User Guide for Lyric self-replacement procedure
These instructions do not replace, but complement the Lyric4 User Guide (reference 029-0836-03).

Advertisement

loading
Need help?

Need help?

Do you have a question about the Lyric 4 and is the answer not in the manual?

Questions and answers

Summary of Contents for Phonak Lyric 4

  • Page 1 Phonak Lyric User Guide for Lyric self-replacement procedure These instructions do not replace, but complement the Lyric4 User Guide (reference 029-0836-03).
  • Page 2 Contents Your hearing aid This user guide is valid for the following hearing aid model: 1. Self-replacement Further information Non wireless model CE mark applied Lyric4 2020 2. Information and explanation of symbols 3. Important safety information...
  • Page 3 Secondly, knowing that Your hearing aids have been developed by Phonak – the you have replacement devices, gives you the world leader in hearing solutions based in Zurich, reassurance that you will benefit more from your Switzerland.
  • Page 4 Take them back to your hearing care professional for your next appointment. If you have experienced any issues with these removed devices, your hearing care professional can have a detailed look at them or send them back to Phonak for analysis.
  • Page 5 1.3 Self-removal instructions 4. Make sure that you remove the device from your ear The following chapter provides instructions on how to before inserting a new one. use your Lyric. Please read it carefully. 5. Optionally, to let your ear canal(s) breathe, proceed Using the SoundLync with self-replacement of the new device(s) a few hours after having removed the old one(s), unless...
  • Page 6 Removing Lyric Step 1: Wash hands and prepare a clean work place, Step 3: Unscrew the cap on the magnet to expose e.g. using a clean paper cloth. the removal tool. Firmly hold the removal tool as you would hold a pencil, with your hand braced against Step 2: If Lyric is still working, turn it OFF using the your cheek.
  • Page 7 Step 4: Use a gentle circular motion to engage the removal loop. You should feel a slight resistance when you tug on it. Gently remove the hearing aid using a gradual circular motion. Note: Lyric can be removed using a blunt-nosed tweezer if the removal tool is not available.
  • Page 8 1.4 Preparation of the new Lyric Step 5: When the hearing aid is out of the ear, place it Step 1: Check that the package of the new Lyric into its container, and mark the date of removal. If you that you receive from your hearing care professional remove Lyric from both ears, please mark the side is neither opened nor damaged.
  • Page 9 Step 3: To switch Lyric ON, place the black portion Step 4: Check to ensure the new Lyric device is of the SoundLync tool close to the Lyric device for 2-3 turned on: The device should whistle in your seconds until it beeps once. Then, immediately remove closed hands.
  • Page 10 1.5 Insertion Orient the device as follows: Step 1: Hold Lyric lightly between thumb and forefinger, - The blue removal loop should face towards your using the right hand for the right ear and the left hand hand. Once Lyric has been inserted in your ears, the for the left ear.
  • Page 11 Step 2: Tilt the head to the opposite side you are Step 3: Optionally, check that the Lyric is correctly holding Lyric. positioned at the entrance of the ear canal using a mirror or asking a third person. If you intend to insert Lyric in your right ear, tilt the head to the left.
  • Page 12 Step 4: Place Lyric at the entrance of the ear canal. Step 5: Press Lyric with your thumb, until it is secure Ensure your neck and shoulders are relaxed. During in the opening of your ear canal. insertion do not move your wrist joint but only your elbow and shoulder.
  • Page 13 Step 6: Hold pinky/little finger and thumb at a 90° angle. Step 7: Use pinky/little finger to slowly advance Lyric to the final insertion.
  • Page 14 With the CE symbol, Sonova AG confirms sound familiar. that this Phonak product – including If you need to, push the Lyric with your pinky/little accessories – meets the requirements finger slightly further until it feels that it is inserted of the Medical Devices Directive 93/42/ to the correct depth and is comfortable.
  • Page 15 This symbol indicates that it is important The symbol with the crossed out number two indicates that this hearing aid is for for the user to read and take into account single use only. Do not reuse. Return your the relevant information in these user guides.
  • Page 16 Atmospheric pressure: 500 hPa to 1100 Do not ingest the contents of the two packets. Operating conditons: 700 hPa - 1060 hPa The symbol with the crossed-out gar- Indicates the date after which the medi- bage bin is to make you aware that this cal device is not to be used.
  • Page 17 3. Important safety information Please read the information on the following pages previously mentioned parties, or by an adult patient before using your hearing aid 22 years and older who have been wearing Lyric for a minimum period of 3 months under the direction and Intended use: training of the ENT physician, Audiologist or Hearing The hearing aid is intended to amplify and transmit...
  • Page 18 3.1 Hazard warnings The use of a hearing aid is only part of hearing Changes or modifications to the hearing aid that habilitation and may need to be supplemented by were not explicitly approved by Sonova AG are not auditory training and instruction in lipreading. permitted.
  • Page 19 3.2 Information on product safety This hearing aid is not for children below 36 Wearing Lyric: months. The usage of this device by children and individuals with cognitive impairment should Once Lyric is removed, it cannot be reinserted. be supervised at all times to ensure their safety. The hearing aid is a small device and contains Medical imaging procedures, such as MRI scans, small parts.
  • Page 20 Using SoundLync: The surface of the SoundLync is nickel free but the keyring is not. Therefore, the keyring should not rest against the skin of those with allergies to nickel. For these clients, it is recommended to remove the keyring prior to using the SoundLync.
  • Page 21 Your hearing care professional: Manufacturer: Sonova AG Laubisrütistrasse 28 CH-8712 Stäfa Switzerland www.phonak.com...
