Garrett Vortex VX5 Quick Start Manual

QUICK START
Step 1
Power on.
Press and release. Vortex powers on in
last mode used and is ready to search.
Step 2
Select Mode.
Tap Mode button to select a different
detection mode, if desired.
Step 3
Adjust settings.
Press Menu button to access all settings.
Scroll up or down using the and
arrows. Tap Plus (+) or Minus (-) button
to adjust selected setting.
Step 4
Ground Balance
Press and hold Ground Balance button
while bouncing coil above the ground
until ground response disappears or
becomes as small as possible.
