Operating the EasyShade

25. Test the operation of your EasyShade by using
the UP and DOWN buttons on the remote.
a. Press and release the UP button. The
EasyShade will roll up into the EasyShade
housing and stop on its own. The Up
stop limit should stop the EasyShade
automatically, before the leading bar at the
bottom of the solar screen fabric reaches the
housing. See Appendix A to adjust this stop
limit.
b. Press and release the DOWN button. The
EasyShade will unroll from the EasyShade
housing and stop on its own. The Down
stop limit should stop the EasyShade
automatically, before the leading bar at the
bottom of the solar screen fabric reaches the
physical limit of the cable guide bracket. See
Appendix A to adjust this stop limit.
26. A wall mount kit has been provided for the
remote (see Figure 2). Position the wall mount in
a safe location, protected from weather.
CAUTION: Do not leave your EasyShade extended
during windy conditions, as the uncontrolled
movement of the extended EasyShade solar screen
fabric panel could cause damage to the product and
surrounding items . Simply retract the EasyShade by
pressing the UP button on the remote .
CAUTION: Do not permit the hand-held remote to
get wet as this can affect its proper operation . It is
recommended to keep the remote indoors when the
EasyShade is not in use or if rain is expected .
CAUTION: The installation procedure for the
EasyShade includes the use of cable guides to
stabilize the extended solar screen fabric panel
during normal use . If your application does not
permit the installation of the necessary cable
guides, or you do not plan to install them, you must
use additional care to prevent damage to your
product . While we do not recommend installing the
EasyShade without the supplied cable guides, some
customers may determine that their application does
not have a vertical surface to install the supplied
cable guides as instructed .
"Congratulations, your installation is complete ."

OPERATION

Remote Transmitters are Unique

Each remote transmitter and each channel of each
remote transmitter (see Figure 19) has its own
unique ID code. Each Solar-Powered EasyShade
is programmed to receive a signal from a unique
remote. A remote can only communicate with a
motor if the motor has been specifically programmed
to accept signals from that specific remote.
Each Solar-Powered EasyShade is packaged with
a remote programmed to control that specific
EasyShade. It is recommended to use channel 1 (see
Figure 19), the first light from the left, to control the
EasyShade.
If you own more than one Solar-Powered or
Motorized EasyShade, keep the remote with the
EasyShade for which it was programmed.
To control multiple EasyShades with one or more
remotes or channels, see Appendix C.
Figure 19
Each light represents a
separate channel with its own
unique ID, which operates as
a unique remote transmitter.
Use channel 1 to operate
your EasyShade.
Channel 1 is the first light on
the left.
9
Channel Selector Button.
Press this button and the
selected Channel blinks.
Press this button while the
selected Channel blinks, and
the next Channel is selected.
