- Page 1 AMP1-16V Universal LCD Replacement Instructions Document Part Number: 823229, Revision D...
- Page 2 Wohler Technologies, Inc. reserves the right to change or improve our products at any time and without notice. In no event will Wohler Technologies, Inc. be liable for direct, indirect, special, incidental, or consequential damages resulting from any defect in the hardware, software, or its documentation, even if advised of the possibility of such damages.
- Page 3 LCD displays and their accompanying bezel with a new bezel containing LCDs. Important: You must remove the AMP1-16V from the rack to perform this procedure since you will need to remove the top cover to replace the bezel. You must also upgrade the AMP1-16V Series monitor to software version V3.10 (or later) before performing this procedure.
-
Page 4: Safety Instructions
AMP1-16V Series Universal LCD Replacement Instructions Safety Instructions Safety Instructions Read, keep, and follow all of these instructions; heed all warnings. Do not use this equipment near water. Use only a dry cloth to clean the equipment. Do not block any ventilation openings. -
Page 5: Tools And Supplies
You must install the V3.10 (or later) software upgrade and it must be functioning correctly before you can replace the OLED or LCD display bezel. The LCDs will only work with V3.10 and later versions. The software update is available on our web site at www.wohler.com. Parts Table 1–1... - Page 6 AMP1-16V Series Universal LCD Replacement Instructions Procedure Remove the top cover. Be careful that you don’t lose the eight flat head and six pan head screws. Remove the left speaker bracket by unscrewing the two sems screws. See Figure 1–1 on Page Figure 1–1...
- Page 7 AMP1-16V Series Universal LCD Replacement Instructions Procedure Figure 1–2 Disconnect the Left Speaker Wire Disconnect the yellow and white speaker wire. Repeat Steps above for the right speaker. From the bottom front side of the chassis, remove the three flat head screws holding front panel to the chassis.
- Page 8 AMP1-16V Series Universal LCD Replacement Instructions Procedure Figure 1–4 Remove Front Side Screws Unscrew the front side screws, then repeat on the other side. The front panel is still connected to the motherboard by two connectors. Place your finger in the speaker openings near each end of the front panel board and pull the front panel assembly toward the front to remove it.
- Page 9 AMP1-16V Series Universal LCD Replacement Instructions Procedure Figure 1–5 Removing the Front Panel Assembly Pull the front panel assembly towards you to disconnect it from the motherboard. Be careful not to lose the nylon washers on top of the standoffs.
- Page 10 AMP1-16V Series Universal LCD Replacement Instructions Procedure Figure 1–6 Removing the Front Panel Assembly Remove the six flat head screws holding the front panel bezel to the front panel metal. See Figure 1–7 below. Figure 1–7 Remove the OLED or LCD Bezel from the...
- Page 11 AMP1-16V Series Universal LCD Replacement Instructions Procedure Remove the OLED or LCD bezel assembly as shown in Figure 1–8 below. Figure 1–8 OLED or LCD Bezel Removed Attach the new LCD bezel assembly using the six flat head screws. For proper alignment install all screws loosely, and then tighten.
- Page 12 AMP1-16V Series Universal LCD Replacement Instructions Procedure Figure 1–10 Install Nylon Washers and Screws Nylon washer Reattach the front panel assembly to the chassis. Concentrate on engaging the two front panel connectors with their mates on the motherboard. Note: It helps to stand the chassis on end to manipulate the panel until the three countersunk screw holes in the chassis line up with their right angled PEM nuts.
- Page 13 AMP1-16V Series Universal LCD Replacement Instructions Procedure Figure 1–12 Align the Bottom Screws Align the bottom screws. Re-insert the four pan head screws you removed in Step 7 to secure the front panel to the chassis. Loosely tighten all four before final tightening.
- Page 14 AMP1-16V Series Universal LCD Replacement Instructions Procedure Reinstall speaker bracket. Make sure the speaker wire is not pinched, especially where it exits the enclosure. See Figure 1–14 below. Secure the bracket with the two SEMS screws you removed in Step 3. See Figure 1–14...
