ASROCK K8NF3-VSTA Brochure

K8NF3-VSTA
ASRock, an Expert in Windows Vista
Product brief
FSB 800MHz, Hyper-Transport Technology and
AMD Cool 'n' Quiet Technology
Supports DDR400/333/266 with 2 DIMM slots, maximum
capacity up to 2GB
Untied Overclocking : During Overclocking, FSB enjoys
better margin due to fixed AGP/ PCI Buses
1 x AGP 8X slot
2 x Serial ATA 1.5 Gb/s, supports RAID (RAID 0, 1 and JBOD)
and "Hot Plug" functions
7.1 CH Windows ® Vista™ Premium Level Superior Audio
(C-Media CM6501 Audio Codec with UAA architecture),
10/100 Ethernet LAN
Windows ® Vista™ Premium Logo Ready
ASRock 8CH I/O: 4 ready-to-use USB ports, 7.1 channel
audio jacks
The specification is subject to change without notice. The brand and product names are trademarks of their respective companies. Any configuration other than original product specification is not guaranteed.
Socket 754 for AMD Athlon™ 64 and Sempron processors
NVIDIA ® nForce3 250 Chipset
TM
Detail Specification
- ATX Form Factor: 12.0-in x 7.5-in, 30.5 cm x 19.1 cm
Platform
CPU
- Socket 754 for AMD Athlon
processors
- Supports AMD's Cool 'n' Quiet Technology
- FSB 800 MHz
- Supports Untied Overclocking Technology
- Supports Hyper-Transport Technology
Chipset
®
- NVIDIA nForce3 250
Memory
- 2 x DDR DIMM slots
- Supports DDR400/333/266
- Max. capacity: 2GB
Hybrid Booster
- CPU Frequency Stepless Control
- ASRock U-COP
- Boot Failure Guard (B.F.G.)
Expansion Slot
- 4 x PCI slots
- 1 x AGP 8X slot
Graphics
N/A
Audio
- 7.1 CH Windows
Audio (C-Media CM6501 Audio Codec with UAA
architecture)
LAN
- Realtek PHY RTL8201CL
- Speed: 10/100 Ethernet
- Supports Wake-On-LAN
Rear Panel I/O
ASRock 8CH I/O
- 1 x PS/2 Mouse Port
- 1 x PS/2 Keyboard Port
- 1 x Serial Port: COM1
- 1 x Parallel Port (ECP/EPP Support)
- 4 x Ready-to-Use USB 2.0 Ports
- 1 x RJ-45 Port
- Audio Jack: Side Speaker / Rear Speaker /
Central Bass / Line in / Front Speaker / Microphone
Connector
- 2 x Serial ATA 1.5 Gb/s connectors, support RAID
(RAID 0, RAID 1, JBOD) and "Hot Plug" functions
- 2 x ATA133 IDE connectors (support 4 x IDE devices)
- 1 x Floppy connector
- 1 x IR header
- 1 x Game header
- CPU/Chassis FAN connector
- 20 pin ATX power connector
- 4 pin 12V power connector
- CD in header
- Front panel audio connector
- 2 x USB 2.0 headers (support 4 USB 2.0 ports; 2
of them are shared with USB23 ports on the I/O
panel)
BIOS Feature
- 4Mb AMI BIOS
- AMI Legal BIOS
- Supports "Plug and Play"
- ACPI 1.1 Compliance Wake Up Events
- Supports jumperfree
- SMBIOS 2.3.1 Support
Support CD
- Drivers, Utilities, AntiVirus Software (Trial Version)
- CPU Temperature Sensing
Hardware Monitor
- Chassis Temperature Sensing
- CPU Fan Tachometer
- Chassis Fan Tachometer
- CPU Quiet Fan
- Voltage Monitoring: +12V, +5V, +3.3V, Vcore
®
- Microsoft Windows
OS
TM
Vista 64-bit compliant
Certifications
- FCC, CE, WHQL
- Quick Installation Guide, Support CD, I/O Shield
Accessories
- Floppy/ATA 133 cables
- 1 x SATA data cable (optional)
- 1 x SATA 1 to 1 power cable (optional)
TM
64 and Sempron
®
Vista™ Premium Level Superior
®
2000/XP/XP 64-bit/Vista TM /
