Mounting Instructions - Watchguard AP325 Hardware Manual

Hardware Specifications

Mounting Instructions

Use the included mounting bracket (15/16", 24mm, Part #: WG8027) to install the AP325 on a ceiling with a
T-rail
Optional T-rail mount brackets are available from WatchGuard:

9/16" T-rail mount, 15mm, Part #: WG8026

Interlude/Silhouette T-rail mount, 15mm, Part #: WG8021
1. Put the first mounting post on the back of the AP over the lower bracket notch and rotate into place.
2. Make sure that all the mounting posts on the back of the AP are securely positioned in their bracket
notches.
3. To attach the bracket to the T-rail, rotate the bracket so it is parallel to the T-rail, and snap the bracket
on the T-rail.
8 WatchGuard AP325
