StoreYourBoard Omni Quick Start Manual

•
(2) 46" Vertical Tracks & Hardware
•
(8) 29" Horizontal Arms & Quick-Release Pins
•
(4) Wall Mount Brackets
•
(4) Wall Mount Lag Screw & Washer
(C)
(A)
3. Determine the desired mounting height of wall rack. Note: The vertical bar is 46" long and the wall mount
brackets should be located ~4" from each end of the bar.
4. Plumb (align vertically) the first upper wall bracket (C) at desired height on wall and mark location of mounting
screw hole. Ensure wall bracket is in correct orientation, as shown in pictures. Drill pilot hole where marked,
using a drill bit narrower than the screws' threads of the provided wall screw.
5. Securely mount upper wall bracket using wall screw and washer provided.
6. Place the vertical track (A) in the wall bracket just installed so that the 4
lined up with the wall bracket holes. Install a quick-release pin (D) thru the bracket holes to temporarily hold the
track in place.

Includes:

Installation Instructions

(B)
1. Determine the length of items to be stored and the necessary spacing
between supports. Recommend consulting the equipment manual for
each item, or if not available, use 40% of the items length as a starting
point for determining support spacing. Example; 10' kayak x 0.4 = 4'
2. Use a stud finder to locate wall studs for the installation of wall
brackets (C). Do not recommend mounting solely in drywall. Use studs
closest to the desired spacing from step 1.
Example; 4' = 3 stud spacing @ 16" o.c.
- INSTRUCTIONS CONTINUED ON REVERSE SIDE -
•
100 lbs per item stored
Up to
•
50 lbs
Up to
•
400 lbs
Up to

Part Identification:

(A) Vertical Track
(B) Horizontal Arm
(C) Wall Mount Bracket
(D) Quick-Release Pin
Prior to installing, please visit the product details page at
www.storeyourboard.com to view installation videos.

Weight Limits:

per hor. arm
(evenly distributed)
rack total (evenly distributed)

Recommended Tools:

Drill/Driver
Nut drivers w/ extension
Drill bits
Level & Pencil
Tape Measure
Adjustable wrench
Stud Finder
th
hole from the top of the vertical track is
Updated: 5-2-2019
