TM
Label Case CSI Pro xxxxxxx REV A
Shows brushed silver
Pantone Black
White
Instruction Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CSI PRO and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Garrett CSI PRO

Summary of Contents for Garrett CSI PRO

  • Page 1 Label Case CSI Pro xxxxxxx REV A Shows brushed silver Pantone Black White Instruction Manual...
  • Page 2 THANK YOU FOR CHOOSING GARRETT METAL DETECTORS! The CSI Pro All Terrain metal detector was designed for use in the recovery of metallic crime scene evidence in all terrains, including shallow water searching. The CSI Pro includes Garrett's exclusive Target ID...
  • Page 3 Garrett Metal Detectors...

  • Page 4: Table Of Contents

    TABLE OF CONTENTS CSI Pro CONTROL PANEL ..............4 QUICk START GUIDE ................5 CSI Pro COmPONENTS ..............6 LIST OF PARTS ..................7 ASSEmBLy ..................8 POWERING ON .................. 11 TARGET INFORmATION ..............12 DIGITAL TARGET ID ................13 SENSITIVITy ..................

  • Page 5: Csi Pro Control Panel

    CSI Pro CONTROL PANEL Target ID Legend indicates Lower Scale metal types. Digital indicates notch Target ID Target ID discrimination pattern. Cursor (also shows indicates High Resolution ground balance probable Iron Discrimination Depth Indicator settings while in target identity. indicates level of iron indicates depth of GND-BAL mode.)

  • Page 6: Quick Start Guide

    The CSI Pro operates with four (4) AA batteries which are already installed by Garrett. 2. Power ON. Press and release the ON / OFF Power button. The CSI Pro powers on in the last mode used and is ready to search. (Factory default mode is Coins.) 3.

  • Page 7: Csi Pro Components

    CSI Pro COmPONENTS Search Control coil Housing Lower Upper Stem Stem Screen Pushbutton Controls Camlocks strap S-shaped Stem Handle Grip Detector Stand Padded Arm Cuff Garrett Metal Detectors...

  • Page 8: List Of Parts

    LIST OF PARTS No tools are required to assemble the CSI Pro. Four (4) AA batteries are included with the detector. The box for your detector contains the following parts:  One (1) control housing with  One (1) 5" x 8" DD...

  • Page 9: Assembly

    Hand-tighten searchcoil assembly with the wing nut. 6. Holding assembly as shown, loosen camlock at the end of the upper shaft by turning counter-clockwise. Note: If the camlock collar slides off during loosening, simply slide it back on and tighten slightly. Garrett Metal Detectors...
  • Page 10 O-ring is felt to be fully inserted. Note: If the O-ring is properly seated, the connector's collar can be easily tightened; if the collar is difficult to turn, the O-ring may not be seated properly. CSI Pro™...
  • Page 11 Note: Headphones are not required but are desired by many hunters to hear faint targets. Connecting the headphones will silence the detector's speaker. Note: The provided headphones are for dry use only; see page 55 for optional waterproof headphones. 10 Garrett Metal Detectors...

  • Page 12: Powering On

    To turn off the detector, press and hold this pushbutton for one (1) second (until the detector produces a second beep). To restore the factory settings, press and hold the power button for 5 to 10 seconds (until the detector produces a fast double beep). CSI Pro™...

  • Page 13: Target Information

    Lower Scale—The lower scale, or Notch Discrimination Scale, continually indicates the discrimination pattern. The CSI Pro will produce an audible target response for the pixels that are switched on, and no audible response for those that have been switched off. The Target ID Cursor will always indicate all targets.

  • Page 14: Digital Target Id

    Digital Cursor Target The CSI Pro’s Digital Target ID system provides a specific target value to help identify targets more precisely. Targets are identified on the LCD by number, with items near 1 being the most ferrous. The most conductive targets (such as large copper items) register closer to to 99.
  • Page 15 Use a magnet to help remove small bits of shallow iron and then scan over the area again to see if the Target ID has changed. 14 Garrett Metal Detectors...

  • Page 16: Sensitivity

    Sensitivity Pushbutton Indicator The CSI Pro has eight (8) settings for sensitivity. Use the (+) or (-) SENSITIVITy buttons to step through the eight levels, which are continuously shown on the LCD. Use higher sensitivity levels when searching for very small or very deep targets.

  • Page 17: Ground Balance

    Target ID accuracy. It is imperative to ground balance the detector to maintain optimal performance. The CSI Pro can be ground balanced either automatically or manually to cancel unwanted ground signals and obtain maximum stability and target detection. By calibrating the...

  • Page 18: Automatic Ground Balance

    Note: If the CSI Pro's Ground Balance setting does not change during the auto ground balancing process, the detector is either sufficiently ground balanced already or the current ground exhibits such neutral mineralization that the settings will not change.
  • Page 19 80–99: Highly ferrous (magnetite, ferrous oxide minerals, black sands, hot rocks, terra cotta) 60–80: moderately mineralized soils (red clay, brown clay, iron-bearing clay minerals, etc.) 20–60: Likely an iron object 0–20: Highly conductive, non-ferrous minerals such as saltwater 18 Garrett Metal Detectors...

  • Page 20: Frequency Adjustment

    Use the PINPOINT/Freq Adj pushbutton in conjunction with the (+) or (-) SENSITIVITy pushbuttons to adjust frequency. The CSI Pro is capable of operating at four slightly different frequencies in order to minimize the interference caused by electrical sources (e.g. power lines) or other metal detectors.

  • Page 21: Tone Id And Tone Roll Audio

    TONE ID AND TONE ROLL AUDIO The CSI Pro's Tone ID feature produces three distinct audible tones based on a target's metal type and conductivity. Low-Tone: Ferrous targets such as nails, iron, steel-core projectile, etc. medium-Tone: Small, thin targets that are non-ferrous, including many lead bullets, foil, and some smaller brass, such as a .22 casing.

  • Page 22: Proportional Audio Characteristics

    Example A: Adjacent targets can often produce a single strong signal with many metal detectors. The fast recovery of the CSI Pro, however, will provide two peaks of audio response to these adjacent casings. These multiple audio responses provide the experienced user with more target information.
  • Page 23 Proportional Audio Target Examples Shallow target Deep target Example B: Notice the different target response provided by the CSI Pro's proportional audio in regards to target depth. The shallow target offers a stronger signal, while the same-sized deep object provides a softer signal.

  • Page 24: Search Modes

    Discrimination and Notch Discrimination as desired. Press the Mode button to change modes. In either of the two modes, the CSI Pro's searchcoil must be in motion to detect targets. Truly static detection is possible while using the detector's Pinpoint pushbutton.
  • Page 25 CUSTOm mode will be retained when the CSI Pro is switched off. (For information on the use of IroN DISC and NoTCH DISC, see pages 25–30.) • ZERO Mode Designed to detect every type of metal; use ZERO mode to find all metal items or when the material of the desired object is unknown.

  • Page 26: Notch Discrimination

    ELIM Pushbutton Pushbutton The CSI Pro has 12 pixels or "notches" of discrimination (in addition to the 40 points of High-Res Iron Discrimination). Any combination of these pixels can be switched on or off based upon your preference. There are two primary methods for modifying the Notch Discrimination Pattern to reject a specific type of trash or unwanted item.
  • Page 27 For example, if a particular shell casing is being sought at a crime scene, scan a matching shell casing with the CSI Pro while in the ZERO mode. Note where the Target ID cursor appears when the casing is scanned.
  • Page 28 Discrimination modifications made while in CUSTOm will be retained when the detector is switched OFF. However, all changes made to the Notch Discrimination pattern while in ZERO mode will return to the factory settings when the detector is switched OFF and back ON again. CSI Pro™...

  • Page 29: Iron Discrimination

    IRON DISCRImINATION Iron Discrimination—The CSI Pro features a high-resolution iron discrimination adjustment. This additional resolution allows more precise control of how much iron discrimination can be applied. The level can be adjusted from 0 (no iron discrimination) to 40 (maximum iron discrimination).
  • Page 30 (seen in Illustration 2) can be missed. Read page 30 to learn how to apply the proper amount of iron discrimination to eliminate the nail shown in Illustration 1 and still detect the bullet shown in Illustration 2. CSI Pro™...
  • Page 31 Example: Detecting Targets in Trash with High-Res Iron Discrimination In the illustration above, the CSI Pro is operating in the ZERO mode with an IRON DISC setting of 20. The nail seen in Illustration 1 (on page 29) registers from 18 to 24 on the Digital Target ID scale. To eliminate the nail from detection, increase the iron discrimination level to 24 using the IRON DISC (+) pushbutton.

  • Page 32: Iron Audio

    Scattered iron objects in the ground can mask good targets and even create “ghost signals” that appear to be a good target. Garrett’s selectable Iron Audio feature allows the user to hear discriminated iron (normally silenced) in order to know the whole picture and avoid being tricked into digging an undesired target.
  • Page 33 For example, a nail will produce several fast low tones as the searchcoil passes over. A flat iron object like a bottle cap or steel washer will produce a very distinctive Low-High-Low response. 32 Garrett Metal Detectors...
  • Page 34 To fully appreciate the additional information offered by the Iron Audio feature, conduct the following experiment. Start with the CSI Pro in Zero mode (IRON DISC setting at 00) and pass the searchcoil over a bottle cap which is lying flat on the ground.

  • Page 35: Bench Tests

    BENCH TESTS you should conduct bench tests to become more familiar with the CSI Pro’s operation, including use of the Iron Audio feature. Suggested test items should include: • Bullets, casings, knives, etc. • Iron nail • Conductive non-ferrous target (coin or gold ring) •...
  • Page 36 Final tip: Record the results of your bench tests and refer to them when hunting in the field. knowledge of the audio characteristics and the Iron Audio feature of the CSI Pro can reduce the amount of trash targets that are dug.

  • Page 37: Create A Crime Scene Test Plot

    CREATE A CRImE SCENE TEST PLOT It is strongly suggested that you develop a target "test plot" to learn how the CSI Pro identifies various targets that are encountered. This test plot will prove invaluable in training others on the use of this metal detector.

  • Page 38: Sweeping The Searchcoil

    In order to fully search an area, overlap the swings of your searchcoil by half the length of the coil (about 4 inches). Sweep the searchcoil in a straight line or with a slight arc at a sweep speed of about 3ft/sec. CSI Pro™...
  • Page 39 Walk slowly to allow overlapping of the searchcoil Scan side to side approx. 3 ft. (1m) per second. 38 Garrett Metal Detectors...

  • Page 40: Pinpointing

    Indicates mount. The opening pinpointing just ahead of the stem center of the mount can serve as 5"x8" DD your reference point searchcoil. for pinpointing. CSI Pro™...
  • Page 41 Then, quickly release and depress the Pinpoint button again to retune the detector and narrow its detection field. Continue moving the searchcoil toward the 40 Garrett Metal Detectors...

  • Page 42: Narrowing The Detection Area

    If needed, repeat the retune process to further narrow the target's response. A quality hand-held pinpointer such as Garrett's CSI Pro- Pointer is recommended to speed the target recovery process and to aid in locating secondary targets.

  • Page 43: Alternative Pinpointing Methods

    (see Image B). Deep targets will be under or just inside your searchcoil's tip. This is because the conical shape of the searchcoil's detection field begins bending in slightly as the depth increases. 42 Garrett Metal Detectors...
  • Page 44 Tip: Practice any or all of these various pinpointing options in your test plot. Choose the technique that works best for you. As you improve your pinpointing accuracy, you will dig smaller holes and make your search time more productive. CSI Pro™...

  • Page 45: Advanced Tips And Techniques

    ADVANCED TIPS AND TECHNIQUES • Ground balance the CSI Pro as often as necessary as the ground conditions are heard to change (excessive noise, etc.) in order to maintain the most effective detection. • Determining ground mineralization level: It is important to understand the soil conditions of your hunting environment.
  • Page 46 • Isolating adjacent targets. The narrow detection field of the CSI Pro's DD searchcoil allows better separation of adjacent targets versus a similar size concentric searchcoil. Use narrow swings of the searchcoil in trashy areas to isolate good targets amongst the trash.

  • Page 47: Underwater Operation

    UNDERWATER OPERATION The CSI Pro can be immersed in water to a maximum depth of 10 feet (3 meters) to search in and along shorelines, rivers, piers, docks or swimming holes. Use of the CSI Pro at depths exceeding 10 feet (3 meters) can cause leaks and damage the detector.
  • Page 48 Continous Wave (VLF) metal detector. Saltwater is conductive and produces signals similar to foil. Although the CSI Pro is not specifically designed for saltwater use, it can be used in this environment. Proper ground balance is the most important step for stable saltwater operation.

  • Page 49: Care And Maintenance

    CARE AND mAINTENANCE Battery Level Indicator Battery Replacement—The CSI Pro is operating with fresh or fully charged batteries when 4 illuminated bars on the Battery Level Indicator are displayed (see above). The detector will maintain full performance until the batteries need to be replaced.
  • Page 50 Pull and remove the cap to slide the battery holder out. Remove batteries when the CSI Pro will be stored for longer than 30 days. The CSI Pro is a rugged machine, designed for outdoor use in all environments.

  • Page 51: Troubleshooting Guide

    NOTE: Large, flat pieces of iron—depending on their orientation in the ground—can read as a good target or can cause erratic Target ID Cursor movement. Use Iron Audio feature to help identify iron targets. 50 Garrett Metal Detectors...

  • Page 52: Warranty / Service

    CSI Pro detector. In the event that repairs or warranty service are necessary for your CSI Pro, contact the local outlet where your detector was purchased. To avoid excessive shipping and import charges, do not attempt to return a Garrett product to the factory in the United States.

  • Page 53: Accessories

    CSI Pro ACCESSORIES 4.5" (11.5cm) Super Sniper ™ Searchcoil— Part No. 2222500 Use when searching for small, shallow targets or in trashy or tight places. 6" x 9" (15 x 23cm) PROformance Concentric Searchcoil—Part No. 2222600 This waterproof searchcoil offers excellent depth for medium-sized targets in less mineralized soils.
  • Page 54 Garrett CSI PRO-POINTER Pinpointing Detector— Part No. 1166020 The CSI Pro-PoINTEr combines performance with sleek design to assist in pinpointing hard-to-find targets. Includes proportional audio/vibration pulse rate target indicators and 360° side scan detection area. Water resistant with LED light for low light uses.
  • Page 55 1881 W. State Street Garland, Texas 75042 Toll Free: 800.234.6151 Tel: 972.494.6151 Fax: 972.494.1881 Email: security@garrett.com © 2012 Garrett Electronics, Inc. PN 1533700.A.0812...
  • Page 56 Ideal for recovering evidence in all terrains 1881 W. State Street Garland, Texas 75042 Tel: 1.972.494.6151 Email: sales@garrett.com Fax: 1.972.494.1881 © 2012 Garrett Electronics, Inc. PN 1533700.A.0812...
