TOLERANCE NOTES
FABRICATED TOLERANCES
≥ 2 ft (610 mm) ± 0.250 in (6.4 mm)
< 2ft (610 mm) ± 0.125 in (3.2 mm)
MACHINED TOLERANCES
± 0.050 DECIMAL DIM (1 PLACE)
± 0.010 DECIMAL DIM (2 PLACES)
± 0.005 DECIMAL DIM (3 PLACES)

3 Electrical Area Classification and Safety Markings

3.1 Description of Equipment Protection System

Special Conditions of Use: The flying leads of the flame scanner shall be suitably protected against
mechanical damage and terminated within a terminal or junction facility for the conditions of use.

3.2 Hazardous Area

The iScan2 DSF-2010 system hazardous area models have been assessed and comply with the following
hazardous area standards:
NEC/CEC/ABS/EAC
60079-0
IECEx
RELATED DOCUMENT – MUST COMPLY WITH SCHEDULE DOCUMENT(S):
FOR A LIST OF RELEVANT PATENTS
AND TRADEMARKS PLEASE SEE
CHENTRONICS.COM/LEGAL-NOTICES
ISO 9001 CERTIFIED
DRAWN BY:
ON:
AR
2022-NOV-01
LAST REV BY: ON:
INSTALLATION & OPERATION MANUAL
FM3610:2009UL, FM7610:1997
ANSI Z21.20
FM3600:1998, FM3615:1989, FM3810:1989
ISA 60079-1:2002
IEC 61508-1:2010, IEC 61508-2:2010, IEC 61508-3:2010
IEC 60079-0:2004
IEC 61241-0:2004
INSTALLATION & OPERATION MANUAL
DCO No
.
15135
DWG. No.
CLASS I, DIVISON 1, GROUPS B, C, & D T5
NEMA TYPE 4X
SIL3
20140305-MH26433
21-2116223-PDA
RU C-US. ГБ04.B.00663
Ex d IIC T5 Ta -30°C to +70°C
Ex tD A21 IP66 T100°C Ta -30°C to +70°C
IECEx FME 10.0004X
MNL-ISCAN2SB
THIS DRAWING OWNED BY CHENTRONICS.
CONDITIONALLY LOANED AND IS TO BE RETURNED UPON
REQUEST. THE BORROWER BY RECEIVING IT HAS AGREED
NOT TO REPRODUCE NOR COPY IT IN WHOLE OR IN PART NOR
TO FURNISH INFORMATION FROM IT TO OTHERS NOR TO
MAKE ANY USE OF IT THAT IS OR MAY BE INJURIOUS TO
CHENTRONICS. FOR MORE INFORMATION PLEASE CONTACT
CHENTRONICS AT +1.607.334.5531.
60730-2-5
CAN/CSA C22.2 No.
CAN/CSA C22.2 No. 30
IEC 60079-1:2007
IEC 61241-1:2004
MNL-ISCANSB
