Page 26
E. 排汙管安裝 1、將排汙管拿出,調整使其滿足以下條件: a. 排污口和地面排污口對齊; b. 地面固定孔至各孔對齊; c. 排汙管的上介面中心距牆距離大於163mm。 繼而擰緊排汙管上的大螺母。 注意:確保地面平整。 2、將蠟封中心和地面排污口對齊,放於地面。 3、用3個螺釘和墊片把排汙管固定在地面,並再次確保彎管排污口中心距牆最小距離大於 163mm。 1295779-T01-E Kohler Co.
Page 27
F. 角閥安裝 1、將角閥纏繞生料帶後和牆面水孔相連。 2、角閥的開關方法 順時針為關,逆時針選擇為開。 注意:接好進水閥之後,請排水至目視清潔為止。 G. 拆下左右側及左側裝飾板 1、將馬桶兩側的側板打開 2、使用螺絲刀將電源安裝的一側裝飾板拆開 Kohler Co. 1295779-T01-E...
These instructions contain important care, cleaning, and warranty information - please leave instructions for the consumer. We appreciate your commitment to Kohler quality. Please take a few minutes to review this manual before installation. If you encounter any installation or performance problem, please don’t hesitate to contact us. Thanks again for choosing Kohler Company.
Page 39
Drill and bits, Expansion bolt and insert, Gasket, Assorted screwdrivers (crosshead, flat, plum head), Wire stripper, Scissor, Socket wrench, Utility knife, Pen, Pliers, Tape, Test pencil, PTFE Tape Others Pad and protection material Masking tape Expansion bolt and insert, Gasket plum head screwdriver Wire stripper Test pencil Kohler Co. 1295779-T01-E...
(10A 600mm) Water outlet (G/2 threads) Front of bowl Fig.#3 Kohler reserves the right to change marked dimensions without prior notice. SPECIFICATIONS Water supply volume Average 3L, Max 3.8L, Min 2.6L Pit distance Floor drain 305/400mm, wall drain (different model) Min water pressure 0.07Mpa (dynamic pressure)
WARNING: Risk of personal injury and product damage! Please do not hold the rim of the bidet seat when lifting the toilet. As the toilet is heavy, please seek help if necessary. Note: do not remove cover and seat protection bag during installation process. Fig.#5 Kohler Co. 1295779-T01-E...
WARNING: Risk of electric shock. Connect only to circuits protected by Ground-Fault Circuit-Interrupters (GFCI's) or Earth-Leakage Circuit-Breakers (ELCB's). Keep bath and shower head away from electrical parts (such as remote controller, receptacle etc). When the electrical supply is mounted on the wall, an anti-splash and waterproof receptacle is required. 1295779-T01-E Kohler Co.
Page 43
Make sure the toilet side mark symbol is align to the drain hole centerline on the finished floor. Mark down the left and right holes. D. Drill 5 holes and insert plastic inserts and T-bolts (Purchased by customer). 10mm Fig.#10 Kohler Co. 1295779-T01-E...
Page 44
Note: ensure floor flatness. 2.Align wax center with floor drain hole and place on floor. 3.Secure discharge pipe by 3 bolts and gaskets on the floor, and ensure discharge elbow center distance to wall distance is larger than 163mm. 1295779-T01-E Kohler Co.
Page 45
Turn clockwise is OFF, turn counter-clockwise is ON. Note: after the intake valve is connected, discharge water completely. G. Dismantle left/right side and left deco board. 1.Open toilet side panel on both sides. 2.Open deco board by screwdriver on power supply side. Kohler Co. 1295779-T01-E...
1. Turn off main power supply before installation. 2. And ensure exposed power wire length no less than 600mm. 3. Plug power wire in backwards. Wire in. 4. Ensure power cord more than 350mm or similar extended wire reserved outside toilet. 1295779-T01-E Kohler Co.
Page 47
I. Vitreous installation. Lift toilet up (2 assistants needed), align toilet axis with drainage centerline and the toilet close to the wall, and gently place it on the floor. J.Inlet connection Connect angle valve outlet and toilet inlet. Kohler Co. 1295779-T01-E...
When hear one “Beep”, night light is OFF, self-inspection completed and the toilet is ready for use. Specific usage refers to Homeowners Guide. 3. Refer to flush water and power on inspection manual to confirm normal flush status. 1295779-T01-E Kohler Co.
Page 49
M. Secure vitreous 1.Secure vitreous on floor by bolts and gaskets. 2.Apply silicon grease around the vitreous. 3. Install sideboards back from both sides. Kohler Co. 1295779-T01-E...
Page 50
2. Unscrew air filter cartridge as shown direction. 3. Slightly press down and unscrew as shown direction, tighten new filter cartridge. 4. Close toilet cover again Snap toilet cover downward manually, no loose snap-fit on both sides and rear end to complete installation. 1295779-T01-E Kohler Co.
Install the screw covers on the screws; Place the remote controller on the holder. Fig.#19 Installation steps Public anti-theft installation Screw Expansion Hook board Remove silicon plug pipe Expansion bolt Remove silicon plug Hook Remote Docking station Seat gasket Fig.#20 Kohler Co. 1295779-T01-E...
Page 52
Night light: ON Ejection position: dial 3 Ejection position: dial 3 Ejection position: dial 3 Energy saving: OFF Auto cover OPEN/CLOSE: ON, distance mid Auto UV function: ON Deodorizer: ON Auto flush function: ON E-water function: ON 1295779-T01-E Kohler Co.
Trouble shooting This guide of trouble shooting is for general help only. Authorized representatives or qualified electricians of Kohler Company shall be able to solve all electrical failures. If you want to know about the service of warranty, please contact local dealers or wholesalers.
Page 54
B. Toilet is on standby mode. B. Press “ ” button on auxiliary keyboard. If you want to check the toilet, first of all, you should: Unplug toilet power cord. Turn off the water supply valve if necessary. 1295779-T01-E Kohler Co.
Do not use abrasive cleaners or solvents. WARNING: Risk of property or product damage. Kohler Company shall not be responsible or liable for any damage to these fittings caused by the use of cleaners containing chlorine (Calcium hypochlorite). Warning: do not use any hard setting material (cement mortar) while installing the toilet. Thermal expansion of hard setting material (cement mortar) will damage or crash the feet of toilet.
Page 56
불필요한 손실을 방지하기 위해 적절한 부분을 참조하여 변기를F 설치하십시오. 정확한 설치방법 외에 모든 조작 및 안전 지침을 자세히 읽어주십시오. 본 매뉴얼에 기재된 모든 자료는 모두 인쇄 최신 제품 상황에 기준하였으며, KOHLER중국에서 최종권한을보유하며 수시로 제품 특성, 포장 혹은 공급상황을 변경하며, 이에 대해 별도 통지를 하지 않는점에 대해 양해를 바랍니다.
Page 57
화락판수, 미공칼, 팬, 집게, 줄자, 전기를 테스트하는 팬, 생료데 기타 와셔 혹은 방호 재료 테이프 전기 드릴 및 드릴의 비트 팽창 나사못 및 팽창관,와셔 각종 드라이버 매화두 드라이버 화락판수 미공칼 팬 집게 줄자 가위 박선간 전기를 테스트하는 팬 Kohler Co. 1295779-T01-E...
Page 58
완공 닥에 갱 거리 (10A 600밀리미터) 배수 (G/2내아) 블록 앞 Fig.#3 KOHLER회사에서 도면에 표시된 사이즈의 변경권한을 보유하고 있으며 변경 시, 별도 통지를 하지 않습니다. 사양 물 사용량 평균3L,대3.8L,소2.6L 사용 구간거리 지면 배수 ,벽배수( 부동한 사이즈) 최소 급수 압력 0.07Mpa (동압) 급수...
Page 59
세라믹 부품의 끝 부분을 잡고 포장박스에서 제품을 꺼냅니다. 경고: 신체 혹은 제품파손 위험! 일체형 양변기를 위로 들어올릴 때, 비데의 시트를 잡지 않습니다. 변기의 무게가 무겁기 때문에 필요한 경우 도움을 청하십시오. 주의:전체 설치 과정에 덮개 판자와 변기 보호 부분을 떼지 마세요. Fig.#5 Kohler Co. 1295779-T01-E...
Page 60
주의: 본 제품은 벽배전 전원과 벽배관 수도에 설치가 가능합니다. 설치방식은 사이즈 차트에 표시되어 있 습니다. 경고: 감전위험: 접지고장 회로차단기(GFCI) 혹은 접지누전 회로차단기(ELCB)가 설치된 회로에만 설치할수 있습니다. 욕조와 노즐의 물줄기가 닿는 위치는 전기부품과 멀리해야 합니다 (예:리모컨,전원 콘센트등). 벽배전 전원인 경우, 구비된 방수 콘센트를 사용해야 합니다. 1295779-T01-E Kohler Co.
Page 61
2.변기 배수구의 중심을 확인 하고 , 앞•뒤 양 옆면의 중심선을 표시 합니다. 3.변기 옆면의 중심선 표시와 바닥의 배수구 중심선이 맞춰지는지 확인 하십시오.왼 쪽과오른 쪽 구멍을 표시하십시오. Fig.#9 D. 고정 홀 5 개를 뚫고 두개의 앙카와 볼트를 삽입하십시오(고객이 자체로 구매). 10mm Fig.#10 Kohler Co. 1295779-T01-E...
Page 62
배출관 중심 거리는 163mm보다 길다.그다음에 오수 배출관에 있는 큰 나사못을 바짝 조이다. 주의: 지면 깔끔을 확보한다. 2.밀랍 중심과 지면 배출구가 맞추고 지면에 놓다. 3.3가지 나사못과 와셔를 오수 배출관을 지면으로 고정한다.그리고 오수 배출관 중심이 가장 작은 거리가 163mm보다 긴 것을 확보한다. 1295779-T01-E Kohler Co.
Page 63
2.앵글 밸브의 열과 닫은 방법. 시곗바늘 방향은 닫는 것을 대표하여 반시계 방향은 여는 것을 대표한다. 주의:물타기 앵글 밸브와 연결해서 청결할 때까지 배수한다. G.좌우측 및 좌측 장식판을 빼다. 1.변기 양측의 측판을 열다. 2.나사못으로 전원 옆에 있는 장식판을 분해한다. Kohler Co. 1295779-T01-E...
Page 64
바닥 급수관식 설치 시 사이즈 차트를 자세히 확인 해야 합니다. 1. 설치하기 전에 총전원을 닫다. 2. 밖에 있는 전원선 길이 600mm보다 긴 것을 보증한다. 3. 3.전원선이 뒷 전원 구멍에서 삽입한다. 전원선 삽입 4. 350mm보다 긴 전원선이나 연장선이 변기 밖에 있는 것을 보증한다. 1295779-T01-E Kohler Co.
Page 65
I. 도자기 외각 설치 변기를 들다.(2사람이 필요한다.)변기의 축선과 방출관의 중축선을 맞추고 지면으로 살살 놓다. J.물타기를 연결한다. 앵글 밸브 배출구와 변기 수도관을 연결한다. Kohler Co. 1295779-T01-E...
Page 66
1. 설치한 후 먼저 통수한 다음에 통전한다. 2. 총전원을 열고 제품 스위치 손잡이를 위로 당기다.기계는 수로를 소통시킨다.물은 물통에 들어간다. “띠”소리를 들어서 가로등불이 꺼지고 검사가 완성하고 사용이 가능한다.구체적 사용 방법은 사용자 수책을 참조한다. 3. 통수 및 통전 테스트 수책을 참조하여 씻다.씻는 것이 정상을 확인한다. 1295779-T01-E Kohler Co.
Page 67
M. 도자기의 고정 1.나사못과 와셔를 사용하여 도자기와 지면을 고정한다. 2.실리카겔로 도자기 주변에 큰 실리카겔을 바르다. 3.양측의 측판을 설치한다. Kohler Co. 1295779-T01-E...
Page 68
2. 그림 표시 방향으로 구 여과필터를 꺼내다. 3. 그림 표시 방향으로 아래로 압력을 가하고 새로운 여과필터를 꽉 죄다 . 4. 다시 조립 완제품 외각을 닫다. 다시 손으로 조립 완제품을 아래로 누 르다.양측과 뒤의 카드가 잘 공제되 어서 약화가 없으면 설치가 완비한다 . 1295779-T01-E Kohler Co.
Page 70
시트 온도:중 수온:중 수온:중 바람온도:중 수온:중 물 흐름강도:중 물 흐름강도:중 물 흐름강도:중 야간조명등:ON 세척위치:3단 세척위치:3단 에너지 절약 모드:OFF 세척위치:3단 동 개폐 기능: ON, 감지거리 중 자동 UV 살균기능: ON 탈취: ON 자동물내림 기능: ON 제균수 기능: ON 1295779-T01-E Kohler Co.
Page 71
고장 검사와 수리 본 고장 검사 수리 지침은 일반적인 문제에 한해 지원합니다. KOHLER사가 지정한 서비스 제공자 혹은 검증된 전기수리공은 모든 전기적인 고장을 해결할 수 있습니다. 품질보증 서비스는 현지 대리점 혹은 구매점에 연락하기 바랍니다. 고장 현상 가능한 원인 건의 조치 1. 비데 불작동...
Page 72
A. 변기 온도를 적당한 위치로 설치합니다. 않습니다 B. 좌변기는 대기 모델에 있습니다. B. 부조 키“ ” 를 누르다 본 비데 점검수리를 의뢰하기전 우선: 만약에 이 좌변기를 수리하려면 반드시 먼저 좌변기 전원의 플러그를 뽑아야 한다. 필요하면 공수 밸브를 닫다. 1295779-T01-E Kohler Co.
Page 73
KOHLER사는 이러한 염화 (차아 염소산 칼슘)을 사용하여 물내림 장치가 파손된 경우에 대해 책임지지 않습니다. 경고:본 일체형 양변기 설치 시, 시멘트(시멘트 모르타르)를 사용하지 말아야 합니다. 시멘트의 열팽창 은 일체형 양변기 도기 부분에 파손을 초래할 수 있다. KOHLER는 시멘트로 시공하여 발생한 양변기의 손상에 대해 책임지지 않는다.
