Sunrise Medical JAY SINGLE FOOTBOX Installation

Please read these instructions carefully before beginning the assembly. Failure to understand and
follow assembly instructions may result in injury to technician and/or end user and may void the
warranty. If you have any questions call Sunrise Medical Technical Support at +1(800) 333-4000.
Parts:
1. Single Footbox (x1)
2. Screws (x2)
C
DEALER/TECHNICIAN WARNING
Attention dealers and qualifi ed technicians, do not operate or service this device without fi rst reading the owners manual. If you
do not understand the instructions and warnings in the owners manual please contact the Quickie Technical Service Department
before operating and/or servicing the JAY device. Failure to do so may result in damage and/or injury.
Find more information and important warnings see the wheelchair owner's manual or at: www.Sunrisemedical.com.
1
A
B
Sunrise Medical 2842 N. Business Park Ave Fresno, CA 93727 USA
Customer Service: +1(800) 333-4000
or visit www.SunriseMedical.com
SINGLE FOOTBOX INSTALLATION
Required tools:
1. 4mm Hex Wrench (x1)
1. Mount Single Footbox onto footplate
a. Fasten Single Footbox onto footplate (A) using screws (B). (Fig 1)
b. See drill guide (Fig 2, on back of this sheet) if footplate holes
cannot accommodate Single Footbox holes.
c. Place hook and loop strap (C) around legrest extension bar.
© 2024 Sunrise Medical (US) LLC
02/2024 129296 Rev.B Page 1 of 2
