- Page 1 PhysioGo 600C / 601C – User Manual...
-
Page 3: Table Of Contents
1. Basic information Contents INTRODUCTION ............................... 5 ................................5 ANUFACTURER INTENDED USE ................................. 6 DEVICE INSTALLATION AND START-UP ........................7 ................................7 NIT INSTALLATION 3.1.1 Mounting of accessory holders ........................7 3.1.2 Connection of accessories – General notices ....................7 3.1.3 Connection of laser applicator ......................... - Page 4 1. Basic information ACCESSORIES ................................. 29 ..............................29 TANDARD ACCESSORIES ..............................29 PTIONAL ACCESSORIES Table of figures Figure 3.1. Laser therapy sockets ............................... 8 Figure 3.2. Handwheels – scanner and arm of the stand ......................8 Figure 3.3. Wheel with brake ..............................8 Figure 3.4.
-
Page 5: Introduction
Read this Guide carefully before starting the unit operation! Follow the recommendations presented in this Guide! PhysioGo 600C / 601C unit should be installed by the seller. The recipient has the right to insist on the product operation training. The unit may only be operated by qualified personnel or under supervision of such personnel! WARNING: The device is intended for adult patients only. -
Page 6: Intended Use
2. Intended use 2. Intended use Multifunctional unit PhysioGo 600C / 601C is an active, non-invasive therapeutic device, intended for carrying our treatment procedures using: laser radiation within the visible (for wave length 660 nm) and invisible range (for wave length 808 nm), •... -
Page 7: Device Installation And Start-Up
3. Device installation and start-up 3. Device installation and start-up 3.1 Unit installation The first installation should be performed by a qualified manufacturer’s or distributor’s representative! After removing the unit from the carton, check if the complete unit has been delivered. In case of any inconsistencies contact the distributor or manufacturer. - Page 8 3. Device installation and start-up Figure 3.1. Laser therapy sockets Operating notes for operation with the scanning laser applicator mounted on a stand: • The stand with a unit and applicators shall be placed near mains socket with power input 230V and 50/60Hz, so that the change of stand position is not limited by the mains cable.
-
Page 9: Connection Of Ultrasound Head
3. Device installation and start-up Connection between scanning applicator and controller should be done with cable run inside the stand. It must be connected to the socket on the rear casing panel of the scanner applicator and laser therapy socket located on the unit. -
Page 10: Laser Therapy Access Code
3. Device installation and start-up In the case of battery operation, please hold on for at least 3 seconds the STANDBY key . Extension of the holding time prevents unintentional activation during transport. If after switching on mains supply the display is illegible and no light indicator is illuminated, check whether mains fuse or mains cable operate correctly. -
Page 11: Global Settings
3. Device installation and start-up 3.2.3 Global settings 3.2.3.1 Date and time In this section there is a possibility to adjust date and time. To change these settings, press the button Edit. Using arrows, set the required value. Confirm settings using Set button or leave the edition mode by pressing Cancel. Figure 3.6. -
Page 12: Program Groups / Medical Fields
3. Device installation and start-up 3.2.4.2 Program groups / medical fields This function allows the user to set filters of available program mode options according to the preferred program groups or medical fields. In order to set the appropriate option, select or clear the selection field by its pressing. For program groups, the following options are available: •... -
Page 13: Head Bad Contact Signaling
3. Device installation and start-up Main features of sensitivity settings are listed below. Sensitivity settings Advantages Disadvantages Default Default manufacturer settings High • forced use of precise treatment technique, • improved sensitivity on i.e. for training purposes load’s changes • protection of the ultrasound head against •... -
Page 14: Statistics
3. Device installation and start-up Laser output power test for a given applicator is only possible if it is not previously selected in a laser therapy channel tab. The applicator selection is performed by: pressing on the screen the selected field with its symbol, or •... -
Page 15: Transport Position - The Stand With Scanning Applicator
3. Device installation and start-up 3.3 Transport position – the stand with scanning applicator Step Description Proceed with the treatment to the end or stop it by pressing the key Put the equipment back. Click the UNIT ON / OFF (STANDBY) button on the front panel A message will appear on the display: Press to shut down the system correctly. -
Page 16: Unit Operation
4. Unit operation 4. Unit operation The unit may operates in one of two modes: program mode, • manual mode. • Notes – unit operation: • In the program mode you can use preset procedures of treatment programs, as well as user-defined programs. -
Page 17: Laser Therapy
4. Unit operation surrounding tissues, tissues repair phase (acute conditions – only mechanical operation of ultrasounds, in chronic conditions mainly thermal effect), chose the method of application (direct, indirect), determine proper exit position: without pain, relaxation position, treated tissues should be moved as close to the surface of skin as possible. -
Page 18: Screen Configuration
4. Unit operation 4.2 Screen configuration Figure 4.1. Field description Symbol Display Description Date and time Quality level battery charging symbols Percentage of charging level Battery Status tab Eco battery mode – charging up to 80% Mains cable connected Therapy selection menu Program mode Manual mode Main menu... -
Page 19: General Configuration
4. Unit operation 4.3 General configuration 4.3.1 Treatment channel configuration Channel Therapy Laser therapy Ultrasound therapy Therapy availability depends on the type of connected accessories (applicators, ultrasound heads) and their condition (undamaged). Accessories are specified in PhysioGo – Technical description manual. 4.3.2 Channel selection tabs The screen displays two channel selection tabs. -
Page 20: Display Description
4. Unit operation The table below explains the meaning of the symbols presented in tabs: Symbol Treatment channel Description Selected laser therapy – laser point probes Selected laser therapy – scanning laser applicator Selected laser therapy – cluster laser applicator Selected ultrasound therapy Ongoing treatment Treatment interrupted... -
Page 21: Laser Therapy
4. Unit operation 4.4.1 Laser therapy Figure 4.3. Screenshot sample view for laser therapy Symbol Description Applicator identification / Program name Output power Presentation of the treatment elapsing time Information field Tab field – channel 1 4.4.2 Ultrasound therapy Figure 4.4. Screenshot sample view for ultrasound therapy Symbol Description Area and frequency / Program name... -
Page 22: Operation With Preset Treatment Programs
4. Unit operation 4.5 Operation with preset treatment programs The simplest method of unit’s operation is to use its preset programs. The unit includes a database containing several dozens of most frequently met disorders together with suggested treatment types and parameters. In this mode, the operation is reduced to selection of disease entity from the list. - Page 23 4. Unit operation If it is necessary to interrupt the treatment procedure (pause), press STOP key. To resume the treatment procedure it is recommended to follow the instructions shown on the display. Schematic procedures for different therapies are presented below. In continuous operation, it is recommended to start the treatment procedure from step 3 of each of the schemes.
-
Page 24: Voll And Nogier Programs
4. Unit operation 4.5.1 Voll and Nogier programs A specific group of preset treatment programs are positions dedicated to biostimulation laser point acupuncture according to Voll and Nogier, the so-called Voll and Nogier frequencies. These programs are only available for low lever laser point applicators. -
Page 25: Manual Mode Operation
4. Unit operation 4.7 Manual mode operation Symbol definition and parameter range are specified in the PhysioGo – Technical description manual. Step Description Switch on the unit. Choose the treatment channel 1 or 2. Select the therapy according to the point 4.3. For laser therapy enter the code PHGL, confirm and select the applicator. - Page 26 4. Unit operation Step Description Select the item number under which the program will be saved. Confirm your choice with the key Enter or edit the program name. Press the key or button Removal of user program: Step Description Prepare the unit to work in the program mode (see section 4.5). Select the option User programs from Program modes menu.
-
Page 27: Indications And Contraindications
5. Indications and contraindications 5. Indications and contraindications 5.1 Indications 5.1.1 Ultrasound therapy biological impact: • increase in cell membranes permeability improvement of tissue respiration and stimulation of cellular metabolism • • changes in tissue colloid structure and their hydration •... -
Page 28: Contraindications For Ultrasound Therapy
5. Indications and contraindications 5.3 Contraindications for ultrasound therapy tumor and status after tumor resection • • gestation (abdomen and lower part of the spine area) • tuberculosis • haemorrhagic condition • circulatory failure and arrhythmia severe general status of system and cachexy •... - Page 29 6. Accessories 6. Accessories 6.1 Standard accessories Name Quantity A-UC-AST-PHG600C PhysioGo 600C / 601C controller A-UC-AST-PHG601C Mains cable DOOR blocking plug A-AL-AST-ZLDOOR Ultrasound therapy gel 500 g Spare fuses – time lag T1L250, 1 A, 250 V Touch screen pen...
- Page 30 6. Accessories Other Name Phillips screwdriver PHG 600C / 601C User Manual Page 30 of 30...
