ASROCK P41C-DE Installation Manual
  1. Manuals
  2. Brands
  3. ASROCK Manuals
  4. Motherboard
  5. P41C-DE
  6. Installation manual
ASROCK P41C-DE Installation Manual

ASROCK P41C-DE Installation Manual

Hide thumbs Also See for P41C-DE:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
Copyright Notice:
Copyright Notice:
Copyright Notice:
Copyright Notice:
Copyright Notice:
No part of this installation guide may be reproduced, transcribed, transmitted, or trans-
lated in any language, in any form or by any means, except duplication of documen-
tation by the purchaser for backup purpose, without written consent of ASRock Inc.
Products and corporate names appearing in this guide may or may not be registered
trademarks or copyrights of their respective companies, and are used only for identifica-
tion or explanation and to the owners' benefit, without intent to infringe.
Disclaimer:
Disclaimer:
Disclaimer:
Disclaimer:
Disclaimer:
Specifications and information contained in this guide are furnished for informational
use only and subject to change without notice, and should not be constructed as a
commitment by ASRock. ASRock assumes no responsibility for any errors or omissions
that may appear in this guide.
With respect to the contents of this guide, ASRock does not provide warranty of any kind,
either expressed or implied, including but not limited to the implied warranties or
conditions of merchantability or fitness for a particular purpose. In no event shall
ASRock, its directors, officers, employees, or agents be liable for any indirect, special,
incidental, or consequential damages (including damages for loss of profits, loss of
business, loss of data, interruption of business and the like), even if ASRock has been
advised of the possibility of such damages arising from any defect or error in the guide
or product.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
CALIFORNIA, USA ONLY
The Lithium battery adopted on this motherboard contains Perchlorate, a toxic
substance controlled in Perchlorate Best Management Practices (BMP) regulations
passed by the California Legislature. When you discard the Lithium battery in
California, USA, please follow the related regulations in advance.
"Perchlorate Material-special handling may apply, see
www.dtsc.ca.gov/hazardouswaste/perchlorate"
ASRock Website: http://www.asrock.com
Copyright©2009 ASRock INC. All rights reserved.
ASRock P41C-DE Motherboard
Published October 2009
1 1 1 1 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P41C-DE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ASROCK P41C-DE

Summary of Contents for ASROCK P41C-DE

  • Page 1 ASRock. ASRock assumes no responsibility for any errors or omissions that may appear in this guide. With respect to the contents of this guide, ASRock does not provide warranty of any kind, either expressed or implied, including but not limited to the implied warranties or conditions of merchantability or fitness for a particular purpose.

  • Page 2: Motherboard Layout

    Motherboard Layout PS2_USB_PWR1 Jumper USB 2.0 Header (USB6_7, Blue) 775-Pin CPU Socket BIOS SPI Chip 2 x 240-pin DDR2 DIMM Slots USB 2.0 Header (USB4_5, Blue) (Dual Channel: DDRII_1, DDRII_2; Yellow) Infrared Module Header (IR1) 2 x 240-pin DDR3 DIMM Slots Floppy Connector (FLOPPY1) (Dual Channel: DDR3_A1, DDR3_B1;...
  • Page 3 Line In (Light Blue) PS/2 Keyboard Port (Purple) ** 8 Front Speaker (Lime) * There are two LED next to the LAN port. Please refer to the table below for the LAN port LED indications. LAN Port LED Indications ACT/LINK...
  • Page 4 To enable Multi-Streaming function, you need to connect a front panel audio cable to the front panel audio header. After restarting your computer, you will find “VIA HD Audio Deck” tool on your system. Please follow below instructions according to the OS you install.

  • Page 5: Package Contents

    This Quick Installation Guide contains introduction of the motherboard and step-by-step installation guide. More detailed information of the motherboard can be found in the user manual presented in the Support CD. Because the motherboard specifications and the BIOS software might be updated, the content of this manual will be subject to change without notice.

  • Page 6: Specifications

    - 1 x Coaxial SPDIF Out Port - 1 x Optical SPDIF Out Port - 4 x Ready-to-Use USB 2.0 Ports - 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) 6 6 6 6 6 ASRock P41C-DE Motherboard...
  • Page 7 - HD Audio Jack: Side Speaker/Rear Speaker/Central/Bass/ Line in/Front Speaker/Microphone (see CAUTION 7) Connector - 4 x SATAII 3.0 Gb/s connectors (No Support for RAID and “Hot Plug” functions) (see CAUTION 8) - 1 x ATA100 IDE connector (supports 2 x IDE devices)
  • Page 8 Overclocking may affect your system stability, or even cause damage to the components and devices of your system. It should be done at your own risk and expense. We are not responsible for possible damage caused by overclocking.
  • Page 9 USB flash drive or hard drive must use FAT32/16/12 file system. 13. The software name itself – OC DNA literally tells you what it is capable of. OC DNA, an exclusive utility developed by ASRock, provides a conve- nient way for the user to record the OC settings and share with others.
  • Page 10 15. While CPU overheat is detected, the system will automatically shutdown. Before you resume the system, please check if the CPU fan on the motherboard functions properly and unplug the power cord, then plug it back again. To improve heat dissipation, remember to spray thermal grease between the CPU and the heatsink when you install the PC system.

  • Page 11: Pre-Installation Precautions

    Before you insert the 775-LAND CPU into the socket, please check if the CPU surface is unclean or if there is any bent pin on the socket. Do not force to insert the CPU into the socket if above situation is found.
  • Page 12 775-LAND CPU For proper inserting, please ensure to match the two orientation key notches of the CPU with the two alignment keys of the socket. Step 2-3. Carefully place the CPU into the socket by using a purely vertical motion.

  • Page 13: Installation Of Cpu Fan And Heatsink

    1. It is recommended to use the cap tab to handle and avoid kicking off the PnP cap. 2. This cap must be placed if returning the motherboard for after service. Step 4. Close the socket: Step 4-1. Rotate the load plate onto the IHS.

  • Page 14: Installation Of Memory Modules (Dimm)

    Channel Memory Technology. For dual channel configuration, you always need to install identical (the same brand, speed, size and chip-type) DDR2/DDR3 DIMM pair in the slots of the same color. In other words, you have to install identical DDR2 DIMM pair in Dual Channel (DDRII_1 and DDRII_2; Yellow slots;...

  • Page 15: Installing A Dimm

    Unlock a DIMM slot by pressing the retaining clips outward. Step 2. Align a DIMM on the slot such that the notch on the DIMM matches the break on the slot. The DIMM only fits in one correct orientation. It will cause permanent damage to the motherboard and the DIMM if you force the DIMM into the slot at incorrect orientation.

  • Page 16: Installing An Expansion Card

    2.4 Expansion Slots (PCI and PCI Express Slots) 2.4 Expansion Slots (PCI and PCI Express Slots) There are 2 PCI slots and 4 PCI Express slots on this motherboard. PCI slots: PCI slots are used to install expansion cards that have the 32-bit PCI interface. PCIE slots: PCIE1 / PCIE3 / PCIE4 (PCIE x1 slot) is used for PCI Express cards with x1 lane width cards, such as Gigabit LAN card, SATA2 card, etc.

  • Page 17: Jumpers Setup

    CLRCMOS1 for 5 seconds. However, please do not clear the CMOS right after you update the BIOS. If you need to clear the CMOS when you just finish updating the BIOS, you must boot up the system first, and then shut it down before you do the clear-CMOS action.
  • Page 18 When you mount a FSB800 or FSB1066 CPU, and try to overclock to FSB1333 (by BIOS setting) you may face the problem, that DRAM frequency will be overclocked very high. Please use jumper to force NB to be strapped at higher frequency, so the DRAM can work at lower frequency.
  • Page 19 FDD connector (33-pin FLOPPY1) (see p.2 No. 21) the red-striped side to Pin1 Note: Make sure the red-striped side of the cable is plugged into Pin1 side of the connector. Primary IDE connector (Blue) (39-pin IDE1, see p.2 No. 6)
  • Page 20 HDA to function correctly. Please follow the instruction in our manual and chassis manual to install your system. 2. If you use AC’97 audio panel, please install it to the front panel audio header as below: A.
  • Page 21 Though this motherboard provides 4-Pin CPU fan (Quiet Fan) support, the 3-Pin CPU fan still can work successfully even without the fan speed control function. If you plan to connect the 3-Pin CPU fan to the CPU fan connector on this motherboard, please connect it to Pin 1-3.
  • Page 22 Though this motherboard provides 8-pin ATX 12V power connector, it can still work if you adopt a traditional 4-pin ATX 12V power supply. To use the 4-pin ATX power supply, please plug your power supply along with Pin 1 and Pin 5.
  • Page 23 STEP 2: Connect the SATA power cable to the SATA / SATAII hard disk. STEP 3: Connect one end of the SATA data cable to the motherboard’s SATAII connector. STEP 4: Connect the other end of the SATA data cable to the SATA / SATAII hard disk. Driver Installation Guide...

  • Page 24: Bios Information

    ROM drive. It will display the Main Menu automatically if “AUTORUN” is enabled in your computer. If the Main Menu does not appear automatically, locate and double- click on the file “ASSETUP.EXE” from the BIN folder in the Support CD to display the menus.
  • Page 25 1. Einführung 1. Einführung 1. Einführung Wir danken Ihnen für den Kauf des ASRock P41C-DE Motherboard, ein zuverlässiges Produkt, welches unter den ständigen, strengen Qualitätskontrollen von ASRock gefertigt wurde. Es bietet Ihnen exzellente Leistung und robustes Design, gemäß der Verpflichtung von ASRock zu Qualität und Halbarkeit.

  • Page 26: Spezifikationen

    Spezifikationen Spezifikationen Spezifikationen Spezifikationen Spezifikationen Plattform - ATX-Formfaktor: 30.5 cm x 21.3 cm; 12.0 Zoll x 8.4 Zoll - Festkondensator für CPU-Leistung - LGA 775 für Intel ® Core 2 Extreme / Core 2 Quad / Core 2 Duo / Pentium ®...
  • Page 27 - 1 x optischer SPDIF-Ausgang - 4 x Standard-USB 2.0-Anschlüsse - 1 x RJ-45 LAN Port mit LED (ACT/LINK LED und SPEED LED) - HD Audiobuchse: Lautsprecher seitlich / Lautsprecher hinten / Mitte/Bass / Audioeingang/ Lautsprecher vorne / Mikrofon (siehe VORSICHT 7) Anschlüsse...
  • Page 28 Beachten Sie bitte, dass Overclocking, einschließlich der Einstellung im BIOS, Anwenden der Untied Overclocking-Technologie oder Verwenden von Overclocking-Werkzeugen von Dritten, mit einem gewissen Risiko behaftet ist. Overclocking kann sich nachteilig auf die Stabilität Ihres Systems auswirken oder sogar Komponenten und Geräte Ihres Systems beschädigen.
  • Page 29 Durch Betriebssystem-Einschränkungen kann die tatsächliche ® Speichergröße weniger als 4 GB betragen, da unter Windows 7 / Vista™ / XP etwas Speicher zur Nutzung durch das System reserviert wird. Unter ® Windows OS mit 64-Bit-CPU besteht diese Einschränkung nicht. Der Mikrofoneingang dieses Motherboards unterstützt Stereo- und Mono- Modi.
  • Page 30 USB-Flash-Laufwerk oder die Festplatte das Dateisystem FAT32/16/12 benutzen muss. 13. Allein der Name – OC DNA* – beschreibt es wörtlich, was die Software zu leisten vermag. OC DNA ist ein von ASRock exklusiv entwickeltes Dienstprogramm, das Nutzern eine bequeme Möglichkeit bietet, Übertaktungseinstellungen aufzuzeichnen und sie Anderen mitzuteilen.

  • Page 31: Einstellung Der Jumper

    +5VSB (Standby) zu setzen (siehe S.2 - No. 1) und die PS/2 oder USB- Weckfunktionen zu aktivieren. Hinweis: Um +5VSB nutzen zu können, muss das Netzteil auf dieser Leitung 2A oder mehr leisten können. CMOS löschen (CLRCMOS1, 3-Pin jumper) (siehe S.2, No. 15)
  • Page 32 Wenn Sie die CPU (außer FSB533) zur Nutzung von FSB1066 mit diesem Motherboard übertakten möchten, müssen Sie Steckbrückeneinstellungen ändern. Bitte überbrücken Sie die Pins 4 und 5 der Steckbrücke FSB2 und die Pins 4 und 5 der Steckbrücke FSB3. Andernfalls arbeitet die CPU eventuell nicht richtig mit Ihrem Motherboard.
  • Page 33 (33-Pin FLOPPY1) die rotgestreifte Seite auf Stift 1 (siehe S.2 - No. 21) Hinweis: Achten Sie darauf, dass die rotgestreifte Seite des Kabel mit der Stift 1- Seite des Anschlusses verbunden wird. Primärer IDE-Anschluss (Blauer) (39-pin IDE1, siehe S.2 - No. 6)
  • Page 34 Geräte), wobei jedoch die Bildschirmverdrahtung am Gehäuse HDA unterstützen muss, um richtig zu funktionieren. Beachten Sie bei der Installation im System die Anweisungen in unserem Handbuch und im Gehäusehandbuch. 2. Wenn Sie die AC’97-Audioleiste verwenden, installieren Sie diese wie nachstehend beschrieben an der Front-Audioanschlussleiste: A.
  • Page 35 Obwohl dieses Motherboard einen 24-pol. ATX-Stromanschluss bietet, kann es auch mit einem modifizierten traditionellen 20-pol. ATX-Netzteil verwendet werden. Um ein 20-pol. ATX-Netzteil zu verwenden, stecken Sie den Stecker mit Pin 1 und Pin 13 ein. Installation eines 20-pol. ATX-Netzteils ASRock P41C-DE Motherboard...
  • Page 36 System zu starten. Obwohl diese Hauptplatine 8-Pin ATX 12V Stromanschluss zur Verfügung stellt, kann sie noch arbeiten, wenn Sie einen traditionellen 4-Pin ATX 12V Energieversorgung adoptieren. Um die 4-Pin ATX Energieversorgung zu verwenden, stecken Sie bitte Ihre Energieversorgung zusammen mit dem Pin 1 und Pin 5 ein.
  • Page 37 Erscheint der Wilkommensbildschirm nicht, so “doppelklicken” Sie bitte auf das File ASSETUP.EXE im BIN-Verzeichnis der Support-CD, um die Menüs aufzurufen. Das Setup-Programm soll es Ihnen so leicht wie möglich machen. Es ist menügesteuert, d.h. Sie können in den verschiedenen Untermenüs Ihre Auswahl treffen und die Programme werden dann automatisch installiert.
  • Page 38 être trouvées dans le manuel l’utilisateur qui se trouve sur le CD d’assistance. Les spécifications de la carte mère et le BIOS ayant pu être mis à jour, •le contenu de ce manuel est sujet à des changements sans notification.
  • Page 39 - Prise en charge de la technologie Hyper-Threading (voir ATTENTION 2) - Prend en charge la technologie Untied Overclocking (voir ATTENTION 3) - Prise en charge de la technologie EM64T par le CPU ® Chipsets - Northbridge: Intel - Southbridge: Intel ®...
  • Page 40 - 1 x Port de sortie coaxial SPDIF - 1 x Port de sortie optique SPDIF - 4 x ports USB 2.0 par défaut - 1 x port LAN RJ-45 avec LED (ACT/LED CLIGNOTANTE et LED VITESSE) - Prise HD Audio: Haut-parleur latéral / Haut-parleur arrière / Central /Basses / Entrée Ligne / Haut-parleur frontal /...
  • Page 41 - FCC, CE, WHQL - Prêt pour EuP (alimentation Prêt pour EuP requise) (voir ATTENTION 16) * Pour de plus amples informations sur les produits, s’il vous plaît visitez notre site web: http://www.asrock.com ATTENTION Il est important que vous réalisiez qu’il y a un certain risque à effectuer l’overclocking, y compris ajuster les réglages du BIOS, appliquer la technologie Untied Overclocking, ou...
  • Page 42 Avant d’installer le disque dur SATAII au connecteur SATAII, veuillez lire le Guide « Installation du disque dur SATAII » à la page 28 du « Manuel de l’utilisateur » qui se trouve sur le CD de support pour régler votre lecteur de disque dur SATAII au mode SATAII.
  • Page 43 Pour améliorer la dissipation de la chaleur, n’oubliez pas de mettre de la pâte thermique entre le CPU le dissipateur lors de l’installation du PC.
  • Page 44 Effacer la CMOS, veuillez enlever le capuchon de cavalier. Toutefois, veuillez ne pas effacer la CMOS tout de suite après avoir mis le BIOS à jour. Si vous avez besoin d’effacer la CMOS lorsque vous avez fini de mettre le BIOS à...
  • Page 45 (FSB3, cavalier à 5 broches, voir p.2 N° 29) Réglage standard: Si vous adoptez la configuration DRAM / CPU ci-dessous sur cette carte mère, vous avez besoin de régler les cavaliers. Veuillez suivre les instructions ci-dessous pour configurer les cavaliers. Sinon, le processeur et la mémoire pourraient ne pas fonctionner correctement sur cette carte mère.
  • Page 46 (FLOPPY1 br. 33) (voir p.2 No. 21) le côté avec fil rouge côté Broche1 Note: Assurez-vous que le côté avec fil rouge du câble est bien branché sur le côté Broche1 du connecteur. Connecteur IDE primaire (Bleu) (IDE1 br. 39, voir p.2 No. 6)
  • Page 47 1. L’audio à haute définition (HDA) prend en charge la détection de fiche, mais le fil de panneau sur le châssis doit prendre en charge le HDA pour fonctionner correctement. Veuillez suivre les instructions dans notre manuel et le manuel de châssis afin installer votre système.
  • Page 48 (voir p.2 No. 32) ien que cette carte mère offre un support de (Ventilateur silencieux) ventilateur de CPU à 4 broches , le ventilateur de CPU à 3 broches peut bien fonctionner même sans la fonction de commande de vitesse du ventilateur.
  • Page 49 Bien que cette carte mère possède 8 broches connecteur d’alimentation ATX 12V, il peut toujours travailler si vous adoptez une approche traditionnelle à 4 broches ATX 12V alimentation. Pour utiliser l’alimentation des 4 broches ATX, branchez votre alimentation avec la broche 1 et la broche 5.

  • Page 50: Informations Sur Le Cd De Support

    BIOS après le POST, veuillez redémarrer le système en pressant <Ctl> + <Alt> + <Suppr>, ou en pressant le bouton de reset sur le boîtier du système. Vous pouvez également redémarrer en éteignant le système et en le rallumant.

  • Page 51: Contenuto Della Confezione

    Grazie per aver scelto una scheda madre ASRock P41C-DE, una scheda madre affidabile prodotta secondo i severi criteri di qualità ASRock. Le prestazioni eccellenti e il design robusto si conformano all’impegno di ASRock nella ricerca della qualità e della resistenza.
  • Page 52 1.2 Specifiche Specifiche Specifiche Specifiche Specifiche Piattaforma - ATX Form Factor: 12.0-in x 8.4-in, 30.5 cm x 21.3 cm - Condensatore solido per alimentazione CPU ® Processore - LGA 775 per Intel Core 2 Extreme / Core 2 Quad / Core ®...
  • Page 53 - 4 x porte USB 2.0 già integrate - 1 x porte LAN RJ-45 con LED (LED azione/collegamento e LED velocità) - Connettore HD Audio: cassa laterale / cassa posteriore / cassa centrale / bassi / ingresso linea / cassa frontale / microfono...
  • Page 54 * Per ulteriori informazioni, prego visitare il nostro sito internet: http://www.asrock.com AVVISO Si prega di prendere atto che la procedura di overclocking implica dei rischi, come anche la regolazione delle impostazioni del BIOS, l’applicazione della tecnologia Untied Overclocking Technology, oppure l’uso di strumenti di overclocking forniti da terzi. L’overclocking può...
  • Page 55 (dischi floppy) o altre complicate utilità Flash. Si prega di notare che l’unità Flash USB o il disco rigido devono usare il File System FAT32/16/ 13. Il nome stesso del software – OC DNA – dice di cosa è capace. OC DNA, una utilità esclusiva sviluppata da ASRock, fornisce un modo comodo per registrare le impostazioni OC e condividerle con gli altri.
  • Page 56 Intel l’alimentatore predisposto EuP deve soddisfare lo standard secondo cui l’efficienza energetica in standby di 5 v è più alta del 50% con un consumo di corrente di 100 mA. Per la scelta di un’alimentatore predisposto EuP consigliamo di verificare ulteriori dettagli con il produttore.
  • Page 57 +5VSB (standby) e (vedi p.2 Nr. 1) abilitare PS/2 o USB wake up events. Nota: Per selezionare +5VSB, si richiedono almeno 2 Ampere e il consumo di corrente in standby sarà maggiore. Resettare la CMOS (CLRCMOS1) (vedi p.2 item 15)
  • Page 58 è necessario regolare i ponticelli (jumper). Mettere in corto i piedini 4, 5 per il ponticello FSB2 ed i piedini 4, 5 per il ponticello FSB3. In caso contrario la CPU potrebbe non funzionare correttamente su questa scheda madre.
  • Page 59 (33-pin FLOPPY1) (vedi p.2 Nr. 21) Lato del Pin1 con la striscia rossa Nota: Assicurarsi che il lato del cavo con la striscia rossa sia inserito nel lato Pin1 del connettore. Connettore IDE primario (Blu) (39-pin IDE1, vedi p.2 Nr. 6)
  • Page 60 1. La caratteristica HDA (High Definition Audio) supporta il rilevamento dei connettori, però il pannello dei cavi sul telaio deve supportare la funzione HDA (High Definition Audio) per far sì che questa operi in modo corretto. Attenersi alle istruzioni del nostro manuale e del manuale del telaio per installare il sistema.
  • Page 61 Sebbene la presente scheda madre disponga di un supporto per ventola CPU a 4 piedini (ventola silenziosa), la ventola CPU a 3 piedini è in grado di funzionare anche senza la funzione di controllo della velocità della ventola. Se si intende collegare la ventola CPU a 3 piedini al connettore della ventola CPU su questa scheda madre, collegarla ai piedini 1-3.
  • Page 62 ATX 12V, l‘unita‘ puo‘ ancora essere funzionante se viene utilizzata una fornitura elettrica tradizionale a 4-pin ATX 12V. Per usare tale fornitura elettrica 4-pin ATX 12V, prego collegare la presa elettrica al Pin 1 e Pin 5. Installazione elettrica 4-Pin ATX 12V...
  • Page 63 BIOS; altrimenti, POST continua con i suoi test di routine. Per entrare il BIOS Setup dopo il POST, riavvia il sistema premendo <Ctl> + <Alt> + <Delete>, o premi il tasto di reset sullo chassis del sistema. Per informazioni più dettagliate circa il Setup del BIOS, fare riferimento al Manuale dell’Utente (PDF file) contenuto nel cd di...

  • Page 64: Contenido De La Caja

    ASRock. Esta Guía rápida de instalación contiene una introducción a la placa base y una guía de instalación paso a paso. Puede encontrar una información más detallada sobre la placa base en el manual de usuario incluido en el CD de soporte.
  • Page 65 1.2 Especificación Especificación Especificación Especificación Especificación Plataforma - Factor forma ATX: 30,5 cm x 21,3 cm, 12,0” x 8,4” - Condensador sólido para alimentación de CPU ® Procesador - LGA 775 para Intel Core 2 Extreme / Core 2 Quad / Core 2 Duo / Pentium ®...
  • Page 66 - 4 x puertos USB 2.0 predeterminados - 1 x Puerto LAN RJ-45 con LED (LED de ACCIÓN/ENLACE y LED de VELOCIDAD) - Conexión de audio: Altavoz lateral / Altavoz trasero / Central/Bajos / Entrada de línea / Altavoz frontal / Micrófono (ver ATENCIÓN 7)
  • Page 67 ADVERTENCIA Tenga en cuenta que hay un cierto riesgo implícito en las operaciones de aumento de la velocidad del reloj, incluido el ajuste del BIOS, aplicando la tecnología de aumento de velocidad liberada o utilizando las herramientas de aumento de velocidad de otros fabricantes.
  • Page 68 * Al usar un FSB533-CPU en esta placa base, se ejecutara a DDR3 533 si adquiere un modulo de memoria DDR3 800. * Si adopta un módulo de memoria de DDR3 1333 / DDR2 1066 en esta placa base, necesita a ajustar los jumpers. Por favor consulte a la página 71 para una correcta configuración de los jumpers.
  • Page 69 ASRock Instant Flash. Ejecute esta herramienta y guarde el archivo correspondiente al sistema BIOS nuevo en su unidad flash USB, unidad de disco flexible o disco duro para poder actualizar el BIOS con sólo pulsar un par de botones, sin necesidad de preparar un disco flexible adicional ni utilizar complicadas utilidades de programación.
  • Page 70 3 para habilitar +5VSB (vea p.2, N. 1) (standby) para PS/2 o USB wake up events. Atención: Para elegir +5VSB, se necesita corriente mas que 2 Amp proveida por la fuente de electricidad. Limpiar CMOS (CLRCMOS1, jumper de 3 pins) (ver p.2, No.
  • Page 71 Por favor, cortocircuite el pin 4 y el pin5 para el puente FSB2 y el pin4 y el pin5 para el puente FSB3. Si no lo hace así, puede que la CPU no funcione adecuadamente en esta placa base. Por favor, consulte las siguientes configuraciones de puente.
  • Page 72 (vea p.2, N. 21) la banda roja debe quedar en el mismo lado que el contacto 1 Atención: Asegúrese que la banda roja del cable queda situado en el mismo lado que el contacto 1 de la conexión. IDE conector primario (Azul) (39-pin IDE1, vea p.2, N.
  • Page 73 2. Si utiliza el panel de sonido AC’97, instálelo en la cabecera de sonido del panel frontal de la siguiente manera: A. Conecte Mic_IN (MIC) a MIC2_L.
  • Page 74 Si pretende enchufar el ventilador de procesador de 3 contactos en el conector del ventilador de procesador de esta placa base, conéctelo al contacto 1-3. Contacto 1-3 conectado Instalación del ventilador de 3 contactos...
  • Page 75 Aunque esta placa base proporciona un conector de energía de 8-pin ATX 12V, puede todavía trabajar si usted adopta un fuente tradicional de energía de 4-pin ATX 12V. Para usar el fuente de energía de 4-pin ATX 12V, por favor ecte los cables del conecte su fuente de energía junto con Pin 1 y Pin 5.
  • Page 76 Para iniciar la instalación, ponga el CD en el lector de CD y se desplegará el Menú Principal automáticamente si «AUTORUN» está habilitado en su computadora. Si el Menú...
  • Page 77 ASRock P41C-DE Motherboard...
  • Page 78 ® ® ® ® ® ® ® ® ® ASRock P41C-DE Motherboard...
  • Page 79 ® ASRock P41C-DE Motherboard...
  • Page 80 “ ” ® ® ASRock P41C-DE Motherboard...
  • Page 81 “ ” “ ” ® ® ASRock P41C-DE Motherboard...
  • Page 82 “ ” “ ” “ ” “ ” ASRock P41C-DE Motherboard...
  • Page 83 ASRock P41C-DE Motherboard...
  • Page 84 ASRock P41C-DE Motherboard...
  • Page 85 ASRock P41C-DE Motherboard...
  • Page 86 ASRock P41C-DE Motherboard...
  • Page 87 1 0 0 1 0 0 1 0 0 1 0 0 1 0 0 ASRock P41C-DE Motherboard...
  • Page 88 “ ” “ ” 1 0 1 1 0 1 1 0 1 1 0 1 1 0 1 ASRock P41C-DE Motherboard...
  • Page 89 1 0 2 1 0 2 1 0 2 1 0 2 1 0 2 ASRock P41C-DE Motherboard...
  • Page 90 ® ® ® ® ® ® ® ® ® 1 0 3 1 0 3 1 0 3 1 0 3 1 0 3 ASRock P41C-DE Motherboard...
  • Page 91 1 0 4 1 0 4 1 0 4 1 0 4 1 0 4 ASRock P41C-DE Motherboard...
  • Page 92 ® ® “ ” 1 0 5 1 0 5 1 0 5 1 0 5 1 0 5 ASRock P41C-DE Motherboard...
  • Page 93 ® ® ® ® ® ® 1 0 6 1 0 6 1 0 6 1 0 6 1 0 6 ASRock P41C-DE Motherboard...
  • Page 94 – 1 0 7 1 0 7 1 0 7 1 0 7 1 0 7 ASRock P41C-DE Motherboard...
  • Page 95 1 0 8 1 0 8 1 0 8 1 0 8 1 0 8 ASRock P41C-DE Motherboard...
  • Page 96 1 0 9 1 0 9 1 0 9 1 0 9 1 0 9 ASRock P41C-DE Motherboard...
  • Page 97 1 1 0 1 1 0 1 1 0 1 1 0 1 1 0 ASRock P41C-DE Motherboard...
  • Page 98 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 ASRock P41C-DE Motherboard...
  • Page 99 1 1 2 1 1 2 1 1 2 1 1 2 1 1 2 ASRock P41C-DE Motherboard...
  • Page 100 1 1 3 1 1 3 1 1 3 1 1 3 1 1 3 ASRock P41C-DE Motherboard...
  • Page 101 ® ® 1 1 4 1 1 4 1 1 4 1 1 4 1 1 4 ASRock P41C-DE Motherboard...
  • Page 102 1 1 5 1 1 5 1 1 5 1 1 5 1 1 5 ASRock P41C-DE Motherboard...
  • Page 103 ® ® ® ® ® ® ® ® ® 1 1 6 1 1 6 1 1 6 1 1 6 1 1 6 ASRock P41C-DE Motherboard...
  • Page 104 ® ® 1 1 7 1 1 7 1 1 7 1 1 7 1 1 7 ASRock P41C-DE Motherboard...
  • Page 105 ® ® 1 1 8 1 1 8 1 1 8 1 1 8 1 1 8 ASRock P41C-DE Motherboard...
  • Page 106 ® ® ® ® 1 1 9 1 1 9 1 1 9 1 1 9 1 1 9 ASRock P41C-DE Motherboard...
  • Page 107 1 2 0 1 2 0 1 2 0 1 2 0 1 2 0 ASRock P41C-DE Motherboard...
  • Page 108 1 2 1 1 2 1 1 2 1 1 2 1 1 2 1 ASRock P41C-DE Motherboard...
  • Page 109 1 2 2 1 2 2 1 2 2 1 2 2 1 2 2 ASRock P41C-DE Motherboard...
  • Page 110 1 2 3 1 2 3 1 2 3 1 2 3 1 2 3 ASRock P41C-DE Motherboard...
  • Page 111 1 2 4 1 2 4 1 2 4 1 2 4 1 2 4 ASRock P41C-DE Motherboard...
  • Page 112 1 2 5 1 2 5 1 2 5 1 2 5 1 2 5 ASRock P41C-DE Motherboard...
  • Page 113 ® ® 1 2 6 1 2 6 1 2 6 1 2 6 1 2 6 ASRock P41C-DE Motherboard...
  • Page 114 1 2 7 1 2 7 1 2 7 1 2 7 1 2 7 ASRock P41C-DE Motherboard...
  • Page 115 1 2 8 1 2 8 1 2 8 1 2 8 1 2 8 ASRock P41C-DE Motherboard...
  • Page 116 ® ® ® ® ® ® ® ® ® 1 2 9 1 2 9 1 2 9 1 2 9 1 2 9 ASRock P41C-DE Motherboard...
  • Page 117 1 3 0 1 3 0 1 3 0 1 3 0 1 3 0 ASRock P41C-DE Motherboard...
  • Page 118 ® ® ® ® 1 3 1 1 3 1 1 3 1 1 3 1 1 3 1 ASRock P41C-DE Motherboard...
  • Page 119 ® ® ® ® 1 3 2 1 3 2 1 3 2 1 3 2 1 3 2 ASRock P41C-DE Motherboard...
  • Page 120 1 3 3 1 3 3 1 3 3 1 3 3 1 3 3 ASRock P41C-DE Motherboard...
  • Page 121 1 3 4 1 3 4 1 3 4 1 3 4 1 3 4 ASRock P41C-DE Motherboard...
  • Page 122 1 3 5 1 3 5 1 3 5 1 3 5 1 3 5 ASRock P41C-DE Motherboard...
  • Page 123 1 3 6 1 3 6 1 3 6 1 3 6 1 3 6 ASRock P41C-DE Motherboard...
  • Page 124 1 3 7 1 3 7 1 3 7 1 3 7 1 3 7 ASRock P41C-DE Motherboard...
  • Page 125 1 3 8 1 3 8 1 3 8 1 3 8 1 3 8 ASRock P41C-DE Motherboard...
  • Page 126 ® ® ® 1 3 9 1 3 9 1 3 9 1 3 9 1 3 9 ASRock P41C-DE Motherboard...

Table of Contents
