Warning:
This equipment should be installed by a qualified individual. This equipment should only be used by one person at a time, under the
supervision of a qualified individual.
Using this equipment for purposes other than those originally intended is prohibited.
Recommendations:
-
Keep these instructions for subsequent reference (inspection, maintenance, etc.).
-
Periodically carry out predictive maintenance.
-
Depending on how much it is used have the equipment serviced yearly or every few years.
Pack list and bulkiness of the springboard:
-
1 Pack (Ref. 0014C) - Weight : 24Kg - Dim.: 1.33 x 0,62 x 0,27m - Vol. : 0,22 m3
Tools required:
-
No. 6
-
Allen Key
I.
General maintenance:
i
:
MportANt
Regular cleaning of the apparatus makes it easier to spot any problems (distortion, breakage or moisture absorption).
Before each use, make a through check on good condition and correct operation of wear parts and safety elements:
-
Check the condition of pads (10') and wheels (2), (6) or (24).
-
Check the condition of springs (17'), wooden tray (12'), wooden batten (13') and wooden hinge (21').
-
Check the tightening of all fixings (4), (5), (8), (9), (11), (14), (18), (19) and (22).
-
If a problem is detected or suspected, do not use the equipment as long as it has not been checked by a technician.
-
Any damaged or distorted component should be replaced as quickly as possible.
Constantly aiming to improve our products, we reserve the right to make changes to the equipment and dimensions without further discussion.
A
i
sseMBly
NstructioNs for
B
eGiNNers
Top view
Plastic mesh
M
AiNteNANce
s
s
oft
priNGBoArD
-
Phillips
-
screwdriver
-
NM101D-GB
- 24
cM
Side view
-
1 open end spanner no 13
1 open end spanner no 10
-
01/02/22
0014C
1 tube spanner no. 13
1 tube spanner no. 10
