ASROCK P41C-DE Brochure

P41C-DE
Intel G41 + ICH7 Chipsets
®

Product Brief

- Supports FSB1333/1066/800/533 MHz CPUs
- Supports Dual Channel DDR3 1333 (OC) +
DDR2 1066 (OC)
- EuP Ready
- Supports Smart BIOS, ASRock OC Tuner,
Intelligent Energy Saver, Instant Boot,
Instant Flash, OC DNA
- 7.1 CH Windows Vista™ Premium Level HD
®
Audio (VIA 1708S Audio Codec with QSound)
®
- Free Bundle : ASRock Software Suite
The specification is subject to change without notice. The brand and product names are trademarks of their
respective companies. Any configuration other than original product specification is not guaranteed.

Detail Specification

Platform
CPU
Chipset
Memory
Expansion Slot
Audio
LAN
EuP EuP
Rear Panel I/O
Ready
Connector
BIOS Feature
Support CD
Unique Feature
Hardware Monitor
OS
Certifications
Accessories
www.as rock.com
- ATX Form Factor: 12.0-in x 8.4-in, 30.5 cm x 21.3 cm
- Solid Capacitor for CPU power
- LGA 775 for Intel ® Core TM 2 Extreme / Core
Core 2 Duo / Pentium Dual Core / Celeron
TM ®
/ Celeron , supporting Penryn Quad Core Yorkfield and
®
Dual Core Wolfdale processors
- Supports FSB1333/1066/800/533 MHz
- Supports Hyper-Threading Technology
- Supports Untied Overclocking Technology
- Supports EM64T CPU
- Northbridge: Intel G41
®
- Southbridge: Intel ICH7
®
- Dual Channel DDR3/DDR2 memory technology
- 2 x DDR3 DIMM slots
- Supports DDR3 1333(OC)/1066/800 non-ECC,
un-buffered memory
- Max. capacity of system memory: 8GB
- 2 x DDR2 DIMM slots
- Supports DDR2 1066(OC)/800/667/533 non-ECC,
un-buffered memory
- Max. capacity of system memory: 8GB
- 1 x PCI Express x16 slot
- 3 x PCI Express x1 slots
- 2 x PCI slots
- 7.1 CH Windows Vista™ Premium Level HD Audio
®
(VIA VT1708S Audio Codec)
®
- PCIE x 1 Gigabit LAN 10/100/1000 Mb/s
- Atheros AR8131L
®
- Supports Wake-On-LAN
I/O Panel
- 1 x PS/2 Mouse Port
- 1 x PS/2 Keyboard Port
- 1 x Parallel Port (ECP/EPP Support)
- 1 x Serial Port: COM1
- 1 x Coaxial SPDIF Out Port
- 1 x Optical SPDIF Out Port
- 4 x Ready-to-Use USB 2.0 Ports
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and
SPEED LED)
- HD Audio Jack: Side Speaker / Rear Speaker / Central /
Bass / Line in / Front Speaker / Microphone
- 4 x SATAII 3.0 Gb/s connectors (No support for RAID
and "Hot Plug" functions)
- 1 x ATA100 IDE connector (supports 2 x IDE devices)
- 1 x Floppy connector
- 1 x IR header
- 1 x HDMI_SPDIF header
- CPU/Chassis/Power FAN connector
- 24 pin ATX power connector
- 8 pin 12V power connector
- Front panel audio connector
- 2 x USB 2.0 headers (support 4 USB 2.0 ports)
- 8Mb AMI Legal BIOS
- Supports "Plug and Play"
- ACPI 1.1 Compliance Wake Up Events
- SMBIOS 2.3.1 Support
- CPU, VCCM, NB, SB, VTT, GTLRef Voltage
Multi-adjustment
- Supports I. O. T. (Intelligent Overclocking Technology)
- Supports Smart BIOS
- Drivers, Utilities, AntiVirus Software (Trial Version),
ASRock Software Suite (CyberLink DVD Suite - OEM
and Trial ; Creative Sound Blaster X-Fi MB - Trial)
- ASRock OC Tuner
- Intelligent Energy Saver
- Instant Boot
- ASRock Instant Flash
- ASRock OC DNA
- Hybrid Booster:
- CPU Frequency Stepless Control
- ASRock U-COP
- Boot Failure Guard (B.F.G.)
- CPU Temperature Sensing
- Chassis Temperature Sensing
- CPU/Chassis/Power Fan Tachometer
- CPU/Chassis Quiet Fan
- Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore
- Microsoft Windows 7 / 7 64-bit / Vista
® ®
/ XP / XP 64-bit compliant
- FCC, CE, WHQL
- EuP Ready (EuP ready power supply is required)
- Quick Installation Guide, Support CD, I/O Shield
- 2 x SATA Data Cables (Optional)
TM 2 Quad /
Dual Core
®
/ Vista 64-bit
TM TM
