1) Card installation
Align the card assembly to the two sides of the card slot, push in parallel and
tighten the left and right screws.
1. Align and push the card in parallel
2. Tighten the left and right screws
2) Device connection
Ethernet interface
PC Monitor AC input
HDMI OUT
SDI OUT
1.2. Device login
1) Device default management IP address:
The decoder has 2 Ethernet ports, in general only need to configure the address 1
of network 1, which can be used for streaming and device management.
The default IP for gate 1 is 192.168.1.168, the subnet mask is 255.255.255.0, the
default IP for gate 2 is 192.168.2.168, and the subnet mask is 255.255.255.0.
2) Network configuration
The computer end clicks in turn: "Network and Internet Settings - "Network and
Sharing Center" - "Ethernet"- "Internet Protocol Version 4" - "Use the IP address
below" for IP settings. Manually enter the IP address and subnet mask for
192.168.1.* (*Refers to numbers other than 168 between 1-255), Click "OK".
