Summary of Contents for Solahart SunCell SOLAHART450H2
- Page 1 Single-Phase PV Systems SunCell Modules SOLAHART450H2 SOLAHART455H2 SOLAHART460H2 Installation Manual Solahart PV Systems must be installed and serviced by a suitably qualified person.
-
Page 2: Table Of Contents
Catalogue Introduction ............................... 3 1.1 Purpose ................................3 1.2 Scope of liability ............................... 3 Regulations ................................. 3 Safety Precautions ............................. 3 3.1 General safety ..............................4 3.2 Operation safety measures ..........................5 Handling and unpacking ..........................6 4.1 Transport ................................6 4.2 Unpack ................................ -
Page 3: Introduction
Introduction manual is complied with is beyond the control of Solahart. Solahart shall not be liable for any form of We appreciate for your trust and confidence towards the loss, including but not limited to loss, damage, casualty photovoltaic (PV) module products from Solahart. -
Page 4: General Safety
unauthorized personnel, including but not limited to ！WARNING replacing any part of PV modules (such as diodes, junction boxes, connectors, etc.). Read and understand all safety instructions before installing, wiring, handling, and/or maintaining PV It is forbidden to plug in connectors of different modules. -
Page 5: Operation Safety Measures
wear any metal accessories to avoid the risk of Avoid partial shading of PV modules for a long electric shock; if it is installed far above the ground, period of time, otherwise the temperature of the please wear a seat belt. shaded module may rise due to hot spot effect, burning the module and causing fire hazard in severe ... -
Page 6: Handling And Unpacking
It is strictly forbidden to touch wet PV box provided by Solahart, and they should be stored modules, unless you are wearing electric shock in the original packaging box before installation. -
Page 7: Unpack
PV module each time. Take out the PV module by tearing a piece Solahart PV modules adopt high and low current bins, of fixing glue, and do not remove the fixing tape at one and the handlers need to place them separately and mark time to prevent the whole PV module from tipping. -
Page 8: Tilt Angle Selection
Solahart recommends an installation tilt angle of no less corrosive substances (e.g. salt, salt spray, brine, than 10°, so that when it rains, the dust on surface is... -
Page 9: Bolted Mounting
The PV module must be securely fastened to the mounting system. If the PV module is mounted in a snowy area, the height of the mounting system should be designed in a way that the lowest end of the PV module is not covered by snow. In addition, it should be ensured that the lowest end of the PV module is not shaded by surrounding trees or other Fig 3. -
Page 10: Clamped Mounting
Then screw on the module, otherwise it should be confirmed by top of a stainless-steel spring washer or toothed lock Solahart in advance. washer. Finally, lock with a stainless-steel nut. The above two diagrams show the mounting method ④... - Page 11 (as shown in Fig. 13), and the overlap between the C Class 8.8 screw and bolts. side of the module and the rail should be ≥ 15mm. Solahart limited warranty will be void if improper clamps or improper installation is used. Fig. 10 Schematic diagram of the mid clamp...
- Page 12 Figure 13 Mounting requirements for rails overlapping the short-side frame Table 1 Installation range and corresponding values Dimensions Installation Method Module type Fig 2 & Fig L*W*H (mm) Fig 5 Fig 8 Fig 9 Fig 6 3 & Fig 4 +5400/-2400Pa SOLAHART450H2 1908 *1134*30...
-
Page 13: Electrical Installation
Maximum system voltage≥N*V *[1+TC -25)] Electrical Installation Where: Electrical characteristics N: number of PV modules in a single string The electrical characteristics are detailed in the PV module product manual. : open-circuit voltage of each PV module (refer to The rated values of electrical characteristics, including the PV module nameplate or product manual) and P , have some tolerance with the measured... -
Page 14: Electrical Connection
Depending on the maximum rated fuse current of the PV module and the local electrical installation standards, the connection of parallel strings of PV modules needs to be equipped with suitable fuses or preventive diodes for circuit protection purposes. 6.2 Electrical connection To ensure the normal operation of the system, make sure the polarity of cables is correct when connecting... -
Page 15: Grounding
PV module. When a diode failure AWG) and withstand the maximum possible open- is suspected or found, please contact Solahart team circuit voltage of the PV system. and do not attempt to open the junction box cover. -
Page 16: Maintenance
Other grounding methods may be used when the M5 bolt and the copper wire. All nuts, bolts, and washers shall be of type M5 and made of stainless racking system is tested following the UL 2703 steel (Fig. 15). Grounding hole location on the panel requirements. -
Page 17: Pv Module Cleaning
7.2 PV module cleaning If the PV module has a sufficient angle of tilt (at least 15°), it is generally not necessary to clean the PV module (as the rainfall will provide a self-cleaning effect). If there is a large accumulation of dirt on the PV module surface that has seriously affected the power production, the module can be rinsed with water without detergent, and use a gentle sponge or brush to clean the... -
Page 18: Modified Version And Date
Modified version and date · Rev 1.5, released in July 2023. Solahart Industries Pty Ltd (A.B.N. 45064945848) For SERVICE Telephone - 1800 638 011 Registered Office Email us: solahart@solahart.com.au 1 Alan Street (PO Box 7508, Silverwater, 2128) Rydalmere or your nearest Solahart Dealer...
