CS 30056 - 45 RUE G. DE FLOTTE
13375 MARSEILLE CEDEX 12 (F
)
RAnCE
TEL : 33.(0).4.91.87.51.20 FAX : 33.(0).4.91.93.86.89
.
.
www
GyMnOvA
COM
Warning:
This equipment should be installed by a qualified individual. This equipment should only be used by one person at a time, under the
supervision of a qualified individual.
Using this equipment for purposes other than those originally intended is prohibited.
Recommendations:
-
Keep these instructions for subsequent reference (inspection, maintenance, etc.).
-
Periodically carry out predictive maintenance.
-
Depending on how much it is used have the equipment serviced yearly or every few years.
Pack list and bulkiness of the springboard:
-
1 Pack (Ref. 2130B) - Weight : 26.2Kg - Dim.: 1.34 x 0,61 x 0,27m - Vol. : 0,22 m3
Tools required:
-
No. 6
-
Allen Key
I.
General maintenance:
i
:
MportANt
Regular cleaning of the apparatus makes it easier to spot any problems (distortion, breakage or moisture absorption).
Before each use, make a through check on good condition and correct operation of wear parts and safety elements:
-
Check the condition of pads (10') and wheels (2), (6) or (25).
-
Check the condition of springs (18'), wooden tray (12'), wooden batten (13'), foam block (17) and wooden hinge (22').
-
Check the tightening of all fixings (4), (5), (8), (9), (11), (14), (19), (20) and (23).
-
If a problem is detected or suspected, do not use the equipment as long as it has not been checked by a technician.
-
Any damaged or distorted component should be replaced as quickly as possible.
Constantly aiming to improve our products, we reserve the right to make changes to the equipment and dimensions without further discussion.
A
i
sseMBly
NstructioNs For
D
ouBle
Top view
Plastic mesh
M
AiNteNANce
s
- 40
priNGBoArD
-
Phillips
-
screwdriver
-
-
Marker felt
NM102F-GB
cM
Side view
-
1 open end spanner no 13
-
1 open end spanner no 10
-
Plastic
spatula
26/01/22
2130B
1 tube spanner no. 13
1 tube spanner no. 10
Abrasive
paper
Fine grain
Advertisement
Related Manuals for Gymnova 2130B
Summary of Contents for Gymnova 2130B
- Page 1 Depending on how much it is used have the equipment serviced yearly or every few years. Pack list and bulkiness of the springboard: 1 Pack (Ref. 2130B) - Weight : 26.2Kg - Dim.: 1.34 x 0,61 x 0,27m - Vol. : 0,22 m3 Top view...
- Page 2 Pair of Springs assembly : see instructions § III. 5. Page 3. III. Assembly of spare parts Kits: Create a clean area for mounting. eplAceMeNt oF oviNG wheels 1 tube spanner no. 13 1 open end spanner no. 13 1 tube spanner no. 10 1 open end spanner no.
- Page 3 eplAceMeNt oF the wooDeN AtteN lAce oNe poiNt oF threAD BrAKe At the eND oF eAch screw BeFore tiGhteNiNG Strong thread brake 1 tube spanner no. 13 1 open end spanner no. 13 1’ 1’ 13’ 12’ 12’ sseMBly AND replAceMeNt oF the pAir oF priNGs lAce oNe poiNt oF threAD BrAKe At the eND oF eAch screw BeFore tiGhteNiNG...
- Page 4 hANGiNG the Full rAy AND the coMplete rAMe No. 6 Allen Key 1 tube spanner no. 13 1 open end spanner no. 13 12’ 22’ 1’ 17’ 17’ IV. Storage: Store material in a clean, dry place, away from moisture and heat. Do not store anything heavy, protruding or otherwise on the tray. NM102F - Page 4...
- Page 5 Constantly aiming to improve our products, we reserve the right to make changes to the equipment and dimensions without further discussion. NM102F - Page 5 This document is the propriety of Gymnova, it is confidential and shall not be reproduced.
