- Page 1 Single-Phase PV Systems SunCell Modules Solahart440R2 Solahart445R2 Solahart450R2 Solahart440DR1 Solahart445DR1 Solahart450DR1 Installation Manual Solahart PV Systems must be installed and serviced by a suitably qualified person.
-
Page 2: Table Of Contents
Catalogue Introduction ............................... 3 1.1 Purpose ................................3 1.2 Scope of liability ............................... 3 Regulations ................................. 3 Safety Precautions ............................. 3 3.1 General safety ..............................4 3.2 Operation safety measures ..........................5 Handling and unpacking ..........................6 4.1 Transport ................................6 4.2 Unpack ................................ -
Page 3: Introduction
Introduction manual is complied with is beyond the control of Solahart. Solahart shall not be liable for any form of We appreciate for your trust and confidence towards the loss, including but not limited to loss, damage, casualty photovoltaic (PV) module products from Solahart. -
Page 4: General Safety
unauthorized personnel, including but not limited to ！WARNING replacing any part of PV modules (such as diodes, junction boxes, connectors, etc.). Read and understand all safety instructions before installing, wiring, handling, and/or maintaining PV It is forbidden to plug in connectors of different modules. -
Page 5: Operation Safety Measures
wear any metal accessories to avoid the risk of Avoid partial shading of PV modules for a long electric shock; if it is installed far above the ground, period of time, otherwise the temperature of the please wear a seat belt. shaded module may rise due to hot spot effect, burning the module and causing fire hazard in severe ... -
Page 6: Handling And Unpacking
It is strictly forbidden to touch wet PV box provided by Solahart, and they should be stored modules, unless you are wearing electric shock in the original packaging box before installation. -
Page 7: Unpack
PV module each time. Take out the PV module by tearing a piece Solahart PV modules adopt high and low current bins, of fixing glue, and do not remove the fixing tape at one and the handlers need to place them separately and mark time to prevent the whole PV module from tipping. -
Page 8: Tilt Angle Selection
Solahart recommends an installation tilt angle of no less corrosive substances (e.g. salt, salt spray, brine, than 10°, so that when it rains, the dust on surface is... -
Page 9: Bolted Mounting
The PV module must be securely fastened to the mounting system. If the PV module is mounted in a snowy area, the height of the mounting system should be designed in a way that the lowest end of the PV module is not covered by snow. In addition, it should be ensured that the lowest end of the PV module is not shaded by surrounding trees or other Fig 3. -
Page 10: Clamped Mounting
Then screw on the module, otherwise it should be confirmed by top of a stainless-steel spring washer or toothed lock Solahart in advance. washer. Finally, lock with a stainless-steel nut. The above two diagrams show the mounting method ④... - Page 11 (as shown in Fig. 13), and the overlap between the C Class 8.8 screw and bolts. side of the module and the rail should be ≥ 15mm. Solahart limited warranty will be void if improper clamps or improper installation is used. Fig. 10 Schematic diagram of the mid clamp...
- Page 12 Fig 2 & Fig Fig 5 L*W*H (mm) Fig 8 Fig 9 Fig 6 3 & Fig 4 1722 *1134*30 +5400/-2400Pa +1400/-1400Pa Solahart 440R2 +5400Pa Installation scope Installation scope Solahart445R2 -2400Pa 1722 *1134*30 D = 316~416mm D = 150~250mm Solahart450R2...
-
Page 14: Electrical Installation
Maximum system voltage≥N*V *[1+TC -25)] Electrical Installation Where: Electrical characteristics N: number of PV modules in a single string The electrical characteristics are detailed in the PV module product manual. : open-circuit voltage of each PV module (refer to The rated values of electrical characteristics, including the PV module nameplate or product manual) and P , have some tolerance with the measured... -
Page 15: Electrical Connection
6.2 Electrical connection To ensure the normal operation of the system, make sure the polarity of cables is correct when connecting modules or loads, such as inverters and batteries. If the PV module is not connected correctly, the bypass diode may be damaged. -
Page 16: Grounding
When a diode failure is suspected or found, please voltage of the PV system. contact Solahart team and do not attempt to open the junction box cover. When fixing the cable to the rack, it is necessary to 6.3 Grounding... -
Page 17: Maintenance
frame of the modules. The frame rails have pre- drilled holes marked with a grounding sign. These holes should be used for grounding purposes and should not be used for mounting the modules. Maintenance PV modules must be inspected and maintained regularly, especially during the warranty period, which is the responsibility of the user. -
Page 18: Pv Module Cleaning
7.2 PV module cleaning If the PV module has a sufficient angle of tilt (15° or more), it is generally not necessary to clean the PV module (as the rainfall will provide a self-cleaning effect). If there is a large accumulation of dirt on the PV module surface that has seriously affected the power production, the module can be rinsed with water without detergent, and use a gentle sponge or brush to clean the... -
Page 19: Modified Version And Date
Modified version and date · Rev 1.4, released in March 2024 Solahart Industries Pty Ltd (A.B.N. 45064945848) For SERVICE Telephone - 1800 638 011 Registered Office Email us: solahart@solahart.com.au 1 Alan Street (PO Box 7508, Silverwater, 2128) Rydalmere or your nearest Solahart Dealer... - Page 20 Annexure - 1: Connectors information Type Name or Model SolahartxxxR2 (xxx = 440, 445, 450) No......... SolahartxxxDR1 (xxx = 440, 445, 450) Manufacturer: Stäubli Electrical Connectors AG Connectors Connectors: PV-KST4-EVO2A/xy; PV-KBT4-EVO2A/xy...
