Tools Needed:
•
Helper
•
Ladder
•
Tape Measure
•
Pencil
•
Electric Drill
•
1/8" Drill Bit
•
Phillips Screwdriver
•
Level
•
7/16" Open-End Wrench
•
Wire Cutter
EasyShade
Mounting Bracket
3' - 9'6" : Qty 2
10' - 12' : Qty 3
Solar Panel with
Internal Battery Qty 1
3' cord not shown
Figure 2 - Parts Supplied
Parts Supplied:
•
Solar-Powered EasyShade Assembly (not shown below)
•
Solar Panel with Internal Battery
•
Mounting Brackets
•
#8 x 1-1/2" Round-Head Screws
•
1/8" Allen Wrench (for the Mounting Bracket Set Screws)
•
Two (2) Cable Guides
•
Two (2) Cable Guide Brackets
•
Two (2) Cable Guide Stops
•
5/64" Allen Wrench (for Cable Guide Stop Set Screws)
•
#8 x 1-1/2" Flat-Head Screws
•
One (1) 4mm Allen Wrench and Allen set screw (for the Solar
Panel Housing)
•
One (1) Multi-Channel Remote Transmitter with Wall Mounting Kit
Cable Guide Bracket
Qty 2
Cable Guide Stop
w/ Set Screw Qty 2
Remote Transmitter, Qty 1
4
Allen Wrenches
5/64", 1/8" & 4mm,
1 EA
#8 Round-Head Screw
3' - 9' : Qty 4
10' - 12' : Qty 6
#8 Flat-Head Screw
Qty 2 for Each Cable
Guide Bracket
Allen Set Screw for
Solar Panel, Qty 1
