- Page 1 RH25H5611** Refrigerator user manual imagine the possibilities Thank you for purchasing this Samsung product. Free Standing Appliance DA68-02981J-00.indb 1 14. 11. 25. 10:26...
-
Page 2: Safety Information
Contents SAFETY INFORMATION ……………………………………………………………… 2 SETTING UP YOUR SIDE-BY-SIDE REFRIGERATOR …………………………… 9 OPERATING THE SAMSUNG SIDE-BY-SIDE REFRIGERATOR………………… 20 TROUBLESHOOTING ………………………………………………………………… 31 Safety information SAFETY INFORMATION CAUTION Before using your new Samsung Side-By-Side Hazards or unsafe practices that may result in Refrigerator, please read this manual thoroughly to minor personal injury or property damage. - Page 3 • Do not install this appliance in a humid, oily, WARNING or dusty location , or in a location exposed to direct sunlight or water (rain, etc.). CRITICAL INSTALLATION • Do not install this appliance in a location where WARNINGS gas may leak.
- Page 4 receptacle box is fully grounded. WARNING • Plug the power plug into the wall socket firmly. Do not use a damaged power plug, damaged CRITICAL USAGE WARNINGS power cord, or loose wall socket. - This may result in an electric shock or fire. •...
- Page 5 • Do not damage the refrigerant circuit. • If you experience difficulty changing a non-LED • Do not spray volatile material such as light, contact a Samsung service center. insecticide onto the surface of the appliance. • If the product is equipped with LED Lamps, do...
- Page 6 3rd party on this - There is a risk of electric shock or fire. finished appliance are not covered under Samsung warranty service, nor is Samsung responsible for safety issues that result from 3rd party modifications. • Do not block the air vents inside the refrigerator.
- Page 7 CAUTION WARNING CLEANING CAUTIONS CRITICAL DISPOSAL WARNINGS • DANGER : Risk of child entrapment. • Do not spray water directly on the inside or outside the refrigerator. Before you throw away your old - There is a risk of fire or electric shock. refrigerator or freezer: •...
- Page 8 ADDITIONAL TIPS FOR Saving Energy Tips PROPER USAGE - Install the appliance in a cool, dry room with adequate ventilation. • In the event of a power failure, call the local Ensure that it is not exposed to direct sunlight office of your Electricity Company and ask how and never put it near a direct source of heat (a long it is going to last.
-
Page 9: Setting Up Your Side-By-Side Refrigerator
Setting up your side-by-side refrigerator GETTING READY TO INSTALL THE REFRIGERATOR Congratulations on the purchase of your Samsung Side-By-Side Refrigerator. We hope you will enjoy the many state-of-the-art features and efficiencies that this new appliance has to offer. Selecting the best location for the... - Page 10 When moving your refrigerator Important: Make sure that you can easily move your refrigerator to its final location by measuring To prevent floor damage, be sure the front leveling doorways (both width and height), thresholds, legs are in the up position (above the floor). ceilings, stairways, etc.
- Page 11 How to install the handles ( 4 ) ( 5 ) Using a Philips head screwdriver, attach fixer screws to the screw holes on each door. If your refrigerator already has the fixer screws installed, skip this step. REMOVING THE REFRIGERATOR DOORS If your entrance won’t allow the refrigerator to pass through it easily, you can remove the refrigerator...
- Page 12 2. Separate the water supply line from 1. With the Freezer door closed, remove the upper hinge cover ( 1 ) using a screwdriver, the refrigerator and then disconnect the wires by gently pulling 1. Remove one or two water lines, depending on them apart ( 2 ).
- Page 13 4. Remove the lower hinge ( 8 ) from the lower 3. Disassemble the three fastening screws on the hinge bracket ( 9 ) by lifting the lower hinge up top hinge of the show case. in the direction of the arrow. 4. Disassemble the show case. Lift the door straight up.
- Page 14 Re-attaching the Water Supply Lines CAUTION 1. The Water Lines must be fully Inserted into the Do not remove the sensor assembly in the right center of the transparent coupler to prevent upper hinge cover. water leakage from the dispenser. 2.
- Page 15 HOW TO ADJUST THE DOOR HEIGHT If one refrigerator door is lower than the other: • The door height levels can be adjusted using the adjustment nut located at the bottom of refrigerator door. • Raising the door too high can cause the door to interfere with the hinge cover when it is opened If the Freezer part is lower than the Fridge or closed.
- Page 16 1. Open the door that needs to be adjusted and WHEN THE FREEZER DOOR IS loosen the clamping nut ( A ) at the bottom of LOWER THAN FRIDGE DOOR the door by turning it clockwise ( ) using the spanner included in the product package. A level refrigerator is necessary for getting the (Raise the lower of the two doors first.) doors perfectly even.
- Page 17 2. Adjust the height difference between the doors MAKING MINOR ADJUSTMENTS by turning the bolt ( 2 ) clockwise ( ) or BETWEEN THE SHOW CASE AND counter clockwise ( ). INNER CASE OF THE FRIDGE After raising the out door, insert the supplied SHIM HINGE MIDDLE in the gap between the Show (3) Wrench case of fridge and the HINGE-SHAFT.
- Page 18 Samsung Refrigerator. You may find these items sold as a kit at your local To help promote better health, the Samsung water hardware store. filter removes unwanted particles from your water. However, it does not sterilize or destroy microorganisms.
- Page 19 2. Tighten the compression nut ( B ) onto the COMPLETING THE SET UP compression fitting. Now that you have your new refrigerator installed Do not over-tighten the compression nut ( B ). in place, you are ready to set up and enjoy the 3.
-
Page 20: Operating The Samsung Side-By-Side Refrigerator
Operating the SAMSUNG side- by-side refrigerator CONTROL PANEL FUNCTIONS ( 3 ) Lighting (Control Lock (3 sec)) Press the Lighting button to turn on the dispenser LED lamp. If you press and hold the Lighting button for 3 seconds, all buttons will be locked and the dispenser pad will not work. - Page 21 CONTROL PANEL FUNCTIONS Remember to turn Power Freeze off when you do not need it and return the freezer to your original temperature setting. Freezer/Fridge (Temperature adjustment) Press the Freezer or Fridge button repeatedly until Energy Saver the desired temperature is set. Each time you press the Freezer or Fridge button, This icon lights when you activate the Energy the temperature indicator will change in the order...
- Page 22 Display Off Power Cool To conserve energy, the Panel Display turns off This icon lights when you activate the Power Cool automatically under the following conditions: When function. no button has been pressed, when no doors have The Power Cool function is great for cooling the been opened, or when no Dispenser Lever has fridge down quickly.
- Page 23 USING THE ICE AND COLD Using the ice dispenser WATER DISPENSER Press the Ice button to select the type of ice you want. Place your cup under the ice outlet and push gently against the dispenser pad. Make sure the glass is in line with the dispenser to prevent the ice from bouncing out.
- Page 24 CAUTION - If you are going on a long vacation or business trip and won't be using the water or ice dispensers for that period of time, close the water valve to prevent leaks. - If you have not used the Ice maker for a while, or you have opened the Freezer door frequently, the Ice may stick together.
- Page 25 STORING FOOD The Samsung Side-By-Side Refrigerator has been designed to provide you with maximum space saving features and functions. Here are some of the customized compartments we have created to keep your food fresher, longer. Important : To prevent odors from penetrating the ice in the ice maker, store all food securely in wraps or containers that are as airtight as possible.
- Page 26 Storing food in the freezer WARNING ( 1 ) Ice Maker Bucket • If you plan to go away for a significant time, Designed to store lots of ice easily. empty the refrigerator and turn it off. Wipe the excess moisture from the inside of the appliance and leave the doors open.
- Page 27 REMOVING THE FREEZER/ 4. Ice Bucket (Freezer) • Remove the Icemaker Bucket by lifting up and FRIDGE ACCESSORIES pulling it out slowly. 1. Door Bin/Dairy Bin - Grip the handle as shown in the figure. • Firmly grab the door bin with both hands and lift it up gently to remove.
- Page 28 CLEANING THE REFRIGERATOR WARNING Caring for your Samsung Side-By-Side Refrigerator Do not use benzene, thinner, or Clorox™ to clean prolongs its life and helps keep it odor and germ- the refrigerator. free. These chemicals can damage the surface of the refrigerator and can create a risk of fire.
- Page 29 REPLACING THE WATER FILTER 5. Press and hold the Water button for 3 seconds after changing the filter to reset the filter Replace the water filter when the water indicator. filter indicator turns red. Confirm the indicator turns blue. The water filter is located on the bottom When you replace the water filter, some water right side of the refrigerator.
- Page 30 USING THE ICE MAKER CAUTION • To Remove the Ice Bucket. • When Ice Off blinks on the display panel, - Hold the handle as shown in figure1. reinsert the bucket and/or make sure it’s - Lift up, and then pull the bucket out slowly. installed properly.
-
Page 31: Troubleshooting
Troubleshooting PROBLEM SOLUTION The refrigerator • Check that the power plug is properly connected. does not work at • Is the temperature control on the display panel set to the correct all or it does not temperature? chill sufficiently. Try setting it to a lower temperature. •... - Page 32 PROBLEM SOLUTION You can hear water • This is normal. bubbling in the The bubbling comes from the refrigerant coolant liquid circulating through refrigerator. the refrigerator. There is a bad • Has a food item spoiled? smell in the • Make sure that strong smelling food (for example, fish) is wrapped so that refrigerator.
- Page 33 Samsung or Samsung authorized service center. Samsung will repair or replace any part found to be defective, at our option and at no charge as stipulated herein, with new or reconditioned parts during the limited warranty period specified above. All replaced parts and products become the property of Samsung and must be returned to Samsung.
- Page 34 If your refrigerator needs service Do not hesitate to call any Samsung Authorized Service Center nearby giving them your name, address and telephone number when your product is not functioning properly. Warranty Information (CANADA) Limited Warranty for Original Purchaser This Samsung product is warranted by Samsung Electronics Canada Inc. (hereafter referred to as SECA) against...
