Important Safety Information - iScan DSF-2010-SB Installation & Operation Manual

TOLERANCE NOTES
FABRICATED TOLERANCES
≥ 2 ft (610 mm) ± 0.250 in (6.4 mm)
< 2ft (610 mm) ± 0.125 in (3.2 mm)
MACHINED TOLERANCES
± 0.050 DECIMAL DIM (1 PLACE)
± 0.010 DECIMAL DIM (2 PLACES)
± 0.005 DECIMAL DIM (3 PLACES)

1 Important Safety Information

The instructions provided in this manual have been prepared to serve as a general guide. It is intended
for use by qualified personnel with knowledge of Equipment of this type. It is not intended to cover all
possible variations in equipment or to provide for specific operating problems which may arise.
You are responsible for adhering to all warnings or cautions provided in this Manual.
In addition to any general safety measures provided in this Manual, you must comply with all current
national, state, local and company safety regulations at all times.
Safety Symbols used in this manual comply with ISO 3864.
Do not open the equipment cover or service the equipment if an explosive atmosphere may
be present. Equipment must be installed and serviced by qualified personnel in accordance
with applicable local and national codes, standards, and ordinances.
RELATED DOCUMENT – MUST COMPLY WITH SCHEDULE DOCUMENT(S):
FOR A LIST OF RELEVANT PATENTS
AND TRADEMARKS PLEASE SEE
CHENTRONICS.COM/LEGAL-NOTICES
ISO 9001 CERTIFIED
DRAWN BY:
ON:
AR
2022-NOV-01
LAST REV BY: ON:
INSTALLATION & OPERATION MANUAL
IMPORTANT SAFETY INFORMATION
Read All Instructions before Using
Indicates a hazard with a high level of risk which, if not avoided
will result in death or serious injury.
Indicates a hazard with a medium level of risk which, if not
avoided could result in death or serious injury.
Indicates a hazard with a low level of risk which, if not avoided
will result in minor or moderate injury.
EXPLOSION HAZARD
