Blueridge S5 Series Instructions Manual

Wi-fi powered by the gree+ app, 9,000/12,000/18,000/24,000 btu 27 seer2 208/230v mini-split heat pump
Hide thumbs Also See for S5 Series:

Advertisement

Table of Contents

S5 Series Wi-Fi Instructions
S5 SERIES
BMKH0938
9,000 BTU 27 SEER2 208/230V Mini-Split Heat Pump
BMKH1231
12,000 BTU 24 SEER2 208/230V Mini-Split Heat Pump
BMKH1824
18,000 BTU 22 SEER2 208/230V Mini-Split Heat Pump
BMKH2422
24,000 BTU 21.5 SEER2 208/230V Mini-Split Heat Pump
Wi-Fi Powered by the GREE+ App

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S5 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Blueridge S5 Series

Summary of Contents for Blueridge S5 Series

  • Page 1 S5 Series Wi-Fi Instructions Wi-Fi Powered by the GREE+ App S5 SERIES BMKH0938 9,000 BTU 27 SEER2 208/230V Mini-Split Heat Pump BMKH1231 12,000 BTU 24 SEER2 208/230V Mini-Split Heat Pump BMKH1824 18,000 BTU 22 SEER2 208/230V Mini-Split Heat Pump BMKH2422...
  • Page 2 Wi-Fi control capabilities built into your Blueridge system. With the intuitive, easy-to-use GREE+ smartphone app, you can control your Blueridge Heat Pump and Air Conditioner – all from your phone. You can feel confident in your selection because the...

  • Page 3: Smartphone Controls

    This allows you to operate the unit through your smartphone anywhere a Wi-Fi network can be found. The GREE+ app is compatible with devices using standard Android or iOS operating systems. The "GREE+" App can connect an unlimited number of Blueridge Wi-Fi enabled products. Operating System Requirements for your smartphone: iOS System supports iOS 7.0 and above.
  • Page 4 STEP 1. TURN ON THE UNIT’S WI-FI INTERFACE. Remote Controls with a “Wi-Fi” button: turn ON the Blueridge system. Press and hold the “Wi-Fi” button for 10 seconds until the unit beeps for the second time and the Wi-Fi icon appears on the display.
  • Page 5 SIGN UP FOR UNIVERSAL WI-FI ACCESS. The GREE+ login screen will be displayed. For first-time users, select the “Sign Up” button to create an account and register your Blueridge unit on the Universal Wi-Fi System. On the Sign Up screen, you should:...
  • Page 6 SMARTPHONE CONTROLS STEP 4. ADD YOUR WI-FI NETWORK TO THE GREE+ APP. This is the local Wi-Fi network the Blueridge unit will be connected to and communicating through. From the My Home screen, tap the “+” button to add your Wi-Fi network.

  • Page 7: Startup And Operations

    Blueridge unit name, lock the device, and check your version of Firmware. STEP 2. CUSTOMIZE Set a custom name for your Blueridge unit for Settings Screen easy and quick identification (ex., Living Room, Den, Bedroom). To change the device name, tap on the current device name and then type in a new name.
  • Page 8 STARTUP AND OPERATION Add up to four Blueridge units to the GREE+ app on your smartphone. Repeat the “Registering your Blueridge unit on the Universal Wi-Fi System” section above for each new device. Single Unit Screen °F °F Multiple Units Screen...
  • Page 9 STARTUP AND OPERATION OPERATING MODE Select “Auto”, “Cool”, “Dry”, “Fan” or “Heat” by sliding the mode icon right or left on the ° smartphone display. The modes will be displayed as follows: °F See Remote Controller instructions for detailed operation of these modes. Heat Cool Mode...
  • Page 10 STARTUP AND OPERATION FAHRENHEIT °F / CELSIUS °C SCREEN Initially, the GREE+ app will display temperatures in °F. To switch the display to °C, tap the °F icon on the smartphone Screen. Repeat the procedure to switch the display back to °F. FAN MODES Fahrenheit °F / Celcius °C Screen Fan mode can be adjusted by sliding the fan...

  • Page 11: Special Function Group

    SPECIAL FUNCTION GROUP OPEN SPECIAL FUNCTIONS The GREE+ app has multiple special functions to improve your comfort, save time and lower energy usage. Tap the “Function” icon to open the Special Function window. Special Functions VENTILATE This function is not included with your system.
  • Page 12 SPECIAL FUNCTION GROUP HEALTH MODE This function is not included with your system. Health Mode...
  • Page 13 SPECIAL FUNCTION GROUP UNIT DISPLAY LIGHT ON/OFF Turn the indoor unit display ON by tapping the “Function” button and then the “Light” button. Tap again to turn it back OFF. Unit Screen Control Unit Screen Unit Screen ENERGY SAVING MODE Energy Saving mode will automatically select the optimal compressor and fan speeds to allow for energy savings while operating in Cooling or...
  • Page 14 SPECIAL FUNCTION GROUP VERTICAL SWING LOUVERS Turn the Vertical (Up & Down) Swing louvers ON and OFF by tapping the “Function” button and then the “Vertical Swing louver” button. To adjust the discharge air direction, tap on the Up & Down button under the icon to bring up the Swing louver Setting screen.
  • Page 15 SPECIAL FUNCTION GROUP HORIZONTAL SWING LOUVERS Turn the Horizontal (Left & Right) Swing Louvers ON and OFF by tapping the “Function” button and then the “Horizonal Swing Louver” button. To adjust the discharge air direction, tap the Left & Right button under the icon to bring up the Swing Louver Setting screen.
  • Page 16 SPECIAL FUNCTION GROUP SLEEP MODE Sleep mode will automatically adjust room temperature during your sleep time. This slight change in temperature will not affect your comfort level due to the natural effects that sleeping has on the body, but it will save on energy consumption and lower your electric bill.
  • Page 17 SPECIAL FUNCTION GROUP SLEEP MODE SETTINGS The Blueridge unit contains between 1 to 4 different Sleep mode functions depending on the model. To select a Sleep Mode, tap the “Sleep” title under the Sleep icon to open the Sleep Setting screen.
  • Page 18 SPECIAL FUNCTION GROUP EXPERT SLEEP MODE Expert Sleep Mode Screen NAP SLEEP MODE Nap Sleep Mode Screen...
  • Page 19 SPECIAL FUNCTION GROUP TRADITION SLEEP MODE Tradition Sleep Mode Screen DIY SLEEP MODE DIY Sleep Mode Screen...
  • Page 20 SPECIAL FUNCTION GROUP TIMER MODE Timer mode will automatically turn the unit ON or OFF on a selected day and time to save on energy consumption and lower your electric bill. Program Timer Mode by tapping the “Function” button and then the “Timer” button.
  • Page 21 SPECIAL FUNCTION GROUP In the Add Preset screen, the unit can be programmed to turn ON and OFF on specific days of the week and time of day. Select the specific days of the week the unit will turn ON or OFF by tapping the buttons at the bottom of the screen.
  • Page 22 SPECIAL FUNCTION GROUP Select the specific time of day the unit will turn ON or OFF by scrolling the Hour and Minute screen UP and DOWN. To have the unit turn ON at the programmed time, tap the “ON” button or tap the “OFF”...
  • Page 23 SPECIAL FUNCTION GROUP The Preset list will list the new program. The optional ON/OFF slide button allows you to activate or deactivate your program. Tap the “+” button to add another program period or tap the back “<” button to return to the full screen.
  • Page 24 SPECIAL FUNCTION GROUP HUMIDIFY MODE Humidify mode will automatically control the humidity in the room. Turn Humidify Mode ON and OFF by tapping the “Function” button and then the “Humidify” button. Humidify Mode Screen HUMIDIFY MODE SETTING To set a humidity level, tap the “Humidify” title under the Humidify icon to open the Humidify Setting screen.
  • Page 25 SPECIAL FUNCTION GROUP INTELLIGENT HUMIDIFYING Intelligent humidifying Intelligent Humidifying Mode Screen CONTINUOUS HUMIDIFYING Intelligent humidifying Continuous Humidifying Mode Screen MANUAL Intelligent HUMIDIFYING humidifying Manual Humidifying Mode Screen Tap the Back “<” button to return to the full screen.
  • Page 26 SPECIAL FUNCTION GROUP INDOOR NOISE MODE Indoor Noise Mode will automatically control the unit noise in the room. Turn Indoor Noise Mode ON and OFF by tapping the “Function” button and then the “Indoor Noise” button. Indoor Noise Mode Screen INDOOR NOISE MODE SETTING To set an indoor noise level, tap the “Indoor Noise”...
  • Page 27 SPECIAL FUNCTION GROUP From the Indoor Noise Setting screen, the Indoor Noise Function can be turned ON and OFF by sliding the ON/OFF button right or left. With the Indoor Noise function ON, the Indoor Noise level can be set by sliding Noise level scale to the desire level.
  • Page 28 SPECIAL FUNCTION GROUP AREA FAN Area fan mode allows you to customize the unit airflow in the room to greater overall comfort. Turn Area Fan Noise Mode ON and OFF by tapping the “Function” button and then the “Area Fan” button.
  • Page 29 SPECIAL FUNCTION GROUP First, turn Area Fan ON by sliding the “Area Fan” button on the right and a person icon will appear on the screen. Next, configure the room airflow sliding the person icon to the approximate main living area in the room. Then, slide the unit right or left to the approximate mounting location on the wall.
  • Page 30 SPECIAL FUNCTION GROUP PURITY This function is not included with your system. Purity Mode SAVE GUIDE This function is not included with your system. Save Guide Mode...

  • Page 31: Troubleshooting

    TROUBLESHOOTING HELP AND UPDATES Scan the QR Code for “Help” and updates to the GREE+ app. Scan for Help COMMON NETWORK SETTING PROBLEMS If Wi-Fi control fails, check the following items one by one: • Make sure electrical power is turned on to the outdoor and indoor units.
  • Page 32 For more information, visit AlpineHomeAir.com or contact us at (800) 865-5931. Specifications are subject to change without notice. Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice or without incurring obligations. Apple, Android, Google Play, and all other trademarked materials referenced herein, are the property of their respective owners.
