- Page 1 300W LED Beam Moving Head Lighting CAUTION! Keep this device away from rain and moisture! FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY BEFORE YOU INITIAL START - UP! ·www.shehds.com...
-
Page 2: Table Of Contents
8-Replacing the fuse..................8 9-Panel operation .................... 8 10-Control menu map ..................9 12-Set Light work mode ................10 13-Set display ....................11 15-Channel List Notes: .................. 13 16-DMX Channel ..................... 13 17-Fault handling ................... 15 18-Accessories list ..................17 ·www.shehds.com... -
Page 3: 1-Maintenance
Do not touch the device’s housing bare hands during its operation (housing becomes hot)! For replacement use fixtures and fuses of same type and rating only. CAUTION! Be careful with your operations. With a high voltage you can suffer a dangerous electric shock when touching the wires! ·www.shehds.com... -
Page 4: 2-Operating Determination
The fixture must never be ignited if the objective-lens or any housing-cover is open, as discharge fixtures may explode and emit a high ultraviolet radiation, which may cause burns. The maximum ambient temperature 45°C must never be exceeded. ·www.shehds.com... -
Page 5: 3-Attention Item
Fixtures may cause severe injuries when crashing down! If you have doubts concerning the safety of a possible installation, do not install the fixture! The fixture has to be installed out of the reach of public. The fixture must never be fixed swinging freely in the room. ·www.shehds.com... -
Page 6: 5-Dmx-512 Connection
The fixture is equipped with both 3-pin sockets for DMX input and output.The sockets are wired in parallel. Only use a shielded twisted-pair cable designed for 3-pin XLR-plugs and connectors in order to connect the controller with the fixture or one fixture with another. ·www.shehds.com... -
Page 7: 6-Technical Specifications
Regular cleaning will not only ensure the maximum light-output, but will also allow the fixture to function reliably throughout its life. A soft lint-free cloth moistened with any good glass cleaning fluid is recommended, under no circumstances should alcohol or solvents be used! ·www.shehds.com... -
Page 8: 8-Replacing The Fuse
This checking is necessary for both fixed installations and preparing fixtures for renting. Any free moving parts inside of the fixture head, cracked plastic or any plastic part of front lens not sitting properly in place need to be immediately replaced. ·www.shehds.com... -
Page 9: 9-Panel Operation
Head TEMP Current temperature Fan1 speed Not date Fan2 speed Not date Pan Coder ======== Tilt Coder ======== Default set Press OK will restore default settings Standard Address 001-512 DMX mode Mode 1 / 2 (Mode 2 is no function) ·www.shehds.com... - Page 10 Here's the action: Enter the DMX address page, click the blank area on the right side of the display, modify the value, click "ENTER" to confirm and save the DMX address code. ·www.shehds.com...
-
Page 11: 12-Set Light Work Mode
When set to 'Mode 1', the save state is off display, and the 'Mode 2' save state will display DMX address code (DMX MODE) or display LOGO (AUTO RUN or SOUND CTRL). When set to 'OFF', the display remains lit and the ·www.shehds.com... - Page 12 Press the reset button to reset the current channel value. 5. Console control programming: This device provides a more convenient console input programming function, which can also be used to step by step input the program of the console, achieving the function of copying the program ·www.shehds.com...
-
Page 13: 15-Channel List Notes
If the X/Y axis of the lamp rotates slowly, please check the data of the "X/Y speed" channel; Only when the channel mode of the light parameter is set to "Extended (20CH)" (refer to "Operation Mode" > "Channel Mode" settings), the extended channel (see Channel Table ) ·www.shehds.com... -
Page 14: 16-Dmx Channel
Orange+Light green 96-101 Light green 102-107 Light green+pink 108-113 Pink 114-119 Pink+Open 120-127 Open 128-191 Color rotate left 192-255 Color rotate right OPen 9-17 Gobo1 18-26 Gobo2 27-35 Gobo3 Gobo1 36-44 Gobo4 45-62 Gobo5 63-127 Gobo6 128-191 Gobo rotate left ·www.shehds.com... -
Page 15: 17-Fault Handling
For your safety and product life, non-professionals should not disassemble the lamp and related accessories without authorization. The bulb does not light up Possible cause: The bulb is not completely cooled, or the bulb has reached the end of its life, the treatment is as follows: ·www.shehds.com... - Page 16 When installing and positioning the luminaire, keep a minimum distance of 10 meters between any point on the surface of the luminaire and any flammable and explosive object, and the distance from the irradiated object is 2.5 meters. Please do not install the luminaire directly on the surface of combustible ·www.shehds.com...
-
Page 17: 18-Accessories List
3 minutes in this state to ensure that multiple lamps can run simultaneously. During use, if there is an abnormality in the lamp, stop using the lamp in time to prevent other malfunctions; 18-Accessories list Quick lock x 2 Power cable x 1 Dmx512 cable x 1 Manual x 1 ·www.shehds.com...
