- Page 1 917X Series Metrology Well Users Guide 2005, Rev. 1, 3/11 © 2005 - 2011 Fluke Corporation. All rights reserved. Specifications subject to change without notice. All product names are trademarks of their respective companies. 1.888.610.7664 www.calcert.com sales@calcert.com...
- Page 2 Fluke authorized resellers shall extend this warranty on new and unused products to end-user customers only but have no authority to extend a greater or different warranty on behalf of Fluke. Warranty support is available only if product is purchased through a Fluke authorized sales outlet or Buyer has paid the applicable interna- tional price.
-
Page 3: Table Of Contents
Table of Contents Before You Start ...............1 Introduction ....................1 Symbols Used ................... 1 Safety Information ..................2 1.3.1 Warnings ......................2 1.3.2 Cautions ......................4 CE Comments ................... 5 1.4.1 EMC Directive ....................5 1.4.2 Immunity Testing .....................5 1.4.3 Emission Testing .....................6 1.4.4 Low Voltage Directive (Safety) ................6 Authorized Service Centers .............. - Page 4 917X Series Metrology Wells Figures Figure 1 Probe connector wiring ..............17 Figure 2 Metrology Well back panel view ............19 Figure 3 Metrology Well front panel view ............21 Figure 4 Metrology Well insert options. Probe sizes indicated in inches for A, B, and C, and millimeters for sleeves D, E, and F except for 0.25 inch reference holes in E and F.
- Page 5 Tables Table 1 International Symbols ................1 Table 2 Metrology Well Specifications ............... 9 Table 3 Built-in Readout Specifications............10 1.888.610.7664 www.calcert.com sales@calcert.com...
-
Page 6: Before You Start
1 Before You Start 1.1 Introduction Fluke’s Hart Metrology Wells (9170, 9171, 9172, and 9173) are designed to be stable heat sources that can be used in a laboratory or field environment. With a calibrated display and an optional built-in reference thermometer input (designated with “-R”), Metrology Wells may also be used as a reference standard. -
Page 7: Safety Information
917X Series Metrology Wells Safety Information Symbol Description Symbol Description Electric Shock C-TICK Australian EMC mark The European Waste Electrical Fuse and Electronic Equipment (WEEE) Directive (2002/96/EC) mark. OVERVOLTAGE (Installation) CATEGORY II, Pollution Degree 2 per IEC1010-1 refers to the level of Impulse Withstand Voltage protection provided. - Page 8 Before You Start Safety Information or has been in a wet environment, take necessary measures to remove moisture prior to applying power such as storage in a low humidity temperature chamber operating at 50°C for 4 hours or more. DO NOT use this instrument for any application other than calibration work. The instrument was designed for temperature calibration.
-
Page 9: Cautions
917X Series Metrology Wells Safety Information DO NOT turn off the instrument at temperatures higher than 100°C. This could create a hazardous situation. Select a set-point less than 100°C and allow the instrument to cool before turning it off. The high temperatures present in Metrology Wells designed for operation at 300°C and higher may result in fires and severe burns if safety precautions are not observed. -
Page 10: Ce Comments
1.4 CE Comments 1.4.1 EMC Directive Fluke’s equipment has been tested to meet the European Electromagnetic Compatibil- ity Directive (EMC Directive, 89/336/EEC). The Declaration of Conformity for your instrument lists the specific standards to which the instrument was tested. The instrument was designed specifically as a test and measuring device. Compliance to the EMC directive is through IEC 61326-1 Electrical equipment for measurement, control and laboratory use –... -
Page 11: Emission Testing
Class B equipment. The instrument was not designed to be used in domestic establishments. 1.4.4 Low Voltage Directive (Safety) In order to comply with the European Low Voltage Directive (73/23/EEC), Fluke’s equipment has been designed to meet the IEC 1010-1 (EN 61010-1) and the IEC 1010-2-010 (EN 61010-2-010) standards. 1.5 Authorized Service Centers www.itm.com... -
Page 12: Specifications And Environmental Conditions
Specifications and Environmental Conditions Specifications 2 Specifications and Environmental Conditions 2.1 Specifications Table 2 Metrology Well Specifications Specification 9170 9171 9172 9173 Range –45°C to 140°C –30°C to 155°C 35°C to 425°C 50°C to 700°C (–49°F to 284°F) (–22°F to 311°F) (95°F to 797°F) (122°F to 1292°F) Display Accuracy ±0.1°C full range... -
Page 13: Environmental Conditions
917X Series Metrology Wells Environmental Conditions Specification 9170 9171 9172 9173 Power 115 V (±10%), 50/60 Hz, 550 W 115 V (±10%), 50/60 Hz, 1025 W 230 V (±10%), 50/60 Hz, 550 W 230 V (±10%), 50/60 Hz, 1025 W System Fuse 115 V: 6.3 A 250 V 115 V: 10 A 250 V... - Page 14 Specifications and Environmental Conditions Environmental Conditions temperature range: 5-40°C (41-104°F) ● ambient relative humidity: maximum 80% for temperature <31°C, decreasing ● linearly to 50% at 40°C pressure: 75kPa-106kPa ● mains voltage: within ±10% of nominal ● vibrations in the calibration environment should be minimized ●...
-
Page 15: Quick Start
Quick Start Unpacking 3 Quick Start 3.1 Unpacking Unpack the instrument carefully and inspect it for any damage that may have occurred during shipment. If there is shipping damage, notify the carrier immediately. Verify that the following components are present: 9170 9170 Metrology Well ●... -
Page 16: Setup
Sleeves of various sizes are available from Fluke Calibration. The well must be clear of any foreign objects, dirt and grit before the sleeve is inserted. The sleeve is inserted with the two small tong holes positioned upward. -
Page 17: System Setup
Quick Start Display 3.3 System Setup Before using the instrument, the parameters in this section need to be setup (Main Menu: SYSTEM|SETUP MENU). 3.4 Display Language Select the preferred language (English, French, or Chinese) using the right/left arrow keys and press “ENTER” to accept the selection. Decimal The decimal of the numbers in the instrument can be either a comma or decimal. -
Page 18: Setting The Temperature
917X Series Metrology Wells Setting the Temperature Stability Alarm (STAB ALARM) The audible alarm described in “Stability Limit” is turned on or off using this param- eter. Select either “On” or “Off” using the right/left arrow keys and press “ENTER” to accept the selection. -
Page 19: Probe Connection
Quick Start Reference Probe (-R models only) 3.6.1 Probe Connection A PRT is the only type of probe that is supported by the reference thermometer input. The PRT (RTD or SPRT) probe connects to the reference thermometer input using a 5-pin DIN connector. - Page 20 If no coefficients can be found, contact the manufacturer or vendor of the probe for assistance. If the probe is out of calibration, Fluke offers calibration services. Contact an Authorized Service Center for assistance on obtaining a calibration for the probe.
-
Page 21: Parts And Controls
Parts and Controls Back panel 4 Parts and Controls This section describes the exterior features of the Metrology Well. 4.1 Back panel The following are found on the back of the Metrology Well (see Figure 2 ). Figure 2 Metrology Well back panel view Power Cord Plug (1) The power supply cord attaches to the back panel. -
Page 22: Front Panel
917X Series Metrology Wells Front panel Power Switch (2) The power switch is located on the power entry module of the unit at the bottom left of the back panel. Serial Connector (3) The serial connector is a 9-pin subminiature D type located on the back panel. The serial (RS-232) interface can be used to transmit measurements and control the opera- tion of the Metrology Well. -
Page 23: Figure 3 Metrology Well Front Panel View
Parts and Controls Front panel Block Temperature Indicator (U.S. Patent 7,561,058) (6) The block temperature indicator lamp allows users to know when the block tempera- ture is above 50°C. Figure 3 Metrology Well front panel view 1.888.610.7664 www.calcert.com sales@calcert.com... -
Page 24: Front Panel Display
917X Series Metrology Wells Front Panel Display 4.3 Front Panel Display The front panel display is shown in detail in Figure 3, on previous page and its fea- tures are described below. Control Focus The most recent block temperature measurement is shown in large digits in the box at the top of the screen. - Page 25 Parts and Controls Front Panel Buttons Numeric Keys (3) The ten number keys, the decimal point, and +/– keys are used to enter numeric data. ENTER (7) The “ENTER” key is used to enter a new parameter value or option or as a shortcut key to the set-point menu while viewing the main screen.
-
Page 26: Accessories
917X Series Metrology Wells Accessories NOTE: Parameter entry will abort if the up or down arrow key is pressed before “ENTER”. Therefore, the up or down arrow keys can be used to cancel a parameter change. Left/Right (4 5) Arrows (11) The left and right arrow keys have three functions: move from digit to digit while editing a parameter, select or change an option for some parameters, and change focus from control to reference or from reference to control. -
Page 27: Figure 4 Metrology Well Insert Options. Probe Sizes Indicated In Inches For A, B
Parts and Controls Accessories 9172-INSZ, Insert, Blank, 9172 ● 9173-INSA, Insert, A, 9173, miscellaneous holes ● 9173-INSB, Insert, B, 9173, comparison holes ● 9173-INSC, Insert, C, 9173, four 0.25 inch holes ● 9173-INSD, Insert, D, 9173, metric miscellaneous holes ● 9173-INSE, Insert, E, 9173, metric, 0.25 inch reference, miscellaneous holes ●...
