ASROCK G41M-VGS3 Quick Manual
Hide thumbs Also See for G41M-VGS3:

Advertisement

Copyright Notice:
Copyright Notice:
Copyright Notice:
Copyright Notice:
Copyright Notice:
No part of this installation guide may be reproduced, transcribed, transmitted, or trans-
lated in any language, in any form or by any means, except duplication of documen-
tation by the purchaser for backup purpose, without written consent of ASRock Inc.
Products and corporate names appearing in this guide may or may not be registered
trademarks or copyrights of their respective companies, and are used only for identifica-
tion or explanation and to the owners' benefit, without intent to infringe.
Disclaimer:
Disclaimer:
Disclaimer:
Disclaimer:
Disclaimer:
Specifications and information contained in this guide are furnished for informational
use only and subject to change without notice, and should not be constructed as a
commitment by ASRock. ASRock assumes no responsibility for any errors or omissions
that may appear in this guide.
With respect to the contents of this guide, ASRock does not provide warranty of any kind,
either expressed or implied, including but not limited to the implied warranties or
conditions of merchantability or fitness for a particular purpose. In no event shall
ASRock, its directors, officers, employees, or agents be liable for any indirect, special,
incidental, or consequential damages (including damages for loss of profits, loss of
business, loss of data, interruption of business and the like), even if ASRock has been
advised of the possibility of such damages arising from any defect or error in the guide
or product.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
CALIFORNIA, USA ONLY
The Lithium battery adopted on this motherboard contains Perchlorate, a toxic
substance controlled in Perchlorate Best Management Practices (BMP) regulations
passed by the California Legislature. When you discard the Lithium battery in
California, USA, please follow the related regulations in advance.
"Perchlorate Material-special handling may apply, see
www.dtsc.ca.gov/hazardouswaste/perchlorate"
ASRock Website: http://www.asrock.com
Copyright©2013 ASRock INC. All rights reserved.
ASRock G41M-VGS3 / G41M-VS3 Motherboard
Published December 2013
1 1 1 1 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G41M-VGS3 and is the answer not in the manual?

Questions and answers

Summary of Contents for ASROCK G41M-VGS3

  • Page 1 ASRock. ASRock assumes no responsibility for any errors or omissions that may appear in this guide. With respect to the contents of this guide, ASRock does not provide warranty of any kind, either expressed or implied, including but not limited to the implied warranties or conditions of merchantability or fitness for a particular purpose.
  • Page 2 Serial Port Connector (COM1) Third SATAII Connector (SATAII_3; Blue) Print Port Header (LPT1, White) Fourth SATAII Connector (SATAII_4; Blue) FSB1 Jumper Chassis Speaker Header (SPEAKER 1, White) 775-Pin CPU Socket 2 2 2 2 2 ASRock G41M-VGS3 / G41M-VS3 Motherboard...
  • Page 3: Speed Led

    Set “Speaker Configuration” to “Quadraphonic” or “Stereo”. Click “Device advanced settings”, choose “Make front and rear output devices playbacks two different audio streams simultaneously”, and click “ok”. Then reboot your system. 3 3 3 3 3 ASRock G41M-VGS3 / G41M-VS3 Motherboard...
  • Page 4 Set “Speaker Configuration” to “Quadraphonic” or “Stereo”. Click “Device advanced settings”, choose “Make front and rear output devices playbacks two different audio streams simultaneously”, and click “ok”. Then reboot your system. 4 4 4 4 4 ASRock G41M-VGS3 / G41M-VS3 Motherboard...
  • Page 5: Package Contents

    In case any modifications of this manual occur, the updated version will be available on ASRock website without further notice. You may find the latest VGA cards and CPU support lists on ASRock website as well. ASRock website http://www.asrock.com If you require technical support related to this motherboard, please visit our website for specific information about the model you are using.
  • Page 6: Specifications

    - 4 x Ready-to-Use USB 2.0 Ports - 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) - HD Audio Jack: Line in / Front Speaker / Microphone 6 6 6 6 6 ASRock G41M-VGS3 / G41M-VS3 Motherboard...
  • Page 7 ® ® / XP 64-bit compliant - FCC, CE, WHQL Certifications - ErP/EuP Ready (ErP/EuP ready power supply is required) * For detailed product information, please visit our website: http://www.asrock.com 7 7 7 7 7 ASRock G41M-VGS3 / G41M-VS3 Motherboard...
  • Page 8 OS with 64-bit CPU, there is no such limitation. ® It is a user-friendly ASRock overclocking tool which allows you to surveil your system by hardware monitor function and overclock your hardware devices to get the best system performance under Windows ®...
  • Page 9 - ASRock APP Charger. Simply installing the APP Charger driver, it makes your iPhone charged much quickly from your computer and up to 40% faster than before. ASRock APP Charger allows you to quickly charge many Apple devices simultaneously and even supports continuous charging when your PC enters into Standby mode (S1), Suspend to RAM (S3), hibernation mode (S4) or power off (S5).
  • Page 10: Jumpers Setup

    (EUP_AUDIO1, 3-pin jumper, see p.2 No. 22) Note: EUP_LAN and EUP_AUDIO jumper design decreases the power consumption of this motherboard to meet EuP standard. With an ASRock EuP ready motherboard and a power supply that the 5VSB power efficiency is higher than 50% under 100mA current consumption, your system is able to submit EuP standard.
  • Page 11 If you adopt FSB1333-CPU and DDR3 1333 memory module on this motherboard, you need to adjust the jumper. Please short pin2, pin3 for FSB1 jumper. Otherwise, the CPU and memory module may not work properly on this motherboard. Please refer to below jumper setting. ASRock G41M-VGS3 / G41M-VS3 Motherboard...
  • Page 12: Onboard Headers And Connectors

    I/O panel, there are (9-pin USB6_7) two USB 2.0 headers on this (see p.2 No. 17) motherboard. Each USB 2.0 header can support two USB 2.0 ports. (9-pin USB4_5) (see p.2 No. 15) ASRock G41M-VGS3 / G41M-VS3 Motherboard...
  • Page 13 (see p.2 No. 16) ground pin. CPU Fan Connector Please connect a CPU fan cable to this connector and match (4-pin CPU_FAN1) the black wire to the ground pin. (see p.2 No. 3) 1 2 3 4 ASRock G41M-VGS3 / G41M-VS3 Motherboard...
  • Page 14 Failing to do so will cause the failure to power up. Serial port Header This COM1 header supports a serial port module. (9-pin COM1) (see p.2 No. 25) ASRock G41M-VGS3 / G41M-VS3 Motherboard...
  • Page 15: Bios Information

    ROM drive. It will display the Main Menu automatically if “AUTORUN” is enabled in your computer. If the Main Menu does not appear automatically, locate and double- click on the file “ASRSETUP.EXE” from the BIN folder in the Support CD to display the menus. ASRock G41M-VGS3 / G41M-VS3 Motherboard...
  • Page 16: Spezifikationen

    Rückseite - 1 x VGA Port - 4 x Ready-to-Use USB 2.0 Ports - 1 x RJ-45 LAN Port mit LED (ACT/LINK LED und SPEED LED) - Audioanschlüsse: Line In / Line Out / Mikrofon ASRock G41M-VGS3 / G41M-VS3 Motherboard...
  • Page 17 ® ® Betriebssysteme Vista 64-Bit / XP / XP 64-Bit - FCC, CE, WHQL Zertifizierungen - Gemäß Ökodesign-Richtlinie (ErP/EuP) (Stromversorgung gemäß Ökodesign-Richtlinie (ErP/EuP) erforderlich) * Für die ausführliche Produktinformation, besuchen Sie bitte unsere Website: http://www.asrock.com ASRock G41M-VGS3 / G41M-VS3 Motherboard...
  • Page 18: Spécifications

    - 1 x port souris PS/2 - 1 x port clavier PS/2 - 1 x port VGA - 4 x ports USB 2.0 par défaut - 1 x port LAN RJ-45 avec LED (ACT/LED CLIGNOTANTE et LED VITESSE) ASRock G41M-VGS3 / G41M-VS3 Motherboard...
  • Page 19 - Monitoring de la tension: +12V, +5V, +3.3V, Vcore - FCC, CE, WHQL Certifications - Prêt pour ErP/EuP (alimentation Prêt pour ErP/EuP requise) * Pour de plus amples informations sur les produits, s’il vous plaît visitez notre site web: http://www.asrock.com ASRock G41M-VGS3 / G41M-VS3 Motherboard...
  • Page 20 - 1 x Porta VGA - 4 x porte USB 2.0 già integrate - 1 x porte LAN RJ-45 con LED (LED azione/collegamento e LED velocità) - Audio Jack: Line In / Line Out / Microfono ASRock G41M-VGS3 / G41M-VS3 Motherboard...
  • Page 21 64 bit / XP / XP 64 bit lità SO Certificazioni - FCC, CE, WHQL - Predisposto ErP/EuP (è necessaria l’alimentazione predisposta per il sistema ErP/EuP) * Per ulteriori informazioni, prego visitare il nostro sito internet: http://www.asrock.com ASRock G41M-VGS3 / G41M-VS3 Motherboard...
  • Page 22 - 1 x Puerto VGA - 4 x puertos USB 2.0 predeterminados - 1 x Puerto LAN RJ-45 con LED (LED de ACCIÓN/ENLACE y LED de VELOCIDAD) - Audio Jack: Line In / Line Out / Micrófono ASRock G41M-VGS3 / G41M-VS3 Motherboard...
  • Page 23 - FCC, CE, WHQL Certificaciones - Cumple con la directiva ErP/EuP (se requiere una fuente de alimentación que cumpla con la directiva ErP/EuP) * Para más información sobre los productos, por favor visite nuestro sitio web: http://www.asrock.com ASRock G41M-VGS3 / G41M-VS3 Motherboard...
  • Page 24 ASRock G41M-VGS3 / G41M-VS3 Motherboard...
  • Page 25 ASRock G41M-VGS3 / G41M-VS3 Motherboard...
  • Page 26 - 1 x porta para teclado PS/2 traseiro - 1 x porta VGA - 4 x portas USB 2.0 padrão - 1 x porta LAN RJ-45 com LED (LED ACT/LIG e LED VELOCIDADE) ASRock G41M-VGS3 / G41M-VS3 Motherboard...
  • Page 27 64 bits / XP / XP de 64 bits Operacional - FCC, CE, WHQL Certificações - “ErP/EuP Ready” (é necessária alimentação eléctrica “ErP/ EuP Ready”) * Para informações mais detalhadas por favor visite o nosso sítio Web: http://www.asrock.com ASRock G41M-VGS3 / G41M-VS3 Motherboard...
  • Page 28 ASRock G41M-VGS3 / G41M-VS3 Motherboard...
  • Page 29 ASRock G41M-VGS3 / G41M-VS3 Motherboard...
  • Page 30 ® ® ® ® ® ® ® ® ® ® ASRock G41M-VGS3 / G41M-VS3 Motherboard...
  • Page 31 ® ASRock G41M-VGS3 / G41M-VS3 Motherboard...
  • Page 32 ® ® ® ® ® ® ® ® ® ® ASRock G41M-VGS3 / G41M-VS3 Motherboard...
  • Page 33 ® ® ® ASRock G41M-VGS3 / G41M-VS3 Motherboard...
  • Page 34 ® ® ® ® ® ® ® ® ® ® ASRock G41M-VGS3 / G41M-VS3 Motherboard...
  • Page 35 ® ® ASRock G41M-VGS3 / G41M-VS3 Motherboard...
  • Page 36 ASRock G41M-VGS3 / G41M-VS3 Motherboard...
  • Page 37 ® ® ® ® ® ® ® ® ® ® ASRock G41M-VGS3 / G41M-VS3 Motherboard...
  • Page 38 ® ® ASRock G41M-VGS3 / G41M-VS3 Motherboard...
  • Page 39 - 1 x Port Mouse PS/2 - 1 x Port Keyboard PS/2 - 1 x Port VGA - 4 x Port USB 2.0 siap-dipakai - 1 x Port LAN RJ-45 - HD Audio Jack: Line in/Penyuara Depan/mikropon ASRock G41M-VGS3 / G41M-VS3 Motherboard...
  • Page 40 - Penjagaan voltasi: +12V, +5V, +3.3V, Vcore ® ® - dapat digunakan Microsoft Windows 7 / 7 64-bit / Vista / Vista 64-bit / XP / XP 64-bit Sertifikasi - FCC, CE, WHQL - EuP Ready (memerlukan catu daya EuP ready) ASRock G41M-VGS3 / G41M-VS3 Motherboard...
