Page 1
CABINET HEATER Homeowner's Manual WARNING! IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOWED EXACTLY, A FIRE MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. AdjustableThermostat COMFORT GLOW PHONE NUMBER: (800) 776-9425 Threesettings http://www.worldmkting.com HIGH Made in China...
Page 2 IMPORTANT INSTRUCTIONS INTENDED USE This product is intended ONLY for indoor household or office use. It is NOT intended for industrial or commercial use. Do not use the product outdoors. When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock, injury to persons, and hyperthermia, including the following: 1) Read all instructions before using this heater.
Page 3
Page 3 ALWAYS OBSERVE THESE SAFETY PRECAUTIONS WHEN OPERATING YOUR ELECTRIC HEATER ALWAYS Read all instructions before operating. ALWAYS Locate your electric heater away from furniture or loose hanging drapes. ALWAYS Keep the rear grill away from walls or drapes so as not to block the air intake. (If applicable) ALWAYS Unplug electric heater when not in use.
Page 4 PRODUCT DIAGRAM FRONT REAR AIR INTAKE HEAT OUTPUT REMOTE CONTROL CORD WRAP PANEL MAIN POWER SWITCH ROLLING WHEELS OVERHEATSAFETYFEATURE This heater is equipped with an automatic overheat protection device. If the heater grill is obstructed, or if the heater gets too hot for any reason, the automatic overheat device will turn the heater off.
Page 5 CONTROL PANEL 1. ON/OFF button: Powers the display on and off.” 2. Mode button: To select between High Low and Eco modes. 3. Energy-saving mode indicator: Will be lit when energy-saving mode is engaged. 4. Timer button: Used to engage timer mode and to set hour value for the timer. 5.
Page 6
Page 6 OPERATING INSTRUCTIONS 1. Start and select working mode Turn the heater on by pressing the ON/OFF button on the control panel or by pressing the Power button on the supplied remote control. Select a heat Mode. Press the MODE button to toggle between the three heat modes. High Mode uses 1500W;...
Page 7
Page 7 3. Setting the POWER OFF TIMER Function Note: The Power-Off-Timer Function will allow for the heater to power OFF after a certain set time and can only be set while the heater’s display is in the “On” position. Turn the heater to the “On”...
Page 8 5. Setting electro lock The Electro Lock can help prevent the heater from being accidentally engaged by children. The locking mechanism can be set in both the ON and OFF modes. Press Temp Up and Temp Down buttons at the same time for 3 seconds.
Page 9 BASIC TROUBLESHOOTING If the heater will not operate, please check the following before seeking repair advice: 1. Check if the power cord is plugged into an electrical outlet, if not, plug in. 2. Check if the electricity to the main power switch (in the back) is working. 3.
Page 10 LIMITED WARRANTY: A limited warranty is extended to the original purchaser of this heater and warrants against malfunction due to manufacturing defects for a period of (1) one year from the date of retail purchase. Please read and follow all details noted below.
Page 11
¡ADVERTENCIA! SI LA INFORMACIÓN EN ESTE MANUAL NO SE SIGUE EXACTAMENTE, PUEDE RESULTAR EN UN INCENDIO Y CAUSAR DAÑOS A LA PROPIEDAD, LESIONES PERSONALES O LA PÉRDIDA DE LA VIDA. Termostato ajustable COMFORT GLOW PHONE NUMBER: Safety Overheat Device Tres configuraciones (800) 776-9425...
INSTRUCCIONES IMPORTANTES Página 2 USO PREVISTO Este producto está destinado ÚNICAMENTE para uso en interiores, domésticos o de oficina. NO está destinado a uso industrial o comercial. No utilice el producto al aire libre. Al usar aparatos eléctricos, siempre se deben seguir las precauciones básicas para reducir el riesgo de incendio, descargas eléctricas, lesiones a personase hipertermia, incluyendo lo siguiente: 1.
Page 13
Página 3 SIEMPRE OBSERVE que ESTAS MEDIDAS DE SEGURIDAD AL OPERAR SU CALENTADORA ELECTRICA Siempre Lea todas las instrucciones antes de operar Siempre Sitúe su calentadora eléctrica lejos de muebles o afloje cortinas colgantes. Siempre Mantenga la parrilla trasera lejos de paredes o cortinas por no bloquear la toma de aire. (Si aplicable) Siempre Desenchufe calentadora eléctrica cuando no en uso Siempre...
Página 4 DIAGRAMA DEL PRODUCTO DELANTERA TRASERA TOMA DE SALIDA DE AIRE CALOR REMOTA ENVOLTURA PANEL DE DEL CABLE CONTROL INTERRUPTOR PRINCIPAL RUEDAS RODANTES FUNCIÓN DE SEGURIDAD SOBRECALENTAMIENTO: Este calentador está equipado con un dispositivo automático de protección contra sobrecalentamiento. Si la rejilla del calentador está...
Página 5 PANEL DE CONTROL 1. Botón ON/OFF: enciende y apaga la pantalla”. 2. Botón Modo: Para seleccionar entre los modos Alto, Bajo y Eco. 3. Indicador del modo de ahorro de energía: Se iluminará cuando el modo de ahorro de energía esté activado.
Página 6 INSTRUCCIONES DE OPERACIÓN 1. Inicie y seleccione el modo de trabajo. Encienda el calentador presionando el botón ON/OFF en el panel de control o presionando el botón Power en el control remoto suministrado. Seleccione un modo de calefacción. Presione el botón MODE para alternar entre los tres modos de calefacción.
Page 17
Página 7 3. Configuración de la función TEMPORIZADOR DE APAGADO Nota: La función de temporizador de apagado permitirá que el calentador se apague después de un cierto tiempo establecido y solo se puede configurar mientras la pantalla del calentador está en la posición "Encendido". Gire el calentador a la posición "Encendido".
Página 8 5. Configuración de electrocerradura El Electro Lock puede ayudar a evitar que los niños enciendan accidentalmente el calentador. El mecanismo de bloqueo se puede configurar en los modos ON y OFF. Presione los botones Temp Up y Temp Down al mismo tiempo durante 3 segundos.
Page 19
Página 9 SOLUCIÓN DE PROBLEMAS BÁSICOS Si el calentador no funciona, verifique lo siguiente antes de buscar asesoramiento sobre reparación: 1. Compruebe si el cable de alimentación está enchufado a una toma de corriente; de lo contrario, conéctelo. 2. Verifique si la electricidad que llega al fusible principal está funcionando. 3.
Page 20
Página 10 GARANTIA ELECTRICA PORTATIL de CALENTADORA La GARANTIA LIMITADA: Una garantía limitada es extendida al comprador original de esta calentadora y autorizaciones contra falla debido a defectos industriales por un período de (1) un año de la fecha de la compra de la venta al por menor. Lea por favor y siga todos los detalles PARA REGISTRAR LA GARANTÍA DE SU NUEVO PRODUCTO, VISITE: www.worldmkting.com notados abajo.
