V/60Hz,...
Page 24: Dimensions Of Refrigerator (Inches)
2. Product Information To do list 2-5. Dimensions of Refrigerator (Inches)
Page 25: Optional Material Specification
2. Product Information To do list 2-6. Optional Material Specification Photograph Part Name Part Code ASSY PACKING-SUB -1 EA DA99-03490N CLIP-FITTING LOCK -2 EA DA61-04522A BAG PE -1 EA DA69-90113K WRENCH-SPANNER -1 EA DA80-00002C DA97-01469W ASSY-INSTALL FILTER -1 EA 6002-000213 SCREW-TAPPING -12EA DA62-01329A...
Page 26 2. Product Information To do list 2-6. Optional Material Specification Photograph Part Name Part Code ASSY PACKING INSTALL -1EA DA99-03680B FIXER-HANDLE -4EA DA61-03734A BAG-PE -1EA DA69-90113S WRENCH-SPANNER -1EA DA80-00026B ASSY LABEL-HANDLE DA99-03429H INSTRUCTION -1EA ASSY INSTALL-ACCESSOR-1EA DA99-03490T BAG PE -1EA DA69-90113S SPANNER -1EA...
Page 27: Refrigerant Route In Refrigeration Cycle
2. Product Information To do list 2-7. Refrigerant Route in Refrigeration cycle Compressor → Condenser → Pipe Hot → Pipe Cluster Rear → Dryer → Capillary Tube → Evaporator → Suction Pipe → Compressor...
Page 28: Digital Display
2. Product Information To do list 2-8. Digital Display Energy Saver (°C↔°F (3 sec)) For better energy eficiency, press the Energy Saver button.If condensation occurs on the doors, turn the Energy Saver Button function off.To switch the temperature units between ºC and ºF. Touch and hold this button for 3 seconds to select the temperature display you want.Each time you press and hold the button, the ºC and ºF temperature modes alternate and the ºC or ºF icon...
Page 29 2. Product Information To do list 2-8. Digital Display Lighting (Control Lock (3 sec)) Press the Lighting button to turn on the dispenser LED lamp.If you press and hold the Lighting button for 3 seconds, all buttons will be locked and the dispenser pad will not work.
Page 30: Full Disassembly And Assembly
3. Full disassembly and assembly To do list 3-1. Precaution • When replacing or repairing electric components, → If the installation is made unstably or the machine is unplug power cord before you replace or repair. installed in humid conditions or water, change its location.
Page 31 3. Full disassembly and assembly To do list 3-1. Precaution - TOOLS REQUIRED FOR DISASSEMBLY IMAGE ITEM (+) SCREW DRIVER (-) SCREW DRIVER (-) SMALL SCREW DRIVER SOCKET WRENCH...
Page 32 3. Full disassembly and assembly To do list - MAKING MINOR ADJUSTMENTS BETWEEN SHOW CASE AND INNER CASE OF FRIDGE After raising the out door, insert the supplied SHIM HINGE MIDDLE in the gap between Show case of fridge and the HINGE-SHAFT.
Page 33: Freezer Door
3. Full disassembly and assembly To do list 3-2. Freezer Door Part name How to do Descriptive Picture Removing the Front leg cover. 1. Open the freezer and refrigerator doors. 2. Take off the front leg cover by turning the three screw counter-clockwise.
Page 34 3. Full disassembly and assembly To do list 3-2. Freezer Door Part name How to do Descriptive Picture Removing the Lower hinge. 1. With the door closed,remove the upper hinge cover (1) using a screwdriver. 2. Disconnect the wires (2). 3.
Page 35: Refrigerator Out Door & In Door
3. Full disassembly and assembly To do list 3-3. Refrigerator Out Door & In Door Part name How to do Descriptive Picture 1. Removing the Upper hinge. With the door closed, remove the upper hinge cover (①) using a screwdriver. 2.
Page 36 3. Full disassembly and assembly To do list 3-3. Refrigerator Out Door & In Door Part name How to do Descriptive Picture Door Ref 4. Removing the Door Put up a OUT DOOR after opening the DOOR slightly Note ·Lift the door straight up. ·Be careful not to pinch the water tubing and wire harness on the door.
Page 37: Control Panel
3. Full disassembly and assembly To do list 3-4. CONTROL PANEL Part name How to do Descriptive Picture Turn off he Refrigerator Power Cord. Disassemble one screw with plus driver as shown in the picture. Control Panel Pull out to the front to disassemble ASSY COVER DISPENSER as shown in the picture.
Page 38 3. Full disassembly and assembly To do list 3-4. CONTROL PANEL Part name How to do Descriptive Picture Disassemble three remarked screws with plus driver. Control Panel Pull out ASSY CASE ICE ROUTE for disassembly...
Page 39: Door Gasket
3. Full disassembly and assembly To do list 3-5. DOOR GASKET Part name How to do Descriptive Picture The door gasket is a molded gasket set into a channel located in the door liner. 1. Open the door Door Gasket 2.
Page 40: Door Handle
3. Full disassembly and assembly To do list 3-6. DOOR HANDLE Part name How to do Descriptive Picture 1. FRE HANDLE : Loose set screw(1) with wrench and lift up the handle Door Handle 2. REF HANDLE : Loose set screw(1) and push the lever On the handle then lift up the handle.
Page 41: Tempered Glass Shelf
3. Full disassembly and assembly To do list 3-7. TEMPERED GLASS SHELF Part name How to do Descriptive Picture These shelves allow storage of larger items and pull out for easy access. 1. Pull the shelf out as far as it goes. 2.
Page 42: Plastic Drawers In Refrigerator
3. Full disassembly and assembly To do list 3-8. PLASTIC DRAWERS IN REFRIGERATOR Part name How to do Descriptive Picture Drawers are designed for storage of fruits, vegetables, and deli items, The drawers are Drawer In located in the lower portion of the refrigerator. Refrigerator 1.
Page 43: Water Filter
3. Full disassembly and assembly To do list 3-10. WATER FILTER Part name How to do Descriptive Picture The water filter is located in the lower right- hand corner of the refrigerator. The water filter for the ice maker and the water Water Filter dispenser.
Page 44: Water Filter Tank Of Refrigerator
3. Full disassembly and assembly To do list 3-11. WATER FILTER TANK OF REFRIGERATOR Part name How to do Descriptive Picture Remove the screw. Remove the fitting clip & Remove the water hose by pressing the coupler. Water Filter Tank Remove the screw.
Page 45 3. Full disassembly and assembly To do list Part name How to do Descriptive Picture Separate Water tank from Case-water tank. Water Tank Remove the Fitting clip. Pull out the Hose by pressing the coupler...
Page 46: Damper Of Refrigerator
3. Full disassembly and assembly To do list 3-12. DAMPER OF REFRIGERATOR Part name How to do Descriptive Picture 1. Put (-) driver into the gap between Cover- Lamp and Damper. 2. Pull out the Cover-Lamp. Damper-Ref Disconnect the wire connector. Remove the screw.
Page 47: Door Bin Of Freezer
3. Full disassembly and assembly To do list 3-13. DOOR BIN OF FREEZER Part name How to do Descriptive Picture Door Bin In 1. Push the bin up Freezer...
Page 48: Ice Maker Compartment
3. Full disassembly and assembly To do list 3-14. Ice Maker Compartment Part name How to do Descriptive Picture Disassemble the Ice-Bucket Assy by holding Ice Bucket the handles and pulling up the bottom part Assy slightly. Cover I/M Lift up the Icemaker Cover and gently pull out. Unscrew the 4 screws and disassemble the ASSY ICE MAKER-INDOOR as shown.
Page 49 3. Full disassembly and assembly To do list 3-14. Ice Maker Compartment Part name How to do Descriptive Picture Unscrew the 3 screws. Ice Maker Assy Disassemble the Ice Maker Assy.
Page 50: Plastic Drawer In Freezer
3. Full disassembly and assembly To do list 3-15. PLASTIC DRAWER IN FREEZER Part name How to do Descriptive Picture Drawers are designed for storage of meat and dry foods. The drawers are located in the PLASTIC lower portion of the freezer. DRAWER IN 1.
Page 51: Cover Multi In Freezer
3. Full disassembly and assembly To do list 3-17. COVER MULTI IN FREEZER Part name How to do Descriptive Picture 1. Pull out the screw caps and remove screws COVER (6). MULTI IN 2. Remove the evaporator cover in the FREEZER direction of outwards.
Page 52: Evaporator In Freezer
3. Full disassembly and assembly To do list 3-19. EVAPORATOR IN FREEZER Part name How to do Descriptive Picture Evaporator is located in the bottom of freezer to produce cold air driven across the evaporator coils. 1. Take off the ductwork in Freezer. 2.
Page 53: Ambient Thermistor
3. Full disassembly and assembly To do list 3-20. AMBIENT THERMISTOR Part name How to do Descriptive Picture The ambient thermistor is located Ambient inside the upper hinge cover. Thermistor The ambient thermistor sends temperature signals to the microprosessor.
Page 54: Door S/W & Humidity Sensor
3. Full disassembly and assembly To do list 3-21. Door S/W & Humidity Sensor Part name How to do Descriptive Picture 1. Removing the upper hinge With the door closed, remove the upper hinge cover(1)using a screwdriver 2. Disconnect the wire Door S/W &...
Page 55: Comp Cooling Fan
3. Full disassembly and assembly To do list 3-22. Comp Cooling Fan Part name How to do Descriptive Picture 1. Unscrew 6 screws of COVER COMP. 2. Remove the DRAIN HOSE. Comp Cooling Fan 3. Remove 1 screw. 4. Disengage the HOUSING CONNECTOR. (Refer to the picture)
Page 56 3. Full disassembly and assembly To do list 3-22. Comp Cooling Fan Part name How to do Descriptive Picture 5. Pull it forward and lean against the DRAIN HOSE. Comp 6. Rotate it based on the PIPE. Cooling Fan 7. The FAN is disassembled. / Assembly it in reverse order.
Page 57: Comp Cooling Fan Motor
3. Full disassembly and assembly To do list 3-23. Comp Cooling Fan Motor Part name How to do Descriptive Picture 1. Remove the screw with a flat blade screwdriver. Comp 2. Remove the motor fan by pulling the fan Cooling Fan out while graping the motor part.
Page 58 3. Full disassembly and assembly To do list 3-23. Comp Cooling Fan Motor Part name How to do Descriptive Picture 4. Remove the BRACKET MOTOR with a flat blade screwdriver. Comp Cooling Fan Motor 5. Remove the MOTOR after pulling the BRACKET MOTOR out.
Page 59 3. Full disassembly and assembly To do list Part name How to do Descriptive Picture 1. Disengage the housing connector. Relay O/L 2.Remove Cover Relay. 3. Remove the relay O/L with a flat-blade screwdriver. (Refer to the picture)
Page 60 3. Full disassembly and assembly To do list Part name How to do Descriptive Picture 1. Unscrew the water valve fixed by the screw. 2. Disassemble the white part. Water Valve Pull out the black pin. 3. Remove 2 water hose parts while pushing the upper part of.
Page 61 3. Full disassembly and assembly To do list Part name How to do Descriptive Picture 4. Disengage 2 housing connector parts. Water Valve 5. Remove the hose connected by the nut with a wrench(8mm).
Page 62: Assy Pba
3. Full disassembly and assembly To do list 3-24. ASSY PBA Part name How to do Descriptive Picture Remove 4 Screws. ASSY PCB MAIN Remove the ASSY PCB MAIN ASSY PCB Remove the ASSY PCB SUB INVERTER INVERTER COIL Remove the COIL FILTER-EMI FILTER-EMI...
Page 63: Assy Case Auger Motor
3. Full disassembly and assembly To do list 3-25. ASSY CASE AUGER MORTOR Part name How to do Descriptive Picture Push direction 1, Pull direction 2 ASSY CASE AUGER Remove the screws 4ea by using (+) driver. MORTOR Disconnect housing and Disassembly ASSY CASE AUGER MORTOR...
Page 64: Check The Installation Status
4. Check the installation status To do list 4-1. Forced Operation Function (Pull-down / Refrigerator-Freezer-Defrost / Cancellation) • This function enables a pull-down mode, a defrost mode for the refrigerator only, a defrost mode for the freezer and the refrigerator at the same time, and a cancellation of this function. •...
Page 65 4. Check the installation status To do list 4-1. Forced Operation Function (Pull-down / Refrigerator-Freezer-Defrost / Cancellation) 1) Pull-down 1-1) At the ready mode, press any button once then the buzzer will beep (ON for 1/2 second and OFF for 1/2 second) until this mode is cancelled. 1-2) At this pull-down mode, the compressor will start immediately (No 10 minute delay) and if the system is in the defrost cycle, it will be cancelled right away.
Page 66 4. Check the installation status To do list 4-1. Forced Operation Function (Pull-down / Refrigerator-Freezer-Defrost / Cancellation) 3) Cancellation 3-1) At the R,F-Defrost mode, press ant button again on the ready mode to return to a normal operation. 3-2) Simply unplug the power cord, then plug it again to return to a normal operation.
Page 67: Sound Function
4. Check the installation status To do list 4-2. Sound function 1) Sound function 1-1) To confirm that a command is inputted properly, whenever a button is pressed, a “ding-dong” sound is produced. 1-2) When two or more buttons are pressed simultaneously or if a wrong button is pressed, there is no sound.
Page 68: Cooling Off Function(Us Model Only)
4. Check the installation status To do list 4-4. Cooling Off Function(US Model Only) This function is for display purpose on the floor of a show room or a store. 1) Mode ON /OFF 1-1) To select for the Cooling Off mode, press Energy Saver and Freezer buttons simultaneously for 5 seconds until a “ding-dong”...
Page 69: Exhibition Mode Function(Non Us Model Only)
4. Check the installation status To do list 4-5. Exhibition Mode Function(NON US Model Only) This function is for display purpose on the floor of a show room or a store. 1)Mode ON /OFF 1-1) To select for the Exhibition Mode, press Energy Saver, Freezer and Light buttons simultaneously for 5 seconds until a “ding-dong”...
Page 70: Self-Diagnostics Function
4. Check the installation status To do list 4-6. Self-Diagnostics Function 1) Self-Diagnostics during the initial Power ON 1-1) The control board performs a self diagnostics test within 1 second and checks out the temperature sensors abilities. 1-2) If a sensor failure occurs, a corresponding LED segment will blink without a beep. 1-3) When a LED segment blinks, only the cancellation function (Press Lighting and Energy Saver buttons simultaneously for 8 seconds) is acceptable.
Page 71 4. Check the installation status To do list Descriptions of Self-Diagnosis Error Code ERROR Item Description How to do Self-Diagnosis CODE Connector Slipped-Out or Open- FREEZER The voltage should be within the range of 4.5V Contact, Wire Cut or Short- Circuited, ~ 1.0V between MAIN PCB CN30 #3 and #7 SENSOR Abnormal Sensing Temp (+50°C and...
Page 72 4. Check the installation status To do list Descriptions of Self-Diagnosis Error Code ERROR Item Description How to do Self-Diagnosis CODE Separation of sensor housing part, HUMIDITY The voltage should be within the range of 4.5V 13 E contact error, disconnection, short SENSOR ~ 1.0V between MAIN PCB CN30 #7 and #9 circuit...
Page 73 4. Check the installation status To do list Descriptions of Self-Diagnosis Error Code ERROR Item Description How to do Self-Diagnosis CODE ICE MAKER I/M Ice Ejection Horizontal Positioning After replacing Ice-Maker, plug in the unit and 26 E FUNCTION Error ** Only for Dispenser models check its operation.
Page 74 4. Check the installation status To do list Descriptions of Self-Diagnosis Error Code ERROR Item Description How to do Self-Diagnosis CODE COMP STARING 1. it will stop blinking after a while 81 E When the Compressor fails starting FAILURE short(U,V,W) ERROR 2.
Page 75 4. Check the installation status To do list Descriptions of Self-Diagnosis Error Code ERROR Item Description How to do Self-Diagnosis CODE 1. Check input voltage under AC 55V(if input COMP UNDER Power is AC110~127V) or AC 106V(if input 85 E When there is a low voltage error VOLTAGE Power is AC 220~240V)
Page 76: Load Operation Check Function
4. Check the installation status To do list 4-7. Load Operation Check Function 1) In the normal operation, press Lighting and Energy Saver buttons simultaneously for 6 seconds, then the display panel will blink for 2 seconds. 2) Press Fridge Temp. button @ to get into this check mode with an audible tone. 3) Each illuminating LED segment stands for the component which has an ouput signal from the control board.
Page 77: Function For Failure Diagnosis
4. Check the installation status To do list 4-8. Function for failure diagnosis * Load Mode Check List Item Description Display Digital no. FRIDGE FAN HIGH R-FAN HIGH RPM Fridge second digit a FRIDGE FAN LOW R-FAN LOW RPM Fridge second digit b FRIDGE DEFROST R-DEF HEATER ON Fridge second digit c...
Page 78 4. Check the installation status To do list 4-8. Function for failure diagnosis * Load Mode Check List Item Description Display Digital no. FREEZER FAN LOW F-FAN LOW RPM Freezer second digit c FREEZER DEFROST F-DEF HEATER ON Freezer second digit d HEATER CONDENSER FAN C-FAN HIGH RPM...
Page 79: Restoration Function For Power Outage
4. Check the installation status To do list 4-9. Restoration Function for Power Outage 1) When the freezer temperature is lower than 50℉(10℃), all on the display panel will be restored. 2) When the freezer temperature is higher than 50℉(10℃), all functions will be initialized. 0℉(-18℃)(US Only) or - 3℉(-19℃)(Non US) for the freezer, 37℉(3℃) for the refrigerator, and crused for the ice type Energy Saver on corresponding models.
Page 80: Set Point Shift Function
4. Check the installation status To do list 4-10. Set Point Shift Function  Press Freezer Temp. and Lighting buttons simultaneously for 12 seconds to get into this mode.  In this mode, only the display LEDs for temperature will be ON. * Load Mode Check List BUTTON Function...
Page 81 4. Check the installation status To do list 1) Freezer Temp Shifting Table ITEM Freezer Temp Shift VALUE MODEL Same for all models TEMP VALUE FREEZER Location: Fridge Temp Display VALU OPTION -0.5°C (-1°F) -1.0°C (-2°F) -1.5°C (-3°F) -2.0°C (-4°F) -2.5°C (-5°F) -3.0°C (-6°F) +0.5°C (+1°F)
Page 82 4. Check the installation status To do list 1) Fridge Temp Shifting Value Code ITEM Freezer Temp Shift TEMP VALUE MODEL Same for all models FREEZER VALU Location: Fridge Temp Display OPTION -0.5°C (-1°F) -1.0°C (-2°F) -1.5°C (-3°F) -2.0°C (-4°F) -2.5°C (-5°F) -3.0°C (-6°F) +0.5°C (+1°F)
Page 83 4. Check the installation status To do list 3) Ice-Maker Water Supply 4) Ice-Maker Ice Ejection Standby Time Controlling; It controls the water supply quantity with It is an option controlling the Ice Ejection Standby the Flow Sensor. time of the Ice-Maker. ITEM Option Item Display Location...
Page 84 4. Check the installation status To do list 5) Ice-Maker Sensor Temp Shifting 6) Minimum Comp RPM Setting - It is an option shifting the ice ejecting base - This option is for sing minimum Comp RPM. temperature. As this option is applied, Comp RPM will be rise. It will help reducing continual Comp operation.
Page 85 4. Check the installation status To do list 7) Temp Display Option 8) Dispenser/Homebar Heater Option - This option is for temp display all on mode. If user wants temp display always on, this option is solution. CODE TEMP DISPLAY FREEZER DISPLAY OPTION DISPENSER HEATER...
Page 86: Self Diagnosis
5. Self Diagnosis To do list 5-1. When there is no power at Inverter PCB or Main PCB [Caution] Start - To check the Inverter PCB, refer to the There is Over AC 115V/220V and Operation and 'Refer' sections in this DC 310V at the Inverter PCB Power manual Circuit.
Page 87 5. Self Diagnosis To do list 5-1. When Power is not supplied(Inverter PBA) IS DC 5V applied to Replace REG2(5V LDO) C111? IS DC 5V applied to - Check MAIN PCB Wire Replace REG3(5V LDO) C118? - Check DOOR PANEL PCB Does PANEL PCB work 1) Check the wire harness normal?
Page 88: When The Compressor Does Not Operate
5. Self Diagnosis To do list 5-2. When the Compressor does not operate When the inverter PBA LED Start is ON, it indicates that the compressor does operate normally 10 minutes have passed since COMP was off. Check in 10 minutes When Forced Operation Refer to the TEST mode is activated, COMP...
Page 89 5. Self Diagnosis To do list 5-2. When the Compressor does not operate COMP Connector(CN04) is Good 1) Check the COMP Wire 2) Check the Compressor COMP ASS'Y is Good Replace COMP ASS'Y Normal...
Page 90 5. Self Diagnosis To do list...
Page 91: Unable To Defrost
5. Self Diagnosis To do list 5-3. Unable to Defrost Start F/R-DEF Sensor is normal (with Self Diagnosis) Replace the sensor F-DEF-HEATER:Read resistance between F/R-DEF Heater is CN102 #1 and CN70 #7 normal R-DEF-HEATER:Read resistance between Check Thermistor, Heater and CN102 #1 and CN70 #3 their connectors Defrost Sensor Temp is...
Page 92 5. Self Diagnosis To do list 5-3. Unable to Defrost F-DEF-SENSOR:Read resistance between Power is supplied to CN30 #4 and #7 Defrost Heater R-DEF-SENSOR:Read resistance between CN30 #6 and #7 It goes back to Cooling Operation afterheating Check all the sensors Note When F/R-DEF Sensor is higher Normal...
Page 93: Self-Diagnosis Error (Defective Sensor)
5. Self Diagnosis To do list 5-4. Self-Diagnosis Error (Defective Sensor) When there is sensor error, display panel show that. When it occurs during the initial power on time, display panel keeps blinking relevant 7-SEG and the refrigerator go into the emergency operation mode. ①...
Page 94 5. Self Diagnosis To do list 5-4. Self-Diagnosis Error (Defective Sensor) 2) When the humidity sensor is defective Start ☞ Checking the supply voltage(5V)Read the voltage between #1-#2 of humidity sensor. MAIN PBA Connector (CN30) is properly inserted? Repair defective contact point or insert the connector properly The voltage between #1-#2 of...
Page 95: When Alarm Sound Continues (Buzzer Sound)
5. Self Diagnosis 5-5. When Alarm Sound continues (Buzzer Sound) 1) When "DingDong" sound continues Start Door is ajar Door is closed completely? Remove causes after comprehending the condition Closed well of interference by door gasket or food etc Is water penetrated into the door switch? Replace Door switch F-Door sensing : CN50 #8-#9...
Page 96 5. Self Diagnosis 5-5. When Alarm Sound continues (Buzzer Sound) 2) When "Beeping" sound continues Start Forced Operation or Forced Defrost is selected Cancel Forced Operation or Forced Defrost, or Replug the unit After plugging in again, it sounds continuously Panel PBA is normal Replace Panel PBA...
Page 97 5. Self Diagnosis 5-5. When Alarm Sound continues (Buzzer Sound) 3) If a buzzer does not sound This model has a buzzer on the Panel PBA. If the buzzer does not sounds when button is pressed, Forced Operation, door open and disconnection with Main PBA, check out defective soldering on PBA or buzzer damage.
Page 98: When Panel Pba Operates Abnormally
5. Self Diagnosis 5-6. When PANEL PBA operates abnormally 1) When PANEL PBA does not light up or partially does Start Refer to Circuit Diagram in this The connector at the manual and check the circuit Freezer upper hinge cover diagram attached on the back of is inserted properly the unit.
Page 99 5. Self Diagnosis 5-6. When PANEL PBA operates abnormally ➀ Check F/R-Door Wiring - Short or Open Wire ➁ Check F/R-CABI Wiring - Short or Open Wire ➂ Check Short/Open on MAIN PBA or replace it 2) When Panel PBA buttons are not working ※...
Page 100 5. Self Diagnosis 5-6. When PANEL PBA operates abnormally After replacing Panel PBA, it works properly Defective PANEL PBA ➀ Check F/R-Door Wiring - Short or Open Wire ➁ Check F/R-CABI Wiring - Short or Open Wire ➂ Check Short/Open on MAIN PBA or replace it...
Page 101: When Fan Does Not Operate
5. Self Diagnosis 5-7. When Fan does not operate - This model has BLDC FAN motor. BLDC motor is driven by DC7~12V - F-Fan motor usually runs together with the Compressor except the Cool Select Zone function is activated. Once the door is open and closed at high ambient temperature, F-Fan motor put off its operation for one minute.
Page 102 5. Self Diagnosis 5-7. When Fan does not operate Reading with Door closed. -.OPEN 5V, CLOSE 0V Upon the initial power on, Comp Plug in again after 5 minutes and F/R/C-Fan operate for 5 minutes from the power off. regardless of the conditions For C-FAN For R-RAN For F-FAN...
Page 103 5. Self Diagnosis 5-7. When Fan does not operate Note ◆ Possible Causes Pulse signal(FG) generated from the Fan motor rotation is 1. Defective FAN-MOTOR transmitted through CN75 #6(F), #7(R), #8(C) 2. Contact problem at the terminal Micom senses these signal. 3.
Page 104: When The Internal Lamp Of The Freezer/Fridge Does Not Light Up
5. Self Diagnosis 5-8. When the internal lamp of the freezer/fridge does not light up Reference 1. When the DOOR is open, the DOOR S/W becomes OPEN. Micom senses 5V from Door S/W and recognizes that the Door is open. If 5V has sensed for more than 2 minutes, buzzer will sounds “DingDong”...
Page 105 5. Self Diagnosis 5-8. When the internal lamp of the freezer/fridge does not light up Start ※ Reed S/W : Open when door is open Short when door is closed Is the Reed S/W operating normally? Check REED S/W or check whether door and home bar are switching normally Is the output...
Page 106 5. Self Diagnosis 5-8. When Crush (Crushed Ice) & Cube (Cubed Ice) does not operate well Freezer door should be closed during Start operation. Ice comes out when extracting it. Ice is in the Icebucket. Ice Off is selected on the Display Panel ①...
Page 107 5. Self Diagnosis 5-8. When Crush (Crushed Ice) & Cube (Cubed Ice) does not operate well Crushed Ice Selection is Cubed Crushed Ice comes out. Cubed Ice comes out. Normal Operation Normal Operation When Water & Ice S/W is When Water & Ice S/W is pressed, CN50 #6 pressed, CN50 #6 changes to 0V.
Page 108 5. Self Diagnosis 5-8. When Crush (Crushed Ice) & Cube (Cubed Ice) does not operate well When Water & Ice S/W is When Water & Ice S/W is pressed, the voltage across pressed, the voltage across CN102 #1 & CN73 #3 is about CN102 #1 &...
Page 109: If Lce Maker Does Not Operate
5. Self Diagnosis 5-9. If lce Maker does not operate 1. Water is automatically supplied to the Ice Maker by temperature & time. Ice Maker Dispenses cubed or crushed ice. 2. Power is applied to the one end of wires. Be careful when disassembling and should refer to diagram in any case.
Page 110 5. Self Diagnosis 5-9. If lce Maker does not operate 1) Replace the Water Valve Is the water supplied * Refer to the operation condition in 6minutes (After sensing ice of Water Valve bucket fully)? 2) Replace the Main PBA Is the Ice Maker Sensor unit 1) Replace the Ice Maker Sensor normal?
Page 111: If Ice Water Is Not Supplied
5. Self Diagnosis 5-10. If ICE Water is not supplied Start Is the confirming Normal(Check Ice sound of the valve operation heard water valve hose) when Ice maker test switch pushed? Does Main PBA IC73 Check soldering short/Replace PBA #4 have high (5V)output? Check soldering Does Main PBA IC73 #15 have about 0.7V output?
Page 112: If Water Is Not Supplied
5. Self Diagnosis 5-11. If Water is not supplied Start Is the confirming Normal(Check Ice sound of the valve operation heard water valve hose) when dispenser switch pushed? Replace Valve Is the valve unit normal? 1) Check the dispensing lever Is the voltage of 2) Check switch unit/ wiring CN50 #6 changed 0V~5V according...
Page 113 5. Self Diagnosis 5-11. If Water is not supplied Does Main PBA IC73 #13 Check soldering have about 0.7V output when short/Replace PBA switch is on Check soldering Is the contact point of main short/Replace PBA PBA RELAY RY79 normal? MAIN PBA normal -- Need to check the other parts ①...
Page 114: If Ice Route Motor Is Not Working Normally
5. Self Diagnosis 5-12. If Ice Route Motor is not working normally 1. When replacing the Ice Route Motor, pull out the plug to avoid an electric shock. 2. Be careful! When disassemble the Ice Route Motor, spring can jumped out and may cause personal injury.
Page 115 5. Self Diagnosis 5-12. If Ice Route Motor is not working normally Is the DISPENSER Select the DISPENSER switch switch selected? Does the wiring at the both side of motor Check the WIRE connected properly? Is the AC input voltage When the MOTOR rotates.
Page 116 5. Self Diagnosis 5-12. If Ice Route Motor is not working normally Is the sensing Check/Repair the Housing SWITCH connection connector normal? Is the switch Check/Repair the Motor pressed area normal when Rotation pressing area motor rotates? Operating Condition of Dispenser Open/Close CN50 - Switch 1,2 Operating Are the voltage of...
Page 117: Diagnostic Method According To The Trouble Symptom(Flow Chart)
5. Self Diagnosis To do list 5-13. Diagnostic method according to the trouble symptom (Flow Chart) DATA1. Temperature table Resistance value and MICOM port voltage of sensor according to the temperature SENSOR CHIP : based on PX41C Voltage Resistance Voltage Resistance ℃...
Page 118 5. Self Diagnosis To do list 5-13. Diagnostic method according to the trouble symptom (Flow Chart) Voltage Resistance Voltage Resistance ℃ ℉ ℃ ℉ -7.6 3.899 35433 3.107 16419 -5.8 3.858 33788 24.8 3.057 15731 3.816 32230 26.6 3.006 15076 -2.2 3.773 30752...
Page 119 5. Self Diagnosis To do list 5-13. Diagnostic method according to the trouble symptom (Flow Chart) Voltage Resistance Voltage Resistance ℃ ℉ ℃ ℉ 53.6 2.253 8200 84.2 1.520 4369 55.4 2.205 7888 1.483 4218 57.2 2.158 7590 87.8 1.447 4072 2.111 7305...
Page 120 5. Self Diagnosis To do list 5-13. Diagnostic method according to the trouble symptom (Flow Chart) Voltage Resistance Voltage Resistance ℃ ℉ ℃ ℉ 114.8 0.988 2462 150.8 0.598 1335 116.6 0.963 2384 152.6 0.574 1297 118.4 0.938 2309 154.4 0.560 1260 120.2...
Page 121: Led Blinking Frequency Depending On Protecting Functions
5. Self Diagnosis To do list 5-14. LED blinking frequency depending on protecting functions If Failure Condition is detected during compressor is operating, immediately stop Compressor operating and stand by 5 minutes. During this 5 minutes. RPM command signal is not available. it means It means, even if available RPM command signal is applied to the compressor, it does not work and keep standing by.
Page 122: Wiring Diagram
6. Wiring diagram To do list "This document can not be used without Samsung's authorization" Adobe Acrobat Document...
Page 123: Pcb Diagram
7. PCB DIAGRAM To do list "This document can not be used without Samsung's authorization" 7-1. Part Arrangement (Main PBA)
Page 124 7. PCB DIAGRAM To do list "This document can not be used without Samsung's authorization" 7-1. Part Arrangement (Main PBA) 0. SMPS Circuit : Not used. 1. Ice Maker Circuit : Receiving the data of sensor, Hall S/W, Ice Route Micro S/W 2.
Page 125: Connector Layout & Descriptions Of Inverter Controller Board
7. PCB DIAGRAM To do list "This document can not be used without Samsung's authorization" 7-2. Connector Layout & Descriptions of Inverter Controller Board 1. PCB Power Supply : From the SMPS circuit, it supplies 15V and 5V for the Main...
Page 126: Connector Arrangement (Main Board)
7. PCB DIAGRAM To do list "This document can not be used without Samsung's authorization" 7-3. CONNECTOR ARRANGEMENT (Main Board)
Page 127: Reference Information
8. Reference Information To do list "This document can not be used without Samsung's authorization" 8-1. Connector Layout & Description (Inverter comp control Board)
Page 128: Schematic Diagram
10. Reference Information To do list "This document can not be used without Samsung's authorization" 10-1. MODEL CODE TABLE...
Page 129 10. Reference Information 10-2. Q&A Problem Possible Causes What To Do • Check that the power plug is • Disconnected power plug properly connected. • Is the temperature control on the • Try setting it to a lower display panel set to the correct temperature.
Page 130: Reference Information
10. Reference Information 10-2. Q&A Problem Possible Causes What To Do • HOT-PIPE is installed in the front corners of refrigerator. That makes refrigerator’s • Normal state The front corners and sides of the temperature low quickly and save cabinet are hot; condensation the power consumption.
Page 131: Q&A
10. Reference Information 10-2. Q&A Problem Possible Causes What To Do Icemaker turned off or water • Turn on icemaker or water supply. supply turned off. Ice cubes are frozen to the • Remove cubes and move the feeler arm to the ON position. icemaker feeler arm.
Page 132 10. Reference Information 10-2. Q&A Problem Possible Causes What To Do Water supply line turned off or • See Installing the water line. not connected. • Replace filter cartridge or remove Water filter clogged. filter and install plug. Water dispenser does not work(on some models) Air may be trapped in the water •...
Page 133 10. Reference Information 10-2. Q&A Problem Possible Causes What To Do Drain in the bottom of the • See Care and cleaning. freezer clogged. • Check the filter lock Water on kitchen floor or on bottom of freezer • Poke ice through with a wooden Cubes jammed in chute.
Page 134: Block Diagram
9. Schematic Diagram To do list "This document can not be used without Samsung's authorization" 9-1. Block Diagram...
Page 135: Block Diagram (Inverter Pba)
9. Schematic Diagram To do list "This document can not be used without Samsung's authorization" 9-2. BLOCK DIAGRAM (INVERTER PBA)
Page 136 EXPLODED VIEW 1. FREEZER...
Page 137 EXPLODED VIEW 1. FREEZER Material Code Description Spec Qty. Status DA97-08689A ASSY COVER EVAP-FRE SSEDA,BEST/GOOD DA63-05333A COVER EVAP-FRE SSEDA,PP,NTR,COOL WHITE(S DA62-02422A INSULATION-EVAP FRE SSEDA,PS FOAM,WHITE, DA61-05768A PLATE-EVAP HEATER FRE SSEDA,GL-SAZCC,T0. DA97-08690E ASSY COVER MULTI-FRE SSEDA,ASSY,BEST,BET DA32-10109W SENSOR TEMP PX-41C,502AT-2,A-TOP,-,5V,-, DA41-00749C ASSY LAMP LED 8ea,CEM-1,335*20,WHITE,SMA DA96-00424S...
Page 138 EXPLODED VIEW 2. FRIDGE...
Page 139 EXPLODED VIEW 2. FRIDGE Material Code Description Spec Qty. Status DA97-08724N ASSY COVER EVAP-REF RS25H5111,TWING COOL DA61-06185A PLATE-DRAIN INS EVAP REF SSEDA,AL,T0.6 DA96-00880D ASSY MOTOR FAN 12 VCD,1920 RPM,RECYCLED 1-2-1 DA31-00146J MOTOR BLDC 1920,DC12V,230mA,2.8W 1-2-2 DA31-00242A FAN-TURBO SSEDA,ABS,ALL MODEL,HF-0660I,C 1-2-3 DA61-20128A SPRING ETC-FAN STS304,PI8.8,ID7.8,OD9.8,...
Page 140 EXPLODED VIEW 3. CABINET 14-3 35-6 35-6-1 35-4 12-2 35-2-3 35-2-1 12-4 12-5 12-3 35-5 12-1 35-2-6 35-3 35-2-4 35-2-2 35-2-5...
Page 141 EXPLODED VIEW 3. CABINET Material Code Description Spec Qty. Status DA61-05546A BRACKET-HINGE LOW SSEDA,AL,NTR DA64-02631A TRIM-BLADE AW2,RD-PVC,NATURAL DA61-01920A FIXER-CASTER ZPC2,MSWR10,OD8.0,L58 DA61-04702A CASTER-FRONT AW-PJT,PP,BLACK,PP(M/B 0103 DA61-04721D FOOT-FRONT AW-PJT,PP,BLACK,RECYCLED DA32-00034B SENSOR HUMIDITY DA32-00034B, HCPV-200H-1 DA61-05572A HINGE-UPP L SSEDA,SHP1,T3.0,BLACK DA61-10393A HINGE-UP RIGHT RH5000H,PO-SPHC,T3.0,- DA63-08028B COVER LEG-FRONT RH5000H,PP,HB,SNOW WHITE...
Page 142 EXPLODED VIEW 3. CABINET Material Code Description Spec Qty. Status DA62-04309B DRYER Cu,137,SINGLE MOUTH,9g DA63-04598B COVER-URETHANE SSEDA/AW-PJT,N-ABS,D54,NT DA63-40171D GROMMET-SUCT PIPE B RAIL L20,NBR,-,ID5.5 6006-001170 SCREW-TAPPING TH,+,WT,2,M4,L10,ZPC(WHT), DA97-12895A ASSY CHASSIS-COMP AW1-12,T1.4 33-1 DA61-04703A CASTER-REAR AW-PJT,PP,BLACK,PP M/B(0103- 33-2 DA66-00649B SHAFT-CASTER POLARIS,MSWR10,L44,ID8.0,OD DA97-06970A ASSY CAP-DRAIN AW-PJT,-,-,-,-,-,DA97-040 34-1...
Page 143 EXPLODED VIEW 4. DOOR FRE...
Page 144 EXPLODED VIEW 4. DOOR FRE Material Code Description Spec Qty. Status DA91-04353C ASSY DOOR FOAM RH5000H, WW DA63-05327D COVER-CAP DOOR FRE SSEDA,HIPS,HB,S834S1, DA61-05576A STOPPER-DOOR L SSEDA,PO-SPHC,BLACK DA66-00695A CAM HINGE-RISER UPP L SSEDA,NY-66,BLACK( DA61-03769A MAGNET-A HERMES,FERRITE,1600Gauss DA71-20208A FIXER-VALVE WATER B SR-S7180,PA6,-,BLUE DA97-06542C ASSY PIPE-WATER ICE SSEDA...
Page 145 EXPLODED VIEW 5. DOOR REF IN 3-4-1...
Page 146 EXPLODED VIEW 5. DOOR REF IN Material Code Description Spec Qty. Status 6002-000213 SCREW-TAPPING TH,+,1,M4,L12,ZPC(WHT),SWR 6002-001122 SCREW-TAPPING FH,+,NO,1,M4,L14,ZPC(WHT), DA91-04327B ASSY DOOR FOAM-REF RIGHT RH5000H,SNOW WH 6002-001122 SCREW-TAPPING FH,+,NO,1,M4,L14,ZPC(WHT), DA66-01035A CAM-RISER REF MID UPP FOOD SHOWCASE,NY-6 6002-001122 SCREW-TAPPING FH,+,NO,1,M4,L14,ZPC(WHT), DA97-15568A ASSY LEVER HANDLE RH5000H,ASSY,LEVER 3-4-1 6002-000239...
Page 147 EXPLODED VIEW 6. DOOR REF OUT...
Page 148 EXPLODED VIEW 6. DOOR REF OUT Material Code Description Spec Qty. Status DA91-04328E ASSY DOOR FOAM-OUT RH5000H, WW DA64-04021A MASCOT ALL,NI,-,T0.06,L90 DA62-03449M SEAL PLATE DOOR-REF RH5000H,NONWOVEN,-,T DA62-03449L SEAL CUTT NONWOVEN RH5000H,NONWOVEN,T3,L DA61-03769B MAGNET SVETA,MAGNET,T5,W15,L18 DA73-00211A RUBBER-CAP HOSE i4-PJT,SILICON,GRAY DA61-09951A STOPPER DOOR-REF LOW FDSR,PO-SPHC,T3.0,B DA63-07566A GROMMET HINGE-REF LOW...
Page 149 EXPLODED VIEW 1. FREEZER...
Page 150 EXPLODED VIEW 1. FREEZER Material Code Description Spec Qty. Status DA97-08689A ASSY COVER EVAP-FRE SSEDA,BEST/GOOD DA63-05333A COVER EVAP-FRE SSEDA,PP,NTR,COOL WHITE(S DA62-02422A INSULATION-EVAP FRE SSEDA,PS FOAM,WHITE, DA61-05768A PLATE-EVAP HEATER FRE SSEDA,GL-SAZCC,T0. DA97-08690E ASSY COVER MULTI-FRE SSEDA,ASSY,BEST,BET DA32-10109W SENSOR TEMP PX-41C,502AT-2,A-TOP,-,5V,-, DA41-00749C ASSY LAMP LED 8ea,CEM-1,335*20,WHITE,SMA DA96-00424S...
Page 151 EXPLODED VIEW 2. FRIDGE...
Page 152 EXPLODED VIEW 2. FRIDGE Material Code Description Spec Qty. Status DA97-08724N ASSY COVER EVAP-REF RS25H5111,TWING COOL DA61-06185A PLATE-DRAIN INS EVAP REF SSEDA,AL,T0.6 DA96-00880D ASSY MOTOR FAN 12 VCD,1920 RPM,RECYCLED 1-2-1 DA31-00146J MOTOR BLDC 1920,DC12V,230mA,2.8W 1-2-2 DA31-00242A FAN-TURBO SSEDA,ABS,ALL MODEL,HF-0660I,C 1-2-3 DA61-20128A SPRING ETC-FAN STS304,PI8.8,ID7.8,OD9.8,...
Page 153 EXPLODED VIEW 3. CABINET 14-3 35-6-1 35-6 35-4 12-2 35-2-3 35-2-1 12-4 12-5 12-3 35-5 12-1 35-3 35-2-2...
Page 154 EXPLODED VIEW 3. CABINET Material Code Description Spec Qty. Status DA61-05546A BRACKET-HINGE LOW SSEDA,AL,NTR DA64-02631A TRIM-BLADE AW2,RD-PVC,NATURAL DA61-01920A FIXER-CASTER ZPC2,MSWR10,OD8.0,L58 DA61-04702A CASTER-FRONT AW-PJT,PP,NATURAL,32, PP+TP DA61-04721D FOOT-FRONT AW-PJT,PP,BLACK,RECYCLED DA32-00034B SENSOR HUMIDITY DA32-00034B, HCPV-200H-1 DA61-05572A HINGE-UPP L SSEDA,SHP1,T3.0,BLACK DA61-10393A HINGE-UP RIGHT RH5000H,PO-SPHC,T3.0,- DA63-08028B COVER LEG-FRONT RH5000H,PP,HB,SNOW WHITE...
Page 155 EXPLODED VIEW 3. CABINET Material Code Description Spec Qty. Status DA62-04309B DRYER C1220,114,SINGLE MOUTH,9g DA63-04598B COVER-URETHANE SSEDA/AW-PJT,N-ABS,D54,NT DA63-40171D GROMMET-SUCT PIPE B RAIL L20,NBR,-,ID5.5 6006-001170 SCREW-TAPPING TH,+,WT,2,M4,L10,ZPC(WHT), DA97-12895A ASSY CHASSIS-COMP AW1-12,T1.4 33-1 DA61-04703A CASTER-REAR AW-PJT,PP,NTR,35,PP+TPE 33-2 DA66-00649B SHAFT-CASTER POLARIS,MSWR10,L44,ID8.0,OD DA97-06970A ASSY CAP-DRAIN AW-PJT,-,-,-,-,-,DA97-040 34-1 DA63-02761A...
Page 156 EXPLODED VIEW 4. DOOR FRE...
Page 157 EXPLODED VIEW 4. DOOR FRE Material Code Description Spec Qty. Status DA91-04353C ASSY DOOR FOAM RH5000H, WW DA63-05327D COVER-CAP DOOR FRE SSEDA,HIPS,HB,S834S1, DA61-05576A STOPPER-DOOR L SSEDA,PO-SPHC,BLACK DA66-00695A CAM HINGE-RISER UPP L SSEDA,NY-66,BLACK( DA61-03769A MAGNET-A HERMES,FERRITE,1600Gauss DA71-20208A FIXER-VALVE WATER B SR-S7180,PA6,-,BLUE DA97-06542C ASSY PIPE-WATER ICE SSEDA...
Page 158 EXPLODED VIEW 5. DOOR REF IN 3-4-1...
Page 159 EXPLODED VIEW 5. DOOR REF IN Material Code Description Spec Qty. Status 6002-000213 SCREW-TAPPING TH,+,2,M4,L12,ZPC(WHT),SWR 6002-001122 SCREW-TAPPING FH,+,NO,1,M4,L14,ZPC(WHT), DA91-04327B ASSY DOOR FOAM-REF RIGHT RH5000H,SNOW WH 6002-001122 SCREW-TAPPING FH,+,NO,1,M4,L14,ZPC(WHT), DA66-01035A CAM-RISER REF MID UPP FOOD SHOWCASE,NY-6 6002-001122 SCREW-TAPPING FH,+,NO,1,M4,L14,ZPC(WHT), DA97-15568A ASSY LEVER HANDLE RH5000H,ASSY,LEVER 3-4-1 6002-000239...
Page 160 EXPLODED VIEW 6. DOOR REF OUT...
Page 161 EXPLODED VIEW 6. DOOR REF OUT Material Code Description Spec Qty. Status DA91-04328E ASSY DOOR FOAM-OUT RH5000H, WW DA64-04021A MASCOT ALL,NI,-,T0.06,L90 DA62-03449M SEAL PLATE DOOR-REF RH5000H,NONWOVEN,-,T DA62-03449L SEAL CUTT NONWOVEN RH5000H,NONWOVEN,-,T3 DA61-03769B MAGNET SVETA,MAGNET,T5,W15,L18 DA73-00211A RUBBER-CAP HOSE i4-PJT,SILICON,GRAY DA61-09951A STOPPER DOOR-REF LOW FDSR,PO-SPHC,T3.0,B DA63-07566A GROMMET HINGE-REF LOW...
Page 162 EXPLODED VIEW 1. FREEZER...
Page 163 EXPLODED VIEW 1. FREEZER MATERIAL CODE PART NAME SPECIFICATION QTY STATUS DA97-08689A ASSY COVER EVAP-FRE SSEDA,BEST/GOOD DA63-05333A COVER EVAP-FRE SSEDA,PP,COOL WHITE,(SC-0 DA62-02422A INSULATION-EVAP FRE SSEDA,PS FOAM,WHITE, DA61-05768A PLATE-EVAP HEATER FRE SSEDA,GL-SAZCC,T0. DA97-16667A ASSY COVER MULTI-FRE SSEDA,2EVAP DA32-10109W SENSOR TEMP PX-41C,502AT-2,A-TOP,-,5V,-, DA41-00749C ASSY LAMP LED 8ea,CEM-1,335*20,WHITE,SMA...
Page 164 EXPLODED VIEW 2. FRIDGE...
Page 165 EXPLODED VIEW 2. FRIDGE MATERIAL CODE PART NAME SPECIFICATION QTY STATUS DA97-16666A ASSY COVER EVAP-REF SSEDA,2EVAP DA61-06185A PLATE-DRAIN INS EVAP REF SSEDA,AL,T0.6 DA31-00287B MOTOR BLDC FAN ARES2120RA,1870±4%,12V,Ma DA63-08486A COVER EVAP-REF RH25H5611SG,PP,T2.0,HB,CO DA62-04735A INSULATION COVER EVAP-REF B PS FOAM DA62-04736A INSULATION COVER EVAP-REF A PS FOAM DA63-05341A COVER-LED REF LOW SSEDA,PP,HB,NATURAL,BJ...
Page 166 EXPLODED VIEW 3. CABINET 14-3 12-2 12-4 12-5 12-3 12-1 19-1 35-3 35-4...
Page 167 EXPLODED VIEW 3. CABINET MATERIAL CODE PART NAME SPECIFICATION QTY STATUS DA61-05546A BRACKET-HINGE LOW SSEDA,Al,NATURAL DA64-02631A TRIM-BLADE AW2,PVC,NATURAL DA61-01920A FIXER-CASTER ZPC2,MSWR10,OD8.0,L58 DA61-04702A CASTER-FRONT AW-PJT,PP,BLACK,PP(M/B 0103 DA61-04721D FOOT-FRONT AW-PJT,PP,SCREW L28,BLACK,-,- DA32-00034B SENSOR HUMIDITY DA32-00034B,SHT20P,5V,0 DA61-05572A HINGE-UPP L SSEDA,SHP1,T3.0,BLACK DA61-10393A HINGE-UP RIGHT RH5000H,PO-SPHC,T3.0,- DA63-08028B COVER LEG-FRONT...
Page 168 EXPLODED VIEW 3. CABINET MATERIAL CODE PART NAME SPECIFICATION QTY STATUS DA27-00019M COIL FILTER SEM-SSEDA,20mH,40m,33±1,82*6 DA39-20389E ASSY WIRE HARNESS-EARTH ALL,FREE VOLT,UL DA60-00280A FITTING-LOKRING 33 SUM23,33 DA60-00281A FITTING-LOKRING 43 GRAND/SAM/HERMES,11SM DA60-10123E BOLT-HEX M6,L19,ZPC(WHT),SWRCH18A,HH Hea 4 DA62-04309B DRYER Cu,137,SINGLE MOUTH,9g DA63-04598B COVER-URETHANE SSEDA/AW-PJT,ABS,NTR,VH-0 DA63-40171D GROMMET-SUCT PIPE B...
Page 169 EXPLODED VIEW 4. DOOR FRE...
Page 170 EXPLODED VIEW 4. DOOR FRE MATERIAL CODE PART NAME SPECIFICATION QTY STATUS DA91-04353C ASSY DOOR FOAM RH5000H, WW DA63-05327D COVER-CAP DOOR FRE SSEDA,HIPS,HB,S834S1, DA61-05576A STOPPER-DOOR L SSEDA,PO-SPHC,BLACK DA66-00695A CAM HINGE-RISER UPP L SSEDA,NY-66,BLACK( DA61-03769A MAGNET-A HERMES,FERRITE,1600Gauss DA71-20208A FIXER-VALVE WATER B SR-S7180,PA6,-,BLUE DA97-06542C ASSY PIPE-WATER ICE...
Page 171 EXPLODED VIEW 5. DOOR REF IN...
Page 172 EXPLODED VIEW 5. DOOR REF IN MATERIAL CODE PART NAME SPECIFICATION QTY STATUS DA91-04327B ASSY DOOR FOAM-REF RIGHT RH5000H,SNOW WH DA63-08235A COVER LOCK FDSR,ABS,INOX GRAY,HG-0760GP DA66-01035A CAM-RISER REF MID UPP FOOD SHOWCASE,PA66 DA97-15449A ASSY GASKET-REF SSEDA-FSR,GRAY DA97-15415A ASSY GUARD-REF UP RH5000H DA97-15415B ASSY GUARD-REF UP...
Page 173 EXPLODED VIEW 6. DOOR REF OUT...
Page 174: Da91-04328E Assy Door Foam-Out
EXPLODED VIEW 6. DOOR REF OUT MATERIAL CODE PART NAME SPECIFICATION QTY STATUS DA91-04328E ASSY DOOR FOAM-OUT RH5000H, WW DA64-04021A MASCOT ALL,NI,-,T0.06,L90 DA61-03769B MAGNET SVETA,MAGNET,T5,W15,L18 DA73-00211A RUBBER-CAP HOSE i4-PJT,SILICON,GRAY DA61-09951A STOPPER DOOR-REF LOW FDSR,PO-SPHC,BLACK, DA63-07566A GROMMET HINGE-REF LOW FOOD SHOWCASE,PA66 DA97-15450A ASSY GASKET SSEDA-FSR,GRAY...
Page 175 EXPLODED VIEW 1. FREEZER...
Page 176 EXPLODED VIEW 1. FREEZER MATERIAL CODE PART NAME SPECIFICATION QTY STATUS DA97-08689A ASSY COVER EVAP-FRE SSEDA,BEST/GOOD DA63-05333A COVER EVAP-FRE SSEDA,PP,COOL WHITE,(SC-0 DA62-02422A INSULATION-EVAP FRE SSEDA,PS FOAM,WHITE, DA61-05768A PLATE-EVAP HEATER FRE SSEDA,GL-SAZCC,T0. DA97-16667A ASSY COVER MULTI-FRE SSEDA,2EVAP DA32-10109W SENSOR TEMP PX-41C,502AT-2,A-TOP,-,5V,-, DA41-00749C ASSY LAMP LED 8ea,CEM-1,335*20,WHITE,SMA...
Page 177 EXPLODED VIEW 2. FRIDGE...
Page 178 EXPLODED VIEW 2. FRIDGE MATERIAL CODE PART NAME SPECIFICATION QTY STATUS DA97-16666A ASSY COVER EVAP-REF SSEDA,2EVAP DA61-06185A PLATE-DRAIN INS EVAP REF SSEDA,AL,T0.6 DA31-00287B MOTOR BLDC FAN ARES2120RA,1870±4%,12V,Ma DA63-08486A COVER EVAP-REF RH25H5611SG,PP,T2,HB,COOL DA62-04735A INSULATION COVER EVAP-REF B PS FOAM DA62-04736A INSULATION COVER EVAP-REF A PS FOAM DA63-05341A COVER-LED REF LOW SSEDA,PP,HB,NATURAL,BJ...
Page 179 EXPLODED VIEW 3. CABINET 12-1 12-3 12-1 19-1 35-3...
Page 180 EXPLODED VIEW 3. CABINET MATERIAL CODE PART NAME SPECIFICATION QTY STATUS DA61-05546A BRACKET-HINGE LOW SSEDA,Al,NATURAL DA61-10385A HINGE-UP RH5000H,PO-SPHC,T4,ELETRODEPOSI DA61-01920A FIXER-CASTER ZPC2,SWRCH10A,OD8.0,L58 DA61-04702A CASTER-FRONT AW-PJT,PP,BLACK,PP(M/B 0103 DA61-04721D FOOT-FRONT AW-PJT,PP,SCREW L28,BLACK,-,- DA32-00034B SENSOR HUMIDITY DA32-00034B,SHT20P,5V,0 DA61-05572B HINGE-UP LEFT SSEDA,PO-SPHC,T3 DA61-10393A HINGE-UP RIGHT RH5000H,PO-SPHC,T3 DA63-08028B COVER LEG-FRONT...
Page 181 EXPLODED VIEW 3. CABINET MATERIAL CODE PART NAME SPECIFICATION QTY STATUS DA61-04932A FIXER HINGE-UPP AW1-12,GI-SGCC,T3 DA62-04309B DRYER Cu,L137,SINGLE MOUTH,For Capi,OD15 DA63-04598B COVER-URETHANE SSEDA/AW-PJT,ABS,-,-,-,-, DA63-40171D GROMMET-SUCT PIPE B RAIL L20,NBR,-,ID5.5 DA60-00279A FITTING-LOKRING 16 SUM23,16, 11SMnPb30K DA97-06969B ASSY CHASSIS COMP SBS, FSR, AW1-12,1.2 33-1 DA61-04703A CASTER-REAR...
Page 182 EXPLODED VIEW 4. DOOR FRE...
Page 183: Sseda-Fsr,Gray
EXPLODED VIEW 4. DOOR FRE MATERIAL CODE PART NAME SPECIFICATION QTY STATUS DA91-04353C ASSY DOOR FOAM RH5000H, WW DA63-05327D COVER-CAP DOOR FRE SSEDA,HIPS,HB,NATURAL DA61-05576A STOPPER-DOOR L SSEDA,PO-SPHC,T3.0,-,-,-, DA66-00695A CAM HINGE-RISER UPP L SSEDA,NY-66,BLACK( DA61-03769A MAGNET-A HERMES,FERRITE,1600Gauss DA71-20208A FIXER-VALVE WATER B SR-S7180,PA6,-,BLUE DA97-06542C ASSY PIPE-WATER ICE...
Page 184 EXPLODED VIEW 5. DOOR REF IN 5-1-2 5-2-1 5-2-2 5-1-1...
Page 185: Rh5000H,Assy
EXPLODED VIEW 5. DOOR REF IN MATERIAL CODE PART NAME SPECIFICATION QTY STATUS DA91-04327B ASSY DOOR FOAM-REF RIGHT RH5000H,SNOW WH DA63-08235A COVER LOCK FDSR,ABS,INOX GRAY,HG-0760GP DA66-01035A CAM-RISER REF MID UPP FOOD SHOWCASE,PA66 DA66-01134A LEVER FDSR,POM,SO301,CREAMY STAINLESS,14 1 DA97-15449A ASSY GASKET-REF SSEDA-FSR,GRAY DA97-15415A ASSY GUARD-REF UP...
Page 186 EXPLODED VIEW 6. DOOR REF OUT...
Page 187 EXPLODED VIEW 6. DOOR REF OUT MATERIAL CODE PART NAME SPECIFICATION QTY STATUS DA91-04328E ASSY DOOR FOAM-OUT RH5000H, WW DA64-04021A MASCOT ALL,Ni,T0.06,L90 DA61-03769B MAGNET SVETA,FERRITE,1600Gauss DA73-00211A RUBBER-CAP HOSE i4-PJT,SILICON,GRAY DA61-09951A STOPPER DOOR-REF LOW FDSR,PO-SPHC,T4.0,B DA63-07566A GROMMET HINGE-REF LOW FOOD SHOWCASE,PA66 DA97-15450A ASSY GASKET SSEDA-FSR,GRAY...

This manual is also suitable for:

Rh25h5611sr Rh25h5613sl Rh25h5611sr/aa Rh25h5613sl/ap Rh25h5613sl/ey Rh25h5613sl/bz ... Show all

Samsung RH25H561 Series Manual

English

Exploded View

Quick Links

Chapters

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Samsung RH25H561 Series

Summary of Contents for Samsung RH25H561 Series

This manual is also suitable for:

Table of Contents
