Samsung I.C.E. PAD RH269LBSH Owner's Manual And Installation

Samsung refrigerator owner's manual and installation
Hide thumbs Also See for I.C.E. PAD RH269LBSH:
Table of Contents

Advertisement

Quick Links

Write the model and serial number here:
Model #
Serial #
THESE NUMBERS CAN BE FOUND INSIDE THE
REFRIGERATOR'S CABINET ON THE LEFT HAND SIDE.
OWNER'S MANUAL AND INSTALLATION
Register your product at www.samsung.com/global/register
CONTENTS
...............................................................2
........................................................4
SETTING UP THE REFRIGERATOR.........................................................4
MAJOR FEATURES .....................................................................................4
CONTROL PANEL........................................................................................5
DIGITAL PANEL...........................................................................................6
TEMPERATURE CONTROL .......................................................................7
ICE and COLD WATER DISPENSER .........................................................7
SHELVES and BINS.....................................................................................8
FOOD STORAGE GUIDE ...........................................................................9
CoolSelect Zone
Drawer GUIDE.............................................................11
REMOVING THE FREEZER ACCESSORIES..........................................13
REMOVING THE REFRIGERATOR ACCESSORIES..............................13
CARE AND CLEANING .............................................................................14
CHANGING THE INTERIOR LIGHT .........................................................15
WATER FILTER ..........................................................................................16
DOORS.......................................................................................................16
INSTALLATION OF THE REFRIGERATOR .............................................17
REMOVING THE REFRIGERATOR DOORS ...........................................18
REATTACHING THE REFRIGERATOR DOORS......................................21
LEVELING THE REFRIGERATOR............................................................24
CHECKING THE WATER DISPENSER LINE...........................................26
INSTALLATION OF THE WATER DISPENSER LINE...............................27
GENERAL INFORMATION ........................................................................32
VIEWS OF I.C.E. PAD AND TRANSMITTER............................................34
I.C.E. PAD POWER MANAGEMENT.........................................................37
HOW TO USE VIRTUAL KEYBOARD.......................................................39
USER INTERFACE ....................................................................................41
TROUBLESHOOTING ...............................................................................58
....................................................................59
WARRANTY ...............................................................................................59
In the U.S. for questions about features,
operation/performance, parts, accesories or service, call:
1-800-726-7864 (1-800-SAMSUNG)
www.samsung.com
I.C.E. PAD
(Interactive Control Entertainment)
REFRIGERATOR
RH269LBSH
................................................17
..............................31
.......................57
DA99-01278D REV(0.0)

Advertisement

Table of Contents
loading

Related Manuals for Samsung I.C.E. PAD RH269LBSH

Summary of Contents for Samsung I.C.E. PAD RH269LBSH

  • Page 1: Table Of Contents

    I.C.E. PAD POWER MANAGEMENT...37 HOW TO USE VIRTUAL KEYBOARD...39 USER INTERFACE ...41 INSTALLATION INSTRUCTIONS(I.C.E. PAD) HOW TO INSERT THE ICEPAD IN THE DOCKING STATION OF THE REFRIGERATOR ...57 TROUBLESHOOTING ...58 CONSUMER SUPPORT WARRANTY ...59 In the U.S. for questions about features,...

  • Page 2: Safety Warning Signs

    I.C.E. PAD. - Otherwise, it may cause malfunction and the risk of fire. Do not heat the I.C.E. PAD and do not place it inside in the refrigerator. - It may cause damage such as explosion fire or electric shock.
  • Page 3 Samsung warranty service Safety Caution section • Samsung does not recommend 3rd party modification, there- fore Samsung is not responsible for safety issues that result from 3rd party modifications. • Any changes or modifications in construction of this device...

  • Page 4: Operating Instructions

    SETTING UP THE REFRIGERATOR Once you have performed the following steps, your refrigerator should be fully operational. If not, check the power supply and electricity source. If you have any questions, contact your SAMSUNG service center. Place the refrigerator in an appropriate location with reasonable clearance between the wall and the refrigerator.

  • Page 5: Control Panel

    Cooling off stops cooling in both the freezer and refrig- erator compartments but does not shut off electrical power to the refrigerator. To use this feature, press the freeze and power freeze buttons simultaneously for 3 seconds until a "beep" sounds. To cancel this mode, press the same buttons again for 3 seconds.

  • Page 6: Digital Panel

    Power Cool • This light goes on when you press the Power Cool button. Press this button to quickly return the refrigerator to its set temperature. • Press this button again to cancel the Power Cool mode. Cubed Ice, Crushed Ice and Ice Off Filter Indicator •...

  • Page 7: Temperature Control

    WARNING blinking when the freezer and refrigerator return to normal temperature. If the temperature control does not reset the temp, unplug the refrigerator, wait 9 min, then plug it back in. ICE and COLD WATER DISPENSER Press the Ice Type button to select the type of ice: •...

  • Page 8: Shelves And Bins

    Ice Maker Light Ice Chute Glass Shelf Wire Shelf Light Switch Tilt Pockets Plastic Drawers Wire Drawers Front Leg Cover Refrigerator Water Filter Compartment Light (upper) Spill-proof glass Shelf Light Switch Foldable Shelf Deodorizer Egg Container CoolSelect Zone Drawer Vegetable & Fruit Drawers...

  • Page 9: Food Storage Guide

    FOOD STORAGE GUIDE FROZEN FOOD STORAGE IN FREEZER Ice chute Do not put your fingers, hands or any other unsuitable objects in the chute or ice-maker bucket, as this may result in personal injury or material damage. WARNING Door Bin •...
  • Page 10 Can be used to store foods in packages, such as milk and yogurt. • If you have a long vacation planned, empty the refrigerator and turn it off. Wipe excess moisture from the inside and leave the doors open. Otherwise, odor and mold may develop.

  • Page 11: Tm Drawer Guide

    CoolSelect Zone “Quick Cool” Button • You can use the Quick Cool feature with the CoolSelect Zone • “Quick Cool” allows 1~3 canned beverages to cool within 60 min. • To cancel this option, press the “Quick Cool” button again. CoolSelect Zone returns to the previous temperature.
  • Page 12 Cool • When “Cool” is selected, the temperature will be the same as the set temperature of the refrigerator. The digi- tal panel shows the same temperature as that of the Control panel. • When using “Cool”, the CoolSelect Zone extra refrigerator space.

  • Page 13: Removing The Freezer Accessories

    It is attached to the cabinet wall. To remove the wine shelf, lift it up in the direction of the arrow as shown. • Simply take the shelf out of the tabs. • Before removing the freezer and refrigerator accessories, please remove the stored foods. NOTE Ice Maker Bucket •...

  • Page 14: Care And Cleaning

    Rubber door seals • If the rubber door seals are dirty, the door will not close properly, The refrigerator will not be able to function efficiently. Clean the doors with a mild detergent and damp cloth. Then wipe with a dry cloth.

  • Page 15: Changing The Interior Light

    NOTE Keep children away from contaminated water. CHANGING THE INTERIOR LIGHT Before changing the interior light, unplug the refrigerator from the power supply. If you have difficulty changing the light, contact your service center. WARNING INTERIOR LIGHT IN THE REFRIGERATOR.

  • Page 16: Water Filter

    Ordering replacement filters • To order more water filter cartridges, call 1-800-SAMSUNG and ask for accessory Part # DA29- 00003B or contact your authorized Samsung dealer. DOORS The refrigerator doors have a special door opening and closing feature to make sure that they close all the way and are securely sealed.

  • Page 17: Installation Instructions

    • See “Separating the water supply line from the refrigerator” on the next page. Allow sufficient space to circulate the air in the internal cooling system. • When the refrigerator does not have enough space, the internal cooling system may not work correctly. inches 0.1inch...

  • Page 18: Removing The Refrigerator Doors

    REMOVING THE REFRIGERATOR DOORS Removing the Front Leg Cover Open the freezer and refrigerator doors, and then take off the front leg cover by turning the three screws counter-clockwise. Separating the Water Supply Line from the Refrigerator 1) Remove the screw from clamp ( ).

  • Page 19: Removing The Freezer Door

    • Be careful not to pinch the water tubing and wire harness on the door. NOTE • Place doors on a protected surface. • Unplug the refrigerator from the power supply. Removing the Freezer Door 1) With the door closed, remove the upper hinge cover (➀) using a screwdriver, and then disconnect the wires (➁).

  • Page 20: Removing The Refrigerator Door

    REMOVING THE REFRIGERATOR DOORS Removing the Refrigerator Door 1) With the door closed, remove the upper hinge cover (➀) using a screwdriver, and then disconnect the wires(➁). 2) Remove all hinge screws ( ③ ) and ground screw ( ④ ) counter-clockwise, and take off the upper hinge (⑤) in the direction of the arrow ( ⑥...

  • Page 21: Reattaching The Refrigerator Doors

    REATTACHING THE REFRIGERATOR DOORS Reattaching the Freezer Door 1) Insert the lower hinge ( ➀ ) in the bracket (➁). 3) Insert the upper hinge shaft (➄) into the hole on the top of the door (➅). After levelling between the upper hinge hole (➆) and the hole of the cabinet (➇).

  • Page 22: Reattaching The Refrigerator Door

    (➆) and cabinet hole (➇). reattach hinge screws (➈) and ground screw (➉) in the clockwise direction. 4) Connect the wires. 2) Align the hole in the refrigerator door (➂) over the lower hinge and push down (➃). 5) Put the front part of the upper hinge cover ( ) on...

  • Page 23: Reattaching The Water Supply Line

    REATTACHING THE REFRIGERATOR DOORS Reattaching the Water Supply Line 1) While pressing the front face of coupler (➁), insert the water line (➀) in the coupler. 2) Tighten the screw on the clamp ( ). 1) Push the "A" collar to the "B" body and hold.

  • Page 24: Leveling The Refrigerator

    LEVELING THE REFRIGERATOR Make sure the refrigerator is level before adjusting its doors. The doors will be uneven if the refrigerator is not level. The front of refrigerator is adjustable. NOTE Case 1) Freezer door is lower than that of the refrigerator...

  • Page 25: Adjusting The Clearance Between The Doors

    NOTE Making small adjustments between doors. If the door of the freezer is lower than that of the refrigerator. Adjustment part Please open the doors and adjust them as follows: 1) Release the nut (①) on the lower hinge until it reaches the upper end of the bolt (➁).

  • Page 26: Checking The Water Dispenser Line

    4) Ensure the water storage tank inside the refrigerator is properly filled initially. Push the water dis- penser lever until the water runs from the outlet. A Water line installation kit is available at extra cost from your dealer. Samsung recommends using a water supply kit containing copper tubing.

  • Page 27: Installation Of The Water Dispenser Line

    Install the water filter. 1) The water filter is located in the upper right hand corner of the refrigerator. Remove the fixed cap (A) as shown. The fixed cap separates from the Water Filter Compartment by rotating it coun- terclockwise.

  • Page 28: Check Amount Of Water

    3) Additional flushing may be required in some households. 4) Open the refrigerator door and check if water leaks around the water filter. • A newly-installed water filter cartridge may cause water to briefly spurt from the dispenser.

  • Page 29: Troubleshooting

    TROUBLESHOOTING The refrigerator does not work at all or it does not chill sufficiently • Check that the power plug is properly connected. • Is the temperature control on the display panel set to the correct temperature? Try setting it to a lower tem- perature.
  • Page 30 MEMO...

  • Page 31: Operating Instructions(I.c.e. Pad)

    I.C.E. PAD Owner ’ ’ s Manual...

  • Page 32: General Information

    GENERAL INFORMATION I.C.E. PAD Major Features. Function Processor Memory Display AC adapter output AC power adapter input Battery Interface Network Size Operation Environment Graphic User Interface (GUI) is an easy access interface for I.C.E. PAD users. Touch Screen allows access to all I.C.E. PAD functions. Wireless Communication (IEEE 802.11a) enables your family to watch high-quality analog This I.C.E.
  • Page 33 GENERAL INFORMATION I.C.E. PAD And Transmitter. I.C.E. PAD : This is a device that works with the Transmitter to Food Family Management Message Scheduler Radio Memo I.C.E. PAD Transmitter : This device transmits audio and video signals to Transmitter Accessories(supplied) Stylus pen AC adapter(2EA) FM Radio Antenna...

  • Page 34: Views Of I.c.e. Pad And Transmitter

    VIEW OF I.C.E. PAD/TRANSMITTER View of I.C.E. PAD. Front view Food Family Management Message Scheduler Radio Memo ⑪ ⑪ Memo button : - Select to bring up the Memo. ⑫ ⑫ TV button : - Select to bring up the TV. The power, battery status and family message lamps can be seen most easily from the front.
  • Page 35 ① ① A/S port : - Service port (for service only). Do not open the cover. ① ① Docking Connection Port : - To charge the I.C.E. PAD, mount the connection port of I.C.E. PAD in the door of the refrigerator(docking station).

  • Page 36: Front View

    VIEW OF I.C.E. PAD/TRANSMITTER View of Transmitter. Front view ① ① Status lamp : This displays the transmission status of the wireless signal. ② ② Power lamp : This displays the Transmitter power status. [Front view ] Rear view TV_ANT IN TV_ANT OUT AUDIO EXTERNAL INPUT 1...

  • Page 37: I.c.e. Pad Power Management

    I.C.E. PAD POWER MANAGEMENT How to turn on the I.C.E. PAD. Food Family Management Message Scheduler Radio Memo How to turn off the I.C.E. PAD. How to turn the Transmitter power on and off. TV_ANT IN TV_ANT OUT AUDIO EXTERNAL INPUT 1 In order to use the TV and radio functions of the I.C.E.

  • Page 38: Battery Management

    Save your data and recharge a battery with the AC adapter or the docking station of the refrigerator. NOTE - The battery is an expendable resource. If you repeatedly recharge and discharge it, the lifetime of the battery will be shortened.

  • Page 39: How To Use Virtual Keyboard

    HOW TO USE VIRTUAL KEYBOARD How to use the virtual keyboard. You can use the on-screen keyboard to type in text on the screen. How to bring up the on-screen keyboard. - Food Management function : Choose the "memo" button( NOTE - Schedule function: The on-screen keyboard bring up automatically.
  • Page 40 HOW TO USE VIRTUAL KEYBOARD In order to continue special characters mode, choose " NOTE 2. Handwriting mode This enables you to handwrite text using the stylus pen. Activates the basic Keyboard Recognizes English Characters Activates the Spanish keyboard Screen keyboard with " "...

  • Page 41: User Interface

    ▶ Task Bar : Indicates the present function, time, date( message( ) and today( ▶ Food Management : You can manage the food you have stored in the refrigerator. ▶ Schedule : You can manage your daily schedule. ▶ Memo : You can save or check necessary memos.
  • Page 42 USER INTERFACE Food Management This feature helps you to keep track of food in the fridge and its expiration date. [Main screen] [Select category mode] How to enter a new food item 1. Choose the "Food Management" icon on the main screen or press the I.C.E. PAD's "Food Management"...
  • Page 43 USER INTERFACE How to change food item. 1. [Saved food display mode] Choose the window containing the food item you previously entered. This window is directly above the calendar window. 2. [Edit mode] Change the contents using the screen keyboard and calendar.
  • Page 44 USER INTERFACE [Daily mode ] 3. [Daily mode] Choose the "New" button( 4. [Input mode ① ① ] Type the content of your memo using the screen keyboard. If you choose the "Recent" button( NOTE 5. [Input mode ② ② ] Press the "Set Time" button( - Choose AM or PM.
  • Page 45 USER INTERFACE How to change your schedule. 1. [Daily mode] Choose the desired schedule to change. 2. [Edit mode] Change the information using the screen keyboard. - To save changes, press the "Save" button( - To cancel the changes, press the "Cancel" button( [Edit mode] How to delete your schedule.
  • Page 46 USER INTERFACE Special Day(Birthday, Party, Wedding and Anniversary) [Main screen] How to enter new special day. 1. Choose the "Schedule" icon on the main screen or press the "Schedule" button on the I.C.E. PAD. 2. [Monthly mode] Choose the "Special day" button( special day mode".
  • Page 47 USER INTERFACE How to change special day. 1. [Saved special day mode] Choose the desired special day to change. 2. [Edit mode] Change the information using the screen keyboard. [Edit mode] How to delete your special day. 1. [Saved special day mode] Choose the desired special day to delete. 2.
  • Page 48 USER INTERFACE 4. [Input memo] Press the "Screen", "Brush" and "Color" button, and then pop up window is displayed. Choose the desired background, pen thickness and pen color. - Eraser( ) : Select to erase the inputted memo in pen mode. - Pen( ) : Select to input a memo in pen mode.
  • Page 49 USER INTERFACE Family Message. This mode enables you to leave a voice or text message for your family members or roomates. [Main screen] How to leave a new voice message. 1. Choose the "Family Message" icon on the main screen or press the "Family Message" button on the I.C.E. PAD. - Default screen will display recent saved family messages.
  • Page 50 USER INTERFACE How to leave new text message. 1. [Saved family message mode] Choose the "Write" button ( 2. [Input mode ① ① ] Choose the person that you want to receive the text message. Enter the text message using the stylus pen or screen keyboard. There are two methods to input your text message.
  • Page 51 USER INTERFACE Setting. Screen - This menu displays the I.C.E. PAD user screen properties including brightness, touch point settings and power saving time settings. [Main screen] How to control screen brightness 1. Choose the "Settings" icon on the main screen, and then it will change to Screen. 2.
  • Page 52 USER INTERFACE Sound - This menu enables you to set the I.C.E. PAD's sound properties including key volume, alarm volume and alarm sound settings. [Setting-Screen mode] How to set the key volume. 1. Choose the "Sound" tab ( ) to bring up the sound mode. 2.
  • Page 53 USER INTERFACE Today. This menu displays food management, schedule and special day. [Main screen] How to use today. 1. Choose the "Today" button ( ) in the upper right corner of the screen to bring up the Today mode. 2. You can check the food management, schedule and special day settings for today. - Check yesterday’s or tomorrow’s content using the direction "...
  • Page 54 USER INTERFACE How to connect the AM Antenna. The AM antenna can be : - Placed on a stable surface. - Fixed to the wall/base/floor, etc. (you must first remove/clean the base) To assemble the AM loop antenna. To connect the AM loop antenna cords. - Connect black cord to the black terminal, and the white cord to the white terminal.
  • Page 55 USER INTERFACE How to watch TV. 1. Press the "TV" button on the I.C.E. PAD, and then the default TV mode will be shown. 2. In the default TV mode, a small TV screen and TV control section will be dis- played.
  • Page 56 USER INTERFACE - To watch TV, you have to turn on the Transmitter and connect the TV antenna cable(sup- plied) to the ANT_IN port of the Transmitter and the other end to an Antenna/Cable TV. NOTE - If the TV cable is connected through external equipment (such as a set-top box), you can- not change channels.

  • Page 57: Installation Instructions(I.c.e. Pad)

    HOW TO INSERT THE I.C.E. PAD IN THE DOCKING STATION OF THE REFRIGERATOR When you put I.C.E. PAD in the docking station of the refrigerator, make sure the I.C.E. PAD screen faces front. Do not drop the I.C.E. PAD. It may cause malfunction and personal injury.

  • Page 58: Troubleshooting

    "Battery is low. Please connect external power supply." • Save your data and recharge the battery with the AC adapter or the docking station of the refrigerator. When the following message is displayed. "Memory is full. you cannot record any more."...

  • Page 59: Consumer Support

    SAMSUNG or SAMSUNG's authorized service center. SAMSUNG will repair or replace any part found to be defective, at our option and at no charge as stipulated herein, with new or reconditioned parts during the limited warranty period specified above. All replaced parts and products become the property of SAMSUNG and must be returned to SAMSUNG.
  • Page 60 If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care centre. Samsung Electronics America, Inc. 105 Challenger Road Ridgefield Park, NJ 07660-0511 1-800-SAMSUNG(1-800-726-7864) www.samsung.com...
