CONTENTS Preface ...............4 Confirm the hard disk drive information About the user manuals .........4 [HDD information] ..........70 Abbreviations ............4 Configure the settings and operations relating to About the settings and operation of the system [System management] .......72 the recorder ............4 Manage the hard disk drives [HDD management] ...76 Restrictions when using this product .....5 How to display the "HDD management"...
Page 3 Play images selected from logs (Log search) ..137 Download root certificate ........184 Display thumbnail screen and paly back Update the firmware ...........184 (Thumbnail search) ..........138 Notification by e-mail ..........185 Search and play recorded images triggered by Alarm mail............185 motion detection (VMD search) ......139 Warning mail ............185 Copy recorded images ...........142 Troubleshooting ............187...
Page 4: Preface
• Although there is description of "live sequence" in this manual and on the screen, this product does not support live sequence on the main monitor. Abbreviations The following abbreviations are used in this manual. WJ-NU101K Series is called NU101. WJ-NU210K Series is called NU201. WJ-NU300K Series is called NU300. WJ-NU301K Series is called NU301.
Page 5: Restrictions When Using This Product
Restrictions when using this product When using this product, some functions have the following restrictions. Before using this product, keep the following in mind. Restrictions for individual cameras are posted on our support website. When connected to a monitor When playing recorded images •...
Page 6 • "Stream 2" in "Do not use stream 2 of camera When using i-PRO Mobile APP with each function of this recorder" and "Display • When using a sub-monitor, the maximum number stream 2 live image when displaying on the of mobile playback connections is one.
Page 7: Before Using This Product
Before using this product Motion detection (VMD) function The motion detection (VMD) function of cameras detects motions referring to changes of luminance (brightness) in areas set in advance. The motion detection function will not effectively work in the following situations or may sometimes be malfunctioning.
Page 8: Black Screen Displayed When Playing Recorded Images
Black screen displayed when playing recorded images In the following cases, a black screen may be displayed during playing recorded images. However, this is not a malfunction. • When changing cameras or screen patterns during playback or pausing • When skipping/reverse skipping during playback •...
Page 9: Setup Via Recorder's Main Monitor
[Setup via recorder's main monitor] Setup via recorder's main monitor The Setup via recorder's main monitor using the mouse include [Quick setup] - [Easy Start], [Basic setup] and [Advanced setup]. [Quick setup] - Easy Start provides the minimum settings necessary to use this product, including date setting, camera registration, and recording settings.
Page 10: Configure The Basic Settings [Basic Setup]
[Setup via recorder's main monitor] Configure the basic settings [Basic setup] The basic settings of the recorder such as date & time and recording mode, etc. can be configured on the "Basic setup" page. The "Basic setup" page provides access to the [Date/Language], [Camera] and [REC & event] pages. Note: •...
Page 11: Set Up Date & Time And Language [Date/Language]
[Setup via recorder's main monitor] Set up date & time and language [Date/Language] The "Date/Language" page has the [Date & time adjustment], [Date & time settings] and [Language] tabs. [Date & time adjustment] tab Set the current date & time. ■...
Page 12 [Setup via recorder's main monitor] Important: Important: • After time zone is changed, if you have specified • Setting is impossible when the interval between date and time or selected from the history, the start (In)/end (Out) is less than an hour. playback start time of the recorded image or the timeline display, etc.
Page 13: Camera Setup [Camera]
[Setup via recorder's main monitor] Camera setup [Camera] The "Camera" page has the [Camera registration] tab, the [Camera setup] tab and the [Advanced setup] tab. [Camera registration] tab Perform settings such as the network settings of the camera (IP address and port number), and the display position on the main monitor.
Page 14 [Setup via recorder's main monitor] Detect cameras for registration [Detect cameras] Clicking the [Setup >] button of "Detect cameras" on the [Camera setup] tab will display the following window. After editing the settings, click the [OK] button to save the settings and return to the [Camera registration] tab. [Results] New: Displayed when the camera is newly connected to the recorder.
Page 15 [Setup via recorder's main monitor] Change the password of camera [Management of camera user] Click the [Setup >] button of "Management of camera user" on the [Camera registration] tab to display the following screen. Note: • The settings can be made from this recorder only for cameras manufactured by us or Panasonic.
Page 16 [Setup via recorder's main monitor] Change the registered information [Registered information] Click the [Setup >] button for "Registered information" on the [Camera registration] tab to display the following items. After editing the settings, click the [OK] button to save the settings and return to the [Camera registration] tab. [Compression] Select the image compression method.
Page 17 [Setup via recorder's main monitor] [Password] [Table to delete] Enter the password to be used for the user whose To delete registration information or remove a name has been registered as "User name" using the previously connected camera, either select the on-screen keyboard.
Page 18 [Setup via recorder's main monitor] Select a camera which performs AI privacy guard recording [AI privacy guard recording camera] Click the [Setup >] button of [AI privacy guard recording camera] on the [Camera registration] tab to display the following screen. [Recording camera] For the registered cameras, select a camera to record the AI privacy guard image.
Page 19 [Setup via recorder's main monitor] [Camera setup] tab Transmit the date & time and text displayed on an image, the refresh rate, the VMD alarm and the Light control mode etc. settings to the camera. Click the [Setup >] button for each item to open the respective setup window.
Page 20 [Setup via recorder's main monitor] Set up date & time display [Date & time display] Select the date & time display position for each camera and transmit it to the cameras to change the camera settings. Clicking the [Setup >] button for "Date & time display" on the [Camera setup] tab will display the following items.
Page 21 [Setup via recorder's main monitor] Set up OSD [Display Title] Determine whether to display the title and select the title to display for each camera, the settings will be changed after the settings have been transmitted to the camera. Clicking the [Setup >] button for "Display Title" on the [Camera setup] tab will display the following items. •...
Page 22 [Setup via recorder's main monitor] Set up how to turn on or off the indicators [Indicator] Select how to turn on or off the link indicator, access indicator or status indicators for each camera and transmit the information to the cameras to change the camera settings. Refer to the operating instructions of the camera for further information.
Page 23 [Setup via recorder's main monitor] Set the camera image transmission priority [Transmission priority] Select the transmission priority setting for each camera and transmit the information to the cameras to change the camera settings. Clicking the [Setup >] button for "Transmission priority" on the [Camera setup] tab will display the setup page. [Control time period] Select the period of controlling H.264 bit rate to be recorded from the following when the transmission...
Page 24 [Setup via recorder's main monitor] Set up the refresh interval [Refresh interval] Select the image refresh interval for each camera and transmit it to the cameras to change the camera settings. Clicking the [Setup >] button for "Refresh interval" on the [Camera setup] tab will display the setup page. Important: •...
Page 25 [Setup via recorder's main monitor] Set up the method of camera installation [Upside-down] Select the method of installation for each camera and transmit the information to the cameras to change the camera settings. Clicking the [Setup >] button for "Upside-down" on the [Camera setup] tab will display the setup window. [Upside-down] On (desktop): Select this when the camera is to be installed with the dome side up.
Page 26 [Setup via recorder's main monitor] Set the image rotation of camera [Image rotation] Select the image rotation for each camera and transmit it to the camera to change the camera settings. Clicking the [Setup >] button for "Image rotation" on the [Camera setup] tab will display the setup window. [Image rotation] •...
Page 27 [Setup via recorder's main monitor] Set up pan/tilt-flip [Pan/tilt-flip] Select the pan/tilt-flip function for each camera and transmit the information to the cameras to change the camera settings. Clicking the [Setup >] button for "Pan/tilt-flip" on the [Camera setup] tab will display the setup page. [Pan/tilt-flip] Select whether or not to activate the pan/tilt-flip function that can achieve camera controllability equal...
Page 28 [Setup via recorder's main monitor] Set self return [Self return] Select the self-return function for individual cameras and transfer it to the camera to change the camera settings. ■ Camera selection Select the camera that transfers the self return setting. In the setting items, check the camera that transfers the selected content.
Page 29 [Setup via recorder's main monitor] Set up Super Dynamic [Super Dynamic (Wide dynamic range)] Select the Super Dynamic function for each camera and transmit the information to the cameras to change the camera settings. Clicking the [Setup >] button for "Super Dynamic (Wide dynamic range)" on the [Camera setup] tab will display the setup page.
Page 30 [Setup via recorder's main monitor] Set the adaptive black stretch function of the camera [Adaptive black stretch] Determine whether to enable the adaptive black stretch function for each camera. The settings will be changed after the settings have been transmitted to the camera. Clicking the [Setup >] button for "Adaptive black stretch"...
Page 31 [Setup via recorder's main monitor] Set the back light compensation function of the camera [Back light compensation (BLC)] Determine whether to enable the back light compensation function for each camera. The settings will be changed after the settings have been transmitted to the camera. Clicking the [Setup >] button for "Back light compensation (BLC)"...
Page 32 [Setup via recorder's main monitor] Set up Light control mode [Light control mode] Select how to control the amount of light for each camera and transmit the information to the cameras to change the camera settings. Clicking the [Setup >] button for "Light control mode" on the [Camera setup] tab will display the setup page. [Light control mode] Outdoor scene: Depending on the brightness level (illuminance), the iris will automatically be...
Page 33 [Setup via recorder's main monitor] Set the automatic slow shutter of the camera [Auto slow shutter (Maximum shutter)] Select the auto slow shutter setting for each camera and transmit the information to the cameras to change the camera settings. Clicking the [Setup >] button for "Auto slow shutter (Maximum shutter)" on the [Camera setup] tab will display the setup page.
Page 34 [Setup via recorder's main monitor] Set the black and white switchover of the camera [Day & Night (IR/electrical)] Select the day and night setting for each camera and transmit the information to the cameras to change the camera settings. Clicking the [Setup >] button for "Day & Night (IR/electrical)" on the [Camera setup] tab will display the setup window.
Page 35 [Setup via recorder's main monitor] Set the intelligent auto of camera [Intelligent auto] Select the intelligent auto for each camera and transmit it to the camera to change the camera settings. Clicking the [Setup >] button for "Intelligent auto" on the [Camera setup] tab will display the setup window. [Intelligent auto] Set whether or not to turn on the intelligent auto function.
Page 36 [Setup via recorder's main monitor] Set up VMD alarm [VMD alarm] Select the VMD function for each camera and transmit the information to the cameras to change the camera settings. Clicking the [Setup >] button for "VMD alarm" on the [Camera setup] tab will display the setup page. [VMD alarm] Select whether or not to use the VMD (VMD: Video Motion Detection) alarm function when a change...
Page 37 [Setup via recorder's main monitor] Set up VMD alarm for individual cameras [VMD alarm (Advanced individual camera setup)] Select the motion detection area and detection sensitivity for each camera and transmit the information to the cameras to change the camera settings. Clicking the "Advanced individual camera setup"...
Page 38 [Setup via recorder's main monitor] Set schedule [Schedule 1 to Schedule 4] Click the [Setting＞] button for "Schedule 1" to "Schedule 4" in the [Camera setup] tab to display the setup window. [Transmission] button Transmit the setting of the "Schedule" to the camera. Once transmission is completed and the setting has been applied to the camera, "OK"...
Page 39 [Setup via recorder's main monitor] [Advanced setup] tab Set the connection method of the camera. Clicking the [Setup >] button of "Connection method" under the [Advanced setup] tab displays the setup screen. ■ Connection method ■ Other setup [Do not use stream 2 of camera with each function of this recorder.] If this item is checked, the multi-screen real-time display of the main monitor and sub monitor will...
Page 40: Set Up Recording/Events [Rec & Event]
[Setup via recorder's main monitor] Set up recording/events [REC & event] The "REC & event" page has 3 tabs; the [Recording setup] tab, the [Event setup] tab and the [Advanced setup] tab. Recording setup tab [Recording setup] Configure the settings relating to schedule recording. Set the day(s), time table(s), frame rate and image quality for recording.
Page 41 [Setup via recorder's main monitor] ■ Recording setup (All cameras) Note: Set the recording frame rate and image quality. The • The referenced recording days will be displayed settings will be applied to all cameras. correctly only when the settings have been saved while the recorder has recognized the camera [Frame rate] correctly.
Page 42 [Setup via recorder's main monitor] Configure the advanced settings for schedule recording [Advanced schedule setup] Up to 16 schedule patterns can be set. Up to 6 time zones of the schedule recording or event recording can be set for each schedule. Clicking the [Advanced >] button in the "Schedules"...
Page 43 [Setup via recorder's main monitor] Set up recording for individual cameras [Advanced recording setup] Set up items such as the image capture size, frame rate and image quality for individual cameras. Clicking the [Advanced >] button on the [Recording setup (All cameras)] tab will open the advanced setup page. Note: •...
Page 44 [Setup via recorder's main monitor] [Emergency] [Referenced recording days] (☞ Page 41) Set the frame rate of the emergency recording. [Back] button 1 ips/ 3 ips/ 5 ips/ 10 ips/ 12.5 ips/ 15 ips/ 25 ips/ 30 ips/ (Same as the basic) Click the button after completing the settings. The Default: Same as the basic screen returns to the [Recording setup] tab.
Page 45 [Setup via recorder's main monitor] Note: [Event type] • If the time set for "Output duration" or "Buzzer Displayed when "On" or "On(ACK/RESET)" is duration" is longer than that set for "Auto reset selected for "Main monitor action". time", the time set for "Auto reset time" will be A event type to be linked is selected.
Page 46 [Setup via recorder's main monitor] Set up terminal alarm [Advanced terminal alarm setup] Configure the settings relating to the recording triggered by an alarm signal supplied to the ALARM/CONTROL connector of the recorder from an external alarm device such as a door sensor. Configure the necessary settings for each alarm input terminal of the ALARM/CONTROL connector on the rear panel of the recorder.
Page 47 [Setup via recorder's main monitor] [Name] Enter the names of terminal alarms 1-6 using the software keyboard (up to 16 characters). Note: • The alarm history and the body of e-mail notifications are displayed with the name you set. [Back] button Click the button after completing the settings.
Page 48 [Setup via recorder's main monitor] Set up camera site alarm [Advanced camera site alarm setup] Set up the action to be taken when a TCP alarm notification received from a camera triggers camera site alarm. Refer to the "Set up terminal alarm [Advanced terminal alarm setup]" section (☞ Page 46) for further information about the items available for "Advanced camera site alarm setup";...
Page 49 [Setup via recorder's main monitor] Configure the advanced settings for recording and events [Advanced setup] Configure the special settings related to recording on this tab. Set up the recording mode, alarm disarm duration and TCP alarm port number (the port number for incoming site alarm). [Extension software alarm] Set the extension software alarm name and message ID.
Page 50 [Setup via recorder's main monitor] [Emergency recording setup] SD backup rec. Configure the settings related to emergency recording The SD memory backup is a function to save images on the SD memory card inserted in the camera when the recorder fails to communicate with the camera during the set recording time.
Page 51 [Setup via recorder's main monitor] Note: [Month] [Day] • All images may not be acquired at one time due to Select a date that you want to set as a special day. [Mode] the time between time tables of the schedule and the total capacity of the images.
Page 52: Configure The Settings Relating To Monitors [Monitor]
[Setup via recorder's main monitor] Configure the settings relating to monitors [Monitor] The settings relating to the display of the main monitor or sub-monitor connected to the recorder are configured on the setup menu - the "Advanced setup" - the "Monitor" page. The settings relating to image switching such as multiscreen display and sequence display of live images are also configured on this page.
Page 53 [Setup via recorder's main monitor] [Fix the HDMI output to the following video mode] Fixes the signal system of the HDMI output when it is checked. The signal system is selectable from 4K and 1080p. Note: • 4K output is p/30Hz(4K/30p). Depending on your monitor, "ERROR"...
Page 54: Configure The Settings Relating To Sub Monitors [Sub Monitor]
[Setup via recorder's main monitor] Configure the settings relating to sub monitors [Sub monitor] Set up the sub monitor by selecting the camera images to display, the image display duration, etc. Important: • When using a sub-monitor, use a full HD (1080p) monitor for the main monitor, or fix the HDMI output signal format to 1080p.
Page 55: Configure Other Settings Relating To Monitors [Advanced Setup]
[Setup via recorder's main monitor] [Secret view] Note: Secret view is a function that causes the camera • While "1-screen live sequence" is being image displayed on a 1-screen or the selected performed, the secret view images will be skipped camera image on a multiscreen on the main monitor (not displayed).
Page 56: Configure The Settings Relating To Network [Network]
[Setup via recorder's main monitor] Configure the settings relating to network [Network] The settings relating to the network of the recorder are configured on the setup menu - the "Advanced setup" menu - the "Network" page. The "Network" page has [Basic], [e-Mail], [TCP alarm notification], [HTTP alarm] and [NTP/SNMP] tabs. Configure the basic network settings [Basic] The basic settings relating to the network can be configured on this tab.
Page 57 [Setup via recorder's main monitor] When using Dynamic DNS Update ■ Other setup [HTTP port number] Specify the HTTP port number to be used to send images from the recorder. It is unnecessary to change it for normal use. 1 - 65535 Default: 80 Note: •...
Page 58: Configure The Settings Relating To The Mail Notification [E-Mail]
[Setup via recorder's main monitor] Configure the settings relating to the mail notification [e-Mail] The settings of alarm mail notice, the settings of warning mail (☞ Page 185) and the settings to use the mail functions can be configured on this tab. [Authentic method - Password] Enter the password to be required together with the user name for the authentication.
Page 59: Configure The Tcp Alarm Notification Settings [Tcp Alarm Notification]
[Setup via recorder's main monitor] Configure the TCP alarm notification settings [TCP alarm notification] The settings to notify the PC of the event and error information when an event or an error occurs can be configured on this tab. To display the event and error information, it is necessary that the software (option) is installed on the recipient Refer to our technical information web site for details on the software.
Page 60: Configure Http Alarm Notification Settings [Http Alarm]
[Setup via recorder's main monitor] Configure HTTP alarm notification settings [HTTP alarm] Configure the settings to notify the PC via HTTP when an event or error occurs. characters, half-width symbols Default setting: / By checking the "Alarm", "Emergency recording input", "Camera/Recorder Error", "HDD/Recording Error"...
Page 61: Configure The Settings Relating To Ntp/Snmp Synchronization [Ntp/Snmp]
[Setup via recorder's main monitor] Configure the settings relating to NTP/SNMP synchronization [NTP/SNMP] The settings to synchronize the system clock with the NTP (Network Time Protocol) and SNMP (Simple Network Management Protocol) server can be configured on this tab. Important: •...
Page 62 [Setup via recorder's main monitor] [SNMPv3 - User name] The user name of SNMPv3 will be set. Number of input characters: 1 to 32 Characters that cannot be input: half-width symbols " " ", " & ", " : ", " ; ", "¥" [SNMPv3 - Authentication method] Select the authentication method of SNMPv3 from MD5/SHA1.
Page 63: Configure The Settings Relating To The User Management [User Management]
[Setup via recorder's main monitor] Configure the settings relating to the user management [User management] The settings such as user authentication On/Off, administrator registration and operation levels can be configured on the setup menu - the "Advanced setup" menu - the "User management" page. The "User management"...
Page 64 [Setup via recorder's main monitor] ■ User level settings * Administrators and managers can perform all Set up the operations allowed at each user level operations. The difference between an (Administrator/Manager/Operator/Viewer) by marking administrator and a manager is that an the respective checkboxes.
Page 65: Register, Edit Or Delete The User Information [User Registration]
[Setup via recorder's main monitor] Set up the user level for individual cameras Select the cameras allowed for operation by each user level (operator/viewer/logged out) by marking the respective checkboxes. Remove the check mark from any cameras not to be displayed. The setting for the administrator/manager cannot be changed.
Page 66 [Setup via recorder's main monitor] [Level] Note: Display the operation level of a user. • Camera operation is not available when "Camera Operable functions can be set on the [Basic] tab control" is limited in "User level settings" of the (☞...
Page 67: Edit The Administrator Information [Administrator Setup]
[Setup via recorder's main monitor] Edit the administrator information [Administrator setup] The administrator information relating to the password and default screen, etc. can be registered on this tab. [Level] Display the operation level of an administrator. It is impossible to change the setting value for an administrator.
Page 68: Register, Edit Or Delete Host [Host Registration]
[Setup via recorder's main monitor] Register, edit or delete host [Host registration] Register, edit or delete the host information of the PC which can access to the recorder via the Internet. ■ Edit host information Change or delete the registered host information. Select a host information to change or delete on [Host IP address].
Page 69: Configure The Settings Relating To Maintenance [Maintenance]
[Setup via recorder's main monitor] Configure the settings relating to maintenance [Maintenance] The version of the recorder and disk information is displayed, and the settings relating to hard disk drives can be configured on the setup menu - the "Advanced setup" menu - the "Maintenance" page. It is also possible to initialize the setup data of the setup pages, check the system logs and register the license on this page.
Page 70: Confirm The Hard Disk Drive Information [Hdd Information]
[Setup via recorder's main monitor] Confirm the hard disk drive information [HDD information] Capacity of the hard disk drive and the running time of this product, time range of the recorded images, etc. will be displayed. [Recorded time range] Displays the time range of the images recorded on the hard disk drives.
Page 71 [Setup via recorder's main monitor] [Capacity] Displays the capacity of HDD. [Remaining capacity] Displays remaining capacity of HDD. Note: • Remaining capacity displayed does not include capacity used to manage data. Therefore, the displayed HDD capacity is less than the actual amount.
Page 72: Configure The Settings And Operations Relating To The System [System Management]
[Setup via recorder's main monitor] Configure the settings and operations relating to the system [System management] The settings relating to the actions at an error occurrence and auto data deletion from hard disk drives can be configured on this tab. It is also possible to display the logs on this page. In addition, general maintenance, such as license registration, setting initialization and firmware upgrade, can be performed on this tab.
Page 73 [Setup via recorder's main monitor] Note: BEFORE TIME CHANGE MANUALLY: Before the • Alarm reset input, network error output, and system clock has been changed recorder error output can be set to either one of AFTER TIME CHANGE MANUALLY: Just after the the General purpose I/O terminals.
Page 74 [Setup via recorder's main monitor] [Load data (from USB medium)] [Other] Loads the setting data saved on a USB medium The special [Functions for maintenance] screen (external storage device) into the recorder. Click the appears. (☞ Page 73) [Execute >] button to display confirmation window to start loading.
Page 75 [Setup via recorder's main monitor] Execute functions for special maintenance and service [Other] Adjusts the date and time on the camera side to the monitoring system or reboots the monitoring system. [Clear the maximum temperature record information.] Clears the highest temperature record information. [Reset the maximum PoE total power supply information] Reset the maximum PoE total power supply...
Page 76: Manage The Hard Disk Drives [Hdd Management]
[Setup via recorder's main monitor] Manage the hard disk drives [HDD management] The operations relating to the hard disk drives such as checking the capacity of each recording area and formatting the drives can be performed on the "HDD management" page of the setup menu - the "Advanced setup"...
Page 77: Check The Hard Disk Drive Information [General]
[Setup via recorder's main monitor] Check the hard disk drive information [General] The capacities, operation time and statuses of the hard disk drives are displayed. Refer to the setup menu - the "Advanced setup" menu - the "Maintenance" page - the [HDD information] tab for further information about the items displayed on the [HDD information] tab.
Page 78: About The Removal Process And The Link Process Of Hard Disk Drives
[Setup via recorder's main monitor] About the removal process and the link process of hard disk drives When replacing the HDD, you need to remove the HDD before replacing it. When the status of the replaced HDD is "Playback-only", in addition to the formatting of the HDD, it can be made into a recordable HDD by embedded processing.
Page 79: About The Change Of The Hdd Operational Mode
[Setup via recorder's main monitor] About the change of the HDD operational mode About the HDD operational mode Single mode: Images and audio from the cameras will be recorded on the HDD of this product. Mirroring mode: The same images and audio from the cameras will be recorded on the 2 HDDs of this product.
Page 80: Configure The Security Settings [Security]
[Setup via recorder's main monitor] Configure the security settings [Security] Set the security settings on the security function page of [Advanced setup] on the setup menu. ■ Security between this product and PC [Connection] Connect the recorder and the PC with the HTTPS. Set the connection method between this product and The HTTPS encodes the access to the recorder and the camera.
Page 81: Lists Of The Setting Items (Setup Menu)
Lists of the setting items (Setup menu) Quick setup (Easy Start) Setting item (including those of the Available range Default "Advanced setup" menu) Date & time adjustment 2022/1/1 0:00 ~ 2046/12/31 23:59 20nn/mm/1 0:00 ("nn" and "mm" are calculated base on the serial number of the recorder.) Set time zone GMT-12:00, GMT-11:00, GMT-10:00, GMT-9:00,...
Page 82 Menu/Tab Setting item (including those of the Available range Default Remarks "Advanced setup" menu) ◎ Date & time Time zone Start/End date and time 1/1 00:00 ~ 12/31 23:59 In: --/-- --:-- settings (Designate by date) In/Out Out: --/-- --:-- ◎...
Page 83 Menu/Tab Setting item (including those of the Available range Default Remarks "Advanced setup" menu) Camera setup Transmission Priority setting Image quality priority, Frame priority rate priority Setting items Checked/Not checked (Burst tolerance level) Burst tolerance level High, Middle, Low Setting items Checked/Not checked (Control time period) Control time period...
Page 84 Menu/Tab Setting item (including those of the Available range Default Remarks "Advanced setup" menu) Camera setup Intelligent auto Intelligent auto Off, On Camera selection Checked/Not checked VMD alarm VMD alarm Off, On Detection sensitivity 1(Low), 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15(High) Camera selection Checked/Not checked...
Page 85 Menu/Tab Setting item (including those of the Available range Default Remarks "Advanced setup" menu) ◎ Recording Schedule1 Schedule Time table1- --:--, 00:00 - 24:00 Schedule bar 1: setup Advanced to record Schedule bar 00:00 - 24:00 setup Schedule bar 2 ~ Schedule bar 6: --:-- - --:-- ◎...
Page 86 Menu/Tab Setting item (including those of the Available range Default Remarks "Advanced setup" menu) ◎ Recording Schedule2 ~ Schedule Time table2- Checked/Not checked Not checked setup Schedule16 to record e-Mail Advanced ◎ Time table2- Checked/Not checked Not checked setup Alarm notification Display the (Indication only)
Page 87 Menu/Tab Setting item (including those of the Available range Default Remarks "Advanced setup" menu) ◎ Event setup Alarm action Output duration 0 s, 2 s, 5 s, 10 s, 20 s, 30 s, 1 min, Ext., Rec. ◎ Buzzer duration 0 s, 2 s, 5 s, 10 s, 20 s, 30 s, 1 min, Ext., Rec.
Page 88 Menu/Tab Setting item (including those of the Available range Default Remarks "Advanced setup" menu) ◎ Advanced Recording mode Off, On setup ◎ Alarm disarm duration 2 s, 3 s, 5 s, 10 s ◎ TCP alarm port number (Port No.) 1818 ◎...
Page 89 Advanced setup Menu/Tab Setting item (including those of the Available range Default Remarks "Advanced setup" menu) Monitor ◎ Main monitor Camera title Display Off, On ◎ Position L-Upper, L-Lower, R-Upper, R-Upper R-Lower ◎ Camera title (Text will be entered.) •NU300/NU301 CAM1, …, CAM16 •NU201 CAM1, …, CAM8...
Page 90 Menu/Tab Setting item (including those of the Available range Default Remarks "Advanced setup" menu) ◎ Sub monitor Camera title Display Off, On ◎ Display settings Mode •NU300/NU301 1-screen live 1-screen live sequence, sequence 4-screen live sequence, 9-screen live sequence, Switch by alarm terminal input, 16Screen •NU201 1-screen live sequence,...
Page 91 Menu/Tab Setting item (including those of the Available range Default Remarks "Advanced setup" menu) ◎ TCP alarm TCP alarm Port number(to PC) (Port No.) 1818 notification notification ◎ Retry 0, ..., 8 ◎ Destination address (Text will be entered.) (Blank) (Address) ◎...
Page 92 Menu/Tab Setting item (including those of the Available range Default Remarks "Advanced setup" menu) ◎ Basic User level Search and playback Checked/Not checked Manager: (Checked, settings Fixed) Operator: Checked Viewer: Checked Logged out: (Not checked, Fixed) ◎ Copy Checked/Not checked Manager: (Checked, Fixed) Operator: Not checked...
Page 93 Menu/Tab Setting item (including those of the Available range Default Remarks "Advanced setup" menu) ◎ Administrator Edit Administrator name (Text will be entered.) (Blank) setup administrator ◎ Password (Text will be entered.) (Blank) information ◎ Password (Retype) (Text will be entered.) (Blank) ◎...
Page 94 Menu/Tab Setting item (including those of the Available range Default Remarks "Advanced setup" menu) ◎ Capacity (Indication only) (Indication only) information ◎ Operation (Indication only) (Indication only) ◎ Status (Indication only) (Indication only) ◎ Recorded time range (Indication only) (Indication only) ◎...
Page 95 Menu/Tab Setting item (including those of the Available range Default Remarks "Advanced setup" menu) ◎ System Functions for Clear the maximum (None) (None) management maintenance temperature record information. ◎ Reset the maximum (None) (None) PoE total power supply information ◎ Measure the network (None) (None)
Page 96 Menu/Tab Setting item (including those of the Available range Default Remarks "Advanced setup" menu) Security function ◎ Communication Security Connection HTTP & HTTPS, HTTPS HTTPS between this ◎ TLS 1.2 Checked/Not checked Checked, Fixed product and PC ◎ TLS 1.3 Checked/Not checked Checked, Fixed ◎...
Page 97: About The Error Logs And The Network Logs
About the error logs and the network logs Error logs This section describes the display contents on the status display panel of the main monitor, the logs of error occurrence (error logs) and their details. The display contents of each error logs are common between the main monitor and the web browser. •...
Page 98 Output from Display of the status display Description Error log panel connector Line speed warning (when Auto setting Line speed warning Line speed warning: PC port Network error is set to Half) When time is not adjusted due to the Skip time adjustment Skip time adjustment –...
Page 99: About The Network Log
About the network log This section describes the details on the network logs and their details. The network logs are displayed by selecting the "Maintenance" page - [System management] tab - [Network log] on the setup menu. Contents to be displayed are the same as when using the web browser. Description Network log E-mail transmission complete...
Page 100: Operation Window
[Operation via recorder's main monitor] Operation window The recorder can be operated using the included mouse connected to the mouse connection port on the recorder. When operating the recorder using a web browser, refer to "Network" (☞ Page 151). Main monitor (A monitor to display the live image, the playback image and the setup menu) The main monitor is used to switch between the control screen and the wide view.
Page 101 [Operation via recorder's main monitor] Wide view display This view offers a large image display area, especially suited for monitoring live images. However, operations are restricted. ① ② ③ ④ ① Image display area ③ Operation panel Displays images from the camera. (☞ Page 107) Switches between screens and screen patterns, playback recordings and so on.
Page 102 [Operation via recorder's main monitor] Image display area The number of images that can be displayed on the multiscreen differs for the control screen and the wide view screen. Note: • It is possible to select whether to display or hide the wide view multi-screen selection button. Refer to the "Set up the main monitor"...
Page 103 [Operation via recorder's main monitor] About the status display panel Normal operation ② ③ In case of alarm/error (When the associated buttons are displayed) ① ② ④ ⑤ ③ ⑥ ⑦ ⑧ ① Status display area Recorder status indications and their details are shown in the table below. In the event that the recorder enters several statuses at the same time, these are displayed in their order of priority.
Page 104: Sub Monitor (Monitor For Display Of Live Images Only)
[Operation via recorder's main monitor] ④ Alarm log display button The alarm log are displayed on the operation panel of the control screen. Up to 1000 alarm logs are saved. When more than 1000 logs are filed, the older logs will be overwritten by the newer logs. In this case, the oldest log is the first to be overwritten.
Page 105: Basic Operations
[Operation via recorder's main monitor] Basic operations To operate, use the mouse connected to the recorder to move the mouse cursor displayed on the main monitor and left-click the buttons or tabs displayed on the screen. (Hereinafter, "Left-click..." will be described as "Click..."...
Page 106: Login Operation At Startup
[Operation via recorder's main monitor] Login operation at startup When "Off" is selected for "Auto login" (☞ Page 63), the recorder will start up in the logged-out state after completing the system check. When the operation window is displayed on the main monitor, enter a user name and password as follows: Note: Step 1 •...
Page 107: Monitor Live Images
[Operation via recorder's main monitor] Monitor live images When the recorder started up, live images from cameras will be displayed according to the configured settings. Live images from cameras are displayed via the recorder. Image data Network cameras Main monitor (HDMI) Recorder Sub monitor (HDMI) It is possible to display live images on a 1-screen or on a multiscreen.
Page 108 [Operation via recorder's main monitor] Multiscreen buttons The buttons switch the number of split screens in the image display area. Digital zoom buttons When displaying images on a 1-screen or 4-screen, the images can be enlarged/reduced. (☞ Page 116) Mute button Each click of this button toggles between mute and mute cancel of the camera audio.
Page 109 [Operation via recorder's main monitor] Wide view operation panel Camera number panel Multiscreen buttons Camera number panel Note: Camera number [CAM]: • During the sequence, the dragging & dropping of (Character color) the camera number panel onto live images can't White: Camera is registered (in the switch over camera images.
Page 110 [Operation via recorder's main monitor] Change the camera display position on the screen The default camera display positions are as follows: 1-screen 4-screen 6-screen 9-screen ※1 ※1 12-screen ※2 16-screen ※2 3-screen 9-screen ※1 16-screen 3-screen 4-screen 2-screen ※2 9 10 3-screen 4-screen 5-screen...
Page 111 [Operation via recorder's main monitor] If the compression method of the registered camera is JPEG, then depending on the resolution setting and operational configuration, it may not be possible to display live images in multiple screens. Main monitor (1080p monitor connection) [No sub-monitor display, no re-encoding transmission] Image capture size HVGAW(640×360) ～...
Page 112 [Operation via recorder's main monitor] [Sub-monitor display or re-encoding transmission available] Image capture size HVGAW(640×360) ～ QXGA(2048×1536) ～ 6M(3328×1872) ～ FHD(1920×1080) 5M(3072×1728) 9M(2992×2992) Multiscreen display ○ ○ ○ 1-screen display ○ ○ × 2-screen display 3-screen, 4-screen display ○ ○* ×...
Page 113: Switch Between Control Screen And Wide View Screen
[Operation via recorder's main monitor] Switch between control screen and wide view screen Camera images will be displayed on a full screen. [Wide view] button of the control screen [Ctrl screen] button of the wide view screen Step 1 Note: •...
Page 114: 1-Screen Display
[Operation via recorder's main monitor] 1-screen display Live images from cameras can be displayed on a 1-screen. Displaying images on a control screen camera number panel, select it on the camera Step 1 number tab and move to Step 2. When displaying in a multi-screen, click the 1-screen button of the "Multiscreen select".
Page 115: Display Images From Cameras On A Multiscreen
[Operation via recorder's main monitor] Display images from cameras on a multiscreen Live images from cameras can be displayed on a multiscreen. Displaying images on a control screen Note: Step 1 • After having switched from multiscreen display to Click one of the [Multiscreen select] buttons. 1-screen display, double-clicking the image →...
Page 116: Use Digital Zoom
[Operation via recorder's main monitor] Use digital zoom Images on the 1-screen or 4-screen of the control screen, or the 1-screen in wide view can be digitally zoomed. It is also possible to move the zoomed area within the displayed image. Displaying images on a control screen Note: •...
Page 117: Correct The Fisheye Image
[Operation via recorder's main monitor] Correct the fisheye image The Fisheye image can be corrected and displayed while the fisheye image is displayed on the 1-screen in the image display area of the control screen. Note: • The fisheye correction display is not available in wide view and on the multiscreen. The fisheye correction display button is not displayed.
Page 118: Operate The Camera
[Operation via recorder's main monitor] Operate the camera When displaying live images from a camera with the panning/tilting function on a 1-screen or 4-screen, the following camera operations are available. Note: • It may be impossible to operate the camera or some functions may be inoperable depending on the model of the camera.
Page 119 [Operation via recorder's main monitor] [Position] [Setup] button Registers the current orientation of the camera as a Displays the camera setup window for registering a preset position. Moves the camera to a previously home position (☞ Page 121), executing auto back registered preset position.
Page 120 [Operation via recorder's main monitor] Camera operation is as follows. Note: • For 4-screen display, select the camera to be operated. Function Function Description Operation Pan/Tilt Adjusts the horizontal/ Click the control button on the camera control panel. Also, if you have vertical position of the checked "Operate camera with mouse", when you click the position in camera image.
Page 121 [Operation via recorder's main monitor] Function Function Description Operation Preset move Moves the camera Click the [▲]/[▼] buttons for ""Preset"" on the advanced camera control orientation to the panel, select a preset number (0 to 256), and click the [Move] button. position preset in the Note preset registration.
Page 122 [Operation via recorder's main monitor] Function Function Description Operation Mask area setup Sets the mask area of Click the [Set] button on the advanced camera control panel. When you the camera. click the [Start] button in [Mask area] on the displayed camera setup screen, a grid-like boundary line is displayed in the image display area, and the squares set as the mask area become white and translucent.
Page 123: Event Function
[Operation via recorder's main monitor] Event function The recorder will take an event action when any of the following events occur. • Terminal alarm: An event when an alarm input signal is supplied from an external device such as a door sensor to the alarm input terminal on the rear of the recorder.
Page 124: Stop Buzzer Beeping
[Operation via recorder's main monitor] Event action Description Mode* Alarm action Send a mail that notifies of An e-mail notifying of the event and its date & time × × ● an event occurrence (alarm mail) will be sent to registered e-mail addresses (up to 4).
Page 125: Cancel The Alarm Action
[Operation via recorder's main monitor] Cancel the alarm action The recorder will take an alarm action according to the settings configured in advance when an event occurs in the alarm mode (ALM). Information of the occurred alarm will be displayed on the status display panel of the main monitor.
Page 126: Record Images
[Operation via recorder's main monitor] Record images Live images can be recorded on the recorder. The image of 4 to 16 cameras can be recorded in the recorder. Network cameras Image data Recorder Record images (Schedule recording) Recording can be automatically started and stopped according to a previously specified schedule. Refer to page 40 for schedule recording.
Page 127: Emergency Recording
[Operation via recorder's main monitor] Emergency recording The recording is manually done using a switch connected to the "Emergency recording input" terminal of the "ALARM/CONTROL connector" on the back side of the recorder when the emergency occurs. For example, you can install a switch into the reception of the store and press the switch for the emergency recording when a suspicious person appears.
Page 128: Play Recorded Images
[Operation via recorder's main monitor] Play recorded images Display the images recorded on the recorder’s hard disk on the main monitor. Playback operation can be made while recording. Playback of images can be controlled from the operation display area or the wide view. Refer to page 133 and following pages for playback operation.
Page 129 [Operation via recorder's main monitor] Main monitor (4K monitor connection) [No sub-monitor display, no re-encoding transmission] Image capture size 6M(3328×1872) ～ HD(1280×720) FHD(1920×1080) 9M(2992×2992) Multiscreen display 1-screen display (N/A) (N/A) 2-screen display (N/A) No display 3-screen, 4-screen display 30 ips No display [Sub-monitor display or re-encoding transmission available] Image capture size...
Page 130: Playback Operation Panel
[Operation via recorder's main monitor] Playback operation panel In playback mode, operation buttons are displayed on the playback operation panel. In addition to the operation buttons, the playback operation panel displays the playback status. Normal status (during display of live images) Image playback status Playback pause status Wide view playback status (Image playback status)
Page 131 [Operation via recorder's main monitor] Function Example Operation Next image/Previous When the next image button is clicked during pausing, the next image button frame is played and paused. When the previous image button is clicked during a pause, the previous frame is played and paused. Note: •...
Page 132 [Operation via recorder's main monitor] About captured images The images captured by clicking the image capture button and saved on a USB medium will not be displayed with this recorder. To display those images on a PC monitor, the data format and destination to save are as follows: File format for recorded images: JPEG (DPOF-compatible) Destination to save: USB storage...
Page 133: Play Images From A Designated Point
[Operation via recorder's main monitor] Play images from a designated point It is possible to start playback from a designated date & time or the latest recorded image. Play image recorded at a designated date & time Start playback by designating the date & time of a recorded image on the date & time operation panel. Date &...
Page 134: Play The Latest Recorded Image
[Operation via recorder's main monitor] Play the latest recorded image When this button is clicked, playback of the latest recorded images will start. The starting point is around 10 seconds before the date & time of the latest recorded images. Date &...
Page 135: Playback By Designating A Timeline
[Operation via recorder's main monitor] Playback by designating a timeline When playback starts, the date & time operation panel will change to playback display. This section explains how to use the timeline display to designate a playback date & time by operating the playback slider.
Page 136 [Operation via recorder's main monitor] • The time-saving playback only functions when the [Display range selection] button image is played back at the actual size on The timeline will be displayed in accordance with the 1-screen ~ 4-screen. setting of the scale selection button. •...
Page 137: Search And Play
[Operation via recorder's main monitor] Search and play Search a desired recorded image and play it. There are the following 3 searching methods. • Play images selected from alarm and error logs (Log search) • Display thumbnail screen and paly back (Thumbnail search) •...
Page 138: Display Thumbnail Screen And Paly Back (Thumbnail Search)
[Operation via recorder's main monitor] Step 4 To stop playback and return to live images, click the stop button on the playback operation panel. (☞ Page 130) → Playback will stop, and live images will be → displayed. Display thumbnail screen and paly back (Thumbnail search) Search a thumbnail from the recorded images and play back.
Page 139: Search And Play Recorded Images Triggered By Motion Detection (Vmd Search)
[Operation via recorder's main monitor] Step 6 Step 7 Click a thumbnail that you want to play and then click To stop playback and return to live images, click the the playback button on the playback operation panel. stop button on the playback operation panel. →...
Page 140 [Operation via recorder's main monitor] Step 4 Step 6 Click the [Search] button. To stop playback and return to live images, click the → This will run a VMD search within the designated → stop button on the playback operation panel. search range and display a list of results as follows.
Page 141 [Operation via recorder's main monitor] Set up VMD areas, etc. [Filtering] Assign the search area, setup the motion detection area in the image and masking period. Step 1 Click [Search] button on the playback operation panel and click [VMD] tab. (☞ Page 139) Step 2 Select a camera that you want to search on the camera number panel.
Page 142: Copy Recorded Images
[Operation via recorder's main monitor] Copy recorded images Copy the recorded image on the recorder to an external storage device (external HDD, USB memory stick). In this document, these are sometimes referred to as media. Personal information may be included in copied images. Take an extra caution to handle and manage the medium used for copying to prevent from information leakage.
Page 143 [Operation via recorder's main monitor] Note: Step 3 • Images recorded in H.264 or H.265 can be copied Set copying conditions following the instructions on in MP4 format. If audio is recorded in AAC-LC, the the screen. image is copied in MP4 format with audio. Clicking [Next]/[Back] button switches the page.
Page 144 [Operation via recorder's main monitor] • Due to characteristics of the file system, the Step 5 copying time becomes longer as the number of Enter the password using on-screen keyboard, and recording data copied to the external storage then click the [Next] button. device at one time increases.
Page 145: Format Usb Medium
[Operation via recorder's main monitor] Format USB medium USB medium recognizable by the recorder can be formatted by the recorder. Important: • Formatting will delete all data and setup information stored on a USB medium. Image data once deleted cannot be restored. •...
Page 146: Play Back Copied Images With This Recorder
[Operation via recorder's main monitor] Play back copied images with this recorder Display recording images copied to the external storage device (copy data) on the list, select among them and playback. It is possible to search for copied data using filters. Important: •...
Page 147 [Operation via recorder's main monitor] Step 5 Select the line with the desired date & time, and click the playback button on the playback operation panel. → Playback will start from the date & time selected. → If the multiscreen was displayed, it will change to the 1-screen.
Page 148: List Of Operation Items
[Operation via recorder's main monitor] List of operation items The following "Top items" mainly shows operation and "Middle items", "Bottom items" and "Details" mainly show each operation menu of the main monitor and the browser. ○, △ and × indicate operable, partially limited, inoperable respectively. Middle Main Bottom items...
Page 149 [Operation via recorder's main monitor] Middle Main Bottom items Details Remarks Browser items items body ○ ○ Alarm Action to be − − action taken upon an event occurrence Stop buzzer − − ○ × only. ○ ○ Cancel the −...
Page 150 [Operation via recorder's main monitor] Middle Main Bottom items Details Remarks Browser items items body ○ ○ Copy/ Copy − − * The viewer software is copied together Download with the recorded image. Format USB − − ○ × medium △...
Page 151: Configure The Network Settings
[ Setup Network ] Configure the network settings The recorder can be operated using a mouse or from a web browser on a PC (excluding certain functions and settings). On the following pages, operation from a web browser, setting up the PC and related matters will be described.
Page 152 [ Setup Network ] Step 2 Step 4 Click "View network status and tasks". Click [Properties] → The "Network and Sharing Center" window will be → displayed. Step 3 Click "Local Area Connection". → The "Local Area Connection Properties" window →...
Page 153 [ Setup Network ] Step 6 Select [Use the following IP address] and set "IP address" and "Subnet mask" as follows: • IP address: 192.168.0.9 • Subnet mask: 255.255.255.0 Depending on the network configuration, it is necessary to configure "Default gateway". Contact the system administrator for further information about the settings.
Page 154: Network Security Of The Recorder
[ Setup Network ] Network security of the recorder The security function of the recorder ① Access restriction by the user authentication It is possible to restrict users to access the recorder by selecting "On" for "User authentication". (☞ Page 63) ②...
Page 155 [ Setup Network ] [Connection example] Firewall Router Router IP address: 192.168.1.1 Network Subnet mask: 255.255.255.0 IP address: 192.168.0.1 Subnet mask: 255.255.255.0 Switching hub IP address: 192.168.1.100 Subnet mask: 255.255.255.0 Default gateway: 192.168.1.1 Recorder (WJ-NU101K) IP address: 192.168.0.250 Subnet mask: 255.255.255.0 Default gateway: 192.168.0.1...
Page 156: Display The Operation Window
[Operation via PC web browser] Display the operation window Boot the PC and operate the recorder using a web browser. Step 1 Step 3 Start the web browser. Enter the user name and password registered in the recorder, and then click the [Login] button. →...
Page 157: About The Operation Window
[Operation via PC web browser] About the operation window Top Page Status display area Current time display area [Wide view] button Image display area Download operation area [CAM] tab [HDD] tab [Control] tab Image display area Displays operations such as searching for and Playback images and live images will be displayed.
Page 158: Control Panel
[Operation via PC web browser] Control panel The following operation panels will be displayed when the [Control] tab is clicked. List display area [Search] box [Copy] button Use this button to search recorded images. The Select [HDD] for "Disk/Medium" to display this search result will be displayed in the list display area.
Page 159: Camera Selection Panel
[Operation via PC web browser] To display search results or a list of copied data, refer to "Search and play recording events" (☞ Page 171) and "Check a list of copied recorded images" (☞ Page 176), respectively. Note: • To start playback from the beginning of the pre- event recording when the "Pre-event duration"...
Page 160: Setup Panel
[Operation via PC web browser] Setup panel The following setup panel will be displayed when the [Setup] tab is clicked. The settings such as the date & time display of the recorder can be configured. Refer to the "Setup via recorder's main monitor" section starting from page 10 for setup items and their further information.
Page 161: Status Display Area
[Operation via PC web browser] Status display area Live/playback status display area Other status display area Recording indicator Live/playback status display area Recording indicator The status of an image (live image/recorded image) Indicates the status of recording. will be displayed. The following information will be : Indicates that recording is being performed.
Page 162: Download Operation Area
[Operation via PC web browser] Download operation area [Start]/[End] setup [Start]/[End] setup [Viewer] button Specify the time range for downloading images and Download the viewer software for playing the audio by setting a start and end time. This operation downloaded images and audio. is available only during playback on a 1-screen.
Page 163: Monitor Live Images
[Operation via PC web browser] Monitor live images Live images will be displayed in the web browser window on a 1-screen. It is possible to display live images to expand the image display area across the full screen. Important: • Cameras with the recording resolution set to JPEG will not be displayed. •...
Page 164: Operate The Camera
[Operation via PC web browser] Operate the camera When displaying live images from a camera with the panning/tilting function, the following camera controls are available. It may be impossible to operate the camera or some functions may be inoperable depending on the model of the camera.
Page 165 [Operation via PC web browser] Function Function Description Operation Auto mode Activates the Auto mode Select "Auto mode" as the operation mode and click the [▼] button to function set in the select the following camera's auto mode. Click the [START] button to camera.
Page 166: Event Function
[Operation via PC web browser] Event function The recorder will take an event action when any of the following events occur. Terminal alarm: An event when an alarm input signal is supplied from an external device such as a door sensor to the alarm input terminal on the rear of the recorder. Camera site alarm: An event when an alarm (camera terminal alarm, etc.) is detected by a camera.
Page 167: Cancel The Alarm Action
[Operation via PC web browser] Cancel the alarm action To cancel the alarm action manually, click the [ALM] button in the status display area. → The alarm action will be canceled. The event recording will stop and return to the operational status just →...
Page 168: Play Recorded Images
• The maximum number of browser connections that can play simultaneously is two. The number of connections includes the number of mobile regenerations of the i-PRO Mobile APP smartphone application. When two browsers are running, a user at the same level cannot run a third browser. When using a sub- monitor, the maximum number of connections is limited to one.
Page 169 [Operation via PC web browser] About playback operation The following operations are available during playback: Function Example Operation [Play]/[Rev play] button • Plays recorded images. • Plays back recorded images in reverse. * Playback and reverse playback may not work when the [Play] or [Rev play] button is clicked while recording images at a lower frame rate.
Page 170: Play Image Recorded At A Designated Date & Time
[Operation via PC web browser] Play image recorded at a designated date & time Start playback by designating the desired date & time of a recorded image. Playback operation can be made while recording. Step 1 Click the [Cam. select] tab on the top page of the operation window, and select a camera for playback from the camera selection box.
Page 171: Search And Play Recording Events (Rec Event Search)
[Operation via PC web browser] Search and play recording events (REC event search) Search the recording event list for a recording event and play it back. Important: • To use recording event search, "HDD" must be selected for [Disk/Medium]. It is also possible to filter recording events using the search filters. SD backup rec.
Page 172 [Operation via PC web browser] [HDD] Step 3 The hard disk drive number in which the Click the [OK] button. corresponding recorded images are stored will be → "FILTERING" appears in the status display area, → displayed. and the filtered result will be displayed in the list display area.
Page 173: Copy Recorded Images
[Operation via PC web browser] Copy recorded images Copy the recorded image on the recorder to an external storage device (external HDD, USB memory stick). Refer to page 142 for further information about the copy function. Refer to page 178 for information on how to play copied images.
Page 174 [Operation via PC web browser] [Password] Important: To copy with password protection, mark the • When copying to an external storage device is corresponding checkbox and enter a password. (5 to being performed, do not disconnect the external 8 alphanumeric characters) The password will be storage device.
Page 175: Download Recorded Images Currently Being Played
[Operation via PC web browser] Download recorded images currently being played Designate the start point and the end point of recorded images currently being played and download images to a PC. When a playback image is downloaded, it is downloaded as an image data file (file name .n3r) and a sound data file (file name .n3a).
Page 176: Check A List Of Copied Recorded Images
[Operation via PC web browser] Check a list of copied recorded images Display a list of data (recorded images) copied on the external storage device and confirm them. It is possible to search for copied data using filters. Available filters are "Date & time range" and "Camera". [Date &...
Page 177 [Operation via PC web browser] [Refresh] button Updates the list to the latest one. [Prev page (<)] button Displays the previous page. [Next page (>)] button Displays the next page. [Date] Start time of recording will be displayed. [Cam] The camera number of the recorded data will be displayed.
Page 178: Play Back The Copied/Downloaded Images On A Pc
[Operation via PC web browser] Play back the copied/downloaded images on a PC The original file or MP4 file is copied to the destination when the playback image is copied or downloaded. It is possible to play, save and print the copied/downloaded data files using the dedicated viewer software. The MP4 file can be played on the general playback software.
Page 179: How To Use The Viewer Software
[ Viewer software ] How to use the viewer software To start the viewer software, double-click the executable file (NX_Viewer.exe) in the external storage device if you copied it to an external storage device, or the executable file in the extracted folder if you downloaded it from a web browser.
Page 180 [ Viewer software ] Select playback images • Do not change the file name of the copied or Step 1 downloaded image data. If the file name is Click the [ ] button. changed, the file information will not be displayed →...
Page 181 The fast playback speed may be limited depending on the performance of the PC in use or process status. Plays the fisheye image of the fisheye network camera (made by i-PRO, hereinafter called "fisheye camera") When you select a fisheye image which can be corrected, the image will be corrected and displayed on 1-screen PTZ/4-screen PTZ.
Page 182 [ Viewer software ] Adjust the volume When the audio data (filename.n3a) is available, a button to adjust the audio will be displayed. Adjusts the volume. Clicking the button can switch the volume in three levels. Toggles Audio playback/Silent. If the audio is controlled or adjusted by another application, the audio may not be played correctly on the viewer software.
Page 183: Setup
[ Setup on browser ] Setup Basic operations Step 1 Step 3 Click the [Setup] tab. Click the button for the desired submenu. Step 4 Configure each setting item. Click the [Set] button after completing the settings. → The settings will be applied. When moving to →...
Page 184: View Oss Licenses
[ Setup on browser ] View OSS licenses Click on "Click here for OSS information." under [Maintenance] - [System management], and the license of the OSS in use will be displayed. Download root certificate Click [Execute >] under "Download root certificate" in [Security] – [Communication] to download the root certificate.
Page 185: Notification By E-Mail
Notification by e-mail Alarm mail The recorder address are indicated in an alarm mail as follows. Contents of the alarm mail (example) In NWDR (192.168.0.250), alarm was occurred. Occurrence date and time: xxxx-xx-xx xx:xx:xx GMT+xx:xx (Example. 2016-11-18 12:00:00 GMT+9:00) Alarm descriptions: Alarm descriptions, camera channel or alarm number will be described.
Page 186 Indication Description Status Camera SD memory write start command CAM xxx SD START ERR error: Camera SD memory write completion CAM xxx SD END ERR command error: Camera SD Image acquisition failure: CAM xxx GET IMG ERR Camera SD Accumulated recording time CAM xxx SD LIFE WARNING (LONG-TERM) warning: Camera SD Overwrite warning:...
Page 187: Troubleshooting
Troubleshooting Before asking for repairs, check the symptoms with the following table. Contact your dealer if a problem cannot be solved even after checking and trying the solution in the table or a problem is not described below. Symptom Cause/solution Reference Recording cannot be performed.
Page 188 Symptom Cause/solution Reference Cannot access from the web • Is the Ethernet cable firmly connected to the 10BASE-T, Installation browser. 100BASE-TX, or 1000BASE-T port on the rear side? Guide Confirm the cable is firmly connected. • Is the connection indicator of the network port lit on the rear side? When it is not lit, connection to a LAN is not Installation...
Page 189 Symptom Cause/solution Reference An error message is displayed when • Decrease the number of the selected files or select files trying to launch the viewer software after launching the viewer software. − by dragging and dropping multiple files onto it. The external storage device is not •...
Page 190 Symptom Cause/solution Reference Copying progress can at times stop • If the data of our network microphone is copied in for a while at 99.9 %, or jump from original format, copying will continue even though 70 ~ 80 % to 100 %. progress remains at 99.9 %, as the calculation error of the audio data is large.
Page 191 Symptom Cause/solution Reference No image is displayed on the HDMI • Does the HDMI output signal format match the monitor. specifications of your monitor? To fix the HDMI output signal format, set the signal format supported by the monitor. • Is an HDMI switcher used between this product and the monitor? It may not work properly depending on the specifications of the HDMI switcher.
Page 192: Glossary
Glossary Bit rate MJPEG Indicates how many bits of data can be processed or Indicates a video format to sequentially transmit transmitted in a unit of time. Generally, the units are in JPEG images from cameras. bps, or bits per second. Used to indicate the Some cameras phrase this video codec as just compression rate of video and audio data, and how "JPEG".
Page 193 Authorised Representative in EU: i-PRO EMEA B.V. Laarderhoogtweg 25, 1101 EB i-PRO Co., Ltd. Amsterdam, Netherlands Fukuoka, Japan i-PRO EMEA B.V. UK Branch 1010 Cambourne Business Park, https://www.i-pro.com/ Cambridgeshire CB23 6DP © i-PRO Co., Ltd. 2022 L1222-0 PGQP3562ZA...

This manual is also suitable for:

Wj-nu201k series Wj-nu300k series Wj-nu301k series

i-PRO WJ-NU101K Series Operating Instructions Manual

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for i-PRO WJ-NU101K Series

Summary of Contents for i-PRO WJ-NU101K Series

This manual is also suitable for:

Table of Contents
