G41MH-GE
Intel
G41 + ICH7 Chipsets
®
EuP
EuP
Product Brief
- Supports 4 x DDR2 1066
- Intel
Graphics Media Accelerator X4500,
®
Pixel Shader 4.0, DirectX 10, Max. shared
memory 1759MB
- Supports Full HD 1080p Blu-ray (BD) / HD-DVD
playback
- Multi VGA Output options: D-Sub, DVI-D and
HDMI
- EuP Ready, PCIE Gigabit LAN
- Supports ASRock Instant Boot, Instant Flash,
OC DNA, Smart BIOS, ASRock OC Tuner,
Intelligent Energy Saver
- Supports - 7.1 CH Windows
Level HD Audio (VIA
QSound)
The specification is subject to change without notice. The brand and product names are trademarks of their
respective companies. Any configuration other than original product specification is not guaranteed.
Ready
Vista™ Premium
®
1708S Audio Codec with
®
www.as rock.com

Detail Specification

Platform
- Micro ATX Form Factor: 9.6-in x 9.6-in, 24.4 cm x 24.4 cm
CPU
- LGA 775 for Intel
Core
2 Duo / Pentium
TM
/ Celeron
, supporting Penryn Quad Core Yorkfield and
®
Dual Core Wolfdale processors
- Supports FSB1333/1066/800/533 MHz
- Supports Hyper-Threading Technology
- Supports Untied Overclocking Technology
- Supports EM64T CPU
Chipset
- Northbridge: Intel
- Southbridge: Intel
- Dual Channel DDR2 memory technology
Memory
- 4 x DDR2 DIMM slots
- Supports DDR2 1066/800/667/533 non-ECC,
un-buffered memory
- Max. capacity of system memory: 8GB
- 1 x PCI Express x16 slot
Expansion Slot
- 1 x PCI Express x1 slot
- 2 x PCI slots
Graphics
- Intel
Graphics Media Accelerator X4500
®
- Pixel Shader 4.0, DirectX 10
- Max. shared memory 1759MB
- Multi VGA Output options: D-Sub, DVI-D and HDMI
- Supports HDMI Technology with max. resolution up to
1920x1200 (1080P)
- Supports DVI with max. resolution up to 1920x1200 @
75Hz
- Supports D-Sub with max. resolution up to 2048x1536 @
60Hz
- Supports HDCP function
- Supports Full HD 1080p Blu-ray (BD) / HD-DVD playback
Audio
- 7.1 CH Windows
(VIA
VT1708S Audio Codec)
®
LAN
- PCIE x 1 Gigabit LAN 10/100/1000 Mb/s
- Realtek RTL8111DL
- Supports Wake-On-LAN
I/O Panel
Rear Panel I/O
- 1 x PS/2 Mouse Port
- 1 x PS/2 Keyboard Port
- 1 x VGA/D-Sub Port
- 1 x VGA/DVI-D Port
- 1 x HDMI Port
- 1 x Optical SPDIF Out Port
- 4 x Ready-to-Use USB 2.0 Ports
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and
SPEED LED)
- HD Audio Jack: Side Speaker / Rear Speaker / Central /
Bass / Line in / Front Speaker / Microphone
Connector
- 4 x SATAII 3.0 Gb/s connectors
(No support for RAID and "Hot Plug" functions)
- 1 x ATA100 IDE connector (supports 2 x IDE devices)
- 1 x Floppy connector
- 1 x IR header
- 1 x Print port header
- 1 x COM port header
- CPU/Chassis/Power FAN connector
- 24 pin ATX power connector
- 4 pin 12V power connector
- CD in header
- Front panel audio connector
- 2 x USB 2.0 headers (support 4 USB 2.0 ports)
BIOS Feature
- 8Mb AMI Legal BIOS
- Supports "Plug and Play"
- ACPI 1.1 Compliance Wake Up Events
- Supports jumperfree
- SMBIOS 2.3.1 Support
- Supports I. O. T. (Intelligent Overclocking Technology)
- Supports Smart BIOS
Support CD
- Drivers, Utilities, AntiVirus Software (Trial Version)
Unique Feature
- ASRock OC Tuner
- Intelligent Energy Saver
- Instant Boot
- ASRock Instant Flash
- ASRock OC DNA
- Hybrid Booster:
- CPU Frequency Stepless Control
- ASRock U-COP
- Boot Failure Guard (B.F.G.)
Hardware Monitor
- CPU Temperature Sensing
- Chassis Temperature Sensing
- CPU/Chassis/Power Fan Tachometer
- CPU Quiet Fan
- Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore
OS
- Microsoft
Windows
®
/ XP / XP 64-bit compliant
Certifications
- FCC, CE, WHQL
- EuP Ready (EuP ready power supply is required)
Accessories
- Quick Installation Guide, Support CD, I/O Shield
- ATA 100 Cable
- 1 x SATA Data Cable (Optional)
Core
2 Extreme / Core
2 Quad /
®
TM
TM
Dual Core / Celeron
Dual Core
®
®
G41
®
ICH7
®
Vista™ Premium Level HD Audio
®
7 / 7 64-bit / Vista
/ Vista
64-bit
®
TM
TM
