- Page 1 INSTALLATION GUIDE O U T D O O R S WI V E L K AYAK Questions or Concerns? Contact us at: info@storeyourboard.com...
- Page 2 It is the consumer’s responsibility to install this system in accordance with all codes, ordinances, Manufactured for Spire LLC by Tellbe in Vietnam and local regulations. When installing the Outdoor Swivel Kayak Rack, it is the consumer’s responsibility to ensure the Quantity: 1 structural integrity of the structure it is being mounted to.
- Page 3 INSTALLATION Using a stud finder, locate the stud and mark its location. Hold Frame (B) up to stud location so that the top hole is approximately 32-72” above the floor and mark the hole locations on Frame (B) with a pencil. Use a level to ensure the holes are straight up and down. Height above floor will depend on how high you want to store the kayak.
- Page 4 CARE INSTRUCTIONS Using a 12mm socket, tighten the lag screws (D) against Washer (E) and Frame (B). Periodically check lag screw tightness. Install Arms (A) onto Frames (B) and secure via detent. Storage: With the Arms (A) completely unweighted, pull the Quickpin (C), and swivel the arms 90 degrees to either side.
