Oxford
Oxford
F
DISTORTION
X Type:
Build Level: Intermediate
Based On: Nobels® ODR-S™
If you are a fan of the Nobels® ODR-1™, you'll no doubt like its cousin the ODR-S™. The addition
of a three-band EQ offers more tonal range. The germanium clipping diodes makes for a thicker
and more compressed overdrive/distortion than offered by the ODR-1™.
•
LEVEL: Total effect output.
•
GAIN: From moderate to heavy distortion.
•
BASS/TREBLE: Active Baxandall style controls which allow for boost or cut in the bass and
treble frequencies.
•
MIDS: Ranges from mids scoop (CCW) to mids boost (CW) by way of a gyrator.
Further study:
https://nordland-electronics.de/en/blog/development-of-the-odr-s.html
Terms of Use:
You are free to use purchased Oxford circuit boards for both DIY and small commercial operations. You may not offer Oxford PCBs for
resale or as part of a "kit" in a commercial fashion. Peer to peer re-sale is fine, though.
Technical assistance
for is available via the
available to respond via email in a timely and continuous manner, and (2) posting technical problems and solutions in the forum creates a record from which other
members may benefit.
All copyrights and registered trademarks are property of their original owners. Any mention of trademarked or intellectual properties in this documents is purely for
comparative purposes.
Overview
Controls
madbeanpedals
forum. Please go there rather than emailing me for personal assistance. This is because (1) I'm not always
Last Updated:
June 7, 2024 11:55 AM
© 2024
madbeanpedals
Advertisement
Table of Contents
Related Manuals for madbeanpedals Oxford
Summary of Contents for madbeanpedals Oxford
- Page 1 Terms of Use: You are free to use purchased Oxford circuit boards for both DIY and small commercial operations. You may not offer Oxford PCBs for resale or as part of a “kit” in a commercial fashion. Peer to peer re-sale is fine, though.
-
Page 2: Parts Layout
Parts Layout Oxford pg. 2... -
Page 3: Component Values
Component Values Oxford pg. 3... - Page 4 Trace Layout Oxford pg. 4...
- Page 5 Wiring The Oxford is compatible with the SSBP and SSABP bypass boards offered at madbeanpedals. Both use the same wiring. Oxford pg. 5...
- Page 6 B.O.M. Resistors Caps Diodes 1n914 1n914 150pF AA112 AA112 1n4001 Transistors 2n5457 2n3904 2n3904 330pF 4558 4558 Pots 200k 100n LEVEL 50kA 50kB HIGH 50kB 50kC GAIN 500kA 200k 220uF 220uF 200k 100n 220uF 47uF 47uF Oxford pg. 6...
-
Page 7: Shopping List
Film 16v min. Film 16v min. Film 16v min. Film 16v min. Film 16v min. Film 16v min. Film 16v min. Film 16v min. Film 16v min. Film 16v min. Film 16v min. 100n Film 16v min. Oxford pg. 7... - Page 8 Build Notes • The Oxford has two additions to the stock circuit: a 47R current limiting resistor on the supply and some additional filtering on the VB voltage. These were used to avoid motorboating when the Gain and Bass knob are maxed. Thanks to Kevin at AION FX for helping me to solve this issue on my prototype build! •...
-
Page 9: Circuit Voltages
2n5457 4.47 9.06 4.47 560mV 4.46 2n3904 0.00 4.48 9.06 4.47 3.48 4.47 2.87 9.06 2n3904 4558 9.06 4.47 4.47 2.54 4.47 0.00 4.48 4.47 4.47 9.07 9.44vDC One Spot supply Current Draw: ~9mA Knobs @ 50% Oxford pg. 9... - Page 10 Coordinates are denoted in (X,Y), drill size format starting from the center (0,0) location of the enclosure. Tayda drill template: https://drill.taydakits.com/box-designs/new?public_key=cGZLSnR5d1BhaUlJb3FmOGVaMTNtdz09Cg== Hardware 125B enclosure Lumberg 1/4” Compact mono jacks Slim 2.1mm DC jack Standard 3PDT footswitch 5mm LED NOTE: Different 1/4” and DC jack styles may require different sized drill holes. Oxford pg. 10...
- Page 11 Build Pic Oxford pg. 11...
- Page 12 Schematic...
