- Page 1 PhysioGo 200A / 201A – User Manual...
-
Page 3: Table Of Contents
1. Basic information Contents INTRODUCTION ............................... 5 ................................5 ANUFACTURER INTENDED USE ................................. 6 DEVICE INSTALLATION AND START-UP ........................7 ................................7 NIT INSTALLATION 3.1.1 Mounting of accessory holders ........................7 3.1.2 Connection of accessories – general notices ....................7 3.1.3 Connection of ultrasound heads ........................ - Page 4 1. Basic information Table of figures Figure 3.1. Ultrasound head sockets ........................7 Figure 3.2. Combination therapy socket TS ......................8 Figure 3.3. Screen view – date and time edition ..................... 9 Figure 4.1. Field description ..........................15 Figure 4.2. Location of the channel tab ........................ 16 Figure 4.3.
-
Page 5: Introduction
These differences may concern size and type of fonts and size of symbols. There are no differences in the content of shown information. Warning: No modification of this equipment is allowed! 1.1 Manufacturer ASTAR Sp. z o.o. ul. Świt 33 43-382 Bielsko-Biała, Poland page 5 of 26... -
Page 6: Intended Use
2. Intended use 2. Intended use Multifunctional unit PhysioGo 200A / 201A is an active, non-invasive therapeutic device, intended for carrying our treatment procedures using ultrasound therapy and phonophoresis. Model 200A Non battery unit Model 201A Battery unit The unit is equipped with one therapeutic channel dedicated for ultrasound therapy treatments. -
Page 7: Device Installation And Start-Up
3. Device installation and start-up 3. Device installation and start-up 3.1 Unit installation The first installation should be performed by a qualified manufacturer’s or distributor’s representative! After removing the unit from the carton, check if the complete unit has been delivered. In case of any inconsistencies contact the distributor or manufacturer. -
Page 8: Connection In Combined Therapy
The unit is equipped with a socket for electrostimulator connection in order to perform the combination therapy treatment. Socket is marked with a symbol TS. It is recommended to work with Astar’s electrotherapy devices due to their full compatibility. Figure 3.2. Combination therapy socket TS Actuating element of ultrasound therapy is the ultrasound head, it is also an active electrode in the case of electrotherapy, while the passive electrode is the electrode properly attached to the patient’s body and suited... -
Page 9: Setup Mode
3. Device installation and start-up 3.2 Setup mode 3.2.1 Basic information Keyboard components designed for the unit operation are called ”keys”. The area on the screen, where after its pressing a specific unit reaction is followed, is called ”button”. The area on the screen that has the possibility to select or deselect any item, is called ”selection field”. To enter Setup mode, press To leave Setup mode, press To go back one level, press... -
Page 10: Volume
3. Device installation and start-up 3.2.3.3 Volume The user may adjust sound volume level. To perform this action: • press the volume bar at desired place, or • use buttons on the screen, or • use keys 3.2.3.4 Display The user may adjust display brightness level. To perform this action: •... -
Page 11: Head Sensitivity
3. Device installation and start-up 3.2.4.4 US head sensitivity For advanced users only! It is possible to modify sensitivity of ultrasound heads in terms of no contact detection. According to treatment specifics, the sensitivity can be improved or reduced beyond default settings. To change it you need to: Step Description... -
Page 12: Service
3. Device installation and start-up 3.2.5 Service 3.2.5.1 US head calibration This function allows the user to change the ultrasound head parameters in case of frequent contact quality problems caused by the frequency changes of ultrasound transducers characteristics. In order to exercise the option, follow the instructions shown on the display. Detailed description of the function is described in the PhysioGo –... -
Page 13: Unit Operation
4. Unit operation 4. Unit operation The unit may operate in one of two modes: program mode, • manual mode. • Notes – unit operation: • In the program mode you can use preset procedures of treatment programs and user-defined programs. •... -
Page 14: Combined Therapy
4. Unit operation It is necessary to localize the tissue affected by the disease, determine its type, depth, which determines • the choice of frequency of ultrasounds (up to 6 cm frequency 1 MHz, up to 1 cm frequency 3,5 MHz), surrounding tissues, tissues repair phase (acute conditions –... -
Page 15: Screen Configuration
4. Unit operation The power density of 0.5 to 1.0 W/cm is employed in the paraspinal area, it is recommended in case of active trigger points and painful conditions of medium intensity and in slim patients. The power density of 1.0 to 1.5 W/cm is recommended in painful conditions of low intensity, on limbs, in the area of hips and buttocks in stout patients. -
Page 16: General Configuration
4. Unit operation Symbol Display Description Date and time Quality level battery charging symbols Percentage of charging level Battery Status tab Eco battery mode – charging up to 80% Mains cable connected Therapy selection menu Program mode Manual mode Main menu User-defined treatment programs edition mode Information mode Setup mode... -
Page 17: Display Description
4. Unit operation The table below explains the meaning of the symbols presented in the tab: Symbol Treatment channel Description Selected ultrasound therapy Ongoing treatment Treatment interrupted Ready to start amplitude adjustment or pause. Channel error (yellow symbol) 4.4 Display description Display Description Ultrasound circuit... -
Page 18: Operation With Preset Treatment Programs
4. Unit operation 4.5 Operation with preset treatment programs The simplest method of unit’s operation is to use its preset programs. The unit includes a database containing several dozens of most frequently met disorders together with suggested treatment types and parameters. In this mode, the operation is reduced to selection of disease entity from the list. - Page 19 4. Unit operation keys or a bar located on the right side of the display to scroll the information. If it is necessary to interrupt the treatment procedure (pause), press STOP key. To resume the treatment procedure, it is recommended to follow the instructions shown on the display. Schematic procedures for ultrasound therapy are presented below.
-
Page 20: Favorite Programs
4. Unit operation 4.6 Favorite programs The function offers quick access to frequently used preset programs without browsing the entire list. To add or remove the program from the favorite list, follow the instructions: Step Description Prepare the unit to work with preset treatment programs (see section 4.5). Select the program remove Press the symbol... -
Page 21: Manual Mode Operation
4.8 Combined therapy treatment PhysioGo 200A/201A device can cooperate with devices manufactured by Astar with electrotherapy function. This allows to perform a combined therapy, where the generator of current is the unit with this function, while Sonaris controls the operation of the ultrasound head. -
Page 22: User Programs
4. Unit operation 4.9 User programs The User has the possibility to save in to the device memory own sets of treatment parameters in the form of programs. Saving of user program: Step Description Prepare the unit to work in manual mode (steps 1 – 4 see section 4.7). Set the program parameters. - Page 23 4. Unit operation User program parameter view: Step Description Prepare the unit to work in the program mode (see section 4.5). Select the option User programs from Program modes menu. Confirm by the key or once again press the selected field. Select the program which parameters will be checked.
-
Page 24: Indications And Contraindications
5. Indications and contraindications 5. Indications and contraindications 5.1 Indications 5.1.1 Ultrasound therapy biological impact: increase in cell membranes permeability • • improvement of tissue respiration and stimulation of cellular metabolism • changes in tissue colloid structure and their hydration changes in tissue ion systems •... -
Page 25: Contraindications For Combined Therapy
5. Indications and contraindications 5.4 Contraindications for combined therapy As for the ultrasound therapy and electrotherapy. page 25 of 26 issue date 02.09.2019, release 10.0... -
Page 26: Accessories
5. Indications and contraindications 6. Accessories 6.1 Standard accessories Name Quantity PhysioGo 200A / 201A controller A-UC-AST-PHG200A A-UC-AST-PHG201A Mains cable Ultrasound therapy gel 500 g Spare fuses – time lag T1L250, 1 A, 250 V Touch screen pen LCD touch screen cloth...
