Watchguard AP325 Hardware Manual page 9

AP Firmware 8.8.1 and Higher
LED
Status
Off
Green
Flashing
Green
Orange
Flashing
Orange
AP Firmware 8.8.0 and Lower
LED
Power
LAN1 / PoE
LAN2
2.4 GHz
5 GHz
Third Radio
Hardware Guide
Power
Powered off.
Powered on. Operating at normal
power and capabilities.
(PoE+ or DC power)
Not connected to Wi-Fi Cloud or
paired with a Gateway Wireless
Controller.
Powered on. Operating at reduced
power and capabilities.
(For example: PoE 802.3af)
See AP Power Requirements.
No IP address received from DHCP.
Status
Solid green
Off
Solid green
Fast flash green
Slow flash green
Intermittent flash green
Off
Solid green
Flashing green
Off
Solid green
Intermittent flash green
Solid green
Intermittent flash green
Intermittent flash green
LAN 1 and 2.4 GHz, 5 GHz, and
LAN2 3rd Scanning Radios
No Ethernet Radio inactive.
link.
Connected at Radio active.
10/100/1000
Mbps.
- -
- -
- -
Description
Power On
Power Off
Device connected to LAN1 port at
10/100/1000 Mbps.
Did not receive valid IP address from
DHCP.
Cannot connect to WatchGuard Wi-Fi
Cloud.
Activity on LAN1 port.
No Ethernet link.
Device connected to LAN2 port at
10/100/1000 Mbps.
Activity on LAN2 port.
No Ethernet link.
Client connected to 2.4 GHz radio.
Activity on 2.4 GHz radio.
Client connected to 5 GHz radio.
Activity on 5 GHz radio.
WIPS scanning activity on third radio.
