- Page 1 Installation/Owner’s Manual S1 SERIES BMX917 9000 BTU 17 SEER2 115V Mini-Split Heat Pump BMX1217 12000 BTU 17.4 SEER2 115V Mini-Split Heat Pump BMY917 9000 BTU 18.5 SEER2 208/230V Mini-Split Heat Pump BMY1217 12000 BTU 17.6 SEER2 208/230V Mini-Split Heat Pump BMY1817 18000 BTU 18.3 SEER2 208/230V Mini-Split Heat Pump...
-
Page 2: Table Of Contents
Table of Contents Specifications table Packing and unpacking the unit Safety Precautions Quick Install Guide Accessories Unit Parts System Installation 1. Select installation location 2. removing Bracket from Unit 3. Attach mounting plate to wall 4. Drill wall hole for connective piping 5. -
Page 3: Specifications Table
S1 Series Quick Specs BMX917C BMY917C BMX1217C BMY1217C BMY1817C BMY2417C BMX917WM BMY917WM BMX1217WM BMY1217WM BMY1817WM BMY2417WM Line Set MInimum Maximum Ambient Ambient Dimensions Weight Dimensions Weight Size System BTUs Breaker Breaker Volts Heating Cooling (ODU) (ODU) LBs (IDU) Inches (IDU) LBs... -
Page 4: Packing And Unpacking The Unit
OMS1-01 Page 2... -
Page 5: Safety Precautions
OMS1-01 Page 3... - Page 6 OMS1-01 Page 4...
- Page 7 OMS1-01 Page 5...
-
Page 8: Quick Install Guide
Quick Install Your indoor air handler has been pre-pressurized with nitrogen. • On the back of the unit, loosen the cap on either of the 2 insulated copper tubes. • You should hear a hissing noise, which is the release of this harmless gas. •... - Page 9 INDOOR UNIT Remove the mounting bracket from the Mark the position of the large hole for back of the indoor unit and mount it to the connecting line set and wires. the wall using the included hardware. By default, the line set will exit the indoor unit on the right side (facing the unit).
- Page 10 INDOOR UNIT Connect wires to indoor unit. Remove wire cover on front of indoor unit. Indoor unit black to red to 14/4 white to stranded green to ground wire 14/4 Feed 14/4 stranded wire from the back of stranded the unit to the front. wire Attach the drain hose and prepare the Bundle the line set, drain, and...
- Page 11 INDOOR UNIT Hang the indoor unit on the Bend the line set on the exterior of the mounting bracket. wall towards the outdoor unit. 30° Tilt Run the drain tubing to the ground, at least Feed the bundled connection 12 inches from the lines through the hole to the structure.
- Page 12 ELECTRICAL • Any high voltage electrical installation should be performed by an electrician or contractor. • Make sure the electricity is off. • Follow all local and national electrical codes. • Always verify line and load lug locations on the disconnect prior to wiring. •...
- Page 13 FOR 208/240 VOLT SYSTEM Wiring shown is based on load, line, line, load. Connect indoor unit to the outdoor unit. Connect outdoor unit to disconnect box. Disconnect box Indoor unit Outdoor unit Outdoor unit black to 1 2 3 L1 L2 2 3 L1 L2 red to Circuit...
- Page 14 REFRIGERANT | INDOOR UNIT Warning: Refrigerant handling should be done by a trained professional. Remove caps from the line set Connect the additional length of line set to connections on air handler. the line set on the back of the indoor unit. Apply Nylog Here Use a standard wrench and a torque wrench to tighten...
- Page 15 Please call 1.800.865.5931 if you have any questions prior to or during the installation process of your Blueridge Mini-Split System. Because of the Blueridge promise for continuous product innovation and improvement, some specifications and instructions may change without notification. 0224 QIS101-01...
-
Page 16: Accessories
OMS1-01 Page 14... -
Page 17: Unit Parts
Unit Parts NOTE ON ILLUSTRATIONS OMS1-01 Page 15... -
Page 18: System Installation
OMS1-01 Page 16... -
Page 19: Removing Bracket From Unit
Wall Mounting Plate Dimensions Step 3 Attach mounting plate to wall The mounting plate is the device on which you will mount the indoor unit. BMX917 NOTE FOR CONCRETE OR BRICK WALLS: 805mm(31.7in) BMY917, BMY1217, BMX1217 958.3mm(37.7in BMY1817) 559mm(22in) 264mm(10.4in) 344mm(13.5in) 299mm(11.8in) 219mm(8.6in) - Page 20 The bottom of the hole should start 1/4 inch above the straight edge will have the hole on the right side. Straight edge Measure the marks on the wall to make Right side hole hole marking methods: sure the center of the hole location is Find and use the included template.
-
Page 21: Drill Wall Hole For Connective Piping
Note for Interior wall installations If installing on an interior wall it's recommended to have the line sets come down from the ceiling. Then they will come in on the left side of the indoor unit. If installing on an interior wall or if you can't gravity drain the condensation a condensate pump is needed. -
Page 22: Idu Connect Signal And Power Cables
OMS1-01 Page 20... - Page 23 OMS1-01 Page 21...
-
Page 24: Prepare Refrigerant Piping
Step 8 Prepare refrigerant piping Left rear (facing the back of the indoor unit): This is the most common installation option for the line sets. If the indoor unit is mounted on an wall you will bend the refrigerant pipes 90 degrees so they are pointing from the back of the unit. -
Page 25: Connect Drain Hose
Step 9 PLUG THE UNUSED DRAIN HOLE Wrap Piping and Cables Space behind unit Refrigerant piping Signal wire Drain hose OMS1-01 Page 23... - Page 26 OMS1-01 Page 24...
-
Page 27: Mount Indoor Unit
Step 10 Mount indoor unit: If you installed new connective piping to the outdoor unit, do the following: Step 11 Bend the refrigerant pipes: OMS1-01 Page 25... -
Page 28: Odu Select Installation Location
Step 12 Select installation location and mounting option: OMS1-01 Page 26... -
Page 29: Install Drain Joint
OMS1-01 Page 27... - Page 30 OMS1-01 Page 28...
-
Page 31: Odu Connect Signal And Power Cables
OMS1-01 Page 29... - Page 32 Using a correctly sized breaker and wire (sourced locally) run the power to an electric disconnect box mounted outside by the outdoor unit. Follow all local and national electrical codes. 220 volt systems use 3 wires for power (hot. hot, ground). The 2 hot wires are connected to the 2 line lugs in the disconnect box the bare wire goes to a ground lug.
- Page 33 volt 14/4 and line voltage connections at the outdoor unit of a system. 14/4 connections black to 1, red to 2, white to 3, green to a ground screw. Line voltage connections black to L1, red L2, green to ground. volt system.
-
Page 34: Refrigerant Piping Connection
OMS1-01 Page 32... -
Page 35: Remove Burrs
Ø Ø Ø Ø OMS1-01 Page 33... - Page 36 Line set Caps Please inspect the flares prior to connecting the line sets. The flares should be smooth and symmetrical. Re-flare the copper tubes if needed to reduce the chance of leaks occurring. Ø Ø Ø Ø OMS1-01 Page 34...
- Page 37 OMS1-01 Page 35...
-
Page 38: Pressure Test
300 5 OMS1-01 Page 36... -
Page 39: Air Evacuation
manifold manifold manifold (if it isn't built into your gauge set the you will need to purchase a separate micron gauge). OMS1-01 Page 37... -
Page 40: Evacuation Instructions
valve low pressure valve a 5 millimeter allen wrench (hex key) and open the OMS1-01 Page 38... -
Page 41: Note On Adding Refrigerant
> OMS1-01 Page 39... -
Page 42: Electrical And Gas Leak Checks
OMS1-01 Page 40... -
Page 43: Test Run
OMS1-01 Page 41... -
Page 44: Owner's Manual Unit Specifications And Features
OMS1-01 Page 42... -
Page 45: Operating Temperature
OMS1-01 Page 43... -
Page 46: Other Features
OMS1-01 Page 44... -
Page 47: Setting Angle Of Air Flow
OMS1-01 Page 45... -
Page 48: Care And Maintenance
OMS1-01 Page 46... - Page 49 OMS1-01 Page 47...
-
Page 50: Troubleshooting
OMS1-01 Page 48... - Page 51 OMS1-01 Page 49...
- Page 52 OMS1-01 Page 50...
-
Page 53: Remote User Manual
REMOTE CONTROLLER OWNER’S MANUAL IMPORTANT NOTE: Thank you for purchasing our air conditioner. Please read this manual carefully before operating your new air conditioning unit. Make sure to save this manual for future reference. OMS1-01 Page 51... - Page 54 OMS1-01 Page 52...
-
Page 55: Remote Controller Specifications
• • • OMS1-01 Page 53... -
Page 56: Handling The Remote Controller
• • • • • • • OMS1-01 Page 54... -
Page 57: Buttons And Functions
Fresh( Sleep( Follow Me( AP mode( Fresh... SHORTCUT Used to restore the current settings or resume previous settings. OMS1-01 Page 55... -
Page 58: Remote Screen Indicators
TIMER ON display TIMER OFF display Silence feature display FAN SPEED display Displays selected fan speed: HIGH 17-30 o C/62-86 o F (20-28 C) (Model dependent) AUTO Timer setting range: 0-24 hours Note: All indicators shown in the figure are for the purpose of clear presentation. But during the actual operation, only the relative function signs are shown on the display window. -
Page 59: How To Use Basic Functions
Basic operation OMS1-01 Page 57... - Page 60 OMS1-01 Page 58...
- Page 61 TIMER turns off turns on OMS1-01 Page 59...
-
Page 62: How To Use Advanced Functions
How to Use Advanced Functions Swing function Press Swing button Swing Swing The horizontal louver will swing up and down Keep pressing this button more than 2 seconds, the automatically when pressing Swing button. Press vertical louver swing function is activated. again to make it stop. - Page 63 ECO function Press ECO button(Not Supported) FP function The unit will operate at high fan speed (while compressor on) with temperature automatically set to 8 C/46 F. Note: This function is for heat pump air conditioner only. Press this button 2 times during one second under HEAT Mode and setting temperature of 17 C/62 F to activate FP function.
- Page 64 SHORTCUT function Press SHORTCUT button(some units) Push this button when remote controller is on, the system will automatically revert back to the previous settings including operating mode, setting temperature, fan speed level and sleep feature (if activated). If pushing more than 2 seconds, the system will automatically restore the current operation settings including operating mode, setting temperature, fan speed level and sleep feature (if activated ).
- Page 65 SET function Press the SET button to enter the function setting, then press SET button or TEMP or TEMP button to select the desired function. The selected symbol will flash on the display area, press the OK button to confirm. To cancel the selected function, just perform the same procedures as above.
