20V Cordless Pole Saw
239-1575
OPERATOR'S MANUAL
TOLL-FREE HELPLINE: 1-888-497-7273
Read this operator manual before using this product. Failure to do so can result in serious injury. SAVE THIS
MANUAL
- 01 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 239-1575 and is the answer not in the manual?

Questions and answers

Skip Lehnhard
April 11, 2025

The greasing of the drive sprocket in the instructions does not make sense to me. Do you have a better visual or a link that shows how it is done

Summary of Contents for Yardworks 239-1575

  • Page 1 20V Cordless Pole Saw 239-1575 OPERATOR’S MANUAL TOLL-FREE HELPLINE: 1-888-497-7273 Read this operator manual before using this product. Failure to do so can result in serious injury. SAVE THIS MANUAL - 01 -...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS SAFETY SYMBOLS ..........................02 IMPORTANT SAFETY INSTRUCTIONS ................04 KNOW YOUR TOOL ......................07 CHARGING YOUR BATTERY ....................09 ASSEMBLY .........................10 OPERATION ........................15 MAINTENACE ........................17 STORAGE ..........................19 TROUBLE SHOOTING ......................20 WARRANTY ........................21 READ ALL INSTRUCTIONS! WARNING: Some dust created by power sanding, sawing, grinding, drilling and other construction activi- ties may contain chemicals known to the state of California to cause cancer, birth defects or other reproductive harm.
  • Page 3 SYMBOL DESCRIPTION SYMBOL DESCRIPTION To reduce the risk of injury, user must Do not expose to rain. read instruction manual SAFETY ALERT – indicate a precau- Wear hearing protection. tion, a warning or a danger. Wear eye protection. Wear dust mask Wear safety footwear Wear protective gloves Warning of danger from overhead...
  • Page 4: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS WARNING: Only use the accessories that are provided with this product or the accessories approved by yardworks . Use other accessories might increase the risk of injury. Follow the instructions in this manual to properly use the accessories. WARNING:...
  • Page 5 battery may cause irritation or burns 7. Do not use a battery pack or power tool that is damaged or modified. Damaged or modified batteries may exhibit unpredictable behavior resulting in fire, explosion or risk of injury. 8. Do not expose a battery pack or power tool to fire or excessive temperature. Exposure to fire or temperature above 266°F may cause explosion.
  • Page 6 14. Use only the battery pack in the application for which it was intended. 15. Remove the battery pack from the equipment when not in use. 16. Dispose of properly. 17. Do not handle the charger, including charger plug, or charger terminals with wet hands. 18.
  • Page 7: Know Your Tool

    KNOW YOUR TOOL 1. Rear handle 18. Bar and chain sheath 2. Lock off button 19. Chain direction symbol 3. On/off switch 20. Oil outlet 4. Shoulder strap seating bracket 21. Fastening bar bolt 5. Soft grip area/lower shaft 22. Tension pin 6.
  • Page 8 TECHNICAL DATA SKU No. 2391575 Model No. EGT050004 Voltage 20V D.C. No-load motor speed 19000/min Bar length 8” Chain speed 14.7f/s Oiler capacity 65ml Chain pitch 3/8” Number of chain drive links Chain gauge 0.05” Cutting Up to 30 Cuts Per Charger (Full 2.0AH to cut Dia 2.3"...
  • Page 9: Charging Your Battery

    CHARGING YOUR BATTERY BATTERY INDICATOR The battery pack is equipped with a push button for checking the charge level. Simply press the push button to read off the battery charge level from the LEDs of the battery indicator: LED Indicator Battery Charge Level/Working Conditions 3 lights on 70%<Charge Level≤100%...
  • Page 10: Assembly

    CHARGER LED INDICATOR TABLE Use the table below to determine charger light patterns and possible causes. For all other issues, please ask the helpline for help. Indication Possible Reason • Red Light – Off No load charging –There’s no battery inserted in the charger. •...
  • Page 11 4. Firmly rotate the shaft locking sleeve clockwise until the shafts are locked in place. (Fig. 4) c. Fit the chain onto the drive sprocket, and make sure the fastening bar bolt on the bar pad fit into the keyway of the opening on the guide bar, and the tension pin on the bar pad fit into the lower oil hole (A) on the guide bar.
  • Page 12 TENSIONING CHAIN NOTICE: New saw chains will stretch. Check the chain tension frequently when first used and tighten when the chain becomes loose around the guide bar. WARNING: ● Removing the battery pack before adjusting saw chain tension. ● Cutting edges on chain are sharp. Use pro- tective gloves when handling chain.
  • Page 13 NOTICE: The chain will stretch while cutting and WARNING: To allow venting of the oiler, small lose proper tension. Always pay attention to the breather channels are provided between the oiler chain tension while working. cap and the strainer, to prevent leakage, and en- sure machine is left in a horizontal position when LUBRICATION not in use.
  • Page 14 ADJUSTING THE HEAD ANGLE 2. Clip the shoulder strap onto the hole of the shoulder strap seating bracket. (Fig. 20) The saw head of this pole saw can be adjusted to 4 different angles: -45°, -22.5°, 0°, 22.5° for your choice.
  • Page 15: Operation

    OPERATION Attaching the shoulder strap correctly before starting the pole saw. ● Wear the shoulder strap over the head and the WARNING: Do not allow familiarity with this shoulder opposite the hand holding on/off switch. product to make you careless. Remember that ●...
  • Page 16 To stop the pole saw: WARNING: Do not operate the pole saw with For switching off, release the on/off switch. arms fully extended or attempt to saw in areas which are difficult to reach. STARTING CUTTING CUTTING THIN BRANCHES 1. Install the battery pack and fill the oiler. Use both Thin branches can be cut off with a single cut.
  • Page 17: Maintenace

    WARNING: For the user’s safety, worn or damaged parts must be replaced. Replace with original replacement parts only. WARNING: To prevent serious injury from ap- pliance failure, do not use damaged equipment. If abnormal noise or vibration occurs, have the problem corrected before further use.
  • Page 18 MAINTENANCE AND STORAGE Conditions which require chain and guide bar maintenance: 1. Remove the battery pack ● Saw cuts to one side or at an angle. ● When not in use ● Saw has to be forced through the cut. ●...
  • Page 19: Storage

    STORAGE LUBRICATE SPROCKET WARNING: Wear heavy duty gloves when performing any maintenance or service to this Pole saw: tool. Always remove the battery pack before per- 1. Examine the cordless pole saw thoroughly for forming any service or maintenance on this tool. worn, loose or damaged parts.
  • Page 20: Trouble Shooting

    TROUBLE SHOOTING The following table gives checks and actions that you can perform if your machine does not operate correctly. If these do not identify/remedy the problem, contact your service agent. WARNING! Switch off the machine and remove the battery packs prior to any troubleshooting. Problem Possible Cause Solution...
  • Page 21: Warranty

    SKU# 239-1575 YARDWORKS WARRANTY POLICY ● Two (2) year limited warranty on all Yardworks 20V lithium ion power tools from date of purchase when used for personal, household, or family use. ● Two (2) year limited warranty on all Yardworks 20V lithium ion batteries and chargers from date of purchase when used for personal, household, or family use.
  • Page 22 - 22 -...
  • Page 23 - 23 -...
  • Page 24 - 24 -...
