Installation
Please check all parts and accessories before installation and setup according to the following.
Site Requirements
Ambient Temperature Range: 10°C to 40°C (50°F to 104°F)
Relative Humidity Range: 10% to 80% (non-condensing)
Operating Altitude: Sea Level to 8000 feet (2438 meters)
Never place the unit in a location where excessive heat, moisture, or corrosive materials are present.
Please put the equipment on a firm, strong bench. Avoid the resonance from the bench. This will decrease the
risk of vibrations and noise.
Dimensions and Weights
Unit
EV400H
EV400
EV400Touch
EV400VAC
HB-03 Thermal Bath
Electrical Requirements
The unit provides extra protection against the risk of electrical shock by grounding appropriate metal parts. The
extra protection may not function unless the power cord is connected to a properly grounded socket. It is the
user's responsibility to assure a proper ground connection is provided. The unit is supplied with a European power
cable. It is used to relate to power supply. Plug the cord into socket and plug the rear into electric socket of the
unit. Then the unit is ready to be used.
The following power options are available:
UNIT
EV400H
EV400
EV400Touch
EV400VAC
HB-03 Thermal
Bath
High (cm)
Width (cm)
64
64
66
66
-
Voltage (V)
Frequency (Hz)
230
50/60
115
60
230
50/60
115
60
230
50/60
115
60
230
50/60
115
60
230
50/60
115
60
www.labtechsrl.com
Length (cm)
44
55
44
55
47
58
47
58
-
-
Fuse
IP Degree
10
21
10
21
10
21
10
21
10
21
10
21
10
21
10
21
10
21
10
21
EV400 SERIES – User Manual
Diameter (cm)
Weight (Kg)
-
-
-
-
33
Power Consumption (W)
100
100
100
100
150
150
150
150
1300
1300
17
25
25
25
4
Page 14 of 39
