How to use the manual?
The game controller is compatible with PC, PlayStation®2 and PlayStation®.
For PC users, please refer to the section A of "Installation for PC system".
For PlayStation®2 and PlayStation®, please refer to the section B of "Installation for
PlayStation®2 and PlayStation®".
A. Installation for PC system
1. Make sure you turn your computer on.
2. Insert the driver's disc into the CD-ROM drive,
and the setup program will start automatically. If
not, start the setup program manually by selecting
Start/Run and type in "E:\setup" (Where "E:"
represents the location of the CD-ROM drive),
then press the Enter key.
(If you are using Windows 98, just follow the
instructions
on
the
screen
installation)
3. Please follow the instructions on the screen to finish the driver installation. (Some
operating systems will install the DirectX program automatically first, so just follow the
instructions on the screen to finish the program installation.)
4. After the software installation is completed, you can plug the USB connector of the cable
to the USB port on your computer or to a USB Hub.
Note: Please power on your USB Hub after connecting this device, because it needs at
least 500mA to operate vibration motors.
5. Click Start / Settings / Control Panel and double click on the "Game controller" or
"Gaming Options" icon.
6. Attach the racing wheelbase to a sturdy tabletop, or a similar surface. Then use the suction
cups on the wheelbase and the C-clamps to secure the wheel to the tabletop.
7. Place the pedals on the floor in a convenient-to-reach location and not on an easy-to-slip
surface.
8. Plug the pedal's connector (RJ-11) to the steering wheel.
9. In the "Game controller" or "Gaming Options" screen, you can calibrate and test your
game controller before you play any game.
10. When you finish the calibration and test, you can now play any game.
Important:
1. The driver will work with the DirectX 7.0a or a newer version in PC system. Please check
the DirectX version on your system, and upgrade if necessary.
to
finish
the
1
ENGLISH

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TWINWHEEL and is the answer not in the manual?

Questions and answers

Summary of Contents for Genius TWINWHEEL

  • Page 1 10. When you finish the calibration and test, you can now play any game. Important: 1. The driver will work with the DirectX 7.0a or a newer version in PC system. Please check the DirectX version on your system, and upgrade if necessary.
  • Page 2 2. Digital Mode: When the controller is in digital mode, all function buttons are operated digitally. 3. Vibration function : The vibration function can be set to ON or OFF on the software option screen when the software supports. 4. You can switch to the appropriate mode for use. But some software makes this adjustment automatically.
  • Page 3 Then push down one of the two pedals (should push it down over 10 degrees), at the same time, press one of the Analog buttons that you wish to set up. (╳, ○, □,△, L1, L2, L3, R1, R2, R3). Then press the Program button again to complete the set up. Use the same steps to set up the other pedal.
