INSTALLATION
3
Fully Fasten Steel Arms (A)
Pre-Drill the remaining two holes and
fully fasten the Steel Arms using the
M5x50mm Screws.
4
Install Next Section
Use a phillips screwdriver to check that
the screws are fully tight and don't allow
the steel arms to rotate unnecessarily.
5
Install Remaining Sections
Use a tape measure to reference the distance from the floor (or ceiling) to the top of the
Wood Upright that is already mounted to the wall. You will then use this distance to ensure
the adjacent section is horizontal. Marking a horizontal line over the stud at this distance
will help to align the top edge of the Wood Upright of the unmounted section. Mount the
remaining section using the same techniques found in earlier steps.
