Owner's Manual

Original Instructions

Split Air Conditioner

Thank you for choosing our product.

Please read this Owner's Manual carefully before operation and

retain it for future reference.

NOTE：

Actual product may be different from graphics,

please refer to actual products.

Need help?

Do you have a question about the BMKH24LM/O and is the answer not in the manual?

Questions and answers

Summary of Contents for Blueridge BMKH24LM/O

Page 1 Owner's Manual Original Instructions Split Air Conditioner Thank you for choosing our product. Please read this Owner’s Manual carefully before operation and retain it for future reference. NOTE： Actual product may be different from graphics, please refer to actual products.
Page 2 Contents Outdoor Unit Installation----------------------01 Indoor Unit Installation-------------------------20...
Page 3 Owner's Manual Original Instructions Split Air Conditioner CONTENTS Safety precautions ..................Parts name ....................Installation notice ..................Installation of outdoor unit ................Test and operation ..................Configuration of connection pipe ..............Thank you for choosing our product. Please read this Owner’s Manual carefully before operation and retain it for future reference.
Page 4 BMKH24LM/O...
Page 5 Explanation of Symbols WARNING This symbol indicates the possibility of death or serious injury. This symbol indicates the possibility of injury or damage to CAUTION property. Indicates important but not hazard-related information, used NOTICE to indicate risk of property damage. Exception Clauses Manufacturer will bear no responsibilities when personal injury or property loss is caused by the following reasons.
Page 6 FCC WARNING WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC STATEMENT This device complies with Part 15 of the FCC Rules.Operation is subject to the following two conditions : (1) this device may not cause harmful interference, and (2) this device must accept any interference received,including interference that may cause undesired operation.
Page 7 IC STATEMENT This equipment complies with FCC’s and IC’s RF radiation exposure limits set forth for an uncontrolled environment. The antenna(s) used for this transmitter must be installed and operated to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter.
Page 8 Safety precautions WARNING Installation should comply with nation- Installation or maintenance al electric safety regula- must be performed by qua- tions. lified professionals. Air Conditioner should be The appliance shall be in- properly grounded. Inco- stalled in accordance with rrect grounding may cause national wiring regulations.
Page 9 Safety precautions CAUTION Installation line. Instructions for installation and use of this product are The yellow-green wire in provided by the manufac- air conditioner is ground- turer. ing wire, which can't be us- Select a location which is ed for other purposes. out of reach for children The air conditioner is the and far away from animals...
Page 10 Safety precautions WARNING Operation and Maintenance ket. Otherwise, it may cau- se fire hazard. This appliance can be used Do disconnect power supp- by children aged from 8 ly when cleaning air condi- years and above and per- tioner. Otherwise, it may sons with reduced physi- cause electric shock.
Page 11 Safety precautions CAUTION Operation and Maintenance Air conditioner gives off burning smell. Do not spill water on the re- Indoor unit is leaking. mote controller, otherwise the remote controller may be broken. Do not use fire or hair dry- er to dry the filter to avoid deformation or fire hazard.
Page 12 Parts name Outdoor Unit air inlet air outlet NOTE ● Actual product may be different from above graphics, please refer to actual product.
Page 13 Installation notice WARNING sure that the unit is running in cooling mode. Then, fully close the valve at high pressure side (liquid valve). About 30-40 seconds later, fully close the valve at low pressure side (gas valve), immediately stop the unit and disconnect power.
Page 14 Selection of installation location Requirements for electric connection Basic requirement The temperature of refrigerant circuit will be hi- Installing the unit in the following places may cau- gh, please keep the interconnection cable away se malfunction. If it is unavoidable, please consu- from the copper tube.
Page 15 Installation of outdoor unit Step 1: Fix the support of outdoor unit (select it according to the actual inst- drain vent allation situation) chassis outdoor drain joint 1. Select installation location according to Drain hose the house structure. 2. Fix the support of outdoor unit on the sele- Step 3: cted location with expansion screws.
Page 16 Step 6: 4. Tighten the union nut with torque wrench Neaten the pipes by referring to the sheet below. 1. The pipes should be placed along the wall, bent Hex nut diameter Tightening torque(ft-l reasonably and hidden possibly. Min. semidiam- 1/4'' 11.06~14.75 eter of bending the pipe is 3.9in.
Page 17 Test and operation Check after installation ● Check according to the following requirement Use vacuum pump after finishing installation. 1. Remove the valve caps on the liquid valve and Items to be checked Possible malfunction gas valve and the nut of refrigerant charging vent. 2.
Page 18 Configuration of connection pipe Additional refrigerant charging amount for R22, R407C, R410A and R134a 1. Standard length of connection pipe: 5m, 7.5m, 2. Min. length of connection pipe is 3m. 3. Max. length of connection pipe is shown as below. Max.
Page 19 Working temperature range C: Put on suitable insulating pipe BMKH24LM/O D: Put on the union nut Outdoor side Indoor side DB/WB(°C/°F) DB/WB(°C/°F) ● Remove the union nut on the indoor connection Maximum 26.7/19.4...
Page 20 600005065340...
Page 21 Owner's Manual Original Instructions Split Air Conditioner CONTENTS Safety precautions ..................Parts name ....................Operation and introduction of remote controller ..........Clean and maintenance ................Checked items before maintenance ............. Installation notice ..................Installation of indoor unit ................Test and operation ..................
Page 22 BMKH09M-LM BMKH12M-LM BMKH18M-LM BMKH24M-LM...
Page 23 Outline Dimension Diagram Indoor Unit BMKH09M-LM BMKH12M-LM 1 3/8 1 3/8 3 19/64 BMKH18M-LM Φ2 1/6 Φ2 1/6 1 1/2 1 1/2 7 1/2 5 1/2 BMKH24M-LM Φ2 3/4 Φ2 3/4 1 21/32 1 21/32 3 7/64 Unit:inch Models 35 13/64 11 1/2 8 21/64 8 1/64...
Page 24 Explanation of Symbols WARNING This symbol indicates the possibility of death or serious injury. This symbol indicates the possibility of injury or damage to CAUTION property. Indicates important but not hazard-related information, used NOTICE to indicate risk of property damage. Exception Clauses Manufacturer will bear no responsibilities when personal injury or property loss is caused by the following reasons.
Page 25 FCC WARNING WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC STATEMENT This device complies with Part 15 of the FCC Rules.Operation is subject to the following two conditions : (1) this device may not cause harmful interference, and (2) this device must accept any interference received,including interference that may cause undesired operation.
Page 26 IC STATEMENT This equipment complies with FCC’s and IC’s RF radiation exposure limits set forth for an uncontrolled environment. The antenna(s) used for this transmitter must be installed and operated to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter.
Page 27 Safety precautions WARNING Installation Installation or maintenance The grounding resistance should comply with nation- must be performed by qua- al electric safety regula- lified professionals. The appliance shall be in- tions. Air Conditioner should be stalled in accordance with properly grounded. Inco- national wiring regulations.
Page 28 Safety precautions CAUTION Installation Instructions for installation For the air conditioner with- out plug, a circuit breaker and use of this product are must be installed in the provided by the manufac- turer. line. The yellow-green wire in Select a location which is air conditioner is ground- out of reach for children ing wire, which can't be us-...
Page 29 Safety precautions WARNING Operation and Maintenance tioner to multi-purpose soc- ket. Otherwise, it may cau- This appliance can be used se fire hazard. by children aged from 8 Do disconnect power supp- years and above and per- ly when cleaning air condi- sons with reduced physi- tioner.
Page 30 Safety precautions CAUTION Operation and Maintenance frequently. Air conditioner gives off Do not spill water on the re- mote controller, otherwise burning smell. the remote controller may Indoor unit is leaking. be broken. Do not use fire or hair dry- er to dry the filter to avoid deformation or fire hazard.
Page 31 Parts name Indoor Unit air inlet panel filter aux. button air outlet horizontal louver If remote controller is lost or damaged, please use aux. button to turn on or turn off the air conditioner. The operation in details is as below: As shown in the figure, open panel and press aux.
Page 32 TIMER TIMER Set temperature WiFi function Set time TIMER ON / TIMER OFF Light Up & down swing Child lock 8C MODE NOT APPLICABLE WHEN PAIRED WITH BMKH30M-NDG3, BMKH42M-NDG3, BMKH36M23UH, AND BMKH42M23UH. The Scavenging function is not supported on Blueridge models.
Page 33 Introduction for buttons on When selecting dry mode, the air conditioner ● remote controller operates at low speed under dry mode. Under dry mode, fan speed can't be adjusted. Press NOTE "SWING" button to adjust fan blowing angle. ● This is a general use remote controller. It could be When selecting fan mode, the air conditioner will ●...
Page 34 change quickly. On releasing button after setting is ● Having set X-FAN function on: After turning off the finished, temperature indicator on indoor unit will unit by pressing " " button, indoor fan will continue change accordingly. (Temperature can't be adjust- running for a few minutes at low speed.
Page 35 decrease 1min. Holding "▲" or "▼" button, 2s button WiFi later, the time will change quickly until reaching your required time. Press " WiFi " button to turn on WiFi function, Press "TIMER ON" to conﬁrm it. The word "ON" "...
Page 36 NOTE I FEEL Function ● Under energy-saving function, fan speed is defaulted at auto speed and it can t be adjusted. Press "▲" and "MODE" buttons simultaneously to ● Under energy-saving function, set temperature can start I FEEL function and " "...
Page 37 Clean and maintenance WARNING The filter should be cleaned every three months. ■ If there is much dust in the operation environme- WARNING nt, clean frequency can be increased. ■ Turn off the air conditioner and disconnect the After removing the filter, do not touch fins to ■...
Page 38 Checked items before maintenance Phenomenon Solution Check items Whether there’s od- General phenomenon analysis Eliminate the odour Odours are our source, such as source. Clean the Please check below items before asking for furniture emitted filter. maintenance. If the malfunction still can’t be cigare- tte, etc.
Page 39 Installation notice WARNING sure that the unit is running in cooling mode. Then, fully close the valve at high pressure side (liquid valve). About 30-40 seconds later, fully close the valve at low pressure side (gas valve), immediately stop the unit and disconnect power.
Page 40 Requirements for electric connection Selection of installation location Basic requirement If the supply cord is damaged, it must be repla- ced by the manufacturer, its service agent or Installing the unit in the following places may cau- similarly qualified persons in order to avoid a se malfunction.
Page 41 Installation of indoor unit NOTE Indoor outdoor ● Pay attention to dust prevention Step 1: and take relevant safety mea- sures when opening the hole. Choose installation location Φ55 5-10 Φ70 Recommend the installation location to the client and then confirm it with the client. Step 2: Step 4: Install wall-mounting frame...
Page 42 Hex nut diameter Tightening torque (N . m) drain hose 1/4'' 15~20 3/8'' 30~40 1/2'' 45~55 insulating pipe 5/8'' 60~65 NOTE 3/4'' 70~75 ● Add insulating pipe in the indoor drain hose in order to prevent condensation. ● The plastic expansion particles are not provided. 4.
Page 43 drain hose connection pipe 3. Remove the wire clip; connect the power conn- band ection wire to the wiring terminal according to the color; tighten the screw and then fix the po- wer connection wire with wire clip. indoor power cord 3.
Page 44 Test and operation Check after installation ● Check according to the following requirement after finishing installation. Items to be checked Possible malfunction Has the unit been The unit may drop, shake or installed firmly? emit noise. It may cause insufficient Have you done the refri- cooling(heating) capacity.
Page 45 Configuration of connection pipe Additional refrigerant charging amount for R22, R407C, R410A and R134a 1. Standard length of connection pipe: 5m, 7.5m, 2. Min. length of connection pipe is 3m. 3. Max. length of connection pipe is shown as below. Max.
Page 46 B: Remove the burrs smooth surface ● Remove the burrs with shaper and prevent the burrs from getting into the pipe. improper expanding pipe shaper leaning damaged crack uneven surface thickness downwards the length is equal Working temperature range Indoor side Outdoor side C: Put on suitable insulating pipe DB/WB(°C/°F)
Page 48 66129936930...
