2.4 Encoder Interface (CON13)

A differential incremental encoder interface is provided for optional closed-loop motor control. For single-
ended encoders, the negative input lines on the motherboard can be connected to signal common (ground),
and the signal lines connected to the positive inputs.

2.5 External Function Interface (CON9)

The external function connector includes additional signal and power rails that can be used for additional
system functionality. These signals may not be utilized in the supplied firmware but are available. All signals
are referenced to control ground and should not be tied to other potentials or high-voltage circuitry without
proper isolation.
PWM_DB
The PWM_DB signal is a 0-5 V digital output signal intended to supply the gate signal for an external dynamic
brake (DB) transistor that can be used in conjunction with a high-power resistor across the DC bus to reduce
the bus voltage during motor braking or regeneration to prevent an overvoltage.
PRECHARGE_RLY
PRECHARGE_RLY is a 0-5 V digital output signal intended to control an external relay bypassing the
precharge resistor for active-front-end (AFE) topologies where the DC bus is charged from the AC mains.
TEMP_EXT
TEMP_EXT is a 0-5 V digital input that can be used for temperature feedback from an external system or
component. It can be implemented as an over-temperature signal (high/low), or as a frequency or duty cycle
