- Page 1 Important Information Network Disk Recorder WJ-NU301K Series Model No. For professional use only WJ-NU301K Series refer to WJ-NU301K, WJ-NU301KG and WJ-NU301KGV. Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use. The model number is abbreviated in some descriptions in this manual.
-
Page 2: Safety Information
Open the fuse cover with a screwdriver and replace the fuse and close or attach the fuse cover. For U.S.A. Supplier's Declaration of conformity Trade Figure A Figure B Name: i-PRO Model No. : WJ-NU301K Responsible Party: i-PRO Americas Inc. 8550 Fallbrook Drive, Suite 200 Houston, Texas 77064 Support Contact: 1-800-513-5417... -
Page 3: Table Of Contents
Contents Safety Information ........................2 Introduction ..........................4 Preface ...................................... 4 Features ....................................4 System requirements for a PC ..............................6 Trademarks and registered trademarks ............................ 6 About HEVC (High Efficiency Video Coding) patents ....................... 6 Copyright ....................................6 Disclaimer of warranty ................................7 Network security .................................. -
Page 4: Introduction
Introduction Preface The network disk recorders WJ-NU301K Series (hereinafter, recorder) equipped H.265 CODEC and are designed for use within a H.265 surveillance system, and record images/audio from up to 16 network cameras (hereinafter, cameras) on the hard disk drives (HDDs). This recorder supports connection with a monitor equipped with the HDMI (High-Definition Multimedia Interface) connector. - Page 5 Introduction (continued) System Configuration Main monitor (HDMI) Sub monitor (HDMI) Network switch Network camera (× 16 max.) Network Mouse (included)
-
Page 6: System Requirements For A Pc
Introduction (continued) System requirements for a PC It is recommended to operate this unit using a PC that meets the following system requirements. Microsoft Windows 10, Microsoft Windows 11 Web browser: Microsoft Edge, Google Chrome™, Mozilla Firefox ® CPU: Intel Core i7-860 Memory:... -
Page 7: Disclaimer Of Warranty
(continued) Disclaimer of warranty IN NO EVENT SHALL i-PRO Co., Ltd. BE LIABLE TO ANY PARTY OR ANY PERSON, EXCEPT FOR REPLACEMENT OR REASONABLE MAINTENANCE OF THE PRODUCT, FOR THE CASES, INCLUDING BUT NOT LIMITED TO BELOW: (1) ANY LOSS OR DAMAGE, INCLUDING WITHOUT LIMITATION, DIRECT OR INDIRECT, SPECIAL, CONSEQUENTIAL OR EXEMPLARY, ARISING OUT OF OR RELATING TO THE PRODUCT;... -
Page 8: Precautions
Precautions Refer installation work to the dealer. Grounding Installation work requires technique and experiences. Failure Use this product after confirming that grounding is properly to observe this may cause fire, electric shock, injury, or installed. damage to the product. If grounding is not installed properly, it may cause ground •... - Page 9 Precautions (continued) Precautions for use Power source Hard disk drive (HDD) The input power source for this product is 100 V - 240 V AC • Hard disk drives are precision devices. Handle them with 50 Hz/ 60 Hz. care. It is possible to damage them if they are moved Do not connect to the outlet that provides the power to while their motors are still running.
- Page 10 Disclaimer of warranty on recoded data i-PRO Co., Ltd. assumes no responsibility or liability, directly or indirectly, for failure of recording or editing including loss of data due to any reason or cause which does not exclude repair or maintenance of this product regardless whether the subject is hard disk or other parts.
-
Page 11: Major Operating Controls And Their Functions
Major operating controls and their functions Front view COPY OPERATE ERROR ALARM BUZZER STOP ① ② ③ ④ ⑤ ⑥ ⑦ ① Copy port (USB3.0) [COPY] ⑦ Buzzer stop button [BUZZER STOP] Connect an external storage device (external Hard disk Press this button to stop the buzzer that started drive, USB memory) to this port and copy images and sounding at an alarm/error occurrence. -
Page 12: Rear View
Major operating controls and their functions (continued) Rear view ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ① Security wire hole ⑨ Network port (Camera port) [CAMERA] Mount the lock device for the anti-theft security wire. Connect the recorder with a PC and cameras via a network compatible with 10BASE-T or 100BASE-TX. - Page 13 Major operating controls and their functions (continued) How to prevent the power cord from disconnecting How to prevent the Ethernet cable from disconnecting Fix the power cord at 15 cm to 20 cm {5-7/8 to 7-7/8 Tighten and secure the bundled Ethernet cable with the two inches} from the connector with the included cable clamp supplied cable clamps inserted in the two clamp mounting (for power cord) passed through the clamp mount.
-
Page 14: User/Host Management
User/Host management It is necessary to register users who directly operate this product, or PCs (hosts) that access through the network such as LAN. Up to 32 users can be registered. It is possible to register the following for the user information. Item Description User name... -
Page 15: Specifications
Specifications • General Power source: 100 V - 240 V AC 50 Hz/ 60 Hz Power consumption: 340 W (347 VA) Ambient operating temperature: Main body: 0 °C - +45 °C {32 °F - 113 °F} Mouse (included): +5 °C - +40 °C {41 °F - 104 °F} Ambient operating humidity: 5 % to 90 % (non condensing) Maximum operating altitude:... - Page 16 Authorised Representative in EU: i-PRO EMEA B.V. Laarderhoogtweg 25, 1101 EB i-PRO Co., Ltd. Amsterdam, Netherlands Tokyo, Japan i-PRO EMEA B.V. UK Branch 1010 Cambourne Business Park, https://www.i-pro.com/ Cambridgeshire CB23 6DP © i-PRO Co., Ltd. 2022 L1222-2064 PGQP3561XA...
